USS tests of fetal wellbeing

1
USS tests of fetal wellbeing
2
USS tests of fetal wellbeing

• Amniotic fluid assessment
• Biophysical profile
• Umbilical artery doppler
• Umbilical vein doppler
• (Uterine artery doppler)
• (Mean cerebral artery (MCA) doppler)

3
Amniotic Fluid assessment

• Must not contain umbilical cord
• Deepest pocket
• lt2cm (oligo) or gt8cm (poly)
• AFI
• lt5th centile for gestational age (oligo)
• gt95th centile for gestational age (poly)
• lt5.1cm
• Subjective assessment by experienced operator

4
Indications

• IUGR
• Reduced fetal movements
• Post dates pregnancy

5
Biophysical ProfileHistory

• Screened out anomalies
• Alternative to Oxytocin Challenge Test
  Contraction Stress test
• Arbitrary Scoring-no reason for the weighting
  some components maybe more important than others
• Limited evidence to support its use
• Normal result useful for 24 hours

6
Indications

• Post dates pregnancy
• IUGR
• Reduced fetal movements
• Maternal hypertension

7
Parameters of Biophysical scoring

• CTG
• 2 accs with mvmts in 20mins
• FBMs
• gt1episode of 30s in 30min-not continuous
• Gross body/limb mvmts
• ?3 mvmts in 30mins-continuous
• Tone/posture
• 1 episode flexion-extension-flexion of
  limb,opening hand, mouth, trunk rotation
• AFV
• 1pool gt2cms X 2cm

8
Tips for best assessment process

• Do CTG first
• Assess fetal state, do when fetus awake
• Transverse fetal abdomen image with limbs
• Score out of 10 - without CTG it is incomplete
• USS part 0,2,4,6 or 8/8
• 6 or 8/8 normal
• BUT for amniotic fluid ALWAYS an abnormal result

9
DOPPLER IN OBSTETRICS

• Flow velocity waveform-spectral display
• Influenced by
• cardiac function
• vessel wall characteristics
• viscosity
• downstream vascular arrangement

10
DOPPLER IN PREGNANCYKEY POINTS

• Need to understand basic principles
• Is user dependent
• Established roles fetal welfare assessment
• assessment of anaemia
• fetal echocardiography
• Potential roles screening for preeclampsia
• uses for venous doppler
• Fetal circulation has low resistance throughout
• absent or reversed velocities abnormal

11
UMBILICAL ARTERIAL DOPPLER

• Mid portion of cord
• In fetal quiescence
• Use RI or PI
• Progressive fall in resistive indices throughout
  normal pregnancy
• Angle, sample volume important
• Extremes of fetal heart rate will affect result

12
S peak systolic frequencies D least
diastolic frequencies S-D/S resistance or
Pourcelot index S-D/mean Pulsatility index (S/D
s d ratio, cannot describe AEDV ) These are
gestation dependent the trend is important
13
(No Transcript)
14
(No Transcript)
15
Use of Umbilical Arterial Doppler in high risk
pregnancy (preeclampsia and SGA)

• 30 reduction in perinatal death
• 40 reduction in admissions
• ? deliverieslt 34 weeks
• No differences in C/S or fetal distress in labour

Cochrane review2000
16
Fetal growth restriction
Fetal overgrowth
17
(No Transcript)
18
Normal Spiral Arteriole Thin walled
Abnormal Spiral Arteriole
Thick walled
19
(No Transcript)
20
Umbilical Doppler
21
FETAL VENOUS DOPPLER

• Venous Doppler
• a marker of fetal cardiac dysfunction
• influenced by fetal behavioural state esp FBM
• Umbilical vein non pulsatile
• pulsatile decreased forward flow at end diastole
• Ductus Venosus M shaped waveform
• reversed velocities abnormal
• proposed uses TTTS
• aneuploidy screening 1st T
• anaemia

22
(No Transcript)
23
FETAL DOPPLER SUMMARY

• Umbilical artery well assessed
• Trend through gestation important
• Absent end diastolic velocities or reversed
  velocites always abnormal
• Doppler does not tell when delivery should occur
• Later in gestation fetus less tolerant of
  abnormal Doppler
• Pulsatile umbilical vein may be preterminal

24
Uterine artery assessment
25
UTERINE ARTERY FLOW VELOCITY WAVEFORMS Upper
panel normal waveform Lower
panel abnormal with notching
26
Uterine arterial dopplera problem of a low
prevalence condition

• Poor predictor of preterm birth
• Ultrasound Obstet Gynecol. 2004
  Sep24(4)Second-trimester uterine artery
  Doppler and spontaneous preterm
  delivery.Cobian-Sanchez F, Prefumo F, Bhide A,
  Thilaganathan B.
• Poor predictor of PET, FGR P.N.Mortality.
• BJOG. 2000 Feb107(2)196-208How useful is
  uterine artery Doppler flow velocimetry in the
  prediction of pre-eclampsia, intrauterine growth
  retardation and perinatal death? An
  overview.Chien PF, Arnott N, Gordon A, Owen P,
  Khan KS.

27
USS tests of fetal wellbeing

• Amniotic fluid assessment
• Biophysical profile
• Umbilical artery doppler
• Umbilical vein doppler
• (Uterine artery doppler)
• (Mean cerebral artery (MCA) doppler)
