Accessing the Genome

1
Accessing the Genome
2
Outline

• 8.1. Inside the Nucleus
• 8.2. Chromatin Modifications and Genome
  Expression

3
Inside the Nucleus

• The internal architecture of the eukaryotic
  nucleus
• Chromatin domains

4
The internal architecture of the eukaryotic
nucleus(1/3)

• Two novel types of microscopy analysis
• Electron microscopy
• Fluorescent microscopy

5
The internal architecture of the eukaryotic
nucleus(2/3)

• Electron microscopy

 image analysis3D restructuring of
images          three types of electron
microscopy                TEM  -
Transmission               SEM  -  Scanning
                 FEM  -  Freeze Fracture
6
                                                          Only, killed, fixed, and sectioned specimens          (no living cells) may be viewed. Lens are electromagnets that focus high velocity e's


7
FEM
8
FEM  -  Freeze Fracture
9
FEM  -  Freeze Fracture
10
The internal architecture of the eukaryotic
nucleus(1/3)

• Two novel types of microscopy analysis
• Electron microscopy
• Fluorescent microscopy

11
The internal architecture of the eukaryotic
nucleus(3/3)

• Fluorescent microscopy
• Fluorescence recovery after photobleaching

12
Chromatin domain(1/2)

• Chromatin structure

• Domains on chromatin
• LCR locus control region
• 2. MAR matrix attachment regions
• 3. delimiter or scs (specialized chromatin
  structures)
• - prevent effects from spreading beyound the
• functional unit

13
Chromatin domain(2/2)

• Two types of heterochromatin
• Constitutive (???) heterochromatin
• Facultative (???) heterochromatin

14
Heterochromatin(1/4)

• Constitutive heterochromatin
• permanent feature of all cells
• includes centromeric and telomeric DNA
• ExampleY chromosome

15
Heterochromatin(2/4)

• Facultative heterochromatin
• Not a permanent feature
• Contain genes that are inactive

16
Heterochromatin(3/4)

• Euchromatin
• Matrix-associated regions (MARs) or Scaffold
  attachment regions (SARs)

• Euchromatin and Heterochromatin
• ???????????(euchromatin)?????(heterochromatin)???

• ??????????,??????????????,????,
• ???????
• 2. ?????????????????????,??????????????,
• ????????????????????

17
Heterochromatin(4/4)
18
(No Transcript)
19
Structural domain and Functional domain

• Structural domains
• Functional domains

20
Insulators(??)(1/3)

• The boundaries of functional domains are marked
  by sequences
• scs and scs

21
Insulators(2/3)

• Two special properties
• Overcome the positional effect
• Gene no longer responds to its regulatory
  modules
• Su(Hw)

22
Insulators(3/3)
23
Functional domains contain locus control
regions(1/2)

• Locus control region (LCR)
• Discovered during a study of the human -globin
  genes

24
Functional domains contain locus control
regions(2/2)

• -globin LCR has shown that it contains five
  separate DNase I hypersensitive sites

25
Activating the genome

• Histone modifications determine chromatin
  structure
• Nucleosome remodeling influences the expression
  of individual genes

26
Histone modifications influence chromatin
structure

• Acetylation
• Deacetylation
• Phosphorylation
• Ubiquitination
• Ubiquitin
• Methylation

27
Acetylation

• Histone acetylation reduces the affinity of the
  histones for DNA
• Histone acetyltransferases (HATs)
• Tetrahymena(???)protein---p55
• Mammalian protein---p300/CBP

28
Deacetylation

• Reversing the activating effects of histone
  acetylation
• Histone deacetylases (HDACs)
• mammalian Sin3 complex
• yeast Sir2

29
Histone acetylation is catalyzed by histone
acetyltransferases (HATs)
and histone deacetylation is catalyzed by
histone deacetylases (denoted by HDs or HDACs).
30
Nucleosome remodeling

• Nucleosome remodeling
• Remodeling
• Sliding(cis-displacement)
• Transfer(trans-displacement )

31
Genome silencing by DNA methylation

• DNA methylation can repress gene activity
  (Cytosine methylation)
• DNA methyltransferase
• The methylation pattern is not random
• in higher eukaryotes5 CG 3
• in plants5 CNG 3

32
DNA Methylation

• DNA methylation is the addition of a methyl group
  (CH3) to the DNA's cytosine base.
• It may affect gene transcription through several
  different mechanisms .
• Therefore, DNA methylation plays an important
  role in cell differentiation during development

33
(No Transcript)
34
Methylation

• Maintenance methylation
• the methylation pattern is maintained after
  cell division
• De novo methylation

35
CpG island

• In humans40-50 of all genes are located close
  to CpG islands
• CpG island reflecting the expression pattern of
  the adjacent gene

36
How methylation influences genome expression

• Methyl-CpG-binding proteins(MeCPs)

37
Methylation is involved in imprinting and X
inactivation

• DNA methylation and genome silencing is provided
  by two intriguing phenomena
• genomic imprinting
• X inactivation

38
Genomic imprinting

• Only one of a pair of genes, present on
  homologous chromosomes in a diploid nucleus, is
  expressed
• The second being silenced by methylation

???????????????????????????, ???????????(turn
on)??? ??????????,????????????????? ??????????????
,????????,??????? ??????????????????????????????
,??????????????
39
Genomic imprinting
40
?????????????DNA??????(methyl group),?????? ???(me
thylation),???????????turn off????, ??????????????
????????,?????????? ??????? ???????????????????,?
????????????? ??????????????????
(imprinting),????????? ????????(turn
off)????????????????? (???????????????? ?????),?
??????????????,????????,?????????????,??????????
?????, ???????
41
?????????1. Prader-Willi syndrome (PWS,
??-????)??????????15?q arm??????????,?????? ?????
???,?????2. Angelman syndrome (AS,
?????)????????????15?q arm????????,?????? ???????
?,?????3. Fragile X syndrome (???X????)X???????
?????? (CGG) ???????????,??? ?????????????????????
,??????? ??????,?????X?????????,?X????????? ??????
,????????????X????????, ?????,?????????????,????
(??????)?
42
X inactivation

• One of the X chromosomes in a female mammalian
  cell
• Condensed X chromosomes structure called the Barr
  body
