Second review meeting EFDA ITER Goal Oriented
Training Programme Port Plug Engineering (PPE)
Participants ITER-PPE training management
board EFDA Malaquias Artur CEA Doceul Louis,
Martins Jean-Pierre, Delphine Keller, Salasca
Sophie FZJ  Neubauer Olaf KIT Neuberger Heiko
(remote) , Scherer Theo (remote) HAS Bede
Otto PPE euro-trainees CEAMiguel Dapena, Julien
Wagrez FZJ  Romaric Voinchet KIT Gaetano
Aiello, Zeile Christian HAS Nemeth
Joszef Observers CEACommin Lorelei, Madeleine
Sylvain FZJ Krimmer Andreas
2
Agenda
9h welcome coffee 9h30 Status of the PPE program
(L. Doceul) 10h00 Work performed in the frame of
WP1 (M. Dapena) 10h30 Work performed in the
frame of WP2 (J. Wagrez) 11h00 Work performed in
the frame of WP3 (G. Aiello) 11h30 Work performed
in the frame of WP4 (C. Zeile) 12h Lunch 13h Work
performed in the frame of WP5 (J. Németh) 13h30
Work performed in the frame of WP6 (R.
Voinchet) 14h Work performed in the frame of
EUROBREED program (L. Commin) 14h30 Open
discussion on PPE program (sharing, conference,
training session,.) (All participants, coffee at
15h included ) 15h15 Presentation of Tore-Supra
(L. Doceul) 15h30 Visit of Tore-Supra 17h End of
Monday meeting
3
Brief recall of the PPE Work Programme The
thematic of the PPE WP is in the field of
Engineering Design and Construction, this
training program is associated to the procurement
of the ITER Port Plug including design,
structural analysis, neutronics, material
requirement, nuclear requirement, safety,
manufacturing aspect, assembly aspect,
maintainability. The official starting date of
the ITER GOT PPE is 1st september 2008
established for 4 years the first year being
devoted to the recruitment of the trainees. Six
work packages of three years duration are
identified 2 CEA, 1 FZJ, 2 KIT, and 1 HAS The
starting date of each work package being the
official date of each euro-trainee recruitment.
4

Work programmes description
WP1 (CEA) Tutor Sophie Salasca Trainee Miguel Dapena Nuclear Requirements in different phases from the engineering design to decommissioning (particular application on ITER diagnostic port plug equatorial 1) Starting date 05/01/09
WP2 (CEA) Tutor Jean Pierre Martins and Delphine Keller Trainee Julien Wagrez Maintainability associated to ITER Component Lifecycle (particular application on ITER diagnostic port plug equatorial 1) Starting date 03/06/09
WP3 (KIT) Tutor Theo Scherer TraineeGaetano Aiello Materials, manufacturing and assembly of upper port plug structures (particular application on ITER ECRH upper port plug) Starting date 01/09/08
WP4 (KIT) Tutor Heiko Neuberger Trainee Christian Zeile Design, manufacturing and integration of ITER relevant structural components (particular application on ITER TBM equatorial port plug) Starting date 05/06/09
 WP5 (HAS) Tutor Otto Bede Trainee Jozsef  Németh Thermo mechanical Engineering of In-Vessel Components (particular application on ITER diagnostics) Starting date 06/07/09
WP6 (FZJ) Tutor Olaf Neubauer Trainee Romaric Voinchet Feasibility of manufacturing in the design of ITER in-vessel components (particular application on ITER CXRS diagnostic port plug) Starting date 05/01/09
ITER GOT PPE WEBSITE
5
Course and events Table to be discussed To be
consolidated at the end of the meeting
Trainee sharing Sharing between association To
be consolidated at the end of the
meeting Sharing with industrial partner To be
consolidated at the end of the meeting
6

• Deliverable
• Deliverables description for 2009
• All Contract have already started and all the
  trainees have been recruited during the first
  year, the ITER GOT PPE training program will run
  from the 01 September of 2008 to the 07 july of
  2012
• First deliverable (3 month) Personal Career
  Development Plan (EFDA form to be filled).
  Completed for each wp
• At the end of 2009, progress report are required
  (progress made, activity status, skill obtained,
  corrective action if any, ) See EFDA
  recommendations
• EFDA recommendations
• For this meeting one shall discuss the
  deliverables on the Task Agreement and produce
  the minutes (this is responsibility of the
  leading Association).
• For later a detailed report is due (by January or
  beginning of February 2010) which is a gathering
  of the individual reports from the associations
  and a summary report from the leading association
  mentioning the activities performed and the
  relation between the due deliverables and
  expenditures at date.
• A template will be sent later as EFDA is
  preparing one possible format at the moment.
• TASK AGREEMENT WP08-GOT-ITER_PPE

7
Training on Nuclear engineering Dates From
Tuesday 8/12/09 to Friday 11/12/09 Location
Cadarache Training Building n143 Training
organisation AREVA TA Objectives Understanding
the basic nuclear phenomena, radiation
protection, safety and approach the specificities
of a basic nuclear installation.
Program Tuesday             Presentation of the
training on nuclear engineering and its
objectives             Nuclear physics
(Neutronics, Fission/fusion reaction, particle,
matter interaction) Wednesday
Radiological risk             General rules on
radiation protection             Risk prevention
and protection rules             The ALARA
principle design and operating
applications Thursday             Review of the
french approach to nuclear safety
Visit of nuclear installations on the AREVA TA
site RNG reactor and associated
installations Friday             Review of safety
objectives of ITER             Visit of nuclear
installations on the CEA/Cadarache site BNI
LECA/STAR             Course overview and
debriefing
