1IMPROVEMENTS IN NUMERICAL PREDICTION OF LOW LEVEL
WINDS
2Motivation
- U.S. Department of Energy (DOE) goal of having
20 of the nations electrical energy from wind
by 2030 - DOE workshop report states 1 error in wind
speed estimates for a 100-MW wind generation
facility can lead to losses approaching
12,000,000 over the lifetime of that plant ..."
- To optimize wind for power generation, accurate
weather forecasts are needed - Better weather forecasts lead to greater
confidence and more reliance on wind energy as a
reliable energy source
3Wind Speed Forecasting Background
- Typically, weather forecasting done for
precipitation and temperature, not wind until
recently - Meteorologists traditionally have focused wind
forecasts at the 10 m level, a height strongly
influenced by surface friction - Prior wind forecasting research in the western
United States has focused on flow in complex
terrain (e.g. Wood 2000, Ayotte et al. 2001) - Not applicable in Iowa where low-level jets and
changing surface conditions are likely to be the
dominant factors - Statistical approach to predict wind speed at
different levels (Huang et al. 1996, Kamal et al.
1997) time series analysis
4Problem Statement
- With the increased growth in the wind energy
sector, wind speed forecasts at turbine hub
height (80 m) are now needed - Due to the lack of observations, validating
forecasts at this height has been difficult and
little attention has been paid to wind forecasts
at 80 m in the meteorological community - In this study, an ensemble was created based on
six different ways to represent drag as well as
other forecasting techniques to improve wind
speed forecasting at 80 m
5PBL Scheme
Fd(z,t)
V
6PBL Parameterizations Different Ways to
Represent Drag
- PBL schemes were developed to help resolve the
turbulent fluxes in the boundary layer aka the
drag force - Due to the complex nature of boundary layer, very
difficult to model changes diurnally and
seasonally - Smaller BL in winter snow pack
- To parameterize the planetary boundary layer -
both local and non-local parameterizations are
used - Local closure - estimates unknown fluxes using
known values and/or gradients at the same point
(Stull 1988) - Non-local closure - estimates unknown fluxes
using known values and/or gradients at many
points in space (Stull 1988)
7Model Domain
- Weather forecast model tested
- Weather Research and Forecasting (WRF) model
- Model Forecast Period
- 54 hour forecasts first 6 hours not used -
model spin-up - Six different ways to Represent Drag Force
- Yonsei University Scheme (YSU) - WRF
- Mellor-Yamada-Janjic (MYJ) - WRF
- Quasi-Normal Scale Elimination PBL (QNSE) -
WRF - Mellor-Yamada Nakanishi and Niino Level 2.5
PBL (MYNN2.5) - WRF - Mellor-Yamada Nakanishi and Niino Level 3.0
PBL (MYNN3.0) - WRF - Pleim PBL scheme (also called Asymmetric
Convective Model (ACM2)) WRF
Pomeroy Iowa Wind Farm
8Model Specifics
- Driving model (Initial and lateral boundary
conditions) - Regional and Global models that
provide data to limited domain used in the WRF - Global Forecast System (GFS)
- North American Model (NAM)
- Observation data
- 80 m meteorological tower on the southwest side
of the Pomeroy, Iowa wind farm - Data was taken at 10 minute increments and
averaged over one hour periods centered on each
hour to match model output - Evaluation period
- From June 2008 through September 2010, excluding
periods where missing data was observed
9(No Transcript)
10Pre-Run Modification
MAE of three different GFS perturbations using
the YSU and MYNN3.0 PBL schemes from 10 cases in
January 2010
Perturbation Number GFS MYNN 3.0 MAE ( ms-1) GFS YSU MAE ( ms-1) Ensemble MAE ( ms-1)
2 2.34 2.06 2.05
4 2.18 2.04 1.98
15 2.27 2.18 2.08
Ensemble - best model skill
MAE associated with the wind speed at 80 m from
three different initialization times from 10
cases in January 2010
Time Initialization GFS MYNN 3.0 MAE ( ms-1) GFS YSU MAE ( ms-1) Ensemble MAE ( ms-1)
18 UTC 1.88 1.78 1.69
00 UTC 1.82 1.74 1.63
06 UTC 1.83 2.07 1.73
Time Initialization - Higher model skill (lower
MAE) than Perturbations
11Day Ahead Market
Midnight
Noon
Noon
12Day Ahead Market
Midnight
Noon
Noon
13Larger the model spread less confidence in
forecast
Day Ahead Market
Midnight
Noon
Noon
14Day Ahead Market
Midnight
Noon
Noon
15Day Ahead Market
Midnight
Noon
Noon
16Day Ahead Market
Noon
Noon
Midnight
17Pre-Run Modification Cont.
