Instrumental Conditioning: Motivational Mechanisms

1
Instrumental Conditioning Motivational Mechanisms
2
Contingency-Shaped Behaviour

• Uses three-term contingency
• Reinforcement schedule (e.g., FR10) imposes
  contingency
• Seen in non-humans and humans

3
Rule Governed Behaviour

• Particularly in humans
• Behaviour can be varied and unpredictable
• Invent rules or use (in)appropriate rules across
  conditions (e.g., language)
• Age-dependent, primary vs. secondary reinforcers,
  experience

4
Role of Response in Operant Conditioning

• Thorndike
• Performance of response necessary
• Tolman
• Formation of expectation
• McNamara, Long Wike (1956)
• Maze
• Running rats or riding rats (cart)
• Association what is needed

5
Role of the Reinforcer

• Is reinforcement necessary for operant
  conditioning?
• Tolman Honzik (1930)
• Latent learning
• Not necessary for learning
• Necessary for performance

6
Results
no food
Average Errors
no food until day 11
food
Days
7
Associative Structure in Instrumental Conditioning

• Basic forms of association
• S stimulus, R response, O outcome
• S-R
• Thorndike, Law of Effect
• Role of reinforcer stamps in S-R association
• No R-O association acquired

8
Hull and Spence

• Law of Effect, plus a classical conditioning
  process
• Stimulus evokes response via Thorndikes S-R
  association
• Also, S-O association creates expectancy of
  reward
• Two-process approach
• Classical and instrumental are different

9
One-Process or Two-Processes?

• Are instrumental and classical the same (one
  process) or different (two processes)?
• Omission control procedure
• US presentation depends on non-occurrence of CR
• No CR, then CS ---gt US
• CR, then CS ---gt no US

10
Omission Control
11
Gormenzano Coleman (1973)

• Eyeblink with rabbits
• USshock, CStone
• Classical group 5mA shock each trial, regardless
  of response
• Omission group making eyeblink CR to CS prevents
  delivery of US

12

• One-process prediction
• CR acquisition faster and stronger for Omission
  group
• Reinforcement for CR is shock avoidance
• In Classical group CR will be present because it
  somehow reduces shock aversiveness
• BUT
• CR acquisition slower in Omission group
• Classical conditioning extinction (not all CSs
  followed by US)
• Supports Two-process theory

13
Classical in Instrumental

• Classical conditioning process provides
  motivation
• Stimulus substitution
• S acquires properties of O
• rg fractional anticipatory goal response
• Response leads to feedback
• sg sensory feedback
• rg-sg constitutes expectancy of reward

14
Timecourse
S
R
O
Through stimulus substitution S elicits rg-sg,
giving motivational expectation of reward
15
Prediction

• According to rg-sg CR should occur before operant
  response but doesnt always
• Dog lever pressing on FR33 ---gt PRP
• Low lever presses early, then higher but
  salivation only later

Lever pressing
Magnitude
salivation
Time from start of trial
16
Modern Two-Process Theory

• Classical conditioning in instrumental
• Neutral stimulus ---gt elicits motivation
• Central Emotional State (CES)
• CES is a characteristic of the nervous system
  (mood)
• CES wont produce only one response
• Bit annoying re prediction of effect

17
Prediction

• Rate of operant response modified by presentation
  of CS
• CES develops to motivate operant response
• CS from classical conditioning also elicits CES
• Therefore, giving CS during instrumental
  conditioning should alter CES that motivates
  instrumental response

18
Explicit Predictions

• Emotional states

19

• Behavioural predictions

Aversive US Instrumental schedule CS(fear)
CS-(relief) Positive reinforcement decrease incr
ease Negative reinforcement increase decrease
20
R-O and S(R-O)

• Earlier interpretations had no response-reinforcem
  ent associations
• Intuitive explanation, though
• Perform response to get reinforcer

21
Colwill Rescorla (1986)

• R-O association
• Devalue reinforcer post-conditioning
• Does operant response decrease?
• Bar push right or left for different reinforcers
• Food or sucrose

Testing of Reinforcers
normal reinforcer
Mean responses/min.
devalued reinforcer
Blocks of Ext. Trials
22
Interpretation

• Cant be S-R
• No reinforcer in this model
• Cant be S-O
• Two responses, same stimuli (the bar), but only
  one response affected
• Conclusion
• Each response associated with its own reinforcer
• R-O association

23
Hierarchical S-(R-O)

• R-O model lacks stimulus component
• Stimulus required to activate association
• Really, Skinners (1938) three term contingency
• Old idea recent empirical testing

