Course of Database and System Analysis

1
Course of Database and System Analysis
2

• Database System

3
Introduction

• Database System it is a computerized system
  whose overall purpose is to store information and
  to allow users to retrieve and update that
  information on demand.
• Data refer to what actually stored in the
  database.
• Information it refer to the meaning of that data
  as understood by some users.
• Single-User System is a system in which at most
  one user can access the database at any given
  time.
• Multi-User System is a system in which many
  users can access the database at the same time.
• A major objective of Multi-User Systems is to
  allow each user to behave as if he or she were
  working with a single-user system instead.
• The data in the database will be both integrated
  and shared.

4
Database Management System(DBMS)
Database Management System (DBMS)
Database
Application Programs
End users
Figure (1) Simplified Picture of a database
system
5
Database Management System(DBMS)

• Collection of interrelated data
• Is a layer of software between the data as
  physically stored and users of system
• Manages very large amounts of data.
• Set of programs to access the data
• DBMS contains information about a particular
  enterprise
• DBMS provides an environment that is both
  convenient and efficient to use.
• Database Applications
• Banking all transactions
• Airlines reservations, schedules
• Universities registration, grades
• Sales customers, products, purchases
• Manufacturing production, inventory, orders,
  supply chain
• Human resources employee records, salaries, tax
  deductions
• Databases touch all aspects of our lives

6
Why Use a DBMS?

• Data independence and efficient access.
• Reduced application development time.
• Data integrity and security.
• Uniform data administration.
• Concurrent access, recovery from crashes.

7
Data Models

• A data model is a collection of concepts for
  describing data.
• A schema is a description of a particular
  collection of data, using the given data model.
• The relational model of data is the most widely
  used model today.
• Main concept relation, basically a table with
  rows and columns.
• Every relation has a schema, which describes the
  columns, or fields.

8
Levels of Abstraction

• Many views, single conceptual (logical) schema
  and physical schema.
• Views describe how users see the data.

• Conceptual schema defines logical structure
• Physical schema describes the files and indexes
  used.

9
Example University Database

• Conceptual schema
• Students (sid string, name string, login
  string,
• age integer, gpareal)
• Courses (cid string, cnamestring,
  creditsinteger)
• Enrolled (sidstring, cidstring, gradestring)
• Physical schema
• Relations stored as unordered files.
• Index on first column of Students.
• External Schema (View)
• Course_info(cidstring,enrollmentinteger)

10
Instance of Students Relation

• Students( sid string, name string, login
  string,
• age integer, gpa real )
• sid name login age gpa
• 53666 Jones jones_at_cs 18 3.4
• 53688 Smith smith_at_ee 18 3.2
• 53650 Smith smith_at_math 19 3.8

11
Databases

• Database
• Is a collection of persistent data that is used
  by the application systems of some given
  enterprise.
• Or A set of information held in a computer.
• A database is a collection of data, typically
  describing the activities of one or more related
  organizations. For example, a university database
  might contain information about the following
• Entities such as students, faculty, courses, and
  classrooms.
• Relationships between entities, such as students'
  enrollment in courses, faculty
• teaching courses, and the use of rooms for
  courses.
• Databases are useful
• Many computing applications deal with large
  amounts of information.
• Database systems give a set of tools for storing,
  searching and managing this information.

12

• Database System Architecture

13
Database System Architecture

• A three-level architecture
• Internal level For systems designers
• Conceptual level For database designers and
  administrators
• External level For database users

14
Database System Architecture
External Schemas
External/Conceptual Mappings
Conceptual Schema
Conceptual/Internal Mapping
Internal Schema
15
Conceptual Level

• Deals with the organisation of the entire
  database content
• Abstractions are used to remove unnecessary
  details of the internal level
• Used by DBAs and application programmers
• Conceptual Schema
• e.g.,
• CREATE TABLE
• Employee (Name VARCHAR(25),
• Salary REAL, Department VARCHAR(10))

16
External Level

• Provides a view of the database tailored to a
  user
• Parts of the data may be hidden
• Used by end users and application programmers
• External Schema
• e.g.,
• Create View myView as SELECT Name FROM
  Employee
• Internal Level
• Deals with physical storage of data
• Structure of records on disk - files, pages,
  blocks
• Indexes and ordering of records
• Used by database system programmers
• Internal Schema
• e.g.,
• RECORD EMP LENGTH44
• HEADER BYTE(5) OFFSET0
• NAME BYTE(25) OFFSET5
• SALARY FULLWORD OFFSET30
• DEPT BYTE(10) OFFSET34

17
Mappings

• Mappings translate information from one level to
  the next.
• External/Conceptual
• Conceptual/Internal
• These mappings provide some data independence.
• Logical data independence
• Conceptual level changes shouldnt affect all
  external levels.
• Physical data independence
• Changes to internal level shouldnt affect
  conceptual level.

