DOEHRS Training-Program Office Equipment

1
DOEHRS Training-Program Office Equipment 2010
2
Audience

• This training is focused to personnel entering
  environmental health sampling and survey
  equipment data in garrison or deployed
  environments.

3
Teleconference Logistics

• Teleconference
• Mute phones -6
• DO NOT PLACE ON HOLD
• All participants will be muted while trainer is
  speaking
• Ask questions via DCO Chat option
• Also QA at end of session

4
Teleconference Logistics (Cont)

• Breaks
• For sessions scheduled for more than 2 hours,
  train for 50 minutes, then break for 10 minutes
• Session will start again promptly at top of hour
• Attendance
• Recorded by the DOEHRS PMO
• For multiple people on line, send list to
  Wendy.Wood.ctr_at_tma.osd.mil

5
Teleconference Logistics (Cont)

• Recording of this presentation available through
  Defense Connect Online (DCO)
• DCO account required to access recording
• Recording provides audio for DOEHRS Trainer led
  session
• Ensure audio is enabled on your computer when
  accessing session
• Recording includes questions and answers captured
  during DOEHRS Trainer led session

6
Teleconference Logistics (Cont)

• URL to access recording
• https//connect.dco.dod.mil/p75817638/
• To request DCO account
• Access https// www.dco.dod.mil
• Click Register button on DCO Home page
• Survey at end of session for feedback
• Slides will be posted under the DOEHRS Resources
  menu tile (in the User Documentation link)

7
Topics

• References
• Overview
• PO Equipment Types
• EH Air, Water, Thermal Stress, Soil
• Radiation Air, Swipe, Tactical Dosimetry, RF,
  X-Ray
• PO Equipment Add
• Detail Page
• PO Equipment Search
• PO Equipment Life Expectancy Report

8
References

• U.S. Army Public Health Command (Provisional)
  Technical Guide (TG) 251, A Soldiers Guide to
  Environmental And Occupational Field Sampling for
  Military Deployment.
• Department of Defense Instruction (DODI) 6055.08,
  Occupational Ionizing Radiation Protection
  Program.
• Department of the Army Pamphlet (385-24),
  Radiation Safety Program.

9
References

• Technical Guide (TG) 251 was developed to comply
  with the environmental surveillance requirements
  in the Department of Defense Instruction (DODI)
  6490.3, Implementation and Application of Joint
  Medical Surveillance for Deployments.
• TG 251 focuses on characterizing the industrial
  chemical and occupational physical threats that
  may be encountered during a deployment.
• The sampling methods selected for this TG are
  either currently part of the preventative
  medicine mission or can be augmented by the U.S.
  Army Center for Health Promotion and Preventive
  Medicine (USACHPPM) or other specialized unit.

10
References

• Department of Defense Instruction (DODI) 6055.8
  establishes policy updates requirements for the
  Occupational Ionizing Radiation Protection
  Program for DOD military operations deployments
• Includes guidance to maintain occupational and
  environmental exposures to ionizing radiation
  associated with DOD operations to a level as low
  as reasonably achievable (ALARA)

• Department of the Army Pamphlet (385-24)
  establishes radiation safety guidance and
  direction. It provides guidance and direction to
  implement 6055.8.
• Includes guidance on use, dosimetry, and
  radiation exposure standards for both ionizing
  and non-ionizing radiation sources

11
Overview

• PO Equipment is equipment (e.g., PS1 Sampling
  Equipment, Field Water Testing Kit, Soil Sampling
  equipment, etc.) that is utilized by EH users to
  perform sampling and surveys.
• Only users with the Equipment Administrator
  Role will have access to the PO Equipment link
  within the Administration menu and the ability
  to
• Maintain survey and sampling equipment including
  manufacturer calibration information.
• Maintain vendor information.
• Add Equipment via sampling forms.

12
Overview

• Other EH Users (without the Equipment
  Administrator Role) can only select equipment
  from picklists that have already been populated.
• If the equipment does not appear in the picklist,
  the Equipment Administrator will have to be
  contacted to add the item.

13
PO Equipment Types

• EH Sampling Equipment
• Air
• Direct Reading
• PS1 Sampler
• Deployable Cartridge Sampler (DCS (TO-9/13)
• Total Organic (TO-14)
• Deployable Volatile Sampler (DVS/TO-17)
• Airmetrics Particulate Matter (PM Mini-Vol)
• Deployable Particulate Sampler (DPS)

14
PO Equipment Types

• EH Sampling Equipment
• Water
• Deployment Water Test Kit Listed as Deployment
  Treated Water Test Kit within DOEHRS
• Thermal Stress
• Wet Bulb Globe Temperature (WBGT)
• Soil
• Deployment Soil Sampling Kit

15
EH Equipment Types (Air)

• Direct Reading Are valuable tools for detecting
  and measuring worker exposure to gases, vapors,
  aerosols, as well as both biological and chemical
  agents
• These instruments permit real-time or near
  real-time measurements
• There are many types of instruments available,
  each of which is designed for a specific
  monitoring purpose.

16
EH Equipment Types (Air)

• PS1 Sampler Is used to conduct EPA Total
  Organic (TO) 4A, 9A, and 13A method sampling
  designed for the following
• PCBs (TO-4A)
• Dioxins Furans (TO-9A)
• Aromatic Hydrocarbons (TO-13A)
• These sampling methods are only used if the
  source is identified

17
EH Equipment Types (Air)

• DCS (TO-9/13) Deployable Cartridge Sampler
  combines a Leland Legacy Pump with a specially
  designed sampling train for the following
• Semi-volatile compounds
• Pesticides
• Dioxins Furans (TO-9)
• Aromatic Hydrocarbons (TO-13)

18
EH Equipment Types (Air)

• TO-14 Volatile Organic Compounds (VOCs) are
  sampled with polished SUMMA, evacuated stainless
  steel canisters.

