Title: Radiographic Interpretation


1
Radiographic Interpretation
Whats Normal?
Bucky Boaz, ARNP
2
(No Transcript)
3
Cervical Spine (Lateral)
  • Anterior arch of the atlas?
  • Dens of axis
  • Posterior arch of the atlas?
  • Soft palate
  • Root of the tongue?
  • Transverse process?
  • Intervertebral disc?
  • Inferior articular process?
  • Superior articular process?
  • Zygapophyseal (facet) joint?
  • Spinous process of C7
  • 2nd-7th The bodies of 2nd to 7th cervical
    vertebrae

4
Lateral Cervical Spine
5
Anterior soft tissue swelling
  • soft tissue swelling is indirect indicator of
    significant trauma, esp. when the soft tissue
    swelling is above the epiglottis
  • retropharyngeal soft tissue swelling should not
    exceed
  • anterior to C3 should not exceed 3 mm.
  • if gt than 5 mm at C3 consider minimally displaced
    C2 fracture
  • w/ children, crying increases the C3 distance
  • below C4 the thickness varies from 8 to 10 mm
    is less reliable

6
Anterior soft tissue swelling
  • distance between tracheal air column anterior
    aspect of vertebral body should be No greater
    than
  • Adults no gt than 7 mm at C2 or 22 mm at C6
  • Child no gt than 14 mm at C6
  • during x-ray child should be in neutral or sl
    extension and w/ a full inspiration
  • fullness and laxity of child's prevertbral soft
    tissues may simulate traumatic swelling if film
    is obtained during expiration or flexion

7
Spinal Laminal Lines
  • Three curves to follow
  • Anterior aspect of vertebral bodies
  • Posterior aspect of vertebral bodies
  • Spinolaminar line
  • Abnormalities in the curves
  • posterior malalignment is more significant than
    anterior because of proximity of the spinal cord
  • spinal canal diameter is significantly narrowed
    if lt 14 mm
  • anterior subluxation is caused by facet
    dislocation
  • lt 50 of vertebral body width unilateral
    dislocation
  • gt 50 of vertebral body width bilateral
    dislocation

8
Lateral Findings
  • Examine bones for symmetry
  • May provide evidence of fracture
  • Abnormal symmetry is often due to compression
  • compression of gt 40 of normal vertebral body
    height usually indicates a burst fracture with
    possibility of bone fragments in the spinal canal
  • anterior compression may cause a teardrop shaped
    fracture

9
Cervical Spine (Lateral)
  • Bifid spinous process of C3?
  • Superimposed articular processes?
  • Uncinate processes?
  • Air filled trachea?
  • Transverse process of C7?
  • Transverse process of T1?
  • 1st rib?
  • Clavicle
  • 4th-7th The bodies of 4th to 7th cervical
    vertebrae

10
AP Cervical Spine
11
Odontoid View
  • to evaluate
  • C1 (Jefferson), Dens, superior facets of C2
  • for evaluating dens fractures, body of C2,
    rotary C1-C2 dislocations
  • mach lines - teeth, C1 arch
  • open mouth view, along w/ lateral view, will
    reveal fractures of the dens
  • atlantoaxial articulation integrity of dens and
    body of C2 are best seen on the odontoid view

12
Odontoid View
  • this is most technically most difficult film to
    obtain as it requires patient to open his mouth
    as wide as possible
  • lateral masses of C1 should align over the
    lateral masses of C2
  • lateral displacement of masses of C1 w/ respect
    to C2 may indicate Jefferson or burst fracture of
    the Atlas
  • combined lateral mass displacement gt 7 mm
    suggests that transverse ligament is torn

13
Anatomy of C2
  • C2 provides rotation at its superior articulation
    w/ C1, limited flexion, tilt, rotation at its
    inferior articulation w/ C3
  • body of C2 is the largest of the cervical
    vertebrae
  • superior articulations are on the lateral masses
  • superior projection of the odontoid is stabilized
    to the C1 ring by transverse and alar ligaments

14
Anatomy of C2
  • lateral masses of C2 have aperture for accepting
    transversing vertebral artery
  • axis is transverse vertebra w/ its superior
    articular facets located anterior and its
    inferior facets located posterior
  • prominent spinous process of C2 is palpable
    beneath of occiput

15
Odontoid
16
Thoracic Vertebra
  • Each vertebra is composed of a body anteriorly
    and a neural arch posteriorly
  • The arch encloses an opening, the vertebral
    foramen, which helps to form a canal in which the
    spinal cord is housed.
  • Protruding from the posterior extreme of each
    neural arch is a spinous process and extending
    from the lateral edges of each arch are
    transverse processes.
  • The parts of the neural arch between the spinous
    and transverse processes are known as the laminae
    and the parts of the arch between the transverse
    processes and the body are the pedicles.
  • At the point where the laminae and pedicles meet,
    each vertebra contains two superior articular
    facets and two inferior articular facets.
  • The pedicle of each vertebra is notched at its
    superior and inferior edges. Together the notches
    from two contiguous vertebra form an opening, the
    intervertebral foramen, through which spinal
    nerves pass

