Title: SS902 ADVANCED ELECTROCHEMISTRY


1
SS902 ADVANCED ELECTROCHEMISTRY
  • Murali Rangarajan
  • Department of Chemical Engineering
  • Amrita Vishwa Vidyapeetham
  • Ettimadai

2
ELECTRODICS
3
Faradaic Processes
  • Two types of processes take place at electrode
  • Faradaic Processes
  • Non-Faradaic Processes
  • Faradaic processes involve electrochemical redox
    reactions, where charges (ex. electrons or ions)
    are transferred across the electrode-electrolyte
    interface
  • This charge transfer is governed by Faradays
    laws
  • Faradays First Law The amount of substance
    undergoing an electrochemical reaction at the
    electrode-electrolyte interface is directly
    proportional to the amount of electricity
    (charge) that passes through the electrode and
    electrolyte

4
Faradays First Law
  • Every non-quantum process has a rate, a driving
    force and a resistance to the process offered by
    the system where the process takes place
  • They are related to each other
  • Reaction rate is given by
  • Here, j is current density, z is the number of
    electrons transferred and F is Faradays constant
    96487 C/mol
  • Problem A 30cm ? 20cm aluminum sheet is anodized
    on both sides in a sulfuric acid bath. (Thickness
    may be ignored for calculation of area.) at 3
    A/dm2 for 1 hour at 30 efficiency. Density of
    aluminum is 2.7 g/cm3. Calculate the thickness of
    anodic film. The atomic weight of aluminum is 27.

5
Non-Faradaic Processes
  • Non-Faradaic processes are those that occur at
    the electrode-electrolyte interface but do not
    involve transfer of electrons across the
    interface
  • Adsorption/Desorption of ions and molecules on
    the electrode surface
  • These can be driven by change in potential or
    solution composition
  • They alter the structure of the
    electrode-electrolyte interface, thus changing
    the interfacial resistance to charge transfer
  • Although charge transfer does not take place,
    external currents can flow (at least transiently)
    when the potential, electrode area, or solution
    composition changes

6
Non-Faradaic Processes
  • Both faradaic and non-faradaic processes occur at
    the interface when electrochemical reactions
    occur
  • Though only Faradaic processes may be of
    interest, the non-Faradaic processes can affect
    the electrochemical reactions significantly
  • For instance, additives are used in
    electroplating which adsorb on electrode surface,
    increases resistance to deposition, resulting in
    smoother deposits
  • So we first examine the structure of the
    electrode-electrolyte interface and the
    non-faradaic processes that happen there

7
Electrical Double Layer
  • Electrode-electrochemical interface may be
    thought of as a capacitor when voltage is
    applied to it
  • A parallel-plate capacitor stores charges by
    polarization of the two plates (due to applied
    voltage/other driving forces molecular
    structure of the medium in between)

The metal-solution interface as a capacitor with
a charge on the metal, qM, (a) negative and (b)
positive
Charging a capacitor with a battery
8
Electrical Double Layer
  • The metal side of the double layer acquires
    either positive or negative charge depending on
    whether the electrode is an anode or a cathode
  • The solution side of the double layer is thought
    to be made up of several layers
  • That closest to the electrode, the inner layer,
    contains solvent molecules and sometimes other
    species (ions or molecules) that are said to be
    specifically adsorbed
  • This inner layer is called the Helmholtz or Stern
    layer
  • The total charge density from specifically
    adsorbed ions in this inner layer is ? i
  • The locus of the electrical centers of the
    specifically adsorbed ions is called the inner
    Helmholtz plane (IHP)

9
Electrical Double Layer
  • Solvated ions can approach the metal only till
    before the IHP
  • The locus of centers of these nearest solvated
    ions is called the outer Helmholtz plane (OHP)
  • The interaction of the solvated ions with the
    charged metal involves only long-range
    electrostatic forces, so that their interaction
    is essentially independent of the chemical
    properties of the ions
  • These ions are said to be nonspecifically
    adsorbed
  • Because of thermal agitation in the solution, the
    nonspecifically adsorbed ions are distributed in
    a 3-D region called the diffuse layer, which
    extends from the OHP into the bulk of the solution

10
Electrical Double Layer
  • The excess charge density in the diffuse layer is
    ?d, hence the total excess charge density on the
    solution side of the double layer, ?s, is given by

The thickness of the diffuse layer depends on the
total ionic concentration in the solution for
concentrations greater than 10?2 M, the thickness
is less than 100 A?
Potential profile across interface
11
Measuring Double Layer Properties
  • Use a cell consisting of an ideal polarizable
    electrode (IPE) and an ideal reversible electrode
    (IRE)

Two-electrode cell with an ideal polarized
mercury drop electrode and an SCE
This cell does not undergo any Faradaic
processes, so only double-layer properties are
measured
Resistances in the IPE-IRE cell
12
Electrochemical Cells
  • Common cells are two-electrode and
    three-electrode cells
  • Refer to Bard and Faulkner pp. 24-28 for their
    description
  • Prepare short notes on both two-electrode and
    three-electrode cells

