Evaluating Products,

1
Chapter 12

• Evaluating Products,
• Processes, and
• Resources
• Shari L. Pfleeger
• Joann M. Atlee
• 4th Edition
• 4th Edition

2
Contents

• 12.1 Approaches to Evaluation
• 12.2 Selecting an Evaluation Techniques
• 12.3 Assessment vs. Prediction
• 12.4 Evaluating Products
• 12.5 Evaluating Process
• 12.6 Evaluating Resources
• 12.7 Information Systems Example
• 12.8 Real-Time Example
• 12.9 What This Chapter Means for You

3
Chapter 12 Objectives

• Feature analysis, case studies, surveys, and
  experiments
• Measurement and validation
• Capability maturity, ISO 9000, and other process
  models
• People maturity
• Evaluating development artifacts
• Return of investment

4
12.1 Approaches to Evaluation

• Measure key aspects of product, processes, and
  resources
• Determine whether we have met goals for
  productivity, performance, quality, and other
  desire attributes

5
12.1 Approaches to Evaluation Categories of
Evaluation

• Feature analysis rate and rank attributes
• Survey document relationships
• Case studies
• Formal experiment

6
12.1 Approaches to Evaluation Feature Analysis
Example Buying a Design Tool

• List five key attributes that the tool should
  have
• Identify three possible tools and rate the
  criterion
• Examine the scores, creating a total score based
  on the importance of each criterion
• Based on the score, we select the highest score
  (t-OO-1)

7
12.1 Approaches to Evaluation Buying a Design
Tool (continued)

• Design tool ratings

Features Tool 1 T-OO-1 Tool 2 Object Tool Tool 3 Easy Design Importance
Good user interface 4 5 4 3
Object-oriented design 5 5 5 5
Consistency checking 5 3 1 3
Use cases 4 4 4 2
Runs on UNIX 5 4 5 5
Score 85 77 73
8
12.1 Approaches to Evaluation Surveys

• Record data
• to determine how project participants reacted to
  a particular method, tool, or technique
• to determine trends or relationships
• Capture information related to products or
  projects
• Document the size of components, number of
  faults, effort expended

9
12.1 Approaches to Evaluation Case Studies

• Identify key factors that may affect an
  activitys outcome and then document them
• Involve sequence of steps conception hypothesis
  setting, design, preparation, execution,
  analysis, dissemination, and decision making
• Compare one situation with another

10
12.1 Approaches to Evaluation Case Study Types

• Sister projects each is typical and has similar
  values for the independent variables
• Baseline compare single project to
  organizational norm
• Random selection partition single project into
  parts

11
12.1 Approaches to Evaluation Formal Experiment

• Controls variables
• Uses methods to reduce bias and eliminate
  confounding factors
• Often replicated
• Instances are representative sample over the
  variables (whereas case study samples from the
  variables)

12
12.1 Approaches to Evaluation Evaluation Steps

• Setting the hypothesis deciding what we wish to
  investigate, expressed as a hypothesis we want to
  test
• Maintaining control over variables identify
  variables that can affect the hypothesis, and
  decide how much control we have over the
  variables
• Making investigation meaningful the result of
  formal experiment is more generalizable, while a
  case study or survey only applies to certain
  organization

13
12.2 Selecting An Evaluation Technique

• Formal experiments research in the small
• Case studies research in typical
• Surveys research in the large

14
12.2 Selecting An Evaluation TechniqueKey
Selection Factors

• Level of control over the variables
• Degree to which the task can be isolated from the
  rest of the development process
• Degree to which we can replicate the basic
  situation

15
12.2 Selecting An Evaluation TechniqueWhat to
Believe

• When results conflict, how do we know which study
  to believe?
• Using series of questions, represented by the
  game board
• How do you know if the result is valid?
• Evaluation pitfalls table

16
12.2 Selecting An Evaluation TechniqueInvestigati
on and Evaluation Board Game
17
12.2 Selecting An Evaluation TechniqueCommon
Pitfalls in Investigation
Pitfall Description
1. Confounding Another factor is causing the effect
2. Cause of effect? The factor could be a result, not a cause, of the treatment
3. Chance There is always a small possibility that your result happened by chance
4. Homogeneity You can find no link because all subjects had the same level of the factor
5. Misclassification You can find no link because you can not accurately classify each subjects level of the factor
6. Bias Selection procedures or administration of the study inadvertently bias the result
7. Too short The short-term effects are different from the long-term ones
8. Wrong amount The factor would have had an effect, but not in the amount used in the study
9. Wrong situation The factor has the desired effect, but not in the situation studied
18
12.3 Assessment vs. Prediction

