Histograms

1
Histograms

• Lecture 18
• Sec. 4.4.4
• Tue, Feb 17, 2004

2
Histograms

• Histogram A display of continuous quantitative
  data in which the data are divided into classes
  and rectangles represent the frequencies of the
  classes.

3
Drawing Histograms

• Use Data Set 1 on p. 184.
• Find the maximum value, the minimum value, and
  the range.
• Maximum 51
• Minimum 32
• Range Max Min 51 32 19.

4
Drawing Histograms

• Divide the data into classes of equal width.
• The classes must not overlap.
• Choose a convenient starting point.
• Choose a convenient class width.
• Write the endpoints of each class.

5
Drawing Histograms

• Starting point 30.
• Class width 5.
• Classes
• 30 up to 35 (but not including 35).
• 35 up to 40.
• 40 up to 45.
• 45 up to 50.
• 50 up to 55.

6
Drawing Histograms

• We may denote the classes in either of two ways.
• Interval notation low, high)
• 30, 35),
• 35, 40),
• 40, 45), etc.
• and mean include endpoints.
• ( and ) mean exclude endpoints.

7
Drawing Histograms

• Range notation low high
• 30 34,
• 35 39,
• 40 44, etc.
• This notation does not indicate whether the
  endpoints are included.
• Therefore, be sure the endpoints do not overlap.

8
Drawing Histograms

• Count the number of observations in each class.
  This is the frequency of the class.

Class Frequency
30, 35) 1
35, 40) 2
40, 45) 8
45, 50) 7
50, 55) 2
9
Drawing Histograms

• Draw horizontal and vertical axes.
• On the horizontal axis, show the class
  boundaries.
• On the vertical axis, show uniform reference
  points representing frequencies apropos to the
  data.
• For example, 0, 2, 4,

10
Drawing Histograms
11
Drawing Histograms

• Over each class, draw a rectangle whose height is
  the frequency of that class.

12
Drawing Histograms
13
Drawing Histograms
14
Drawing Histograms
15
Drawing Histograms
16
Drawing Histograms
17
Drawing Histograms
18
Drawing Histograms
19
Guidelines

• Never use too few or too many classes.
• Usually 5 to 12 classes is about right.
• Use simple round numbers for the class
  boundaries.
• Mark off the vertical axis uniformly, showing
  regular reference points, not the actual
  frequencies.
• Frequencies must start at 0.

20
Lets Do It!

• Lets do it! 4.14, p. 224 Histogram of
  Household Income.
• Lets do it! 4.16, p. 226 Matching Shapes to
  Characteristics.

21
Example

• See Example 4.10, p. 227 Histogram versus Bar
  Graph.

22
Histograms on the TI-83

• See page 263 for more detailed instructions.
• Enter the data into list L1.
• 45, 41, 51, , 37 ? L1
• Press STAT PLOT
• Turn Plot1 On.
• Select Histogram Type.
• Specify List L1.

23
Histograms on the TI-83

• Press WINDOW
• Set Xmin to the starting point.
• Set Xmax to the last endpoint.
• Set Xscl to the class width.
• Set Ymin to 0.
• Set Ymax to the maximum frequency.
• Press GRAPH
• The histogram appears.

24
Frequency Distributions on the TI-83

• After getting the histogram, press TRACE.
• The display shows the first class and its
  frequency.
• Use the left arrow to see the other class
  frequencies.

25
Assignment

• Page 227 Exercises 30 38.
• Page 249 Exercises 68, 69.
