Molecules of Life

1
Molecules of Life

• Chapter 2
• Part 1

2
2.1 Impacts/IssuesFear of Frying

• All living things consist of the same kinds of
  molecules, but small differences in the ways they
  are put together have big effects on health
• Artificial trans fats found in manufactured and
  fast foods raise cholesterol and increase risk of
  atherosclerosis, heart attack, and diabetes

3
Video Fear of frying
4
Fear of Frying

• Trans fats are made by adding hydrogen atoms to
  liquid vegetable oils

5
trans fatty acid
Fig. 2-1, p. 20
6
2.2 Start With Atoms

• All substances consist of atoms
• Atom
• Fundamental building-block particle of matter
• Lifes unique characteristics start with the
  properties of different atoms

7
Subatomic Particles and Their Charge

• Atoms consist of electrons moving around a
  nucleus of protons and neutrons
• Electron (e-)
• Negatively charged subatomic particle that
  occupies orbitals around the atomic nucleus
• Charge
• Electrical property of some subatomic particles
• Opposite charges attract like charges repel

8
Subatomic Particles in the Nucleus

• Nucleus
• Core of an atom, occupied by protons and neutrons
• Proton (p)
• Positively charged subatomic particle found in
  the nucleus of all atoms
• Neutron
• Uncharged subatomic particle found in the atomic
  nucleus

9
An Atom
10
an atom
Fig. 2-2a, p. 21
11
Elements Different Types of Atoms

• Atoms differ in numbers of subatomic particles
• Element
• A pure substance that consists only of atoms with
  the same number of protons
• Atomic number
• Number of protons in the atomic nucleus
• Determines the element

12
Elements in Living Things

• The proportions of different elements differ
  between living and nonliving things
• Some atoms, such as carbon, are found in greater
  proportions in molecules made only by living
  things the molecules of life

13
Same Elements, Different Forms

• Isotopes
• Forms of an element that differ in the number of
  neutrons their atoms carry
• Changes the mass number, but not the charge
• Mass number
• Total number of protons and neutrons in the
  nucleus of an elements atoms

14
Radioactive Isotopes

• Radioisotope
• Isotope with an unstable nucleus, such as carbon
  14 (14C)
• Radioactive decay
• Process by which atoms of a radioisotope
  spontaneously emit energy and subatomic particles
  when their nucleus disintegrates

15
Carbon 14 A Radioisotope

• Most carbon atoms have 6 protons and 6 neutrons
  (12C)
• Carbon 14 (14C) is a radioisotope with six
  protons and eight neutrons
• When 14C decays, one neutron splits into a proton
  and an electron, and the atom becomes a different
  element nitrogen 14 (14N)

16
Radioactive Tracers

• Researchers introduce radioisotope tracers into
  living organisms to study the way they move
  through a system
• Tracers
• Molecules with a detectable substance attached,
  often a radioisotope
• Used in research and clinical testing

17
Why Electrons Matter

• Electrons travel around the nucleus in different
  orbitals (shells) atoms with vacancies in their
  outer shells tend to interact with other atoms
• Atoms get rid of vacancies by gaining or losing
  electrons, or sharing electrons with other atoms
• Shell model
• Model of electron distribution in an atom

18
Shell Models
19
Fig. 2-3 (top), p. 22
20
Fig. 2-3 (a-c), p. 22
21
1 proton
1
2
1 electron
first shell
hydrogen (H)
helium (He)
8
10
6
second shell
carbon (C)
oxygen (O)
neon (Ne)
11
17
18
third shell
sodium (Na)
chlorine (Cl)
argon (Ar)
Fig. 2-3 (a-c), p. 22
22
Stepped Art
Fig. 2-3 (a-c), p. 22
23
Animation Shell models of common elements
24
Ions

• The negative charge of an electron balances the
  positive charge of a proton in the nucleus
• Changing the number of electrons may fill its
  outer shell, but changes the charge of the atom
• Ion
• Atom that carries a charge because it has an
  unequal number of protons and electrons

25
Ion Formation
26
electron gain
Chlorine atom
17p
17
17e
charge 0
Chloride ion
17
17p
18e
charge 1
Sodium atom
electron loss
11p
11
11e
charge 0
Sodium ion
11
11p
10e
charge 1
Fig. 2-4, p. 23
27
Fig. 2-4a, p. 23
28
electron gain
Chlorine atom
17p
17
17e
charge 0
Chloride ion
17p
17
18e
charge 1
Fig. 2-4a, p. 23
29
Fig. 2-4b, p. 23
30
electron loss
Sodium atom
11p
11
11e
charge 0
Sodium ion
11
11p
10e
charge 1
Fig. 2-4b, p. 23
31
Stepped Art
Fig. 2-4, p. 23
32
Animation How atoms bond
33
Animation PET scan
34
Animation The shell model of electron
distribution
35
Animation Subatomic particles
36
Animation Atomic number, mass number
37
Animation Electron arrangements in atoms
38
Animation Isotopes of hydrogen
39
Video ABC News Nuclear Energy
40
Animation Electron distribution
41
2.3 From Atoms to Molecules

• Atoms can also fill their vacancies by sharing
  electrons with other atoms
• A chemical bond forms when the electrons of two
  atoms interact
• Chemical bond
• An attractive force that arises between two atoms
  when their electrons interact

42
From Atoms to Molecules

• Molecule
• Group of two or more atoms joined by chemical
  bonds
• Compound
• Type of molecule that has atoms of more than one
  element

43
Referring to a Molecule
44
Same Materials, Different Results
45
Animation Building blocks of life
46
Ionic Bonds and Covalent Bonds