• Assessment system examines an existing entity by
  characterizing it numerically
• Prediction system predicts characteristic of a
  future entity involves a model with associated
  prediction procedures
• deterministic prediction (we always get the same
  output for an input)
• stochastic prediction (output varies
  probabilistically)

19
12.3 Assessment vs. PredictionValidating
Prediction System

• Comparing the models performance with known data
  in the given environment
• Stating a hypothesis about the prediction, and
  then looking at data to see whether the
  hypothesis is supported or refuted

20
12.3 Assessment vs. PredictionSidebar 12.1
Comparing Software Reliability Prediction
Modeling techniques Predictive validity Proportion of false negatives () Proportion of false positive () Proportion of false classification () Completeness () Overall Inspection Wasted Inspection
Discriminant Analysis P 0.621 28 26 52 42 46 56
Principal component analysis plus discriminant analysis P0.408 15 41 56 68 74 55
Logistic regression P0.491 28 28 56 42 49 58
Principal component analysis plus logistic regression P0.184 13 46 59 74 82 56
Logical classification model P0.643 26 21 46 47 44 47
Layered neural network P0.421 28 28 56 42 49 58
Holographic network P0.634 26 28 54 47 51 55
Heads or tails P1.000 25 50 50 50 50 50
21
12.3 Assessment vs. PredictionValidating Measures

• Assuring that the measure captures the attribute
  properties it is supposed to capture
• Demonstrating that the representation condition
  holds for the measure and its corresponding
  attributes

22
12.3 Assessment vs. PredictionSidebar 12.2 Lines
of Code and Cyclomatic Number

• The number of lines of code is a valid measure of
  program size, however, it is not a valid measure
  of complexity
• On the other hand, there are many studies that
  exhibit a significant correlation between lines
  of code and cyclomatic number

23
12.3 Assessment vs. PredictionA Stringent
Requirement for Validation

• A measure (e.g., LOC) can be
• an attribute measure (e.g., program size)
• an input to a prediction system (e.g., predictor
  of number of faults)
• Do not reject a measure if it is not part of a
  prediction system
• If a measure is valid for assessment only, it is
  called valid in the narrow
• If a measure is valid for assessment and useful
  for prediction, it is called valid in the wide
  sense

24
12.4 Evaluating Products

• Examining a product to determine if it has
  desirable attributes
• Asking whether a document, file, or system has
  certain properties, such as completeness,
  consistency, reliability, or maintainability
• Product quality models
• Establishing baselines and targets
• Software reusability

25
12.4 Evaluating Products Product Quality
Models

• Boehms model
• ISO 9126
• Dromeys Model

26
12.4 Evaluating Products Boehms Quality Model
27
12.4 Evaluating Products Boehms Quality Model
(continued)

• Reflects an understanding of quality where the
  software
• does what the user wants it do
• uses computer resources correctly and efficiently
• is easy for the user to learn and use
• is well-designed, well-coded, and easily tested
  and maintained

28
12.4 Evaluating Products ISO 9126 Quality Model

• A hierarchical model with six major attributes
  contributing to quality
• Each right-hand characteristic is related to only
  to exactly one left-hand attribute

29
12.4 Evaluating Products ISO 9126 Quality Model
(continued)
30
12.4 Evaluating Products ISO 9126 Quality
Characteristics
Quality Characteristic Definition
Functionality A set of attributes that bear on the existence of a set of functions and their specified properties. The functions are those that satisfy stated or implied needs
Reliability A set of attributes that bear on the capability of software to maintain its performance level under stated conditions for a stated period of time
Usability A set of attributes that bear on the effort needed for use and on the individual assessment of such use by a stated or implied set of users
Efficiency A set of attributes that bear on the relationship between the software performance and the amount of resources used under stated conditions
Maintainability A set of attributes that bear on the effort needed to make specified modifications (which may include corrections, improvements, or adaptations of software to environmental changes and changes in the requirements and functional specifications)
Portability A set of attributes that bear on the ability of software to be transferred from one environment to another (including the organizational, hardware or software environment)
31
12.4 Evaluating Products Dromey Quality Model

• Product quality depends on the tangible
  properties of components and component
  composition
• Correctness properties
• Internal properties
• Contextual properties
• Descriptive properties