17
Thoracic Spine
  • Spinous process
  • Pedicles
  • Intervertebral disc space
  • Ribs
  • Vertebral body
  • Neural foramen

18
Lumbar Vertebra
  • Lumbar vertebrae are characterized by massive
    bodies and robust spinous and transverse
    processes.
  • Their articular facets are oriented somewhat
    parasagittally, which is thought to contribute
    the large range of anteroposterior bending
    possible between lumbar vertebrae.
  • Lumbar vertebrae also contain small mammillary
    and accessory processes on their bodies.
  • These bony protuberances are sites of attachment
    of deep back muscles

19
Lateral Lumbar Spine
20
Lateral Lumber Spine
21
AP Lumbar Spine
22
Vertebral Fractures
23
Pelvis
24
AP Pelvis
  1. Lateral part of the sacrum
  2. Gas in colon
  3. Ilium
  4. Sacroiliac joint
  5. Ischial spine
  6. Superior ramus of pubis
  7. Inferior ramus of pubis
  8. Ischial tuberosity
  9. Obturator foramen
  10. Intertrochanteric crest
  11. Pubic symphysis
  • Pubic tubercle
  • Lesser trochanter
  • Neck of femur
  • Greater trochanter
  • Head of femur
  • Acetabular fossa
  • Anterior inferior iliac spine
  • Anterior superior iliac spine
  • Posterior inferior iliac spine
  • Posterior superior iliac spine
  • Iliac crest

25
AP Hip
  1. Anterior superior iliac spine
  2. Ilium
  3. Anterior inferior iliac spine
  4. Pelvic brim
  5. Acetabular fossa
  6. Head of femur
  7. Fovea
  8. Superior ramus of pubis
  9. Obturator foramen
  10. Inferior ramus of pubis
  11. Pubic symphysis
  12. Ischium
  13. Lesser trochanter
  14. Intertrochanteric crest
  15. Greater trochanter
  16. Neck of femur

26
Lateral Hip
  1. Greater trochanter
  2. Intertrochanteric crest
  3. Lesser trochanter
  4. Neck of femur
  5. Head of femur
  6. Acetabular fossa
  7. Superior ramus of pubis
  8. Obturator foramen
  9. Inferior ramus of pubis
  10. Ischium

27
AP Knee
  1. Femur
  2. Patella
  3. Medial epicondyle of femur
  4. Lateral epicondyle of femur
  5. Medial condyle of femur
  6. Lateral condyle of femur
  7. Intercondylar eminence
  8. Intercondylar notch
  9. Knee joint
  10. Lateral condyle of tibia
  11. Medial condyle of tibia
  12. Tibia
  13. Fibula

28
Lateral Knee
  1. Femur
  2. Lateral condyle of femur
  3. Medial condyle of femur
  4. Fabella
  5. Patella
  6. Base of patella
  7. Apex of patella
  8. Intercondylar eminence
  9. Apex of fibula
  10. Fibula
  11. Tibia
  12. Tibial tuberosity

29
AP Ankle
  1. Fibula
  2. Tibia
  3. Distal tibiofibular joint
  4. Malleolar fossa
  5. Lateral malleolus
  6. Ankle joint
  7. Medial malleolus
  8. Talus

30
Lateral Ankle
  1. Fibula
  2. Tibia
  3. Ankle joint
  4. Promontory of tibia
  5. Trochlear surface of talus
  6. Talus
  7. Posterior tubercle of talus
  8. Calcaneus
  9. Sustentaculum tali
  10. Tarsal tunnel
  11. Navicular
  12. Cuneiforms
  13. Cuboid

31
Talar Dome
  • The talar dome should be scrutinised for a subtle
    indentation of the joint surface, or a small
    detached fragment.
  • This is evidence of an osteochondral fracture.
  • May be subtle, is often missed, but this injury
    is clinically significant.

32
(No Transcript)
33
Boehlers Angle
  • Compressive fractures occur after a fall from a
    height.
  • Subtle fractures may only be identified by
    assessing Boehlers angle.
  • This angle is measured by drawing a line from the
    highest point of the posterior tuberosity to the
    highest midpoint, and a 2nd line from the highest
    midpoint to the highest point of the anterior
    process.
  • The angle, posteriorly, should be gt30 degrees.
  • If there is flattening of the bone due to a
    fracture, this angle will be decreased, to lt30
    degrees.

