Forensic Analysis of Glass

1
Chapter 5

• Forensic Analysis of Glass

2
Objectives

• Students should gain an understanding of
• The composition of different types of glass
• The optical and nonoptical properties of glass
• Techniques to determine the way in which glass
  has fractured
• Techniques to match glass fragments
• The use of scanning electron microscopy and X-ray
  fluorescence to determine the elemental
  composition of glass

3
Introduction

• Glass is often encountered in criminal
  investigations.
• Fragments may be found on a suspect as transfer
  evidence.
• Key considerations for investigators
• Which types of glass are found at the scene
• How glass fragments can be classified
• How to individualize glass fragments

4
Types of Glass (1 of 3)

• Glass is a solid with an amorphous structure its
  atoms have a random, disordered arrangement.
• Glass softens over a wide temperature range.
• Soda-lime glass is common in windows and bottles
• The addition of metal oxides can give a special
  appearance to glass.

5
Types of Glass (2 of 3)

• Tempered glass is four times stronger than window
  glass.
• Manufacture of tempered glass
• Hot glass is rolled into sheets.
• The upper and lower surfaces are cooled rapidly
  with jets of air.
• Tempered glass does not shatter it breaks into
  dices.

6
Types of Glass (3 of 3)

• Windshield glass is a kind of laminated glass.
• It consists of two layers of glass with
  high-strength vinyl plastic film in between the
  layers.
• The film holds the glass in place when it breaks.

7
Forensic Examination of Glass Evidence An
Overview (1 of 2)

• Goals in examining glass evidence
• Determine the class to which the glass belongs
• Individualize the glass to one source

8
Forensic Examination of Glass Evidence An
Overview (2 of 2)

• Two samples are needed for forensic analysis
• Glass from the crime scene
• Glass on items belonging to the suspect
• Compare characteristics of the samples
• Color, fracture pattern, scratches, striations
  from manufacturing, unevenness of thickness,
  surface wear, surface film or dirt, weathering
  patterns

9
Nonoptical Physical Properties of Glass (1 of 5)

• Nonoptical physical properties include the
  glasss surface curvature, texture, and any
  special treatments.
• Such properties are useful in proving two pieces
  of glass are not associated.

10
Nonoptical Physical Properties of Glass (2 of 5)

• Surface striations and markings
• Rollers leave parallel ream marks on sheet glass
• Markings may indicate the glasss orientation
  when pieces are missing
• Relative spacing of marks may be used for
  individualization
• Surface scratches, etchings, and other markings
  may also be used to individualize evidence

11
Nonoptical Physical Properties of Glass (3 of 5)

• Surface contaminants
• Contaminants show the presence of impurities.
• Patterns of adhering materials might suggest how
  pieces fit together.
• Chemical analysis of adhering materials might
  further individualize the pieces.

12
Nonoptical Physical Properties of Glass (4 of 5)

• Thickness
• The thickness of glass must be measured with a
  high degree of accuracy.
• The investigator cannot assume the glasss
  thickness is constant.
• Determinations of curvature can distinguish flat
  glass from container, decorative, or ophthalmic
  glass.

13
Nonoptical Physical Properties of Glass (5 of 5)

• Hardness measured on the Mohs scale, which
  indicates a substances hardness relative to
  other substances
• Talc (softest) assigned a value of 1
• Diamond (hardest) assigned a value of 10
• Glass tends to fall in the 56 range
• For unknown minerals, relative hardness is
  determined by using the sample to try to scratch
  benchmark minerals

14
Glass Fractures (1 of 8)

• Elasticity the ability of a material to return
  to its previous shape after a force is exerted on
  it
• Use in forensic investigation may be able to
  analyze fractured window panes at a crime scene
  and determine what happened

15
Glass Fractures (2 of 8)

• Three types of forces are distinguished
• Compressive squeezes the material
• Tensile expands the material
• Shear slides one part of material in one
  direction and another part in another direction
• Each force causes a deformation.

16
Glass Fractures (3 of 8)

• Glass breaks when a tensile strain is applied
  that overcomes the materials natural tensile
  stress limit.
• Cracks grow from the unloaded side to the loaded
  side.
• Radial cracks radiate outward, away from the load
  point.
• Tangential (concentric) cracks form if a load
  persists, leading to a spider web appearance.

17
Glass Fractures (4 of 8)

• Bullets are projectile loads through glass.
• Load side is the entrance unloaded side is the
  exit.
• As the bullets velocity increases, the central
  hole becomes smaller, cracking patterns become
  simpler, and the exit hole becomes wider than the
  entrance hole.

18
Glass Fractures (5 of 8)

• Edges of broken pieces of glass will show rib
  (stress) marks.
• In a radial crack, the rib marks are
  perpendicular to unloaded side and parallel to
  loaded side the opposite is true for a
  tangential crack.

