BONE TUMORS

1
BONE TUMORS
By Dr. Ahmed Hosny
2

• Clues by Appearance of Lesion
• Clues by Location of Lesion
• Clues by Density of Lesion
• Other Clues

3
Clues by Appearance of Lesion

• Patterns of Bone Destruction
• Periosteal Reactions
• Tumor Matrix
• Expansile Lesions of Bone

4
Clues by Appearance of Lesion

• Patterns of Bone Destruction
• Geographic
• Moth-eaten
• Permeative

5
Geographic Bone Destruction

• Destructive lesion with sharply defined border
• Implies a less-aggressive, more slow-growing,
  benign process
• Narrow transition zone

6
Patterns of Bone Destruction

• Geographic
• Moth-eaten
• Permeative

Non-ossifying fibroma
7
Geographic Bone Destruction

• Examples
• Non-ossifying fibroma
• Chondromyxoid fibroma
• Eosinophilic granuloma

8
Moth-eaten Bone Destruction

• Areas of destruction with ragged borders
• Implies more rapid growth
• Probably a malignancy

9
Patterns of Bone Destruction

• Geographic
• Moth-eaten
• Permeative

Multiple Myeloma
10
Moth-eaten Bone Destruction

• Examples
• Myeloma
• Metastases
• Lymphoma
• Ewings sarcoma

11
Permeative Bone Destruction

• Ill-defined lesion with multiple worm-holes
• Spreads through marrow space
• Wide transition zone
• Implies an aggressive malignancy
• Round-cell lesions

12
Patterns of Bone Destruction

• Geographic
• Moth-eaten
• Permeative

Leukemia
13
Permeative Bone Destruction

• Examples
• Lymphoma, leukemia
• Ewings Sarcoma
• Myeloma
• Osteomyelitis
• Neuroblastoma

14
Patterns of Bone Destruction
Moth-eaten
Permeative
Geographic
15
Periosteal Reactions

• Benign
• None
• Solid
• More aggressive or malignant
• Lamellated or onion peel
• Sunburst
• Codmans triangle

16
Periosteal Reactions

• Benign
• None
• Solid
• Aggressive/malignant
• onion-peel
• Sunburst
• Codmans triangle

Non-ossifying fibroma
17
Periosteal Reactions

• Benign
• None
• Solid
• Aggressive/malignant
• onion-peel
• Sunburst
• Codmans triangle

Chronic osteomyelitis
18
Periosteal Reactions

• Benign
• None
• Solid
• Aggressive/malignant
• onion-peel
• Sunburst
• Codmans triangle

Ewing sarcoma
19
Periosteal Reactions

• Benign
• None
• Solid
• Aggressive/malignant
• onion-peel
• Sunburst
• Codmans triangle

Osteo-sarcoma
20
Periosteal Reactions

• Benign
• None
• Solid
• Aggressive/malignant
• onion-peel
• Sunburst
• Codmans triangle

Osteo-sarcoma
21
Periosteal Reactions
Solid
onion-peel
Sunburst
Codmans triangle
22
Tumor Matrix

• Osteoblastic
• Fluffy, cotton-like or cloud-like densities
• Osteosarcoma
• Cartilaginous
• Comma-shaped, punctate, annular, popcorn-like
• Enchondroma, chondrosarcoma, chondromyxoid fibroma

23
Tumor Matrix

• Osteoblastic
• Cartilaginous

24
Tumor Matrix

• Osteoblastic
• Fluffy, cotton-like or cloud-like densities
• as Osteosarcoma
• Cartilaginous
• Comma-shaped, punctate, annular, popcorn-like
• as Enchondroma, chondrosarcoma, chondromyxoid
  fibroma

25
Tumor Matrix

• Osteoblastic
• Cartilaginous

Chondrosarcoma
26
Expansile Lesions of Bone

• Multiple myeloma
• Mets
• Brown tumor
• Enchondroma
• Aneurysmal bone cyst
• Fibrous dysplasia