• Depending on the atoms, a chemical bond may be
  ionic or covalent
• Ionic bond
• A strong mutual attraction formed between ions of
  opposite charge
• Covalent bond
• Two atoms sharing a pair of electrons

47
An Ionic Bond Sodium Chloride
48
ionic bond
11
17
sodium ion (Na)
chloride ion (Cl)
p. 24
49
Covalent Bonds

• Molecular hydrogen (HH) and molecular oxygen
  (OO)

50
1
1
molecular hydrogen (H2)
8
8
molecular oxygen (O2)
p. 24
51
Polarity

• A covalent bond is nonpolar if electrons are
  shared equally, and polar if the sharing is
  unequal
• Polarity
• Any separation of charge into distinct positive
  and negative regions

52
Polar and Nonpolar Covalent Bonds

• Nonpolar
• Having an even distribution of charge
• When atoms in a covalent bond share electrons
  equally, the bond is nonpolar
• Polar
• Having an uneven distribution of charge
• When the atoms share electrons unequally, the
  bond is polar

53
Importance of Polar Molecules

• A water molecule (H-O-H) has two polar covalent
  bonds the oxygen is slightly negative and the
  hydrogens are slightly positive which allows
  water to form hydrogen bonds

54
p. 25
55
1
8
1
water (H2O)
p. 25
56
Hydrogen Bonds

• Hydrogen bond
• Attraction that forms between a covalently bonded
  hydrogen atom and another atom taking part in a
  separate covalent bond

57
hydrogen bond
p. 25
58
Importance of Hydrogen Bonds

• Hydrogen bonds form and break more easily than
  covalent or ionic bonds they do not form
  molecules
• Hydrogen bonds impart unique properties to
  substances such as water, and hold molecules such
  as DNA in their characteristic shapes

59
Animation Ionic bonding
60
Animation Examples of hydrogen bonds
61
Video ABC News Fuel Cell Vehicles
62
Animation Sucrose synthesis
63
Animation Covalent bonds
64
2.4 Water

• All living organisms are mostly water, and all
  chemical reactions of life are carried out in
  water
• Hydrogen bonds between water molecules give water
  unique properties that make life possible
• Capacity to dissolve many substances
• Cohesion (surface tension)
• Temperature stability

65
Polarity and theUnique Properties of Water
66
Fig. 2-7a, p. 26
67
slight negative charge
slight positive charge
slight positive charge
Fig. 2-7a, p. 26
68
Fig. 2-7b, p. 26
69
Fig. 2-7c, p. 26
70
Animation Structure of water
71
Water and Solutions

• Polar water molecules hydrogen-bond to other
  polar (hydrophilic) substances, and repel
  nonpolar (hydrophobic) substances
• Hydrophilic (water-loving)
• A substance that dissolves easily in water
• Hydrophobic (water-dreading)
• A substance that resists dissolving in water

72
Water and Solutions

• Water is an excellent solvent
• Solvent
• Liquid that can dissolve other substances
• Solute
• A dissolved substance

73
Water and Solutions

• Salts, sugars, and many polar molecules dissolve
  easily in water
• Salt
• Compound that dissolves easily in water and
  releases ions other than H and OH-
• Example sodium chloride (NaCl)

74
Water and Solutions

• Water molecules surround the atoms of an ionic
  solid and pull them apart, dissolving it

75
Animation Spheres of hydration
76
Temperature Stability

• Temperature stability is an important part of
  homeostasis
• Water absorbs more heat than other liquids before
  temperature rises
• Hydrogen bonds hold ice together in a rigid
  pattern that makes ice float
• Temperature
• Measure of molecular motion

77
Cohesion

• Cohesion helps sustain multicelled bodies and
  resists evaporation
• Cohesion
• Tendency of water molecules to stick together
• Evaporation
• Transition of liquid to gas
• Absorbs heat energy (cooling effect)

78
2.5 Acids and Bases

• Water molecules separate into hydrogen ions (H)
  and hydroxide ions (OH-)
• pH
• A measure of the number of hydrogen ions (H) in
  a solution
• The more hydrogen ions, the lower the pH
• Pure water has neutral pH (pH7)
• Number of H ions OH- ions

79
Acids and Bases

• Acid
• Substance that releases hydrogen ions in water
• pH less than 7
• Base
• Substance that releases hydroxide ions (accepts
  hydrogen ions) in water
• pH greater than 7

80
A pH Scale
81
0
battery acid
1
gastric fluid
acid rain
2
lemon juice
cola
vinegar
more acidic
3
orange juice
tomatoes, wine
4
bananas
beer
bread
5
black coffee
urine, tea, typical rain
corn
6
butter
milk
pure water
7
blood, tears
egg white
8
seawater
baking soda
detergents
9
Tums
toothpaste
10
hand soap
milk of magnesia
more basic
11
household ammonia
12
hair remover
bleach
13
oven cleaner
14
drain cleaner
Fig. 2-9, p. 27
82
Animation The pH scale
83
Acid Rain

• Sulfur dioxide and other airborne pollutants
  dissolve in water vapor to form acid rain

84
Buffer Systems

• Most molecules of life work only within a narrow
  range of pH essential for homeostasis
• Buffers keep solutions in cells and tissues
  within a consistent range of pH
• Buffer
• Set of chemicals that can keep the pH of a
  solution stable by alternately donating and
  accepting ions that contribute to pH

85
CO2 and the Bicarbonate Buffer System

• CO2 forms carbonic acid in water
• CO2 H2O ? H2CO3 (carbonic acid)
• Bicarbonate buffer system
• Excess H combines with bicarbonate
• H HCO3- (bicarbonate) ? H2CO3

86
Video ABC News Bottle Backlash
87
Video ABC News Water Use
88
Video ABC News Water Wars
89
3D Animation Dissolution
