The CompactRIO Control System for FIRST Robotics

1
The CompactRIO Control System for FIRST Robotics

• Rob Heslin
• ritfirst.org

2

• The information herein is based on the '08 season
  and released information about the new control
  system. Some information is only a prediction
  based on this information. This seminar does not
  substitute READING the Rules.

3
Outline CompactRIO

• Robot Control Systems
• Sensors
• Operator Interface

4
General Digital Inputs The Signal

• Digital Signals have two states

Voltage 0V 5V
Switch Closed Open
Electrical Grounded Not Grounded
Programming FALSE TRUE
Binary 0 1
This is a Discrete Input(it is either one or the
other)?
5
What is an analog input?

• An analog input is one that has a range of
  acceptable values
• 0 to 255
• 0V to 5V
• It is a continuous input

6
Control System

• Rides on the robot
• Contains
• Robot Controller (The cRIO)?
• Bumpers Digital Side Car
• WiFi
• Speed Controllers (The Jaguar)?
• Relays
• Sensors

7
Control System Overview
WiFi Bridge
CompactRIO
Pneumatics Bumper
Digital Sensor
Analog Bumper
Solenoid
Digital Side Car
Speed Controller
Analog Sensor
Speed Controller
Spike Relay
8
CompactRIO

• Provided by FIRST
• Use is required
• The brain of the robot
• Programmed to take inputs, process them, and
  output to motors, etc.

• Processor is linked to modules via the FPGA
  backplane

9
FPGA
10
PWM Connectors and Signal

• Commonly used in previous years
• Stock up on PWM wires and connectors
• PWM signal is digital

5V
GND
SIGNAL
Voltage
5 V-
0 V-
Time
11
Digital Module Side Car
32 pin D-sub cable

• The digital module connects via a D-sub cable to
  the digital side car

• FPGA back plane connects to the digital module

12
Digital Side Car
PWM Outputs (10)?

• All Digital I/O from the cRIO
• Uses PWM style connectors

GPIO (10)?
Relay Output(8)?
13
Comparisonnew and old
14
Digital Sensors

• Sensors that can be set to either an On or
  Off state
• Examples
• Limit Switch
• Pressure Switch
• Button
• Reed (Magnetic) Switch
• Optical Sensor

15
General Digital Inputs Switches

• Can be normally open or normally closed
• A Closed Switch is Shorted to Ground - FALSE
• An Open Switch is Not Grounded - TRUE

SWITCH
NC
Signal Input
NO
COM
Ground
16
Analog Module Bumper

• The FPGA backplane connects to the analog module
• The analog module connects directly to the analog
  bumper
• The analog bumper connects via a PWM Connector
  to the analog sensor

17
Analog Sensors

• Sensors that can provide a range of output values
• Examples
• Potentiometer
• Rotational Rate Sensor
• Optical/Sonic Range Sensor

18
Potentiometer

• Acts as a variable resistor
• The output voltage varies as it is turned

5V
Signal
GND
19
Potentiometer States
20
Camera
Uses an ethernet cable
21
WiFi Bridge

• N type WiFi
• Dual Bandwidth

22
(No Transcript)
23
-------Break-------
24
Operator System Overview
Radio Modem
Old System --gt
Operator Interface
Custom Interface Box
Joystick
Joystick
WiFi
? New System
Drivers Station
Joystick
Joystick
Custom Interface Box
25
The Drivers Station (DS)?

• New Part
• Ports
• 4 USB ports
• 2 Ethernet ports
• Power Supply (12 V)?
• 1 competition port
• Pins for custom switches

2
2
Images are of prototype Driver's Station
26
On Drivers Station switch for testing
autonomous mode
Menu Selection
Note the Lack of robot reset (maybe included in
newer models)?
27
USB Ports

• 4 ports
• Can be used with any HID device
• Similar power limitations to previous OI
• Used for updates to firmware
• Each device requires detection by firmware

28
User IO

• For custom control boxes
• Unique shapes or designs
• LED feadback
• Can be used with jumpers to change drive
  configuration

Digital Input
Digital Output
Analog Input
29
Custom Interface Box

• Made by team
• Can consist of (almost) any number of
• Buttons
• Dials (Potentiometers)?
• LEDs
• Other sensors

30
Ethernet Ports

• Self sensing
• Used to communicate with robot
• Tethering
• Practice WiFi
• Dashboard Viewer

31
Competition Port

• 9 pin D-sub
• Used by FIRST to manage matches
• Custom circuit can be built to disable robot

32
(No Transcript)
33
Network Protocol

• Every device needs an address

10.0.1.1
19.18.1.10
10.0.1.2
10.0.0.6
34
Wireless Networks

• The router has a name (SSID)?
• N-type is dual band

35
Your Networked Robot
WiFi Router
The DS
Computer/ Dashboard
WiFi Bridge
The cRIO
Camera
36
The FIRST Field Network
37
(No Transcript)
38

• This presentation is for educational purposes. As
  such I do not claim ownership over all the
  pictures used, but I do claim fair use.
• This presentation was partially based on a
  presentation by Matt Leese
• Feel free to use the pictures I have taken
• Please share this presentation, but leave me some
  credit -Rob Heslin