18
Database Users

• Database systems programmer
• Writes the database software itself
• Database Administrator (DBA)
• The technical person responsible for implementing
  the data administrators decisions. Or designs
  manages the database system.
• End users
• Use the database system to achieve some goal.
• Application developers
• Write software to allow end users to interface
  with the database system

19

• Overview of Storage and Indexing

20
Data on External Storage

• Disks Can retrieve random page at fixed cost
• But reading several consecutive pages is much
  cheaper than reading them in random order
• Tapes Can only read pages in sequence
• Cheaper than disks used for archival storage
• File organization Method of arranging a file of
  records on external storage.
• Record id (rid) is sufficient to physically
  locate record
• Indexes are data structures that allow us to find
  the record ids of records with given values in
  index search key fields
• Architecture Buffer manager stages pages from
  external storage to main memory buffer pool. File
  and index layers make calls to the buffer
  manager.

21
Basic Concepts

• Maximum CPU utilization obtained with
  multiprogramming
• CPUI/O Burst Cycle Process execution consists
  of a cycle of CPU execution and I/O wait
• CPU burst distribution

22
Alternating Sequence of CPU And I/O Bursts
23
Alternative File Organizations

• Many alternatives exist, each ideal for some
  situations, and not so good in others
• Heap (random order) files Suitable when typical
  access is a file scan retrieving all records.
• Sorted Files Best if records must be retrieved
  in some order, or only a range of records is
  needed.
• Indexes Data structures to organize records via
  trees or hashing.
• Like sorted files, they speed up searches for a
  subset of records, based on values in certain
  (search key) fields
• Updates are much faster than in sorted files.

24
Indexes

• An index on a file speeds up selections on the
  search key fields for the index.
• Any subset of the fields of a relation can be the
  search key for an index on the relation.
• Search key is not the same as key (minimal set of
  fields that uniquely identify a record in a
  relation).
• An index contains a collection of data entries,
  and supports efficient retrieval of all data
  entries k with a given key value k.
• Given data entry k, we can find record with key
  k in at most one disk I/O. (Details soon )

25
B Tree Indexes
26

• Storing Data Disks and Files

27
Disks and Files

• DBMS stores information on (hard) disks.
• This has major implications for DBMS design!
• READ transfer data from disk to main memory
  (RAM).
• WRITE transfer data from RAM to disk.
• Both are high-cost operations, relative to
  in-memory operations, so must be planned
  carefully!

28
Why Not Store Everything in Main Memory

• Costs too much. 1000 will buy you either 128MB
  of RAM or 7.5GB of disk today.
• Main memory is volatile. We want data to be
  saved between runs. (Obviously!)
• Typical storage hierarchy
• Main memory (RAM) for currently used data.
• Disk for the main database (secondary storage).
• Tapes for archiving older versions of the data
  (tertiary storage).

29
Disks

• Secondary storage device of choice.
• Main advantage over tapes random access vs.
  sequential.
• Data is stored and retrieved in units called disk
  blocks or pages.
• Unlike RAM, time to retrieve a disk page varies
  depending upon location on disk.
• Therefore, relative placement of pages on disk
  has major impact on DBMS performance!

30
Components of a Disk
31
The Entity-Relationship Model
32
Modeling

• A database can be modeled as
• a collection of entities,
• relationship among entities.
• An entity is an object that exists and is
  distinguishable from other objects.
• Example specific person, company, event, plant
• Entities have attributes
• Example people have names and addresses
• An entity set is a set of entities of the same
  type that share the same properties.
• Example set of all persons, companies, trees,
  holidays

33
Entity Sets customer and loan

• customer_id customer_ customer_
  customer_ loan_ amount
  name street
  city number

