IOI 2005 Training

1
IOI 2005 Training

• Dr Kan Min-Yen

2
Topics and outline

• Sorting
• Computer Arithmetic and Algebra
• Invariants and Number Theory

3
Sorting

• Problems and Parameters
• Comparison-based sorting
• Non-comparison-based

www.personaltouchmailing.com
4
What sort of problems?

• Sorting is usually not the end goal, but a
  prerequisite
• (Efficient) searching!
• Uniqueness / Duplicates
• Prioritizing (c.f. priority queues)
• Median / Selection
• Frequency Counting
• Set operations
• Target Pair

5
Two properties of sorting

• Stable
• Items with the same value are ordered in the same
  way after the sort as they were before
• Important for doing multiple stage sorts
• E.g., sorting by First name, Last name
• In-place sorts the items without needing extra
  space
• Space proportional to the size of the input n

6
Comparison-based sort

• Based on comparing two items
• Many variants, but not the only way to sort
• Discuss only the important ones for programming
  contests
• Selection, Insertion, Merge and Quick

7
Comparison Sorts

• Comparison Sort Animation http//math.hws.edu/TMC
  M/java/xSortLab/
• Selection
• Algo find min or max of unsorted portion
• Heapsort is selection sort with heap data
  structure
• Remember Minimize amount of swaps
• Insertion
• Algo insert unsorted item in sorted array
• Remember Minimize amount of data

8
Comparison Sorts

• Merge
• Idea divide and conquer, recursion
• Algo merge two sorted arrays in linear time
• Remember Dont recurse to the base case if using
  this sort, not in-place
• Quick
• Idea randomization, pivot
• Algo divide problem to smaller and larger half
  based on a pivot
• Remember Partition can be used to solve problems
  too!
• A problem with sorting as its core may not be
  best solved with generic tool. Think before
  using a panacea like Quicksort.

9
Miscellaneous sort

• Most sorting relies on comparisons between two
  items.
• Proven to be T(n log n)
• Example sort an array of distinct integers
  ranged 1-k
• Well go over
• Radix sort
• Counting sort

10
What is radix?

• Radix is the same as base. In decimal system,
  radix 10.
• For example, the following is a decimal number
  with 4 digits

0 3 2 8
1st Digit
3rd Digit
4th Digit
2nd Digit
11
Radix Sort

• Suppose we are given n d-digit decimal integers
  A0..n-1, radix sort tries to do the following
• for j d to 1
• By ignoring digit-1 up to digit-(j-1), form the
  sorted array of the numbers

12
Radix Sort (Example)
Sorted Array if we only consider digit-4
0
1
2
3 ? 0123, 2043, 1773
4 ? 1024
5
6
7
8 ? 9738, 0008, 2048
9 ? 1239
Original
0123
2043
1773
1024
9738
0008
2048
1239
0123
2043
9738
1024
0008
2048
1773
1239
Group using4th digit
Ungroup
13
Radix Sort (Example)
Sorted Array if we only consider digits-3 and 4
0 ? 0008
1
2 ? 0123, 1024
3 ? 9738, 1239
4 ? 2043, 2048
5
6
7 ? 1773
8
9
Original
0008
0123
1024
9738
1239
2043
2048
1773
0123
2043
1773
1024
9738
0008
2048
1239
Group using3rd digit
Ungroup
14
Radix Sort (Example)
Sorted Array if we only consider digit-2, 3, and 4
0 ? 0008, 1024, 2043, 2048
1 ? 0123
2 ? 1239
3
4
5
6
7 ? 9738, 1773
8
9
Original
0008
1024
2043
2048
0123
1239
9738
1773
0008
0123
1024
9738
1239
2043
2048
1773
Group using2nd digit
Ungroup
15
Radix Sort (Example)
Done!
0 ? 0008, 0123
1 ? 1024, 1239, 1773
2 ? 2043, 2048
3
4
5
6
7
8
9 ? 9738
Original
0008
0123
1024
1239
1773
2043
2048
9738
0008
1024
2043
2048
0123
1239
9738
1773
Group using1st digit
Ungroup
16
Details on Radix Sort

