WHITE MOUNTAIN ENERGY PROJECT UPDATE

1
WHITE MOUNTAIN ENERGY PROJECT UPDATE

• JIM MEACHAM
• RYAN GAYLORD
• ADVANCED POWER AND ENERGY PROGRAM

03/15/05
2
OVERVIEW

• Barcroft Vision and Goals
• System Characterization
• Power Demand
• Solar Resources
• Wind Resources
• Heat Demand
• Future Work

3
BARCROFT VISION

• Program Goals
• Increase Safety
• Increase Reliability and Power Quality
• Lower Utility Bills
• Test Innovative Power Generation Technologies

4
BARCROFT VISION
Current Barcroft Distribution System
5
BARCROFT VISION
Future Barcroft Distribution System (Initial
Vision)
6
BARCROFT DEMAND DATA
7
POWER MONITORING SUMMARY

• AVERAGE DEMAND SUMMARY (kW)

• Pace and large animal buildings consume more
  than 52 of the average power (and energy)
• Observatory consumes approximately 29 of the
  power and energy at Barcroft
• Remaining 19 goes to small animal and telescope
  buildings.

8
PV IMPACTS (SIMULATED)
9
PV IMPACTS (SIMULATED)

• Using demand data from September, simulations
  were performed analyzing the economic impacts of
  varying the installed PV capacity 5,10,15, and
  20kW

• Peak reduction benefit disappears for this month
  after 10kW of PV (peak occurring with no solar
  power available is maintained)
• - cost of peak demand is 5.40/kW during winter
  (savings 36/month), and 13.15/kW during summer
  (June September savings 87/month)

10

• Wind Power at WMRS

11
The Turbines
Rotor Diameter 2 m Rotor Height 3 m Hub Height
7.5 m
Rotor Diameter 19 m Hub Height 30 m
Rotor Diameter 33.4 m Hub Height 50 m
Rotor Diameter 6.7 m Hub Height 18 m
12
Observatory Wind Resource
Data span (days) 20
Maximum velocity (m/s) 20.4
Average velocity (m/s) 4.1
Turbine availability 46
13
Wind Power for Observatory
14
Wind Power for Barcroft
15
Wind Energy Analysis
Observatory 5 kW Turby 10 kW BWC 20 kW BWC 100 kW NPS 330 kW Enercon
Total wind energy produced (kWh) 252 420 840 5,195 21,443
Total observatory energy consumed (kWh) 1,989 1,989 1,989 1,989 1,989
Percent load met 13 21 42 261 1078
Net metering credits (kWh) n/a n/a n/a 3,206 19,454

Total Barcroft
Total wind energy produced (kWh) 252 420 840 5,195 21,443
Total barcroft energy consumed (kWh) 6,636 6,636 6,636 6,636 6,636
Percent load met 4 6 13 78 323
Net metering credits (kWh) n/a n/a n/a n/a 14,807
16

• Proposed Barcroft Heating Strategy

17
Winter Heating Simulation
POWER MARKET
  kWh Btu Btu/hr
Energy Consumed during Simulation 65.9 224,898 62,662
18
System Configuration
Munchkin Boilers
19
Baseboard Heating
20
FUTURE WORK

• Complete analyses of generation technologies
• Investigate interconnection issues
• Install infrastructure for future heating and
  generation installations
• Get funding to make it happen!