19
Glass Fractures (6 of 8)

• 3R rule
• Radial cracks give rib marks that make
• Right angles on the
• Reverse side from where the force was applied

20
Glass Fractures (7 of 8)

• High-speed projectiles exit hole will be wider
  than entrance hole
• Low-speed projectiles rib marks may indicate
  where breaking force was applied

21
Glass Fractures (8 of 8)

• Contaminants such as paint or window putty might
  help identify the inside and outside sides of
  glass.
• Analysis can even determine the sequence of
  impacts for multiple bullet holes.
• Glass fragments from suspects will be very small
  and lost fairly rapidly.

22
Glass Density Tests

• Density a class characteristic
• Density gradient column method used to determine
  glass density
• Fragments of different densities settle at
  different levels in the column
• Technique is not accurate for fragments that are
  cracked or contain an inclusion
• Density tests can exclude fragments that do not
  match the known specimen

23
Optical Physical Properties of Glass (1 of 11)

• Color
• Make side-by-side comparisons using similar-sized
  fragments
• Place the samples over a white surface using
  natural light
• Use both fluorescent and incandescent light to
  determine the glasss color

24
Optical Physical Properties of Glass (2 of 11)

• Refractive index measure of how much light is
  bent as it enters the glass
• Velocity of light in the air ? velocity of light
  in the glass
• The temperature of the sample affects its
  density the density change affects the velocity
  of light as it passes through the sample
• Single sheets of plate glass do not usually have
  a uniform refractive index value
• The index of refraction can vary as much as
  0.0002 from one side of the glass to another

25
Optical Physical Properties of Glass (3 of 11)

• Oil immersion method
• The forensic examiner places the questioned glass
  fragments in specialized silicone oils with known
  refractive indices.
• The immersion oil is heated to change its
  refractive index.
• The refractive index of the oil decreases as
  temperature increases until the Becke line
  disappears.
• At the match point, the refractive indices of the
  oil and the glass fragment are the same.

26
Optical Physical Properties of Glass (4 of 11)

• Emmons procedure uses a hot stage microscope
  plus different source lamps
• Measures the index of refraction for the sample
  at multiple wavelengths
• Correlates the refractive index and the
  wavelength at fixed temperatures for the silicone
  oil into which the glass sample is placed

27
Optical Physical Properties of Glass (5 of 11)

• Emmons procedure
• Step 1 crush the glass and place it in silicone
  oil on the hot stage
• Step 2 measure the glasss index of refraction
  with a sodium lamp and with a hydrogen lamp
• Step 3 as the temperature of the hot stage
  increases, take measurements at three different
  wavelengths
• Step 4 record a line for the refractive index of
  the glass at each wavelength for each temperature
• Step 5 superimpose the lines to create a
  Hartmann net

28
Optical Physical Properties of Glass (6 of 11)

• Annealing is used to distinguish tempered glass
  from nontempered glass.
• Glass fragments are heated in a furnace at a
  temperature gt 600 C.
• The change in refractive index reveals whether
  the glass is tempered or nontempered.

29
Optical Physical Properties of Glass (7 of 11)

• Properties of glass are more often used to
  exonerate suspects than to prove an association.
• Glass evidence is not always individualized
  Fragments from different sources may have similar
  indices of refraction and similar densities.
• Once the refractive index is known, measurement
  of the glasss density will improve
  discrimination capability twofold.

30
Optical Physical Properties of Glass (8 of 11)

• The FBI has compiled density and refractive index
  data for glass from around the world.
• The FBI has also identified the relationship
  between their refractive indices and densities
  for 1400 glass specimens.

31
Optical Physical Properties of Glass (9 of 11)

• Elemental analysis of glass
• Elemental analysis should be performed only after
  all nondestructive methods of examination are
  complete and when additional discrimination is
  necessary.
• Scanning electron microscopy may be used to
  analyze glass, but precise quantitative
  determination of the element concentrations is
  not possible.

32
Optical Physical Properties of Glass (10 of 11)

• Techniques for elemental analysis of glass
• X-ray fluorescence focuses a beam of X-rays on
  the glasss surface and measures the energy of
  the X-rays emitted
• Flameless atomic absorption spectrophotometry
  (FAAS)
• Inductively coupled plasma (ICP) when used with
  an optical emissions spectrometer, can identify
  10 elements in glass (aluminum, barium, calcium,
  iron, magnesium, manganese, sodium, strontium,
  titanium, zirconium)

33
Optical Physical Properties of Glass (11 of 11)

• Disadvantages of the elemental analysis of glass
• The fragment must be dissolved in acid, so the
  original sample is destroyed
• Techniques require the use of hazardous chemicals