Highest Model skill associated with 10 km grid
spacing
Computing power limited in most private
companies, running 10 km model runs are much more
feasible than 4 km runs
Grid Spacing GFS MYNN 3.0 MAE ( ms-1) GFS YSU MAE ( ms-1) Ensemble MAE ( ms-1)
10 km 1.82 1.74 1.63
4 km 2.16 1.79 1.73
MAE of wind speed at 80 m from two different grid
spacings (4 km and 10 km) from 10 cases in
January 2010
18Day Ahead Market
Midnight
Noon
Noon
19Similar model skill with terrain effects, like
mountains results would be much different
Day Ahead Market
Midnight
Noon
Noon
20Post-Processing
Training of the model based on day 1 results 15
cases from June 2008 to May 2009
Model Number
00 UTC MYJ GFS - 10 km grid spacing
00 UTC MYJ NAM - 10 km grid spacing
00 UTC Pleim NAM - 10 km grid spacing
00 UTC Pleim GFS - 10 km grid spacing
00 UTC YSU NAM - 10 km grid spacing
00 UTC YSU GFS - 10 km grid spacing
Day 2 Picked ensemble best MAE Day 2 Non-Picked ensemble best MAE Day 2 All Member Ensemble best MAE
5/15 4/15 6/15
Training approach was not a reliable method to
predict wind speed as conditions change from day
to day
Picked Ensemble showed best model skill only
33 of time
Non-Picked Ensemble showed best model skill 27
of time
21Bias Correction of the Model
- Bias corrections developed from 30 cases (all
seasons) from June 2008 to Jan. 2010 - Applied to Case study from Oct. 11, 2009 to Nov.
11, 2009 - Wind Speed bias correction seen as best way to
improve forecast (green box) - Non bias correction showed worst results (red box)
22Day Ahead Market
Model over-prediction Nighttime
Model under-prediction Daytime
Noon
Noon
Midnight
23Operational Model Development
MAE MYJ (m/s) MYNN 2.5 (m/s) MYNN 3.0 (m/s) Pleim (m/s) QNSE (m/s) YSU (m/s) Ensemble (m/s)
GFS 00Z 1.59 1.66 1.66 1.52 1.65 1.57 1.48
GFS 18Z 1.68 1.81 1.72 1.61 1.77 1.63 1.58
NAM 00Z 1.67 1.71 1.69 1.63 1.71 1.57 1.56
NAM 18Z 1.66 1.75 1.74 1.60 1.70 1.63 1.57
Green boxes show highest model skill
- Bias corrections for 00Z and 18Z time
initializations and NAM and GFS initial boundary
conditions over a period from Aug. 14-28, 2009 - Six schemes that showed best model skill (lowest
MAE) formed operational model
Member Number PBL Scheme Time Initialization Land Surface Scheme Land Layer Scheme Initial Boundary Conditions
1 ACM2 18 UTC Pleim-Xiu Pleim-Xiu GFS
2 ACM2 18 UTC Pleim-Xiu Pleim-Xiu NAM
3 ACM2 00 UTC Pleim-Xiu Pleim-Xiu GFS
4 YSU 00 UTC Noah Monin-Obukhov NAM
5 YSU 00 UTC Noah Monin-Obukhov GFS
6 MYJ 00 UTC Noah Janjic Eta Monin-Obukhov GFS
- Five out of six scheme either YSU or Pleim both
non-local turbulent closure schemes - Four out of six scheme use the 00Z time
initialization - Four out of six scheme use the GFS initial
boundary conditions
24Operational Model Results
Ensemble MAE after Bias Correction (m/s) MAE Prior to Bias Correction (m/s) Standard Deviation after Correction (m/s)
GFS 00Z 1.67 1.99 0.74
GFS 18Z 1.66 2.05 0.80
NAM 00Z 1.68 1.91 0.67
NAM 18Z 1.70 1.93 0.73
Deterministic Forecast 1.70 1.77 - - -
Operational Model 1.52 1.67 0.98
- Tested over 25 cases during the summer and fall
of 2010 - Best model skill seen in Operational Model after
wind speed bias correction (Green Box) - Largest standard deviation (measure of model
spread) in operation model ensemble - Deterministic forecast is the best individual
model found from the period studied
25Ramp Events
Sensitive Area Ramp events not important above
or below this area
- Ramp event - changes in wind power of 50 or
more of total capacity in four hours or less
(Greaves et al. 2009) - Approximated using a typical wind turbine power
curve such that any wind speed increase or
