AREMA VIBRATION REQUIREMENTS - UPDATE

1
October 9, 2003
Subtitle (Arial 22 to 24)
AREMA VIBRATION REQUIREMENTS - UPDATE
- Add text to be highlighted here -
2
AGENDA

• Review AREMA Vibration Guidelines
• Review Project Scope
• Methodology
• Progress
• Next Steps

3
AREMA Vibration Guidelines

• Summary of Test Recommendations
• Section 11.5.1
• Sinusoidal Vibration Test
• Exploratory Sine Sweep (identify resonance)
• Mechanical Shock
• ex) Class A Sinusoidal
• Range / Levels
• 5 to 20 Hz 0.2 peak-peak
• 20 to 200 Hz 4.2 g-peak
• 12 Minute Sweeps (0.9 Octave/Minute)
• 4 Hours per Axis (20 cycles)

4
Review Project Scope

• Re-evaluate Current Specification.
• Current Spec - Accurately characterize
  environment?
• Possible over-test condition.
• Goal Develop scientific basis for vibration test
  specification.
• Ensures durable and reliable products.
• Avoids unnecessary design and test cost in new
  products.
• Field Study and Report
• Four railroad sites for data acquisition.
• Limit scope to Class A.
• ALSTOM investment, will share data and results
  with Committee.
• Full Presentation and Recommendation at C38,
  Spring 2004.

5
Methodology

• LMS Engineering Services contracted by ALSTOM
• Leader in the Vibration Industry
• State-of-the-art Equipment and Analysis Tools
• Experience in Specification Development
• Strong Project Management
• Statistical Analysis of Environment to identify
• Fatigue Damage Spectrum (FDS) (WEAR)
• Maximum Response Spectrum (MRS) (OVERSTESS)

6
Methodology
7
PROGRESS - Site 1 BNSFData capture completed,
Analysis in Progress
8
Progress Next Steps
9
Next Steps

• Complete Analysis of BNSF Data LMS
  Oct/Nov 03
• Complete Data Collection CN LMS, ALSTOM
  Oct 03
• Walk-through Data Collection CP LMS, ALSTOM, CP
  Nov 03
• Identify Site 4 Committee 38 Oct. 9,
  2003
• Walk-through Data Collection 4 LMS, ALSTOM, RR
  Dec 03
• Complete Data Analysis - all sites LMS
  Jan 04
• Complete Mission Synthesis LMS Feb
  04
• Present Project to C38 LMS, ALSTOM Mar
  04

10