34
Relationship Sets

• A relationship is an association among several
  entities
• Example Hayes depositor
  A-102customer entity relationship
  set account entity
• A relationship set is a mathematical relation
  among n ? 2 entities, each taken from entity sets
• (e1, e2, en) e1 ? E1, e2 ? E2, , en ?
  Enwhere (e1, e2, , en) is a relationship
• Example
• (Hayes, A-102) ? depositor

35
Relationship Set borrower
36
Relationship Sets (Cont.)

• An attribute can also be property of a
  relationship set.
• For instance, the depositor relationship set
  between entity sets customer and account may have
  the attribute access-date

37
Degree of a Relationship Set

• Refers to number of entity sets that participate
  in a relationship set.
• Relationship sets that involve two entity sets
  are binary (or degree two). Generally, most
  relationship sets in a database system are
  binary.
• Relationship sets may involve more than two
  entity sets.
• Relationships between more than two entity sets
  are rare. Most relationships are binary. (More
  on this later.)

• Example Suppose employees of a bank may have
  jobs (responsibilities) at multiple branches,
  with different jobs at different branches. Then
  there is a ternary relationship set between
  entity sets employee, job, and branch

38
Attributes

• An entity is represented by a set of attributes,
  that is descriptive properties possessed by all
  members of an entity set.
• Domain the set of permitted values for each
  attribute
• Attribute types
• Simple and composite attributes.
• Single-valued and multi-valued attributes
• Example multivalued attribute phone_numbers
• Derived attributes
• Can be computed from other attributes
• Example age, given date_of_birth

Example customer (customer_id,
customer_name, customer_street,
customer_city ) loan (loan_number, amount )
39
Composite Attributes
40
Mapping Cardinality Constraints

• Express the number of entities to which another
  entity can be associated via a relationship set.
• Most useful in describing binary relationship
  sets.
• For a binary relationship set the mapping
  cardinality must be one of the following types
• One to one
• One to many
• Many to one
• Many to many

41
Mapping Cardinalities
One to one
One to many
Note Some elements in A and B may not be mapped
to any elements in the other set
42
Mapping Cardinalities
Many to one
Many to many
Note Some elements in A and B may not be mapped
to any elements in the other set
43
Revision on Normalisation
44
Purpose of Normalisation

• To avoid redundancy by storing each fact within
  the database only once.
• To put data into a form that conforms to
  relational principles (e.g., single valued
  attributes, each relation represents one entity)
  - no repeating groups.
• To put the data into a form that is more able to
  accurately accommodate change.
• To avoid certain updating anomalies.
• To facilitate the enforcement of data
  constraints.

45
Redundancy and Data Anomalies
Redundant data is where we have stored the same
information more than once. i.e., the redundant
data could be removed without the loss of
information.
46
Repeating Groups
A repeating group is an attribute (or set of
attributes) that can have more than one value for
a primary key value.
47
Functional Dependency
Formal Definition Attribute B is functionally
dependant upon attribute A (or a collection of
attributes) if a value of A determines a single
value of attribute B at any one time.
Formal Notation A ? B This should be read as
A determines B or B is functionally dependant
on A. A is called the determinant and B is
called the object of the determinant.
48
Functional Dependency
Partial Functional Dependency This is the
situation that exists if it is necessary to only
use a subset of the attributes of the composite
determinant to identify its object uniquely.
49
Functional Dependency
Compound Determinants If more than one attribute
is necessary to determine another attribute in an
entity, then such a determinant is termed a
composite determinant.
Full Functional Dependency Only of relevance
with composite determinants. This is the
situation when it is necessary to use all the
attributes of the composite determinant to
identify its object uniquely.
50
Transitive Dependency
Definition A transitive dependency exists when
there is an intermediate functional dependency.
Formal Notation If A ? B and B ? C, then it can
be stated that the following transitive
dependency exists A ? B ? C
51
Stages of Normalisation
52

Structured Query Language SQL
53
Introduction to SQL

• SQL is a standard language for accessing and
  manipulating databases
• What is SQL?
• SQL stands for Structured Query Language
• SQL lets you access and manipulate databases
• SQL is an ANSI (American National Standards
  Institute) standard

54
What Can SQL do?

• SQL can execute queries against a database
• SQL can retrieve data from a database
• SQL can insert records in a database
• SQL can update records in a database
• SQL can delete records from a database
• SQL can create new databases
• SQL can create new tables in a database
• SQL can create stored procedures in a database
• SQL can create views in a database
• SQL can set permissions on tables, procedures,
  and views