decrease of more than 3 ms-1 within the 6-12 ms-1
window in four hours or less was considered a
ramp - Fifty eight cases spanning 116 days from June
2008 through June 2009 were validated Models
all used GFS initial boundary conditions
26Ramp Event Results
Event was considered a ramp event if change in
wind power was 50 or more of total capacity in
four hours or less - wind speed increase or
decrease of more than 3 m/s within the 6-12 m/s
PBL Scheme MYJ MYNN 2.5 MYNN 3.0 Pleim QNSE YSU Obs
Ramp-up 23 29 27 19 26 16 35
Ramp-down 23 28 21 14 28 13 31
Total Ramp Events 46 57 48 33 54 29 66
All PBL schemes under-predict number of ramp
events
Number of ramp events during Day 1 for GFS
initial boundary conditions (06-30 hours after
model start up)
PBL Scheme MYJ MYNN 2.5 MYNN 3.0 Pleim QNSE YSU Obs
Ramp-up 17 25 24 17 26 11 37
Ramp-down 19 22 16 20 23 11 35
Total Ramp Events 36 47 40 37 49 22 72
Fewer Ramp events forecasted on Day 2
Number of ramp events during Day 2 for GFS
initial boundary conditions (30-54 hours after
model start up)
27Ramp Events Results Cont.
Average amplitude of ramp up and ramp down events
for GFS initial boundary conditions
PBL Scheme MYJ (ms-1) MYNN 2.5 (ms-1) MYNN 3.0 (ms-1) Pleim (ms-1) QNSE (ms-1) YSU (ms-1) Obs (ms-1)
Ramp-up (Day 1) 4.50 4.62 4.75 4.85 4.60 4.67 4.53
Ramp-up (Day 2) 4.54 5.16 5.2 4.56 4.69 4.73 4.01
Ramp-down (Day 1) 3.74 4.62 4.20 4.60 4.31 4.17 4.34
Ramp-down (Day 2) 3.83 4.28 4.46 4.27 4.59 4.43 4.21
- Amplitude was over-predicted by all six PBL
schemes for ramp-up events - Obs. show on average over 4m/s ramp event
- If ramp-up event occurred at 6m/s and went to
10m/s within 4hrs - Power increase from 216 kW to 1000 kW
28Sensitive Area Ramp events not important above
or below this area
29- Three hour averaged diurnal cycle of ramp-up
events using the midpoint of the ramp event - Peak at 01Z LLJ related
- Peak at 16Z Growth of BL
- Three hour averaged diurnal cycle of ramp-down
events using the midpoint of the ramp event - Less noticeable trend
30Summary of Results
- To forecast winds, we have focused on drag (six
different schemes) - However, explored other methods to improve
forecasts - Perturbations of GFS model
- Low skill
- Varied Time Initializations
- High skill
- Grid Spacing
- Little difference as terrain is flat less
computing power with 10km - Training of the Model
- Not a reliable method as conditions change from
day to day - Bias Correction
- Noticed a diurnal bias in the model data
- Investigated whether other biases existed wind
speed bias correction - Combination of techniques yields a model that is
significantly more skillful
31Summary of Results
- All six PBL schemes tested underestimated the
number of ramp-up and ramp-down events - Average ramp-up events around 4m/s increase
- Increase in power produced from 216 kW to 1000 kW
- For example, caused a blackout in Texas
- Modeled ramp-up events occurred most often
between 22 UTC and 01 UTC - closely matched
observed ramp-up events (occurred most frequently
around 01 UTC)
32Great Plains Low Level Jet (LLJ)
- LLJs - first described in the late 1930s by
Goualt (1938) and Farquharson (1939) - Areas of relatively fast-moving winds in the
lower atmosphere, LLJs were first studied because
of their roll in transporting warm, moist air
from the Gulf of Mexico into the Great Plains,
leading to convective events (Stensrud 1996) - Most well-known LLJs occur over the Great Plains
of the United States, although found around the
world - Europe, Africa, and Australia (Stensrud
1996) - Maximum winds during nocturnal LLJ events over
the Great Plains are between 10 ms-1 and 30 ms-1
(Whiteman et al. 1997)
33Great Plains LLJ Cont.
