RHIC and our understanding of hot hadronic systems

1
RHIC and our understanding of hot hadronic systems

• Wojciech Broniowski
• Institute of Nuclear Physics, Cracow and
• Institute of Physics, Swietokrzyska Academy,
  Kielce
• Ljubljana, 18 September 2006

2
1. A short story of quarks

• 1964 Gell-Mann Phys. Lett. 8 (1964) 214-215,
• A schematic model of baryons and mesons
• Zweig simultaneous CERN preprint
• 1965 Greenberg, Han, Nambu introduction of
  color, confinement
• For many years treated as a purely theoretical
  concept!
• 60/70 Friedman Kendall Taylor SLAC-MIT
  experiment
• deep inelastic scattering,
• 1968-69 Bjorken Feynman parton model
• 1973 Fritch Gell-Mann QCD
• Gross Wilczek Politzer asymptotic
  freedom, partonsquarks
• 1979 three-jet events at PETRA/DESY, gluons
• 70- Current and constituent quarks, effective
  quark models

3
from BNL web page
4
2. Quark-gluon plasma

• 1975 Collins Perry our basic picture then is
  that matter at densities higher than nuclear
  consists of a quark soup
• 1975 Cabibbo Parisi phase transition at the
  Hagedorn temperature
• 1978 Shuryak first to use quark-gluon plasma
  (QGP)
• Yad. Fiz. 28 (1978) 796
• 1978 Chin and 1979 Kapusta consider
  quantitatively the possibility of QGP production
  in relativistic heavy ion collisions
• 1983 Bjorken estimation of energy available for
  QGP production

5
3. Relativistic heavy-ion collisions

• 70 BEVALAC (LBL) SYNCHROPHASOTRON
  (DUBNA), 1-4 GeV/nucleon
• 1986 AGS (BNL) (14 GeV/n, Si) and SPS (CERN)
• (60 and 200 GeV/n, O i S)
• 1992 AGS (11 GeV/n, Au)
• 1995 SPS (158 GeV/n, Pb)
• 2000 RHIC (BNL) collider 200 GeV/nucleon pair
• 1999 - 2003 SPS (NA49) collisions of various
  nuclei at energies of 20, 30, 40 and 80 GeV/n

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
from BNL web page
13
4. Signatures of QGP

• Enhanced strangeness production, J/? suppression,
  modified dilepton production, collective
  behavior, ...
• After 15 years of experiments CERN on 10 February
  2000 issued an official statement
• a compelling evidence now exists for the
  formation of a new state of matter
• Doubts remain, circumstances, models not
  referring to QGP or phase transition in many
  instances describe the data
• Since 2000 new data from RHIC at 200 GeV/nucleon
  pair in CM frame against expectations!

14
5. Elliptic flow
Phenomenon known for 20 years ...
film by J. Mitchell
15

• not a superposition of independent NN colisions
• all particles flow together pions, kaons,
  protons, heavy flavor (!)
• flow develops very early
• QGP leads to flow!

16
6. Jet quenching
film by J. Mitchell
17

• Evidence for very dense medium, many
  scattering centers
• Bjorkens formula indicates density where hadrons
  largely overlay - quarks and gluons are the
  proper degrees of freedom
• Parton interactions lead to flow
• Simulation of partonic cascades and the success
  of hydrodynamic calculations with zero viscosity
  indicate very strong interaction of partons
• Shuryak QGP ? sQGP
• (nearly perfect fluid, 1000 times less viscous
  than water!)

Cross sections 50-100 times larger than in
perturbative QCD!
18
7. The fate of sQGP

• Hard scatterings, strings, color glass
  condensate, ...
• sQGP forms
• sQGP expands and gradually changes into a gas of
  hadrons
• Due to expansion the mean free path of hadrons
  increases and at some point the particles become
  free - freeze-out
• The chemical composition (pions, kaon, nucleons,
  hyperons, K) corresponds to full chemical
  equilibrium with T 165 MeV, transverse momentum
  spectra have a Boltzmann shape with T 110 MeV
  and average velocity of transverse expansion of
  v 0.5 c

19
8. The Cracow freeze-out model PRL 87 (2001)
272302, WB W. Florkowski

• All resonance decays included, simple
  description of freeze-out

P. Bozek, M. Michalec, A. Baran, M. Chojnacki,
B. Biedron
20
(No Transcript)
21
Spectra of hyperons
(predictions compared to STAR)
22
Pion pair distribution in invariant mass M
(WBWF Brigitte Hiller), compared to STAR
plot by P. Fachini
23
Charge balance function (WBWF Piotr Bozek) -
correlation measure of positive and negative
pions compared to the results of STAR
24
Topography of the fireball
ratio of protons to antiprotons
baryonic
strange
prepared by B. Biedron
25
Thermal description works remarkably!
Spectra at different rapidities compared to BRAHMS
26
by M. Chojnacki
27
9. The freeze-out curve
RHIC
QGP
HADRONS
adapted from F. Becattini
28
Phase diagram of hadronic matter
29
crossover
first-order transition
30
Phase diagram of water
31
10. Summary and outlook

• sQGP - thermalized matter
• freeze-out successful description of many
  phenomena
• to come LHC an order of magnitude larger
  energies, RHIC at SPS energies, NA49 future,
  new facility at GSI low temperature and high
  density

32
BRAHMS _at_200GeV

• Question on the nature of collision transition
  (Bjorken) or stopping and explosion (Landau)
• No plateau in rapidity!

33

• Search and investigation of the critical point in
  the QCD phase diagram
• More precise scan at lower energies
• RHIC overshoots (Gazdzicki plots)

34

• Fundamental theoretical question what makes QGP
  sQGP?
• What happens in the earliest phase?
• Correlation studies, HBT, event-by-event
  fluctuations cluster picture of
  fireball

WB, B. Hiller, W. Florkowski, P. Bozek
35
(No Transcript)