• A stable sorting algorithm
• Done from least signficant to most signficant
• Can be used with a higher base for better
  efficiency
• Decide whether its really worth it
• Works for integers, but not real, floating point
• But see http//codercorner.com/RadixSortRevisited
  .htm
• The combination of 1 and 2 can be used for
  combining sorts in general

17
Counting Sort

• Works by counting the occurrences of each data
  value.
• Assumes that there are n data items in the range
  of 1..k
• The algorithm can then determine, for each input
  element, the amount of elements less than it.
• For example if there are 9 elements less than
  element x, then x belongs in the 10th data
  position.
• These notes are from Cardiffs Christine Mumford
  http//www.cs.cf.ac.uk/user/C.L.Mumford/

18
Counting Sort

• The first for loop initialises C to zero.
• The second for loop increments the values in C,
  according to their frequencies in the data.
• The third for loop adds all previous values,
  making C contain a cumulative total.
• The fourth for loop writes out the sorted data
  into array B.

• countingsort(A, B, k)
• for i 1 to k do
• Ci 0
• for j 1 to length(A) do
• CAj CAj 1
• for 2 1 to k do
• Ci Ci Ci-1
• for j 1 to length(A) do BCAj Aj
• CAj CAj - 1

19
Counting Sort

• Demo from Cardiff
• http//www.cs.cf.ac.uk/user/C.L.Mumford/tristan/Co
  untingSort.html

20
Counting and radix sort

• Whats their complexity?
• Radix sort O(dn) O(n), if d ltlt n
• Counting sort 2k 2n O(n), if k ltlt n
• Why do they work so fast??
• No comparisons are made
• Both are stable sorts, but not in-place
• Can you fix them to be in-place?
• When to use?
• When you have lots of items in a fixed range

21
Quiz and discussion

• There are no right answers
• Which sort better used for a very large random
  array?
• For sorting a deck of cards?
• For sorting a list of first name, last names?
• For sorting single English words
• For sorting an almost sorted set?

22
Computer Arithmetic and Algebra

• Big Numbers
• Arbitrary precision arithmetic
• Multiprecision arithmetic
• Computer Algebra
• Dealing with algebraic expressions a la Maple,
  Mathematica

23
Arithmetic

• Want to do standard arithmetic operations on very
  large/small numbers
• Cant fit representation of numbers in standard
  data types
• What to do?
• Sassy answer use java and BigInt class

24
Two representations

• How to represent 10 00000 00000 02003
• Linked list 1e16 ? 2e3 ? 3e0
• Dense representation
• Good for numbers with different or arbitrary
  widths
• Where should the head of the linked list point
  to?
• Array ltas abovegt
• Sparse representation
• Good for problems in the general case
• Dont forget to store the sign bit somewhere
• Which base to choose 10 or 32?
• How to represent arbitrary large real numbers?

25
Standard operations

• Most large number operations rely on techniques
  that are the same as primary school techniques
• Adding
• Subtracting
• Multiplying
• Dividing
• Exponentiation / Logarithms

26
Algorithms for big numbers

• Addition of bigints x and y
• Complicated part is to deal with the carry
• What about adding lots of bigints together?
• Solution do all the adds first then worry about
  the carries

27
Canonicalization and adding

• Canonicalizing
• 12E2 34E0 gt 1E3 2E2 3E1 4E0
• Strip coefficient of values larger than B and
  carry to next value
• Reorder sparse representation if necessary
• Adding
• Iteratively add all Ai Bi Zi then canonicalize
• Hazard
• Data type for each entry must be able to hold
  maximum expected data or overflow will occur

28
Algorithms for big numbers

• Subtraction
• Like addition but requires borrowing (reverse
  carry)
• Place the higher absolute magnitude number at the
  top
• Applicable to addition of mixed sign numbers
• Comparison
• Start from higher order bits then work backwards

29
Multiplying

• Given two big integers X and Y in canonical form

• the big integer Z XY can be obtained thanks to
  the formula
• Notes
• This is the obvious way we were taught in primary
  school, the complexity is T(N2)
• Canonicalize after each step to avoid overflow in
  coefficients
• To make this operation valid, B2 must fit in the
  coefficient