- Whiteman (1997) classified two years of LLJs in
northern Oklahoma and discovered that LLJs occur - 47 of the time during the warm season
- 45 of the time during the cold season
- Whiteman (1997) found approximately 50 of the
maximum wind speeds during LLJ events occurred
less than 500 m above the surface - With the potential for wind turbine hub heights
to increase from 80 m to 120 m or higher, LLJ
interaction with wind turbines could largely
affect the power performance of wind farms
(Schwartz and Elliot, 2005).
34Problem Statement
- Few studies have examined the performance of
forecasting models during LLJ events, or the
sensitivity to how surface drag is represented in
models - In this study, the ability of the WRF model to
accurately reproduce vertical wind structure
during LLJ events was evaluated using six
different drag schemes in the WRF model to
observations from the Lamont, OK wind profiler
site
35Observed Data Location
- Observed data from the U. S. Department of Energy
ARM project located at Lamont, OK. - 915-MHz wind profiler - measure wind speeds below
500 m, unlike the NOAA 404-MHz profilers - Observed data ranged from 96 m - 2462 m above the
surface vertical resolution of 60 m - 30 LLJ cases and 30 non-LLJ cases were chosen
between June 2008 and May 2010 - Same forecasts model was used as in Pomeroy
different dates, different heights evaluated,
different location
36LLJ Maximum Wind Speeds
All PBL schemes under-predict max LLJ wind speed
Average Maximum LLJ Wind Speed over 30 LLJ events
for GFS initial boundary conditions
MYJ (ms-1) Pleim (ms-1) YSU (ms-1) QNSE (ms-1) MYNN 2.5 (ms-1) MYNN 3.0 (ms-1) OBS (ms-1)
Maximum LLJ Wind Speed 19.0 18.2 16.3 19.1 18.2 17.9 22.7
Lowest predicted max LLJ wind speed occurred in
YSU scheme
P-values of the YSU PBL scheme vs. other PBL
schemes for maximum LLJ wind speed
Null hypothesis was rejected in favor of the
alternative hypothesis, indicating that the
under-prediction of the wind speed in the YSU PBL
scheme was highly significant
Ho Ha Ho Ha Ho Ha Ho Ha Ho Ha Ho Ha
MYJ MYNN 2.5 MYNN 3.0 Pleim QNSE
P-value lt 0.0001 lt 0.0001 0.0002 lt 0.0001 lt 0.0001
Null hypothesis - difference between the maximum
LLJ wind speed of the YSU scheme (u1) will be
equal to the maximum LLJ wind speed of the other
PBL schemes (u2)
37Height of LLJ Maximum Wind Speed
All PBL schemes under-predict height of LLJ max
Average Maximum LLJ Wind Speed over 30 LLJ events
for GFS initial boundary conditions
MYJ (m) Pleim (m) YSU (m) QNSE (m) MYNN 2.5 (m) MYNN 3.0 (m) OBS (m)
Height of LLJ Maximum 371.2 427.0 538.3 344.5 365.3 340.3 553.0
Highest predicted height of LLJ max occurred in
YSU scheme
P-values of the YSU PBL scheme vs. other PBL
schemes for height of LLJ maximum
Null hypothesis was rejected in favor of the
alternative hypothesis, indicating that the
higher height predicted by the YSU PBL scheme was
highly significant
Ho Ha Ho Ha Ho Ha Ho Ha Ho Ha Ho Ha
MYJ MYNN 2.5 MYNN 3.0 Pleim QNSE
P-value lt 0.0001 0.0005 lt 0.0001 0.0007 0.0038
Null hypothesis - difference between the height
of LLJ maximum of the YSU scheme (u1) will be
equal to the height of the LLJ maximum of the
other PBL schemes (u2)
38June 26, 2008 LLJ Maximum
39LLJ Case Study March 24, 2009Wind Speed
Under-prediction of wind speed maximum in YSU
Scheme
LLJ structure not present in YSU scheme
LLJ feature present in all other PBL schemes
40Eddy Viscosity
YSU scheme - eddy viscosity value five times
larger than any other scheme
Larger eddy viscosity - more mixing and turbulence
Higher speeds occurred above and below the jet
core, with higher momentum air being mixed closer
to the surface resulting in substantially
