Suvarnabhumi Airport Development

1
Suvarnabhumi Airport Development
Case study for Airport Security

( Incheon International Airport 1)
September, 2004
KOICA (NESDB)
2
1. Security Regulations
1
3
LAWS REGULATIONS
? International Conventions Regulation -
Tokyo Convention - Hague Convention -
Montreal Convention - ICAO Annex 17
(Security) ? National Legislation -
Aviation Act Aircraft Safety Act -
Aviation Safety Security Act(26th Nov) -
National Antiterrorism Guidance - Integrated
Defense Guidance
2
4
? Airport Security Regulation - Airport
Security Program - Security Operation
Procedures - Airport Contingency Plan -
Security Pass Regulation - Security
Regulation- Document Facilities - Airport
Emergency Plan
3
5
2. State of Security Guarding
4
6
ARmory
WANGSAN RADAR
ASU
Army - seaside 61km - Island Protection
TVOR/DME
?
Main Sub StationA
Fuel Facility
Power StationB
?
Hangar
Gorvenment Support Facilities
G-2 ?
? G-8
?
G-3 ?
Receiving Station
Co-Generation
AICC
? G-4
New airport expressway
?
?
Control Tower
G-5 ?
Cargo Terminal
?
? G-6
Passenger Terminal
Transmission Station
? G-1
? G-7
?
?
?
ADMIN Building
???
Shinbul RADAR
Main Sub StationB
5
4
7
Security Pass

• ? Prototype of Security Pass

Airport Logo
ATC Area
Support Complex Area
Sterile Area
Movement Area
Cargo Terminal Area
Customs Area
Expiration
Name
Classified Restrict Area
Organization
6
8
? Responsibilities for badging ? IIAC
Under the supervision of Seoul Regional
Office, MOCT ? Amount of Security Badging
- Permanent (People) 24,400, Permanent
(Vehicle) 1,300 - Temporary (People)
2,300, Temporary (Vehicle) 60,
Visitor Pass 6,400/monthly ? Types of Pass
- RF Card (Radio Frequency Card)
7
9
? Security Badging Requirement
8
13
10
? Classification of Restricted Area
Badging on restricted area is determined by the
task of each individual
9
11
?. Prototype of Vehicle Pass
10
12
11
13
State of Security Guarding

• ? Guarding responsibilities
• ? 1st area Areas beyond outer fence (Coast
  Line)
• The military guarding unit
• ? 2nd area Outer fence area (Observation
  tower and
• guard post) IIAC
• ? 3rd area Major buildings within inner
  fence
• (Passenger Terminal, Air Traffic Control
  Tower, etc) IIAC
• ? Airport Police, Combat Police, Police
  SWAT (Reserved for
• emergencies)
• ? Operations
• ? Security guard operations
• with scientific guarding system
• ? Outsourced to special guarding unit

12
3
14
Integrated Security System(ISS)
Intrusion Detection Sys

• Tension system 21.3Km
• Detection Sensor 1.2Km
• IR System 1.4Km

CCTV Sys
ID Badging Sys
TSC
Security Center System
Security Communication System
Access Control Sys
TCSC
PSC
Intrusion Detection System
Warning System
Interface System
Disaster Prev Sys
TOC
BHS
Move Area Sys
ELV Sys
Others
13
9
15

• ? SECURITY CENTER OPERATION

Operator
System installed
Function
Name
5 operator each shift

• CCTV Monitor 32
• (CCTV 775)
• Access Control/Alarming/Recording
• Security Communication,, TRS ? GPS

• Terminal Area Monitor
• Coordination Control
• Situation Room function

Terminal Security Center (TSC)
4 operator each shift

• CCTV Monitor 24
• (CCTV 289)
• Access Control/Alarming/Recording Security
  Communication, TRS GPS

• Perimeter Area Monitor
• Surveillance for Intruder

Perimeter Security Center (PSC)
2 operator each shift

• CCTV Monitor 28
• (CCTV 203)
• Access Control/Alarming/Recording

• Transportation Center
• Monitoring
• Inform incidents to Security
• Unit

Transportation Security Center ( TCSC)
14
8
16
Passenger Terminal Security Sys
Central Monitor Sys

• Integrated Security Center -
  Terminal Security System Integrated

CCTV Sys
Access Control Sys

• Door Control at Passenger Terminal (Access
  Control Function)

• CCTV Camera
• CCTV Monitor

Screening Sys
Security Com Sys

• X-RAY ,HD,MD

• Intercom TRS

15
17
Perimeter Security System
Central Monitor Sys
CCTV Sys
Access Control Sys

• Integrated Perimeter Security System

• Perimeter Area Access Control
• Vehicle Person Control

• CCTV Camera
• CCTV Monitor
• Interface with IDS

Warning Sys
Security Com Sys

• Communication Sys
• Interface with CCTV
• Automatic Warning Sys?

• Intercom TRS

Intrusion Det Sys

• Tension Detector
• IR Detector

16
18
Security Responsibilities
IIAC Main Responsibilities of airport
security related tasks
(Guarding, screening Sup, etc) National
Intelligence Service Coordination of
counter-terrorism
and security
Ministry of Construction Transportation, Seoul
Regional Office Government supervision
Airport police Maintaining public peace of
airport through measures for
crime prevention and illegal
actions Military unit Protection of airport
boundaries, support upon the
outbreak of illegal acts Customs
Inbound baggage or carry-on baggage screening
Ministry of Justice, Immigration Bureau Arrival
or departure

immigration Airlines Security work of
airlines (Aircraft inspection and guarding,
catering securities)
17
19
Thank you !!