55
SQL Syntax

• Database Tables
• A database most often contains one or more
  tables. Each table is identified by a name (e.g.
  "Customers" or "Orders"). Tables contain records
  (rows) with data.
• Below is an example of a table called "Persons"

P_Id LastName FirstName Address City
1 Hansen Ola Timoteivn 10 Sandnes
2 Svendson Tove Borgvn 23 Sandnes
3 Pettersen Kari Storgt 20 Stavanger
The table above contains three records (one for
each person) and five columns (P_Id, LastName,
FirstName, Address, and City).
56
SQL Statements

• Most of the actions you need to perform on a
  database are done with SQL statements.
• The following SQL statement will select all the
  records in the "Persons" table
• SELECT FROM Persons

57
SQL DML and DDL

• SQL can be divided into two parts The Data
  Manipulation Language (DML) and the Data
  Definition Language (DDL)
• The query and update commands form the DML part
  of SQL
• SELECT - extracts data from a database
• UPDATE - updates data in a database
• DELETE - deletes data from a database
• INSERT INTO - inserts new data into a database
• The DDL part of SQL permits database tables to be
  created or deleted. It also define indexes
  (keys), specify links between tables, and impose
  constraints between tables. The most important
  DDL statements in SQL are
• CREATE DATABASE - creates a new database
• ALTER DATABASE - modifies a database
• CREATE TABLE - creates a new table
• ALTER TABLE - modifies a table
• DROP TABLE - deletes a table
• CREATE INDEX - creates an index (search key)
• DROP INDEX - deletes an index

58
SQL SELECT Statement

• The SELECT statement is used to select data from
  a database.
• The result is stored in a result table, called
  the result-set.
• SQL SELECT Syntax
• SELECT column_name(s( FROM
  table_name
• and
• SELECT FROM table_name

59
An SQL SELECT Example

• The "Persons" table

P_Id LastName FirstName Address City
1 Hansen Ola Timoteivn 10 Sandnes
2 Svendson Tove Borgvn 23 Sandnes
3 Pettersen Kari Storgt 20 Stavanger
Now we want to select the content of the columns
named "LastName" and "FirstName" from the table
above. We use the following SELECT statement
SELECT LastName,FirstName FROM
Persons The result-set will look like this
LastName FirstName
Hansen Ola
Svendson Tove
Pettersen Kari
60
SELECT Example

• Now we want to select all the columns from the
  "Persons" table.
• We use the following SELECT statement
• SELECT FROM Persons
• Tip The asterisk () is a quick way of selecting
  all columns!
• The result-set will look like this

P_Id LastName FirstName Address City
1 Hansen Ola Timoteivn 10 Sandnes
2 Svendson Tove Borgvn 23 Sandnes
3 Pettersen Kari Storgt 20 Stavanger
61
SQL SELECT DISTINCT Statement

• In a table, some of the columns may contain
  duplicate values. This is not a problem, however,
  sometimes you will want to list only the
  different (distinct) values in a table.
• The DISTINCT keyword can be used to return only
  distinct (different) values.
• SQL SELECT DISTINCT Syntax
• SELECT DISTINCT
  column_name(s( FROM table_name
• SELECT DISTINCT Example
• The "Persons" table

P_Id LastName FirstName Address City
1 Hansen Ola Timoteivn 10 Sandnes
2 Svendson Tove Borgvn 23 Sandnes
3 Pettersen Kari Storgt 20 Stavanger
62
SQL SELECT DISTINCT Statement

• Now we want to select only the distinct values
  from the column named "City" from the table
  above.
• We use the following SELECT statement
• SELECT DISTINCT City FROM
  Persons
• The result-set will look like this

City
Sandnes
Stavanger
63
SQL WHERE Clause

• The WHERE clause is used to filter records.
• The WHERE clause is used to extract only those
  records that fulfill a specified criterion.
• SQL WHERE Syntax
• SELECT column_name(s)
  FROM table_name WHERE
  column_name operator value
• WHERE Clause Example
• From the "Persons" table we want to select only
  the persons living in the city "Sandnes"
• We use the following SELECT statement
• SELECT FROM Persons
  WHERE City'Sandnes
• The result-set will look like this

P_Id LastName FirstName Address City
1 Hansen Ola Timoteivn 10 Sandnes
2 Svendson Tove Borgvn 23 Sandnes
