Fieldbus Foundation A Decade of Leadership

1
Fieldbus FoundationA Decade of Leadership
2
Born in 1994

• On 23 Sep 94 Fieldbus Foundation was formed
• World FIP North America and the ISP Foundation
  members voted with an overwhelming majority to
  proceed
• Clear mandate to deliver the benefits of Fieldbus
  technology
• Would require global cooperation across a wide
  spectrum of suppliers and end users

3
Humble Beginnings
H1 31.25 Kbps
Computers

Control
network

Process
controllers
H1 Fieldbus

Junction
box

Field
devices
4
H1 Development History

• H1 Today
• Over 62 Registered Stacks from 26 suppliers
• Over 200 Registered Devices from suppliers
• Over 305,000 H1 Devices in the Field
• HIST Compliant Hosts
• ABB
• Emerson Delta V
• Honeywell Plantscape and Experion PKS
• Invensys
• Smar System 302
• Yamatake Industrial DEO
• Yokogawa Centum and Stardom
• Rockwell Process Logix

5
1997IEC 61158 DLL AL Ballot
FIELDBUS IEC RESULTS ON FDIS
6
Freedom to Choose Power to Integrate

• We need open specifications that provide us with
  the "Freedom to Choose" interoperable
  best-in-class products that meet our application
  needs and the "Power to Integrate the
  information from those products into our
  enterprise model.

7
Freedom to Choose Power to Integrate
176 unique and 256 total devices registered
2
8
Foundation fieldbus Digital presence
9
Fieldbus Acceptance Has Been Outstanding

• FOUNDATION fieldbus installations
• include leaders in key industries
• 9 of the top 10 oil and gas companies
• 24 of the top 25 pharmaceutical companies
• 23 of the top 25 chemical companies
• 15 of the top 20 pulp and paper companies
• 10 of the top 20 food and beverage companies

10
Market Distribution
11
H1 technology forward through HSE and beyond
12
HSE Development History

• HSE Today
• 10 Registered Linking Devices
• ABB (2 versions)
• Emerson
• National Instruments
• Rockwell
• Smar(3)
• Softing
• HMS Networks
• HSE Function Block Devices in Beta Registration
  Test
• HSE Redundant Devices in Lab System Test
• Planning for FBCiHAB Demo at BP is Underway
• - Includes registered HSE Linking Devices, FB
  Devices, and HSE Redundancy

13
Business requirements

• Meeting business challenges in the 21st century
  requires a new way of thinking.
• The industry as a whole is turning the corner on
  increased production demands with informed asset
  management and predictable system performance

14
Unneeded Trips To The Field - Avoided Through
Remote Diagnostics
15
International Standards
Yes!

• IEC 61804
• Function Blocks (FB) for Process Control
• - Part 1 Overview of system aspects
• - Part 2 Specification of FB concept and
  Electronic Device Description Language (EDDL)
• Covers DDL used in the FOUNDATION fieldbus,
  HART and Profibus communication protocols
• Used to support about 1000 different devices

16
What is IEC 61804-2
It is a Super Set Specification of Device
Description Languages (DDL)
IEC 61804-2
DDL
DDL
DDL
The three languages are 95 the same with only
small differences
17
Impact of IEC 61804

• Standardization of existing technology
• No Changes to existing DDs
• First Time the HART Communication Foundation, the
  Fieldbus Foundation and Profibus
  Nutzerorganisation e.V have co-operated!
• Paves the way for future co-operation!

18
DD Cooperation Project
Working Group Members - Volunteers from FF, HCF
and PNO
ABB Emerson Process Management Endress
Hauser FlowServe Honeywell Siemens Yokogawa
19
Application on PC or Handheld Reads DD
Digits of precision
Descriptions for values are obtained from the DD.
Values are read from the device.
Engineering Unit
Label of the value
25.50

Measured_Value
Application on PC or Handheld uses the same DD
20
DD Cooperation Project

• Graphing System
• Key Features
• Visualize Complex Data
• Support for Charts and Graphs
• Multiple plots
• Interactive zooming
• Direct editing of graphs
• Emphasis, Key Points, Notes
• Example Applications
• Radar Level Configuration
• Valve Signatures
• Analyzers

21
DD Cooperation Project
RADAR LEVEL GAUGE EXAMPLE

• A graph is used to present the echo waveform to
  enable configuration of thresholds and false
  echoes areas in the device.
• Trigger device to build waveform data
• Retrieve waveform data
• Update the graph with the retrieved values

DD Cooperation Project
Radar Gauge
22
DD Cooperation Project

• Valve Step Response
• A graph is used to present the Step Response
  waveform of a Valve.
• Trigger device to build
• waveform data
• Retrieve waveform
• Update the graph with the retrieved values

Blue line is a reference
23
DD Cooperation Project

• Valve Signature
• - with Best Fit Line
• graph is used to present the Valve Signature
  waveform as a measure of the force-to-open and
  the force-to-close
• Trigger device to build
• waveform data
• Retrieve waveform
• Update the graph with
• the retrieved values
• Best Fit line can be calculated
• Retrieve, save and draw the data on the graph.

Best Fit
24
Infraserv Höchst To Host FF-SIS Validation
Testing

• Testing will evaluate devices based on IEC safety
  standards
• Effective March 19, 2004, Infraserv Höchst, an
  independent consultancy located in Frankfurt,
  Germany, will host Fieldbus Foundation Safety
  Instrumented Systems (FF-SIS) lab specification
  validation testing during 2004.
• The foundation, in concert with leading device
  manufacturers and end users, is developing
  specifications and guidelines complying with the
  International Electrotechnical Commission (IEC)
  61508 standard (functional safety of
  electrical/electronic/programmable electronic
  safety-related systems), and IEC 61511
  (functional safety safety instrumented systems
  for the process industry sector). IEC 61511
  addresses the application of safety instrumented
  systems.
• The FF-SIS development team included ABB,
  DuPont, Emerson Process Management, ExxonMobil,
  HIMA, Honeywell, Invensys/Triconex, Metso
  Automation, Rockwell Automation, Rotork Control
  Systems, Saudi Aramco, Shell Global Solutions,
  Smar, Softing, TÜV and Yokogawa.

25
Fieldbus Foundation Future

• We are always open to new ideas and better
  methods of sharing benefits of the technology.

www.fieldbus.org
26

• Thank you

www.fieldbus.org