weaker LLJ with a higher elevation of the maximum
41Occurrence of LLJ Maximum
- All six PBL schemes showed the maximum LLJ wind
speed occurring near or just after midnight - Observed maximum LLJ wind speeds occurred a
little later, with dual peaks at 08 UTC (2 am
LST) and 10 UTC (4 am LST) - Overall, the PBL schemes appeared to predict the
timing of the peak LLJ occurrence reasonably well
with perhaps a small early bias
42Influences on Wind Energy
96 m Wind speed 1.2 m/s stronger during LLJ
events power increase of 117 kW
LLJ vs. Non-LLJ event comparison
LLJ (ms-1) Non-LLJ (ms-1)
96 m Wind Speed 6.3 5.1
157 m Wind Speed 9.9 7.8
Speed Shear 5.58 2.91
157 m Wind speed 2.1 m/s stronger during LLJ
events power increase of 496 kW
Speed shear difference between 157 m and 96 m
wind speed - is almost double during LLJ events
- Number of kW to power an average home per day
50-70 kW - Speed shear is present at current hub height
(80m) - Project this summer will focus on speed shear
from 10m to 80m and from 40m to 120m (entire
reach of wind turbine blades)
4396 and 157 m Wind Speed
All six PBL schemes over-predicted the wind speed
during LLJ events
Bias and MAE associated with 96 m wind speed
forecasts during LLJ events for GFS initial
boundary conditions
96 m MYJ (ms-1) MYNN 2.5 (ms-1) MYNN 3.0 (ms-1) Pleim (ms-1) QNSE (ms-1) YSU (ms-1)
Wind Speed Bias 3.26 4.38 4.14 2.45 3.15 1.80
Wind Speed MAE 4.52 5.48 5.28 4.04 4.38 3.34
YSU scheme showed the lowest MAE, while the
highest was observed with the MYNN 2.5 scheme
All six PBL schemes over-predicted the wind speed
during LLJ events although YSU small positive
bias
Bias and MAE associated with 157 m wind speed
forecasts during LLJ events for GFS initial
boundary conditions
157 m MYJ (ms-1) MYNN 2.5 (ms-1) MYNN 3.0 (ms-1) Pleim (ms-1) QNSE (ms-1) YSU (ms-1)
Wind Speed Bias 3.20 3.66 3.40 1.87 3.15 0.15
Wind Speed MAE 3.80 3.94 3.69 3.14 3.72 2.09
YSU scheme showed the lowest MAE, while the
highest was observed with the MYNN 2.5 scheme
44Summary of Results - LLJ
- LLJ maximum wind speeds were under-predicted by
all PBL schemes - largest under-prediction
occurred with the YSU scheme larger drag
present - All the PBL schemes except the YSU scheme
under-predicted the height of the LLJ maximum by
more than 125 m - YSU scheme - likely cause of the under-predicted
wind speed and higher jet elevation - result of
the strong eddy viscosity occurring during stable
conditions - Increased mixing - LLJs in the YSU scheme were
substantially under-predicted and momentum was
spread out over a deeper layer of the atmosphere - Timing or temporal trends of the LLJ maximum -
models had wind speed maxima occurring near or
just after midnight (06-08 UTC), typically a few
hours before observed LLJs (08-10 UTC)
45Summary of Results - LLJ
- LLJ impacts at 96 m and 157 m - increased wind
speeds and speed shear during LLJ events compared
to non-LLJ events - Implies that wind production would increase
during LLJ events however, wind turbine
durability would need to be improved to
accommodate the increased shear - At 96 and 157 m, the YSU PBL scheme showed
significantly better skill (lower MAE) than the
other schemes
46General Conclusions
- Non-local PBL schemes appear to show better model
skill overall, however no one scheme is the
answer for predicting low level winds - Example - YSU
- High model skill at predicting 80 m wind speeds
- High model skill during LLJ events at 96 m and
157 m - Ramp events are poorly predicted
- LLJ max wind speeds are significantly
under-predicted - As a result, no one scheme performed
considerably better than any other and all showed
room for improvement.