13
Electrochemical Experiments
  • A number of electrochemical experiments may be
    performed with an electrochemical cell
  • There are three main properties of
    electrochemical systems that may be measured
  • Voltage
  • Current
  • Impedance or Resistance
  • Some of them are
  • Potential Step Experiments
  • Current Step Experiments
  • Potential Sweep (Voltage Ramp) Experiments
  • Electrochemical Impedance Spectroscopy

14
Electrochemical Experiments
  • In each of these experiments, a predefined
    perturbation of one of the properties is applied
    on the system
  • One of the other properties is measured as a
    response
  • From these responses, both Faradaic and
    Non-Faradaic processes, their rates and
    resistances may be studied

Experiment Perturbed Variable Measured Variable
Potential Step Voltage Current
Current Step Current Voltage
Potential Sweep Voltage Current
Impedance Spectroscopy Voltage Impedance
15
Potential Step Experiments
The current response for a potential step is
  • There is an exponentially decaying current
    having a time constant ? RsCd.
  • Peak Current E/Rs.

16
Current Step Experiments
The voltage response for a current step is
  • Potential increases linearly with time
  • The initial jump in the potential is iRs.
  • Slope is i/Cd.

17
Potential Sweep Experiments
The current response for a linear voltage ramp E
?t is
  • The time constant for current is ? RsCd.
  • The limiting current (maximum current) is ?Cd.

18
Potential Sweep Experiments
  • A triangular wave is a ramp whose sweep rate
    switches from ? to ? at some potential, E?.
  • The steady-state current changes from ?Cd during
    the
  • forward (increasing E) scan to ?Cd during the
    reverse (decreasing E) scan

19
Faradaic Processes
  • When charger-transfer reactions (Faradaic
    processes) take place in an electrochemical cell,
    the driving force for the reactions is the
    departure in the voltage from the equilibrium
    voltage of the cell
  • This departure of voltage from the equilibrium
    voltage of the cell is termed as overpotential
  • The rate of the reaction must be proportional to
    the driving force
  • Therefore there must be a relationship between
    the overpotential and the Faradaic current
  • Current-potential curves, particularly those
    measured under steady-state, are termed
    polarization curves

20
Polarizable Vs. Non-Polarizable
  • An ideal polarizable electrode is one that shows
    a very large change in voltage for the passage of
    an infinitesimal current
  • An ideal non-polarizable electrode is one that
    shows a very large change in current for an
    infinitesimal overpotential

21
What Affects Polarization?
  • Consider the overall electrochemical reaction
  • A dissolved oxidized species, O, is converted to
    a reduced form, R, also in solution
  • There are a number of steps that are involved in
    the overall electrochemical reaction
  • The rate of electrochemical reaction is
    determined by the slowest, i.e., rate-determining
    step
  • Each step will contribute to the overpotential
    (polarization)
  • The overpotential needed for a certain reaction
    rate will largely be determined by the
    rate-determining step
  • Equally, the rate constants of the different
    steps will also be dependent on the potential

22
Steps in Electrochemical Rxn
  • The following steps are involved in an
    electrochemical rxn
  • Mass transfer (e.g., of ? from the bulk solution
    to the electrode surface).
  • Electron transfer at the electrode surface.
  • Chemical reactions preceding or following the
    electron transfer. These might be homogeneous
    processes (e.g., protonation or dimerization) or
    heterogeneous ones (e.g., catalytic
    decomposition) on the electrode surface.
  • Other surface reactions, such as adsorption,
    desorption, or crystallization (electrodeposition)
    .

23
Steps in Electrochemical Rxn
24
Overpotential
  • The driving force for an electrochemical reaction
    is the overpotential
  • This driving force is used up by all the steps in
    the electrochemical reaction
  • Thus an applied overpotential may be broken into
  • Mass transfer overpotential
  • Charge transfer overpotential
  • Reaction (Chemical) overpotential
  • Adsorption/Desorption overpotential
  • Correspondingly, the resistance offered to the
    passage of current may be viewed as sum of a
    series of resistances

25
Electrode Kinetics
  • Consider the reversible charge transfer redox
    reaction taking place at an electrode-electrolyte
    interface
  • Let the rate constants be kf and kr respectively
    for the forward and the reverse reactions
  • In the limit of thermodynamic equilibrium, the
    potential established at the electrode-electrolyte
    interface is given by the Nernst equation
  • Here CO and CR are bulk concentrations, z is
    the number of electrons transferred, E0 is the
    formal potential

26
Tafel Equation
  • Without derivations, we present the rate
    equations (relating current-overpotential)
  • It is important to recall that a number of
    factors (including interfacial electron transfer
    kinetics) that determine the overall rate of an
    electrochemical reaction
  • When the current is low and the system is
    well-stirred, mass transfer of reactants to the
    interface is not the rate-limiting step
  • At such conditions, adsorption/desorption are
    also not usually rate-limiting
  • The reaction rate is determined mainly by
    charge-transfer kinetics governed by Tafel
    Equation