30
Shift Multiplication

• If a number is encoded in base B
• Left shift multiplies by B
• Right shift multiples by B
• Yet another reason to use arrays vs. linked lists
• If your problem requires many multiplications and
  divisions by a fixed number b, consider using b
  as the base for the number

31
Karatsuba Multiplication

• We can split two big numbers in half
• X X0 B X1 and Y Y0 B Y1
• Then the product XY is given by
• (X0 BX1) (Y0 BY1)
• This results in three terms
• X0Y0 B (X0Y1 X1Y0) B2(X1Y1)
• Look at the middle term. We can get the middle
  term almost for free by noting that
• (X0 X1) (Y0 Y1) X0Y0 X0Y1 X1Y0 X1Y1

X0Y0
X1Y1
(X0 X1) (Y0 Y1)
X0Y1 X1Y0
- -
32
Karatsuba Demonstration

• 12 34
• Given X1 1, X0 2, Y1 3, Y0 4
• Calculate X0Y0 8, X1Y1 3 (X0X1)(Y0Y1)
  37 21
• Final middle term 21 8 3 10
• Solution 8 10 101 3 102 408
• Notes
• Recursive, complexity is about T(n1.5)
• Theres a better way FFT based multiplication
  not taught here that is T (n log n)
• http//numbers.computation.free.fr/Constants/Algor
  ithms/fft.html

33
Division

• Algo long division
• (Skiena and Revilla, pg 109) Iterate
• shifting the remainder to the left including the
  next digit
• Subtract off instances of the divisor
• Demo
• http//www.mathsisfun.com/long_division2.html

34
Exponentiation

• How do you calculate x256?
• x256 ((((((((x2)2)2)2)2)2)2)
• What about x255?
• Store x, x2, x4, x8, x16, x32, x64, x128 on the
  way up.
• Complexity T(log n)

35
Computer Algebra

• Applicable when you need an exact computation of
  something
• 1/7 does not exactly equal 0.142857142857
• 1/7 7 1
• Or when you need consider polynomials with
  different variables

36
Data structures

• How to represent x5 2x 1?
• Dense (array) 15 04 03 02 21 -10
• Sparse (linked list) 1,52,1-1,0
• What about arbitrary expressions?
• Solution use an expression tree(e.g. abc)

37
Simplification Introduction

• But CA systems have to deal with equivalency
  between different forms
• (x-2) (x2)
• X2 4
• So an idea is to push all equations to a
  canonical form.
• Like Maple simplify
• Question how do we implement simplify?

38
Simplify - Transforming Negatives

• Why?
• Kill off subtraction, negation
• Addition is commutative

To think about How is this related to big
integer computation?
39
Simplify Leveling Operators

• Combine like binary trees to n-ary trees

40
Simplify Rational Expressions

• Expressions with and / will be rewritten so
  that there is a single / node at the top, with
  only operators below

41
Simplify Collecting Like Terms
42
Exact / Rational Arithmetic

• Need to store fractions. What data structure can
  be used here?
• Problems
• Keep 4/7 as 4/7 but 4/8 as 1/2
• How to do this?
• Simplification and factoring
• Addition and subtraction need computation of
  greatest common denominator
• Note division of a/b ? c/d is just a/b ? d/c

43
Invariants

• Sometimes a problem is easier than it looks
• Look for another way to define the problem in
  terms of indirect, fixed quantities

44
Invariants

• Chocolate bar problem
• You are given a chocolate bar, which consists of
  r rows and c columns of small chocolate squares.
• Your task is to break the bar into small squares.
  What is the smallest number of splits to
  completely break it?

45
Variants of this puzzle?

• Breaking irregular shaped objects
• Assembling piles of objects
• Fly flying between two trains
• Adding all integers in a range (1 1000)
• Also look for simplifications or irrelevant
  information in a problem

46
The Game of Squares and Circles

• Start with c circles and s squares.
• On each move a player selects two shapes.
• These two are replaced by one according to the
  following rule
• Identical shapes are replaced with a square.
  Different shapes are replaced with a circle.
• At the end of the game, you win if the last shape
  is a circle. Otherwise, the computer wins.

