Supporting Queries with Imprecise Constraints

1
Supporting Queries with Imprecise Constraints

• Ullas Nambiar
• Dept. of Computer Science
• University of California, Davis

Subbarao Kambhampati Dept. of Computer
Science Arizona State University
18th July, AAAI -06, Boston, USA
2
Dichotomy in Query Processing

• IR Systems
• User has an idea of what she wants
• User query captures the need to some degree
• Answers ranked by degree of relevance

• Databases
• User knows what she wants
• User query completely expresses the need
• Answers exactly matching query constraints

3
Why Support Imprecise Queries ?
4
Others are following
5

What does Supporting Imprecise Queries Mean?

• The Problem Given a conjunctive query Q over a
  relation R, find a set of tuples that will be
  considered relevant by the user.
• Ans(Q) xx ? R, Rel(xQ,U) gtc
• Constraints
• Minimal burden on the end user
• No changes to existing database
• Domain independent

Relevance Assessment
6
Assessing Relevance Function Rel(xQ,U)

• We looked at a variety of non-intrusive relevance
  assessment methods
• Basic idea is to learn the relevance function for
  user population rather than single users
• Methods
• From the analysis of the (sample) data itself
• Allows us to understand the relative importance
  of attributes, and the similarity between the
  values of an attribute
• ICDE 2006WWW 2005 poster
• From the analysis of query logs
• Allows us to identify related queries, and then
  throw in their answers
• WIDM 2003 WebDB 2004
• From co-click patterns
• Allows us to identify similarity based on user
  click pattern
• Under Review

7
Our Solution AIMQ
8
The AIMQ Approach
For the special case of empty query, we start
with a relaxation that uses AFD analysis
9
An Illustrative Example

• Relation- CarDB(Make, Model, Price, Year)
• Imprecise query
• Q - CarDB(Model like Camry, Price like
  10k)
• Base query
• Qpr - CarDB(Model Camry, Price 10k)
• Base set Abs
• Make Toyota, Model Camry, Price
  10k, Year 2000
• Make Toyota, Model Camry, Price
  10k, Year 2001

10
Obtaining Extended Set

• Problem Given base set, find tuples from
  database similar to tuples in base set.
• Solution
• Consider each tuple in base set as a selection
  query.
• e.g. Make Toyota, Model Camry, Price
  10k, Year 2000
• Relax each such query to obtain similar precise
  queries.
• e.g. Make Toyota, Model Camry, Price
  , Year 2000
• Execute and determine tuples having similarity
  above some threshold.
• Challenge Which attribute should be relaxed
  first?
• Make ? Model ? Price ? Year ?
• Solution Relax least important attribute
  first.

11
Least Important Attribute

• Definition An attribute whose binding value
  when changed has minimal effect on values binding
  other attributes.
• Does not decide values of other attributes
• Value may depend on other attributes
• E.g. Changing/relaxing Price will usually not
  affect other attributes but changing Model
  usually affects Price
• Dependence between attributes useful to decide
  relative importance
• Approximate Functional Dependencies Approximate
  Keys
• Approximate in the sense that they are obeyed by
  a large percentage (but not all) of tuples in the
  database
• Can use TANE, an algorithm by Huhtala et al
  1999

12
Deciding Attribute Importance

• Mine AFDs and Approximate Keys
• Create dependence graph using AFDs
• Strongly connected hence a topological sort not
  possible
• Using Approximate Key with highest support
  partition attributes into
• Deciding set
• Dependent set
• Sort the subsets using dependence and influence
  weights
• Measure attribute importance as

• Attribute relaxation order is all non-keys first
  then keys
• Greedy multi-attribute relaxation

13
Tuple Similarity

• Tuples obtained after relaxation are ranked
  according to their
• similarity to the corresponding tuples in base
  set
• where Wi normalized influence weights, ? Wi 1
  , i 1 to Attributes(R)
• Value Similarity
• Euclidean for numerical attributes e.g. Price,
  Year
• Concept Similarity for categorical e.g. Make,
  Model

14
Categorical Value Similarity

• Two words are semantically similar if they have a
  common context from NLP
• Context of a value represented as a set of bags
  of co-occurring values called Supertuple
• Value Similarity Estimated as the percentage of
  common Attribute, Value pairs
• Measured as the Jaccard Similarity among
  supertuples representing the values

ST(QMakeToyota)
Model Camry 3, Corolla 4,.
Year 20006,19995 20012,
Price 59954, 65003, 40006
Supertuple for Concept MakeToyota
15
Value Similarity Graph
16
Empirical Evaluation

• Goal
• Evaluate the effectiveness of the query
  relaxation and similarity estimation
• Database
• Used car database CarDB based on Yahoo Autos
• CarDB( Make, Model, Year, Price, Mileage,
  Location, Color)
• Populated using 100k tuples from Yahoo Autos
• Census Database from UCI Machine Learning
  Repository
• Populated using 45k tuples
• Algorithms
• AIMQ
• RandomRelax randomly picks attribute to relax
• GuidedRelax uses relaxation order determined
  using approximate keys and AFDs
• ROCK RObust Clustering using linKs (Guha et al,
  ICDE 1999)
• Compute Neighbours and Links between every tuple
• Neighbour tuples similar to each other
• Link Number of common neighbours between two
  tuples
• Cluster tuples having common neighbours

17
Efficiency of Relaxation
Guided Relaxation
Random Relaxation
18
Accuracy over CarDB

• 14 queries over 100K tuples
• Similarity learned using 25k sample
• Mean Reciprocal Rank (MRR) estimated as
• Overall high MRR shows high relevance of
  suggested answers

19
Handling Imprecision Incompleteness

• Incompleteness in data
• Databases are being populated by
• Entry by lay people
• Automated extraction
• E.g. entering an accord without mentioning
  Honda

• Imprecision in queries
• Queries posed by lay users
• Who combine querying and browsing

General Solution Expected Relevance Ranking
Challenge Automated Non-intrusive assessment
of Relevance and Density functions
20
Handling Imprecision Incompleteness