34
Boehlers Angle
35
AP Foot
  • A-E Toes 1-5. (AGreat toe)?
  • I-V. Metatarsals
  • 1,3. Distal phalax?
  • 4. Middle phalax?
  • 2,5. Proximal phalax
  • Interphalangeal joints
  • Metatarsophalangeal joints
  • Sesamoids
  • Head of metatarsal
  • Shaft (body) of metatarsal
  • Base of metatarsal
  • Cuneiform
  • Navicular
  • Cuboid
  • Talus
  • Calcaneus
  • Tibia
  • Fibula
  • Tarsometatarsal joints
  • Transverse midtarsal joint

36
Oblique Foot
  • Base of metatarsal
  • Cuneiforms
  • Navicular
  • Cuboid
  • Talus
  • Calcaneus
  • Tibia
  • Fibula
  • Tarsometatarsal joints
  • Transverse midtarsal joint
  • A-E Toes 1-5. (AGreat toe)
  • 1,3. Distal phalax?
  • Middle phalax?
  • 2,5. Proximal phalax
  • Interphalangeal joints
  • Metatarsophalangeal joints
  • Sesamoids
  • Head of metatarsal
  • Shaft (body) of metatarsal

37
AP Foot
38
Oblique Foot
39
Lateral Foot
40
Lisfranc
41
Lisfranc
42
AP Shoulder
  1. Clavicle
  2. Acromioclavicular joint
  3. Acromion
  4. Greater tubercle of humerus
  5. Head of humerus
  6. Lesser tubercle of humerus
  7. Surgical neck of humerus
  8. Coracoid process
  9. Glenoid fossa
  10. Shoulder joint
  11. Lateral border of scapula

43
AP Elbow
  1. Lateral supracondylar ridge
  2. Medial supracondylar ridge
  3. Olecranon fossa
  4. Medial epicondyle
  5. Lateral epicondyle
  6. Capitulum
  7. Olecranon
  8. Trochlea
  9. Coronoid process of ulna
  10. Proximal radioulnar joint
  11. Head of radius
  12. Neck of radius
  13. Tuberosity of radius
  14. Ulna

44
Lateral Elbow
  1. Supracondylar ridge
  2. Trochlea
  3. Olecranon
  4. Trochlear notch
  5. Coronoid process of ulna
  6. Head of radius
  7. Neck of radius
  8. Tuberosity of radius
  9. Ulna

45
PA Wrist
  • I-V Metacarpals
  • Trapezium
  • Trapezoid
  • Capitate
  • Head of capitate
  • Hamate
  • Hook of hamate
  • Scaphoid
  • Lunate
  • Triquetrum
  • Pisiform
  • Styloid process of radius
  • Head of ulna
  • Styloid process of ulna
  • Radiocarpal joint
  • Distal radioulnar joint

46
Lateral Wrist
  1. 1st metacarpal
  2. Metacarpals II-V
  3. Trapezium
  4. Tubercle of scaphoid
  5. Lunate
  6. Triquetrum
  7. Radiocarpal joint
  8. Distal end of radius
  9. Distal end of ulna

47
Rule of 11s
  • Radial length or height
  • Radial length is measured on the PA radiograph as
    the distance between one line perpendicular to
    the long axis of the radius passing through the
    distal tip of the radial styloid. ?
  • A second line intersects distal articular surface
    of ulnar head. ?
  • This measurement averages 10-13 mm.

48
Rule of 11s
  • Radial inclination or angle?
  • Radial inclination represents the angle between
    one line connecting the radial styloid tip and
    the ulnar aspect of the distal radius and a
    second line perpendicular to the longitudinal
    axis of the radius. ?
  • The radial inclination ranges between 21? and
    25?. ?Loss of radial inclination will increase
    the load across the lunate.

49
Rule of 11s
  • Radial tilt?
  • Radial tilt is measured on a lateral radiograph.
    ?
  • The radial tilt represents the angle between a
    line along the distal radial articular surface
    and the line perpendicular to the longitudinal
    axis of the radius at the joint margin.
  • The normal volar tilt averages 11? and has a
    range of 2?-20?.

50
PA Hand
  • Thumb?
  • Index
  • Middle finger
  • Ring finger
  • Little finger
  • I-V. Metacarpal bones
  • 1,4. Distal phalanx?
  • Middle phalanx?
  • 3,5. Proximal phalanx?
  • Sesamoid bones
  • Distal interphalangeal joint (DIP)
  • Proximal interphalangeal joint (PIP)?
  1. Metacarpophalangeal joint (V.)
  2. Carpometacarpal joints
  3. Trapezium
  4. Trapezoid
  5. Capitate
  6. Hamate
  7. Scaphoid
  8. Lunate
  9. Triquetrum
  10. Pisiform
  11. Radius
  12. Ulna

51
QUESTIONS?
Write a Comment
User Comments (0)
About PowerShow.com