24
Colwill Delameter (1995)

• Rats trained on pairs of S
• Biconditional discrimination problem
• Two stimuli
• Two responses
• One reinforcer
• Match the correct response to the stimuli to be
  reinforced
• Training, reinforcer devaluation, testing

25

• Training
• Tone lever --gt food chain --gt nothing
• Noise chain --gt food lever --gt nothing
• Light poke --gt sucrose handle --gt nothing
• Flash handle --gt sucrose poke --gt nothing
• Aversion conditioning
• Testing marked reduction in previously
  reinforced response
• Tone lever press vs. chain
• Noise chain vs. lever
• Light poke vs. handle
• Flash handle vs. poke

26
Analysis

• Cant be S-O
• Each stimulus associated with same reinforcer
• Cant be R-O
• Each response reinforced with same outcome
• Cant be S-R
• Due to devaluation of outcome
• Each S activates a corresponding R-O association

27
Reinforcer Prediction, A Priori

• Simple definition
• A stimulus that increases the future probability
  of a behaviour
• Circular explanation
• Would be nice if we could predict beforehand

28
Need Reduction Approach

• Primary reinforcers reduce biological needs
• Biological needs e.g., food, water
• Not biological needs e.g., sex, saccharin
• Undetectable biological needs e.g., trace
  elements, vitamins

29
Drive Reduction

• Clark Hull
• Homeostasis
• Drive systems
• Strong stimuli aversive
• Reduction in stimulation is reinforcer
• Drive is reduced
• Problems
• Objective measurement of stimulus intensity
• Where stimulation doesnt change or increases!

30
Trans-situationality

• A stimulus that is a reinforcer in one situation
  will be a reinforcer in others
• Subsets of behaviour
• Reinforcing behaviours
• Reinforcable behaviours
• Often works with primary reinforcers
• Problems with other stimuli

31
Primary and Incentive Motivation

• Where does motivation to respond come from?
• Primary biological drive state
• Incentive from reinforcer itself

32
But Consider

• What if we treat a reinforcer not as a stimulus
  or an event, but as a behaviour in and of itself
• Fred Sheffield (1950s)
• Consummatory-response theory
• E.g., not the food, but the eating of food that
  is the reinforcer
• E.g., saccharin has no nutritional value, cant
  reduce drive, but is reinforcing due to its
  consumability

33
Premacks Principle

• Reinforcing responses occur more than the
  responses they reinforce
• H high probability behaviour
• L low probability behaviour
• If L ---gt H, then H reinforces L
• But, if H ---gt L, H does not reinforce L
• Differential probability principle
• No fundamental distinction between reinforcers
  and operant responses

34
Premack (1965)

• Two alternatives
• Eat candy, play pinball
• Phase I determine individual behaviour
  probability (baseline)
• Gr1 pinball (operant) to eat (reinforcer)
• Gr2 eating candy (operant) to play pinball
  (reinforcer)
• Phase II (testing)
• T1 play pinball (operant) to eat (reinforcer)
• Only Gr1 kids increased operant
• T2 eat (operant) to play pinball (reinforcer)
• Only Gr2 kids increased operant

35
Premack in Brief
Any activity
could be a reinforcer
if it is more likely to be preferred than the
operant response.
36
Response Deprivation Hypothesis

• Restriction to reinforcer response
• Theory
• Impose response deprivation
• Now, low probability responses can reinforce high
  probability responses
• Instrumental procedures withhold reinforcer until
  response made in essence, deprived of access to
  reinforcer
• Reinforcer produced by operant contingency itself

37
Behavioural Regulation

• Physiological homeostasis
• Analogous process in behavioural regulation
• Preferred/optimal distribution of activities
• Stressors move organism away from optimum
  behavioural state
• Respond in ways to return to ideal state

38
Behavioural Bliss Point

• Unconstrained condition distribute activities in
  a way that is preferred
• Behavioural bliss point (BBP)
• Relative frequency of all behaviours in
  unconstrained condition
• Across conditions
• BBP shifts
• Within condition
• BBP stable across time

39
Imposing a Contingency

• Puts pressure on BBP
• Act to defend challenges to BBP
• But requirements of contingency (may) make
  achieving BBP impossible
• Compromise required
• Redistribute responses so as to get as close to
  BBP as possible

40
Minimum Deviation Model

• Behavioural regulation
• Due to imposed contingency
• Redistribute behaviour
• Minimize deviation of responses from BBP
• Get as close as you can

41
restricted running
40 30 20 10
Time drinking
restricted drinking
10 20 30 40
Time running
42
Strengths of BBP Theory

• Reinforcers not special stimuli or responses
• No difference between operant and reinforcer
• Explains new allocation of behaviour
• Fits with findings on cognition for costbenefit
  optimization