32
12.4 Evaluating Products Dromey Quality Model
Attributes

• The six attributes of ISO 9126
• Attributes of reusability
• machine independence
• separability
• configurability
• Process maturity attributes
• client orientation
• well-definedness
• assurance
• effectiveness

33
12.4 Evaluating Products Dromey Quality Model
Framework

• Linking product properties to quality attributes

34
12.4 Evaluating Products Dromey Quality Model
Example
35
12.4 Evaluating Products Dromey Quality Model
Example (continued)

• The model is based on the following five steps
• identify a set of high-level quality attributes
• identify product components
• identify and classify the most significant,
  tangible, quality-carrying properties for each
  component
• propose a set of axioms for linking product
  properties to quality attributes
• evaluate the model, identify its weaknesses, and
  refine or recreate it

36
12.4 Evaluating Products Establishing Baseline
and Targets

• A baseline describes the usual or typical result
  in an organization or category
• Baselines are useful for managing expectations
• A target is a variation of a baseline
• minimal acceptable behavior

37
12.4 Evaluating Products Quantitative Targets
For Managing US Defense Projects
Item Target Malpractice Level
Fault removal efficiency gt95 lt70
Original fault density lt4 per function point gt7 per function point
Slip or cost overrun in Excess of risk reverse 0 gt10
Total requirements creep (function points or equivalent) lt1 per month average gt 50
Total program documentation lt3 pages per function point gt6 pages per function point
Staff turnover 1 to 3 per year gt5 per year
38
12.4 Evaluating Products Software Reusabilty

• Software reuse the repeated use of any part of a
  software system
• documentation
• code
• design
• requirements
• test cases
• test data

39
12.4 Evaluating Products Type of Reuse

• Producer reuse creating components for someone
  else to use
• Consumer reuse using components developed for
  some other product
• Black-box reuse using component without
  modification
• Clear- or white-box reuse modifying component
  before reusing it

40
12.4 Evaluating Products Reuse Approaches

• Compositional reuse uses components as building
  blocks development done from bottom up
• Generative reuse components designed
  specifically for a domain design is top-down
• Domain analysis identifies areas of commonality
  that make a domain ripe for reuse

41
12.4 Evaluating ProductsAspects of Reuse
Substance Scope Mode Technique Intention Product
Ideas and Vertical Planned and Compositional Black-box, Source Code
concepts Horizontal Systematic Generative as is Design
Artifacts and Ad hoc, Clear-box Requirements
components opportunistic modified Objects
Procedures, Data
skills, and Processes
experience Documentation
Patterns Tests
Architecture
42
12.4 Evaluating Products Reuse Technology

• Component classification collection of reusable
  components are organized and catalogued according
  to a classification scheme
• hierarchical
• faceted classification

43
12.4 Evaluating Products Example of A
Hierarchical Scheme

• New topic can be added easily at the lowest level

44
12.4 Evaluating Products Faceted Classification
Scheme

• A facet is a kind of descriptor that helps to
  identify the component
• Example of the facets of reusable code
• a application area
• a function
• an object
• a programming language
• an operating system

45
12.4 Evaluating Products Component Retrieval

• A retrieval system or repository an automated
  library that can search for and retrieve a
  component according to the users description
• A repository should address a problem of
  conceptual closeness (values that are similar to
  but not exactly the same as the desired
  component)
• Retrieval system can
• record information about user requests
• retain descriptive information about the component

46
12.4 Evaluating Products Sidebar 12.3 Measuring
Reusability

• The measures must
• address a goal
• reflect perspective of the person asking the
  question
• Even if we had a good list of measurements, still
  it is difficult to determine the characteristic
  of the most reused component
• Look at past history
• Engineering judgment
• Automated repository

47
12.4 Evaluating Products Experience with Reuse

• Raytheon
• A new system contained an average of 60 reused
  code increasing productivity by 50
• GTE Data Services
• Established incentives and rewards for program
  authors whenever their components were reused
• 14 reuse on its project, valued at a savings of
  1.5 million
• Nippon Novel
• Paid 5 cents per line of code to a developer who
  reused a component

48
12.4 Evaluating Products Sidebar 12.4 Software
Reuse at Japans Mainframe Makers