47
Whats the key?

• Parity of circles and squares is invariant
• After every move
• if circles was even, still will be even
• If circles was odd, still will be odd

48
Sam Loyds Fifteen Puzzle

• Given a configuration, decide whether it is
  solvable or not
• Key Look for an invariant over moves

8
7
12
15
1
2
3
4
1
5
2
13
8
7
5
6
Possible?
6
3
14
9
12
10
11
9
4
10
11
15
13
14
49
Solution to Fifteen

• Look for inversion invariance
• Inversion when two tiles out of order in a row
• inverted
  not inverted
• For a given puzzle configuration, let N denote
  the sum of
• the total number of inversions
• the row number of the empty square.
• After a legal move, an odd N remains odd whereas
  an even N remains even.

11
10
10
11
50
Fifteen invariant

• Note if you are asked for optimal path, then
  its a search problem

b
c
a
d
51
Story time Euclid of Alexandria
(325 BC 265 BC)
How many others have been on the bestseller list
for over 1,000 years?

• Greek geometer
• Led school in Alexandria
• Probably wroteThe Elements, the definitive math
  text until the 19th century

• Developed geometry, number theory and others from
  a set of 5 postulates
• Knowledge survived Dark Ages in the Western world
  as it was translated into Arabic

52
Euclidian Algorithm for GCD

• Rational calculation require the calculation of
  the greatest common divisor
• The Euclidean algorithm is a good way to do this.
  Its a recursive procedure
• gcd(N,M) gcd(M, N mod M)
• Demo
• http//www.math.umn.edu/garrett/crypto/a01/Euclid
  .html

53
Sieve of Eratosthenes

• Initialization
• Keep a boolean array 1...n PRIME. We will
  change entries to COMPOSITE as we go on.
• Algorithm
• Set k1. iterate towards vn
• Find the first PRIME in the list greater than k.
  (e.g., 2.) Call it m. Change the numbers 2m, 3m,
  4m, ... to COMPOSITE.
• Set km and repeat.

54
Sieve of Eratosthenes

• Demo from Univ. of Utah (Peter Alfeld)
• http//www.math.utah.edu/alfeld/Eratosthenes.htm
  l
• Notes
• If at n in the sieve, we know that all numbers
  not crossed out under n2 are also prime.

55
Review Time
56
For self-review

• Other topics related that you should cover on
  your own
• Roman number conversion these problems crop up
  every once in a while
• Playing cards and other common games
• Divisibility criteria and modular arithmetic

57
For Fun Monty Hall

• Suppose you're on a game show, and you're given
  the choice of three doors. Behind one door is a
  car, behind the others, goats. You pick a door,
  say number 1, and the host, who knows what's
  behind the doors, opens another door, say number
  3, which has a goat. He says to you, "Do you want
  to pick door number 2?" Is it to your advantage
  to switch your choice of doors?

58
Analysis of the Monty Hall Dilemma

• Door
• case A B C
• 1 bad bad good
• 2 bad good bad
• 3 good bad bad
• assume you choose door A you have a 1/3 chance
  of a good prize.
• But (this is key) Monty knows what is behind each
  door, and shows a bad one.
• In cases 1 and 2, he eliminates doors B and C
  respectively (which happen to be the only
  remaining bad door) so a good door is left
  SWITCH!
• Only in case 3 (you lucked out in your original 1
  in 3 chances) does switching hurt you.

59
References

• Books and websites used tocompile this lecture

60
References

• Skiena, S. and Revilla, M. Programming Challenges
• Gathen, J. and Gerhard, J. Modern Computer
  Algebra

61
References

• Arbitrary-Precision Arithmetichttp//www2.toki.or
  .id/book/AlgDesignManual/BOOK/BOOK4/NODE144.HTM
• World of Sevenhttp//www.comp.nus.edu.sg/steve
  nha/programming/programming.html
• Common Mistakes in Online and Real-time
  Programming Contestshttp//www.acm.org/crossroads
  /xrds7-5/contests.html
• Mathematical Constants and Computation
  http//numbers.computation.free.fr/Constants/const
  ants.html
• Euclids Elements http//mathworld.wolfram.com/El
  ements.html
• Monty Hall Problemhttp//www.cut-the-knot.org/hal
  l.shtml
• Cut the Knothttp//www.cut-the-knot.org/
