Petroleum Engineering 411 Well Drilling

1
Petroleum Engineering 411Well Drilling

• Lesson 28
• SMD Well Control

2
Subsea Mudlift Drilling ( SMD )Note Pump
and ReturnLine
3
DESIGN PROJECT
Your PETE 411 Design Project is Due in Dr. J-Ws
Office by 5 p.m. on Monday, Dec. 9, 2002Monday,
Dec. 2 is set aside for you to get together with
your team mates to work on the project during
regular class hours.
4
Contents -

• Review of Conventional Well Control
• Kick Detection in SMD
• Kick containment in SMD
• Behavior of Real Gases in SMD Wells
• Well Control in SMD

5
Kick Detection Well Control- Review -
Conventional -

• Kick Indication (what is a KICK?)
• Kick Detection (confirmation)
• Kick Containment (stop flow into well)
• Circulate Kick out of hole
• Increase Mud Weight in hole (if necessary)

6
Circulate Kick out of hole
Conventional Wait and Weight Method
Old Mud
Kill Mud
Kick
BHP Constant
Keep the BHP constant throughout
7
Gas Kick Behavior - Perfect Gas
Maximum Choke Pressure 1,000 psia. BHP 6,000
psia
0.02 deg F/ft
0.00 deg F/ft
0.01 deg F/ft
8
Z-Factor - In Shallow Wells
Gas Specific Gravity 0.65 (S.G. of air
1)
9
Shallow Gas Kick - Summary
0.02 deg F/ft
Real Gas Ideal Gas PV
constant
10
Gas Kicks in Deep SMD Wells
MudLine
MudLift Pump
As expected, most of the expansion occurs in the
top 3,000 ft or so
11
Gas Kicks in Deep SMD Wells
PV ZnRT
PV constant
12
Gas Kick Behavior - Z-Factor
Gas Specific Gravity 0.65 (S.G. of air
1)
3.0
30
60
pVZnRT
100
150
200
2.5
300
400
2.0
Compressibility (Z-Factor)
o
Temperature,
F
1.5
1.0
0.5
0
5,000
10,000
15,000
20,000
25,000
Pressure, psig
13
Subsea Mudlift Drilling System
FLOATER
Surface Pump Constant Rate Mudlift Const. Inlet
Press.
SEAWATER HYDROSTATIC PRESSURE
10,000
SEAFLOOR
BOP
MUDLIFT
30,000
KICK
What next??
14
Kick Detection and Control
15
Kick Detection and Control
Influx has stopped and pressures have stabilized
ATM
16
Kick Detection and Control
ATM
17
(No Transcript)
18
SICP
CONVENTIONAL
19
(No Transcript)
20
(No Transcript)
21
Kick Detection Method Still Valid for
SMD? Pit Gain Still valid Flow Rate Increase
(Returns) Much Better Well Flows With Rig Pump
Off U-tubing ... Fluid Fill-up on Trips
More complicated Increased Hook Load Still
Valid Drop in Standpipe Pressure Better Drop in
BHP - MWD Still Valid Drilling Break Still
valid Decreased Mud Weight (Gas Cut) Still valid
22

• Well Control Summary
• Most Conventional kick detection methods are
  still valid
• New differential flow rate method - better
  - use with computer monitoring
• Lower standpipe pressure makes kick detection
  easier and faster
• Conventional well control can be adapted -
  with modifications

23

• Well Control Summary contd
• Not necessary to shut well in
• Seafloor pump controls the BHP
• Surface choke pressure generally does not
  affect wellbore pressures
• Well control training will be essential !!

24
General Summary Subsea Mudlift Drilling is a
method that offers potential for lowering
drilling costs in very deep waters. ( fewer
casing strings, smaller rigs, less time on
location, larger hole ) The method utilizes one
or more small-diameter return lines from the
seafloor to the surface. The drillpipe is not
inside a return line.
25
Summary - contd A mudlift system is used in
the return line thereby making a dual-density
mud system possible. Wellhead pressure is
maintained at seawater hydrostatic, so well is
dead at all times Well control is quite
similar to that in conventional drilling with a
riser - There are some real
advantages higher margins, choke line DP, etc.
26
ATM
THE END
27
U-Tubing in SMD
ATM
FLOATER
SEAWATER HYDROSTATIC PRESSURE
STATIC FLUID LEVEL
MUDLIFT
BOP
28
Static Pressures - SMD
ANNULUS AND RETURN LINE
DRILLSTRING PRESSURE
SEAFLOOR
DEPTH
SEA WATER HYDROSTATIC PRESSURE
PRESSURE