• NEC reuse library was established to classify,
  catalog, and document
• Hitachi integrated software environment, called
  Eagle, to allow software engineers to reuse
  standard program patterns and functional
  procedures
• Fujitsu created Information Support Center
  (ISC), that is a regular library staffed with
  system analysts, software engineers, reuse
  experts, and switching system domain experts

49
12.4 Evaluating Products Benefits of Reuse

• Reuse increases productivity and quality
• Reusing component may increase performance and
  reliability
• A long term benefit is improved system
  interoperability

50
12.4 Evaluating Products Example of Reuse
Success

• Quality, productivity, and time to market at HP

Project Characteristics HP Project 1 HP Project 2
Size 1100 noncommented source statements 700 noncommented source statements
Quality 51 fault reduction 24 fault reduction
Productivity 57 increase 40 increase
Time to market Data not available 42 reduction
51
12.4 Evaluating Products Example of Cost of
Reuse

• Cost to produce and reuse at HP

Air traffic control system () Menu- and forms Management system () Graphics Firmware ()
Relative cost to create Reusable code 200 120 to 480 111
Relative cost to reuse 10 to 20 10 to 63 19
52
12.4 Evaluating Products Sidebar 12.5 Critical
Reuse Success Factors at NTT

• Success factors at NTT in implementing reuse
• senior management commitment
• selecting appropriate target domains
• systematic development of reusable modules based
  on domain analysis
• investing several years of continuous effort in
  reuse

53
12.4 Evaluating Products Reuse Lessons

• Reuse goals should be measurable
• Management should resolve reuse goals early
• Different perspectives may generate different
  questions about reuse
• Every organization must decide at what level to
  answer reuse questions
• Integrate the reuse process into the development
  process
• Let your business goals suggest what to measure

54
12.4 Evaluating ProductsConflicting
Interpretation of Goals

• A division managers reuse goal may conflict with
  a project managers goal, so no reuse ever gets
  done

55
12.4 Evaluating ProductsQuestions for Successful
Reuse

• Do you have the right model of reuse
• What are the criteria for success
• How can current cost models be adjusted to look
  at collections of projects, not just single
  projects?
• How do regular notions of accounting fit with
  reuse?
• Who is responsible for component quality?
• Who is responsible for process quality and
  maintenance

56
12.5 Evaluating ProcessPostmortem Analysis

• A postimplementation assessment of all aspects of
  the project, including products, process, and
  resources, intended to identify areas of
  improvement for future projects
• Takes places shortly after a projects is
  completed, or can take place at any time from
  just before delivery to 12 months afterward

57
12.5 Evaluating ProcessWhen Postimplemlentaion
Evaluation Is Done
Time period Percentage of Respondent (of 92 organizations)
Just before delivery 27.8
At delivery 4.2
One month after delivery 22.2
Two months after delivery 6.9
Three months after delivery 18.1
Four months after delivery 1.4
Five months after delivery 1.4
Six months after delivery 13.9
Twelve months after delivery 4.2
58
12.5 Evaluating ProcessSidebar 12.6 How Many
Organizations Perform Postmortem Analysis

• Kumar (1990) surveyed 462 medium-sized
  organizations
• 92 organizations that responded, more than
  one-fifth did not postmortem analysis
• those that did, postmortem were conducted on
  fewer than half of the projects in the
  organization

59
12.5 Evaluating ProcessPostmortem Analysis
Process

• Design and promulgate a project survey to collect
  relevant data
• Collect objective project information
• Conduct a debriefing meeting
• Conduct a project history day
• Publish the results by focusing on lessons learned

60
12.5 Evaluating ProcessPostmortem Analysis
Process Survey

• A starting point to collect data that cuts across
  the interests of project team members
• Three guiding principles
• Do not ask for more than you need
• Do not ask leading questions
• Preserve anonymity
• Sample questions shown in Sidebar 12.7

61
12.5 Evaluating ProcessSidebar 12.7 Sample
Survey Questions From Wildfire Survey

• Were interdivisional lines of responsibility
  clearly defined throughout the project?
• Did project-related meetings make effective use
  of your time?
• Were you empowered to participate in discussion
  regarding issues that affected your work?
• Did schedule changes and related decision involve
  the right people
• Was project definition done by the appropriate
  individuals?
• Was the build process effective for the component
  area your work on?
• What is your primary function on this project?