19
EH Equipment Types (Air)

• DVS Deployable Volatile Sampler combines a
  Leland Legacy Pump with a specially designed
  sampling train to collect ambient VOC emissions
• Samples are analyzed using the EPA TO-17 method.
• TO-17 uses a metal Supelco Carbosieve 300
  Sampling tube, filled with 3 different collection
  media

20
EH Equipment Types (Air)

• The Airmetrics Particulate Matter (PM) Mini-Vol
  Air Sampler samples ambient air at 5 liters per
  minute for the following
• Total Suspended Particulate (TSP)
• PM 10 micron
• PM 2.5 micron
• Non-reactive gases
• Carbon Monoxide (CO)
• Nitrogen Oxide (NOx)

21
EH Equipment Types (Air)

• DPS Deployable Particulate Sampler combines a
  Leland Legacy Pump with a specially designed
  sampling train for the following
• Ambient PM
• PM 10 micron
• PM 2.5 micron

22
EH Equipment Types (Water)

• Deployment Field Water Test Kit Is capable of
  testing for all regulated environmental
  contaminants
• Organic
• Inorganic
• Radiological
• The kit is not designed to analyze for bacterial
  analysis
• Samples can be collected from potable water or
  potential potable water sources

23
EH Equipment Types (Thermal)

• Wet Bulb Globe Temperature (WBGT) Is a
  real-time heat stress meter, which measures and
  data logs the following
• Wet bulb
• Dry bulb
• Globe Temperatures
• The meter automatically calculates the heat
  stress level using the WBGT Temperature Index
• There are also manual WBGTs

24
EH Equipment Types (Soil)

• Deployment Soil Sampling Kit Used to determine
  health risks to soldiers from soil exposures to
  the following
• Metals, VOCs, SVOCs, Explosives,
  Pesticides/PCBs/Herbicides

Deployment Soil Sampling Kit
25
PO Equipment Types

• Radiation Sampling Equipment
• Air High Volume
• Direct Reading
• Swipe
• Tactical Dosimetry
• Area Monitoring
• Collective
• Personal

26
Radiation Equipment Types (Air)

• High Volume Air Sampler A lightweight rugged
  grab sampler designed specifically for sampling
  airborne particulates or combination particulates
  and radiodines
• Typically utilized with a combination filter and
  cartridge holders

27
Radiation Equipment Types (Direct)

• Direct Reading Instrumentation Portable survey
  meters are used for measuring either
• Levels of ionizing (X-Ray/Gamma Ray) and
  non-ionizing (RF) radiation intensity
• Instruments that measure radiation intensity are
  designed to quantify
• Radiation flux density
• Exposure
• Dose / Equivalent Dose

28
Radiation Equipment Types (Swipe)

• Swipe Sampling are pieces of paper, or cloth,
  or other material used to wipe the surface of
  work areas, personnels skin and clothing,
  vehicles, tools or equipment.
• Swipes are then counted in a laboratory-counting
  instrument to determine if removable radioactive
  contamination exists

29
Radiation Equipment Types (Dosimetry)

• Tactical Dosimetry Is associated with tactical
  warfare in which small tactical nuclear weapons
  might be used. A tactical dosimeter, which is a
  high range direct reading device measuring
  (Gamma/Neutron) radiation, provides a means for
  rapid determination of total dose
• Tactical Dosimetry may include the following
• Area
• Collective
• Personal

30
PO Equipment Add

• After clicking the PO Equipment link found within
  the Administration menu, the following search
  page is displayed. Users may search the
  following
• PO Equipment Name, Manufacturer, Model Number,
  Serial Number, or Sample Type

31
PO Equipment Add
From the main search screen, PO Equipment can be
added by selecting the Add Program Office
Equipment link from the search screen.
32
PO Equipment Add
After the user selects the Equipment Name(Type),
the corresponding PO Equipment Detail page will
be displayed
33
PO Equipment Add
PO Equipment Information Model , Serial ,
Life Expectancy, Site Assignment, Status
(Available/Unavailable)
34
PO Equipment Add
Users edit existing model numbers or add new
ones
35
PO Equipment Add
Users can add sites where equipment might be
located
36
PO Equipment Add

• Potential Interferences Information Device
  sampling
• Interferences
• Calibration Summary Last/Next Calibration
  Dates, Calibration
• Method Frequency

37
PO Equipment Add

• Cost Summary Purchase Stop Date as well as
  various
• equipment costs may be entered.

38
PO Equipment Add

• Calibration Maintenance History Provides
  calibration Date
• Sent, Actual Date, Lab, Cost information
• Users may add additional equipment calibration
  information by
• selecting the () icon

39
PO Equipment Add

• Add/update equipment calibration data through the
  Calibration Maintenance Information page

40
PO Equipment Add

• PO Equipment search results appear as follows.
  In addition to adding
• Equipment through the main search screen, users
  may do so by either
• selecting the () icon or Other Actions drop
  down list

41
Life Expectancy Report
From the main PO Equipment search screen, users
can also generate a PO Equipment Life
Expectancy Report
42
Life Expectancy Report

• Once PO Equipment Name Replacement Start/Stop
  dates have been selected a report similar to the
  following is displayed that may be exported as PDF

43
Recap

• References
• Overview
• PO Equipment Types
• EH Air, Water, Thermal Stress, Soil
• Radiation Air, Swipe, Tactical Dosimetry, RF,
  X-Ray
• PO Equipment Add
• Detail Page
• PO Equipment Search
• PO Equipment Life Expectancy Report

44
Questions