27
Tafel Equation
28
Butler-Volmer Equation
  • The exponential relationship between current
    density and overpotential, observed
    experimentally by Tafel, is an important result
    and is true for more general cases as well
  • For a one-step (only charge transfer resistance
    in a single step), one-electron process, the
    general rate equation is
  • Here i is current, A is area of the electrode, F
    is Faradays constant, k0 is the standard rate
    constant (at eqbm), CO(0,t) CR(0,t) are
    instantaneous concentrations of O R at the
    electrode surface, ? is the transfer coefficient,
    f is F/RT, E0 is a reference potential

29
Standard Rate Constant
  • The standard rate constant k0 It is the measure
    of the kinetic facility of a redox couple. A
    system with a large k0 will achieve equilibrium
    on a short time scale, but a system with small k0
    will be sluggish
  • Values of k0 reported in the literature for
    electrochemical reactions vary from about 10 cm/s
    for redox of aromatic hydrocarbons such as
    anthracene to about 10?9 cm/s for reduction of
    proton to molecular hydrogen
  • So electrochemistry deals with a range of more
    than 10 orders of magnitude in kinetic reactivity
  • Another way to approach equilibrium is by
    applying a large potential E relative to E0.
  • Both of these together are represented by the
    term exchange current

30
Exchange Current
  • Exchange current is the current transferred
    between the forward and the reverse reactions at
    equilibrium they are equal at equilibrium and
    the net current is zero
  • CO is the concentration of species O at
    equilibrium
  • The exchange current density values for two
    electrochemical reactions are 1 ? 109 and 1 ?
    103 A/cm2. How do they reflect on Tafel plot,
    all other parameters being constant?
  • No effect on b only on a
  • One with larger i0 needs lesser overpotential to
    achieve same current or rate of the reaction

31
Exchange Current
32
Butler-Volmer Equation
  • In terms of exchange current and overpotential,
    Butler-Volmer equation is represented as
  • First term denotes cathodic contribution and the
    second denotes anodic contribution
  • Ratio of concentrations is a measure of effects
    of mass transfer they govern how much reactants
    are supplied to the electrode
  • In the absence of mass transfer effects (CO(0)
    CO always), the current-overpotential
    relationship is given by

33
Limiting Current
  • Now let us look at the other extreme where the
    electron transfer is extremely fast compared to
    mass transfer
  • Therefore the current (rate of charge transfer)
    is entirely governed by the rate at which the
    reacting species (say, O) is brought to the
    electrode surface
  • This rate of mass transfer is proportional to the
    concentration difference of O between the bulk
    and the interface, i.e., CO ? CO(0)
  • The proportionality constant is termed as mass
    transfer coefficient k
  • This is equal to the electrochemical reaction
    rate il/nF
  • Here il is called the limiting current the
    maximum current when the process is
    mass-transfer-limited

34
Butler-Volmer Equation
Note Butler-Volmer equation is not valid under
mass-transfer-limited conditions
Note For small ?, i increases linearly with ?
For medium ?, Tafel behavior is seen For large
?, i is independent of ? limiting current
? 0.5, T 298 K, il,c ? il,a il, and i0/il
0.2. Dashed lines show the component currents
ic and ia.
35
Exchange Current Overpotential
  • Therefore the regime where Butler-Volmer equation
    is valid is the charge-transfer-limiting regime
  • Here, most of the driving force is spent in
    overcoming the activation energy barrier of the
    charge transfer process
  • Therefore, the overpotential in this regime is
    termed activation overpotential
  • We have already seen that for sluggish redox
    kinetics, the exchange current must be small
    Small i0 ? ? Activation overpotential
  • On the other hand, when the exchange current is
    very large, even for very small overpotentials,
    the current approaches the limiting current,
    i.e., since charge transfer is very fast, mass
    transfer to the electrode becomes rate-limiting
  • In such conditions, Large i0 ? ? Concentration
    overpotential

36
Transfer Coefficient
  • The second parameter in the Butler-Volmer
    equation is transfer coefficient ?
  • Transfer coefficient determines the symmetry of
    the current-overpotential curves
  • For the cathodic term, the exponential term is
    multiplied by ? while for the anodic term the
    multiplying factor is (1 ? ?)
  • If ? 0.5, both cathodic and anodic behavior of
    the electrode will be symmetric
  • If ? gt 0.5, the system is likely to behave a
    better cathode (since more cathodic currents are
    achieved for smaller overpotentials)
  • If ? lt 0.5, the system is likely to behave a
    better anode (since more anodic currents are
    achieved for smaller overpotentials)

37
Transfer Coefficient
Write a Comment
User Comments (0)
About PowerShow.com
