Title: Analysis of DNA Sequences: Bioinformatics


1
Analysis of DNA SequencesBioinformatics
  • Julia Saxonov
  • Tom Chen
  • Montville High School

2
Biological Databases
  • The simplest tasks used in bioinformatics concern
    the creation and maintenance of databases of
    biological information.
  • Nucleic acid sequences (and the protein
    sequences derived from them) comprise the
    majority of such databases.

3
Most Pressing Tasks of Bioinformatics
  • Finding the genes in the DNA sequences of various
    organism
  • Developing methods to predict the structure
    and/or function of newly discovered proteins and
    structural RNA sequences.
  • Clustering protein sequences into families of
    related sequences and the development of protein
    models.
  • Aligning similar proteins and generating
    phylogenetic trees to examine evolutionary
    relationships.

4
So how do we go about doing this?
5
Sequence Analysis Flow Chart
6
Use a Waveform program to briefly analyze the
quality of your DNA sequence
  • We will be using the 4Peaks program
  • Briefly scan through the sequence using the arrow
    keys
  • Make sure the sequence is fairly clean with no
    long runs of Ns in the middle
  • Long runs of Ns are not good and should be edited
    from the sequence

7
(No Transcript)
8
The linker used
  • AATTCGCGGCCGCT- cDNA insert AGCGGCCGCG
  • GCGCCGGCGA- cDNA insert -
    TCGCCGGCGCTTA

9
Remove vector and bad sequences from your 5-EX
DNA sequence
  • Look for the EcoRI site GAATTC
  • If the site was defective, it would be useful to
    look for a different restriction site, such as
    the SmaI site CCCGGG
  • This is a starting point. Now in order to
    isolate the cDNA, you must find the linker site.
    Remove it and the bases before.

10
Bad Sequences
  • Examine the sequence until you are not confident
    with the base-calling, which could be lots of Ns
    or problems in the sequence itself

11
(No Transcript)
12
Just as you did for the 5-EX DNA sequence,
remove vector and bad sequences from the 3-EX
sequence
  • The sequence using the 3-EX end will be read
    from right to left
  • This means that although on the DNA, the 3
    sequence begins on the right, your sequences 3
    end is on the left.

5
GCTAGCTA
3
Sequence will appear
ATCGATCG
13
So now repeat the steps the same way as with the
5 sequence
  • Again, look for the EcoRI site
  • If this is defective, you can search for either
    the PstI site, or the BamHI site
  • Remember, since it is being read from right to
    left, these restriction sites will be at the
    beginning of the sequence.

14
BLAST for Beginners
  • A step-by-step tutorial to searching for DNA
    sequences

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
NEB Cutter
27
(No Transcript)
28
Size of the open reading frame.
These are the different restriction sites that
are found in this section of DNA.
29
Blasting Sanger
30
(No Transcript)
31
This range from 59536 to 62018 is important to
remember
32
The range of our match found from before is
within this range of cosmid Y50D7A.
There is no specific gene shown so you must click
the name column to find it yourself.
33
These are the four sections where the query
matched the DNA in the library.
34
(No Transcript)
35
Performing Structural Analysis
  • How does it fold?
  • Is it composed of one or multiple domains?
  • If it is an enzyme, how does it bind substrate?
  • Where is the active site?
  • Are the regions that are conserved between your
    protein and other homologs on the interior or
    exterior of the protein structure?
  • If there are mutants, where would the structure
    be affected?
  • Why is this important
  • Understanding how structure relates to function
    benefits in the successful design of drugs to
    activate or deactivate proteins. Understanding
    that a structure is related to proteins in
    another homologous organisms, such as humans,
    also allows us to test drugs on lower life forms.

36
The End
  • Disclaimer
  • Presentation was the original work of Tom Chen
    and Julia Saxonov.
  • NCBI blast slides courtesy of http//www.geospiza.
    com/outreach/BLAST/