62
12.5 Evaluating ProcessPostmortem Analysis
Process Objective Information

• Obtain objective information to complement the
  survey opinions
• Collier, Demarco and Fearey suggest three kinds
  of measurements cost, schedule, and quality
• Cost measurements might include
• person-months of effort
• total lines of code
• number of lines of code changed or added
• number of interfaces

63
12.5 Evaluating ProcessPostmortem Analysis
Process Debriefing Meeting

• Allows team members to report what did and did
  not go well on the project
• Project leader can probe more deeply to identify
  the root cause of positive and negative effects
• Some team members may raise issues not covered in
  the survey questions
• Debriefing meetings should be loosely structured

64
12.5 Evaluating ProcessPostmortem Analysis
Process Project History Day

• Objective identify the root causes of the key
  problems
• Involves a limited number of participants who
  know something about key problems
• Review schedule predictability charts
• Show where problems occurred
• Spark discussion about possible causes of each
  problem

65
12.5 Evaluating ProcessPostmortem Analysis
Process Schedule-Predictability Charts

• For each key project milestone, the chart shows
  when the predictions was made compared with the
  completion date

66
12.5 Evaluating ProcessPostmortem Analysis
Process Publish Results

• Objective Share results with the project team
• Participants in the project history day write a
  letter to managers, peers, developers
• The letter has four parts
• Introduction to the project
• A summary of postmortems positive findings
• A summary of three worst factors that kept the
  team from meeting its goals
• Suggestions for improvement activities

67
12.5 Evaluating ProcessProcess Maturity Models

• Capability Maturity Model (CMM)
• Software Process Improvement and Capability
  dEtermination (SPICE)
• ISO 9000

68
12.5 Evaluating ProcessCapability Maturity Model

• Developed by Software Engineering Institute
• There are five levels of maturity
• Each level is associated with a set of key
  process area

69
12.5 Evaluating ProcessCMM Levels of Maturity
70
12.5 Evaluating ProcessCMM Maturity Levels

• Level 1 Initial
• Level 2 Repeatable
• Level 3 Defined
• Level 4 Managed
• Level 5 Optimizing

71
12.5 Evaluating ProcessCMM Level 1

• Initial describes a software development process
  that is ad hoc or even chaotic
• It is difficult even to write down or depict the
  overall process
• No key process areas at this level

72
12.5 Evaluating ProcessRequired Questions for
Level 1 of The Process Maturity Model
Question number Question
1.1.3 Does the software quality assurance function have a management reporting channel separate from the software development project management?
1.1.6 Is there a software configuration control function for each project that involves software development?
2.1.3 Is a formal process used in the management review of each software development prior to making contractual commitments?
2.1.14 Is a formal procedure used to make estimates of software size?
2.1.15 Is a formal procedure used to produce software development schedules?
2.1.16 Are formal procedures applied to estimating software development cost?
2.2.2 Are profiles of software size maintained for each software configuration item over time?
2.2.4 Are statistic on software code and test errors gathered?
2.4.1 Does senior management have a mechanism for the regular review of the status of software development projects/
2.4.7 Do software development first-line managers sign off on their schedule and cost estimates?
2.4.9 Is a mechanism used for controlling changes to the software requirements?
2.4.17 Is a mechanism used for controlling changes to the code?
73
12.5 Evaluating ProcessKey Process Areas in The
CMM
CMM Level Key Process Areas
Initial None
Repeatable Requirement Management Software project planning Software project tracking and oversightsoftware subcontract management Software quality assurance Software Configuration management
Defined Organization process focus Organization process definition Training program Integrated software management Software product engineering Intergroup coordination Peer reviews
Managed Quantitative process management Software quality management
Optimizing Fault prevention Technology change management Process change management
74
12.5 Evaluating ProcessCMM Level 2

• Repeatable identifying the inputs and outputs of
  the process, the constraints, and the resources
  used to produce final product

75
12.5 Evaluating ProcessCMM Level 3

• Defined management and engineering activities
  are documented, standardized and integrated

76
12.5 Evaluating ProcessCMM Level 4

• Managed process directs its effort at product
  quality

77
12.5 Evaluating ProcessCMM Level 5

• Optimizing quantitative feedback is incorporated
  in the process to produce continuous process
  improvement

78
12.5 Evaluating ProcessCMM Key Practices

• Commitment to perform
• Ability to perform
• Activities performed
• Measurement and analysis
• Verifying implementation

79
12.5 Evaluating ProcessSPICE

• SPICE is intended to harmonize and extend the
  existing approaches (e.g., CMM, BOOTSTRAP)
• SPICE is recommended for process improvement and
  capability determination
• Two types of practices
• Base practices essential activities of a
  specific process
• Generic practices institutionalization
  (implement a process in a general way)