47Questions?
48References
- Arribas A., K. B. Robertson, and K. R. Mylne,
2005 Test of a poor mans ensemble prediction
system for short-range probability forecasting.
Mon. Wea. Rev., 133, 18251839. - Ayotte, K.W., R.J. Davy and P.A. Coppin, 2001 A
simple temporal and spatial analysis of flow in
complex terrain in the context of wind energy
modeling. Bound.-Layer Meteorol., 98, 275295. - Bélair, Stéphane, Jocelyn Mailhot, J. Walter
Strapp, J. Ian MacPherson, 1999 An examination
of Local versus Nonlocal Aspects of a TKE-Based
Boundary Layer Scheme in Clear Convective
Conditions. J. Appl. Meteor., 38, 14991518. - Bowler, N. E., A. Arribas, and K. R. Mylne, 2008
The benefits of multianalysis and poor mans
ensembles. Mon. Wea. Rev., 136, 41134129. - Bradford, K. T., R. L. Carpenter, and B. Shaw,
2010 Forecasting Southern Plains wind ramp
events using the WRF model at 3km. Ninth Annual
Student Conference, Atlanta, GA, Amer. Meteor.
Soc., Available online at http//ams.confex.com/a
ms/90annual/techprogram/paper_166661.htm. - Dalcher, A., E. Kalnay, and R. N. Hoffman, 1988
Medium range lagged average forecasts. Mon. Wea.
Rev., 116, 402416. - Department of Energy, 2008 20 wind energy by
2030. Energy Efficiency and Renewable Energy Rep.
DOE/GO-102008-2567, 1-2. - Schreck, S, J. Lundquist, and W. Shaw, 2008 U.S.
Department of Energy Workshop ReportResearch
needs for wind resource characterization. NREL
Rep. TP-500-43521, 81-82. - Shin, H.H., S. Hong, 2011 Intercomparison of
Planetary Boundary-Layer Parametrizations in the
WRF Model for a Single Day from CASES-99.
Boundary-Layer Meteor., 139, 261-281. - Stensrud, David J., Jian-Wen Bao, Thomas T.
Warner, 2000 Using Initial Condition and Model
Physics Perturbations in Short-Range Ensemble
Simulations of Mesoscale Convective Systems. Mon.
Wea. Rev., 128, 20772107. - Stull, R.B., 1998 An Introduction to Boundary
Layer Meteorology. Boston, Massachusetts Kluwer
Academic Publishers. 197-242 pp. - Sukoriansky S, Galperin B, Perov V (2005)
Application of a new spectral theory of stable
stratified turbulence to the atmospheric boundary
layer over sea ice. Boundary-Layer Meteorol. 117,
231257. - Theis, S. E., A. Hense and U. Damrath, 2005
Probabilistic precipitation forecasts from a
deterministic model a pragmatic approach.
Meteorological Applications, 12, 257-268. - Walser, A., D. Lüthi, and C. Schär, 2004
Predictability of precipitation in a
cloud-resolving model. Mon. Wea. Rev., 132,
560577. - Wei, M., Z. Toth, R.Wobus, Y. Zhu, C. H. Bishop
and X. Wang 2006 Ensemble Transform Kalman
Filter-based ensemble perturbations in an
operational global prediction system at NCEP,
Tellus 58A, 28-44. - Whitaker, Jeffrey S., Andrew F. Loughe, 1998 The
Relationship between ensemble Spread and Ensemble
Mean Skill. Mon. Wea. Rev., 126, 32923302. - Wilks, D. S., 1995 Statistical Methods in the
Atmospheric Sciences. Academic Press, 467. - Wood, N., 2000 Wind flow over complex terrain A
historical perspective and the prospect for
large-eddy modeling. Bound.-Layer Meteor., 96,
1132. - Xiu, A., and J. E. Pleim, 2001 Development of a
land surface Model. Part I Application in a
mesoscale meteorological model. J. Appl. Meteor.,
40, 192209.