27
Expansile Lesions of Bone

• Multiple myeloma
• Mets
• Brown tumor
• Enchondroma
• Aneurysmal bone cyst
• Fibrous dysplasia

28
Expansile Lesions of Bone
Multiple myeloma Mets Brown tumor Enchondroma Ane
urysmal bone cyst Fibrous dysplasia
Renal cell carcinoma
29
Expansile Lesions of Bone
Multiple myeloma Mets Brown tumor Enchondroma Ane
urysmal bone cyst Fibrous dysplasia
30
Expansile Lesions of Bone
Multiple myeloma Mets Brown tumor Enchondroma Ane
urysmal bone cyst Fibrous dysplasia
31
Expansile Lesions of Bone
Multiple myeloma Mets Brown tumor Enchondroma Ane
urysmal bone cyst Fibrous dysplasia
32
Expansile Lesions of Bone
Multiple myeloma Mets Brown tumor Enchondroma Ane
urysmal bone cyst Fibrous dysplasia
33
Clues by Location of Lesion

• In the Transverse Plane
• In the Longitudinal Plane
• Characteristic Locations by tumors
• Characteristic Tumors by Body Site
• Pelvic Lesions
• Expansile Rib Lesions
• Lesions of the Spine

34
In the Transverse Plane
35
In the longitudinal Plane

• Epiphyseal
• GCT, chondroblastoma
• Metaphyseal
• Osteomyelitis, osteo-and chondrosarcoma
• Diaphyseal
• Round cell lesions, ABC, enchondroma

36
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

37
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

38
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

39
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

40
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

41
Characteristic Locations

• Simple bone cyst
• Proximal humerus
• Chondroblastoma
• Epiphyses
• Giant Cell tumor
• Epiphyses
• Adamantinoma
• Tibia
• Chordoma
• Sacrum, clivus
• Osteoblastoma
• Spine, posterior

42
Clues by Density of Lesion

• Sclerotic Cortical Lesions
• Lytic Lesions in Children
• Lytic Lesions in Adults
• Blastic Lesions in Children
• Blastic Lesions in Adults

43
Sclerotic Cortical Lesions

• Osteoid osteoma
• Brodies abscess

44
Sclerotic Cortical Lesions

• Osteoid osteoma
• Brodies abscess

45
Lytic Lesions in Children

• Eosinophilic granuloma
• Leukemia

46
Lytic Lesions in Children

• Eosinophilic granuloma
• Leukemia

47
Lytic Lesions in Adults

• Metastatic lesions
• Lung
• Renal
• Thyroid
• Multiple myeloma
• Primary bone tumor

Metastatic thyroid carcinoma
48
Lytic Lesions in Adults

• Metastatic lesions
• Lung
• Renal
• Thyroid
• Multiple myeloma
• Primary bone tumor

49
Lytic Lesions in Adults

• Metastatic lesions
• Lung
• Renal
• Thyroid
• Multiple myeloma
• Primary bone tumor

Chondrosarcoma
50
Blastic Lesions in Children

• Lymphoma

51
Blastic Lesions in Adults

• Metastatic disease
• Breast female
• Prostate male
• Lymphoma
• Pagets disease
• Fluorosis

Prostatic Ca.
52
Blastic Lesions in Adults

• Metastatic disease
• Breast female
• Prostate male
• Lymphoma
• Pagets disease
• Fluorosis

53
Blastic Lesions in Adults

• Metastatic disease
• Breast female
• Prostate male
• Lymphoma
• Pagets disease
• Fluorosis

54
Blastic Lesions in Adults

• Metastatic disease
• Breast female
• Prostate male
• Lymphoma
• Pagets disease
• Fluorosis

55
Other Clues

• Soft Tissue Extension
• Benign vs. Malignant

56
Soft Tissue Extension

• Usually implies malignancy
• More likely to form discrete soft tissue mass
• Benign conditions with soft tissue extension
• Osteomyelitis
• Usually infiltration of fat

57
Soft Tissue Extension
lymphoma
58
Benign vs. Malignant
59
Thank You