80
12.5 Evaluating ProcessSPICE Architecture for
Process Assessment
81
12.5 Evaluating ProcessSPICE Functional View
Activities/Processes

• Customer-supplied processes that affect the
  customer directly
• Engineering processes that specify, implement,
  or maintain the system
• Project processes that establish the project,
  and coordinate and manage resources
• Support processes that enable other processes
• Organizational processes that establish business
  goals

82
12.5 Evaluating ProcessSPICE Six Levels of
Capability

• 0 Not performed failure to perform
• 1 Performed informally not planned and tracked
• 2 Planned and tracked verified according to the
  specified procedures
• 3 Well-defined well-defined processusing
  approved processes
• 4 Quantitatively controlled detailed
  performance measures
• 5 Continuously improved quantitative targets
  for effectiveness and efficiency based on
  business goals

83
12.5 Evaluating ProcessISO 9000

• Produced by The International Standards
  Organization (ISO)
• Standard 9001 is most applicable to the way we
  develop and maintain software
• Used to regulate internal quality and to ensure
  the quality suppliers

84
12.5 Evaluating ProcessISO 9001 Clauses
Clause number Subject matter Subject matter
4.1 4.1 Management responsibility
4.2 4.2 Quality system
4.3 4.3 Contract review
4.4 4.4 Design control
4.5 4.5 Document and data control
4.6 4.6 Purchasing
4.7 4.7 Control of customer-supplied product
4.8 4.8 Product identification and traceability
4.9 4.9 Process control
4.10 4.10 Inspection and testing
4.11 4.11 Control of inspection, measuring, and test equipment
4,12 4,12 Inspection and test status
4,.13 4,.13 Control of nonconforming product
4.14 4.14 Corrective and preventive action
4.15 4.15 Handling, storage, packaging, preservation, and delivery
4.16 4.16 Control of quality records
4,17 4,17 Internal quality audits
4.18 4.18 Training
4.19 4.19 Servicing
4.20 4.20 Statistical techniques
85
12.6 Evaluating Resources

• People Maturity Model
• Return on investment

86
12.6 Evaluating ResourcesPeople Maturity Model

• Proposed by Curtis, Hefley and Miller for
  improving the knowledge and skills of the
  workforce
• It has five levels
• Initial
• Repeatable
• Defined
• Managed
• Optimizing

87
12.6 Evaluating ResourcesPeople Capability
Maturity Model Levels
Level Focus Key Practices
5 Optimizing Continuous knowledge and Skill improvements Continuous workforce innovation Coaching Personal competency development
4 Managed Effectiveness measure and managed, high-performance teams developed Organizational performance alignment Organizational competency management Team-based practice Team building Mentoring
3 Defined Competency-based workforce practice Participatory culture Competency-based practices Career development Competency development Workforce planning Knowledge and skill analysis
2 Repeatable Management takes responsibility for managing its people Compensation Training Performance management Staffing Communication Work environment
1 Initial
88
12.6 Evaluating ResourcesReturn on investment

• Use net present value
• value today of predicted future cash flows
• Example

89
12.6 Evaluating ResourcesReturn on Investment at
Chase Manhattan

• RMS has increased customer calls by 33 and
  improved profitability by 27
• By protecting its old investment and encouraging
  communication among employees, Chase Manhattan
  accomplished
• avoid huge investment in new hardware
• provide more data more quickly to its service
  representative
• achieved an admirable return on investment
• created cohesive teams that understand more about
  Chase Manhattans business

90
12.7 Information Systems ExamplePiccadilly System

• A postmortem analysis must review the business as
  well as technology
• Is this system good for business

91
12.7 Real-Time ExampleAriane-5

• A fine example of a postmortem analysis
• Focused on the obvious need to determine what
  caused the fault that required exploding the
  rocket
• Avoided blamed and complaint

92
12.8 What This Chapter Means For You

• There are several approaches to evaluation,
  including feature analysis, surveys, case
  studies, and formal experiments
• Measurement is essential for any evaluation
• It is important to understand the difference
  between assessment and prediction
• Product evaluation is usually based on a model of
  the attributes of interest
• Process evaluation can be done in many ways
• Return-on-investment strategies helps us
  understands whether business is benefiting from
  investment in people, tools, and technology
