Learning Decision Trees

1
Learning Decision Trees

• Brief tutorial by M Werner

2
Medical Diagnosis Example

• Goal Diagnose a disease from a blood test
• Clinical Use
• Blood sample is obtained from a patient
• Blood is tested to measure current expression of
  various proteins, say by using a DNA microarray
• Data is analyzed to produce a Yes or No answer

3
Data Analysis

• Use a decision tree such as

P1 gt K1
Y
N
P2 gt K2
P2 gt K2
N
Y
Y
P3 gt K3
P4 gt K4
P4 gt K4
No
Y
N
Y
N
Y
N
Yes
No
Yes
No
Yes
No
4
How to Build the Decision Tree

• Start with samples of blood from patients known
  to either have the disease or not (training set).
• Suppose there are 20 patients and 10 are known to
  have the disease and 10 not
• From the training set get expression levels for
  all proteins of interest
• i.e. if there are 20 patients and 50 proteins we
  get a 50 X 20 array of real numbers
• Rows are proteins
• Columns are patients

5
Choosing the decision nodes
10 have disease 10 dont

• We would like the tree to be as short as possible
• Start with all 20 patients in one group
• Choose a protein and a level that gains the most
  information

10/10
Possible splitting condition
Mostly diseased
Px gt Kx
9/3
1/7
Mostly not diseased
10/10
Alternative splitting condition
Py gt Ky
7/7
3/3
6
How to determine information gain

• Purity A measure to which the patients in a
  group share the same outcome.
• A group that splits 1/7 is fairly pure Most
  patients dont have the disease
• 0/8 is even purer
• 4/4 is the opposite of pure. This group is said
  to have high entropy. Knowing that a patient is
  in this group does not make her more or less
  likely to have the disease.
• The decision tree should reduce entropy as test
  conditions are evaluated

7
Measuring Purity (Entropy)

• Let f(i,j)Prob(Outcomej in node i)
• i.e. If node 2 has a 9/3 split
• f(2,0) 9/12 .75
• f(2,1) 3/12 .25
• Gini impurity
• Entropy

8
Computing Entropy
9
Goal is to use a test which best reduces total
entropy in the subgroups
10
Building the Tree
11
Links

• http//www.ece.msstate.edu/research/isip/publicati
  ons/courses/ece_8463/lectures/current/lecture_27/l
  ecture_27.pdf
• Decision Trees Data Mining
• Andrew Moore Tutorial
