Title: Welcome to Siemens


1
Welcome to Siemens
2
Power Generation Product Service Scope
Group Executive Management
Klaus Voges, Andreas Kley, Norbert König, Randy
Zwirn
Industrial Applications (I)
Fossil Power Generation (F)
Stationary Fuel Cells (SFC)
  • Small turbines and power plants
  • Turbocompressors and drives
  • Service
  • Gas turbines and Econopacs
  • Gas turbine power plants and combined-cycle
    plants
  • Steam turbines and power plants
  • Electrical generators
  • Service

JV (Siemens stake 34) Framatome
Advanced Nuclear Power
Power Generation
Alstom Industrial Turbines)
Instrumentation Controls for Power Generation
(L)
JV (Siemens stake 35) Voith Siemens Hydro
  • Instrumentation and control systems
  • IT solutions for power plant management
  • Service

Regional offices worldwide
Integrated global network for Power Generation
) Closing of the acquisition is subject to
approval by the relevant antitrust authorities.
3
Business Figures 2002 vs. 2001 (FY) PG Total
10,586 9,446 234 309
1,582 25,945
12,219 8,563 235 262
634 26,485
New Orders Sales Capital expenditures and
investments Research and development EBITA
2) Number of employees
2002 1)
2001 1)
Power Generation
Figures in millions of EUR, unless stated
otherwise 1) Fiscal year (October 1 - September
30) 2) Earnings Before Interest, Taxes and
Amortization
4
The acquisition of ALSTOMs Industrial Turbine
Business
Oil and Gas
Industrial Power Plants
Turbines/ Drives
Steam Turbine
Generator Sets
Steam Turbine Combined Heat and
Power Gas Turbine
Tempest
Pump Sets
Electric Drive
Typhoon
Compressor Sets
Gas Turbine
Cyclone
Typhoon
Cyclone
... will enable us to satisfy our customer needs
from one source
5
Small Industrial Gas Turbines - Lincoln
6
Key Facts Figures
  • Main Markets Industrial Power Generation
  • Oil and Gas
  • Annual Sales 375 million
  • Employees 2,300
  • Experience 3,335 machines
  • 88 countries
  • 172 million operating hours
  • Market Share No.2

7
Main Products Services
  • High efficiency industrial gas turbines up to
    13MW
  • Design, Manufacture, Installation and
    Commissioning
  • Advanced Technology
  • Financing
  • Lifetime Customer Support

8
EDEN
  • Electronic Data Exchange Network
  • Offers operator benefits through improved
    performance monitoring and resultant plant
    optimisation
  • Reduced downtime as problems can be resolved
    on-line quickly and efficiently
  • Real time information available to quantify
    performance and indicate corrective action
  • Extended service intervals as component life can
    be calculated from actual data
  • Remote software upgrades possible without site
    visit

9
Industrial Gas Turbine Family
  • High Efficiency
  • Long Life
  • Low Emissions
  • Dual Fuel
  • Steam Injection

MW ratings nominal
10
Advanced Technology - Emissions
  • Natural Gas
  • Less than 25 ppm NOx (Typhoon Mechanical Drive
    40 ppm)
  • Less than 25 ppm CO
  • Less than 10ppm UHC
  • No visible smoke
  • Distillate
  • Less than 50 ppm NOx (Typhoon Mechanical Drive,
    Tornado Cyclone 60 ppm)
  • Less than 50 ppm CO
  • Less than 20ppm UHC
  • No visible smoke
  • Tempest Cyclone
  • Less than 10 ppm NOx on Natural Gas for US Market
  • Data is full load, ISO conditions

11
Emissions Control
  • Siemens is committed to environmental issues
  • Dry Low Emissions Technology
  • Simplicity principle
  • State-of-the-art NOx/ CO control
  • No operational tuning
  • Dual fuel configuration
  • Leading Position in NOx control
  • Tempest
    Cyclone
  • Gas fuel Market leader lt10 ppmV
    Market leader lt10 ppmV
  • Liquid fuel State-of-the-art lt25 ppmV
    Market leader lt55 ppmV

Unrivaled Emissions Performance
12
DLE Design Objectives
  • Full engine range read across
  • Standardized components
  • Off design point operation
  • VGV schedule for turndown
  • Bleed for additional turndown on two shaft
    applications

16
40
12
30
_at_ 15 O2 (ppmvd)
NOx
CO
8
20
4
10
Gas Operation
0
0
Load ()
0
20
40
60
80
100
Unrivaled Emissions Performance
13
DLE Achievements
  • Entered Commercial Operation 1995
  • 200 DLE units worldwide
  • DLE Operation gt 2,000,000 Hours
  • Lead Engine gt 50,000 Hours
  • No extended commissioning required
  • No reduction in component life
  • NOx Achieved
  • 5-20 ppmV on Gas
  • 25-50 ppmV on Liquid
  • CO - Negligible
  • Dual fuel DLE operational
    since April98

Unrivaled Emissions Performance
14
Dual Fuel DLE System
  • Dual fuel DLE capability fuel changeover in
    both directions
  • Simple design
  • Low dynamics

Basic 2 Stream Liquid Fuel System
Pilot Burner
Double Skin Impingement Cooled Combustor
Igniter
Liquid Core
Main Burner
Unrivaled Emissions Performance
15
Wide Fuel Capability
  • Gas fuel DLE Typhoon in, service on Mittelplate
    1997.
  • Rich gas composition with Wobbe Index gt50MJ/m3
  • Temperature corrected Wobbe _at_ 780C - 48MJ/m3
  • Hours run gt 35,000

Mittelplate - Offshore Germany
CURRENT DLE CAPABILITY RANGE -
TEMPERATURE CORRECTED WOBBE INDEX
48.6MJ/m3
37.3 MJ/m3
Gas supply heated to 78OC - 48MJ/m3
Gas at nominal supply temperature - 50MJ/m3
Planned Development to 54.0MJ/m3
UK Nat Gas 45.3MJ/m3
Mittelplate - Offshore Germany
Unrivaled Emissions Performance
16
DLE Users in Oil Gas
124 Units with 500,000 hours operation
Unrivaled Emissions Performance
17
DLE Users - Onshore Oil Gas
74 Units with 250,000 hours operation
Unrivaled Emissions Performance
18
DLE Users - Offshore Oil Gas
74 Units with 250,000 hours operation
Unrivaled Emissions Performance
19
Experience
  • Annual sales 260 million
  • Total engine sales to date 3330 - 80 for export
  • 170 Million running hours
  • 512 Turbines have achieved 100,000 hours
  • 177 Turbines have achieved 150,000 hours
  • 52 Turbines have achieved 200,000 hours

20
Gazprom
  • Urengoi to Uzhgorod gas pipeline
  • 67 x 3 MW TB5000 Generators
  • Ordered in 1984
  • Operating

21
Krasnodar Heat and Power
  • District Heating
  • 2 x 4 MW Typhoon Generators
  • Location - Krasnodar
  • Ordered in 1995
  • Operating

22
Surgutneftegas
  • Tyanskoe oilfield in Western Siberia
  • Pilot well head gas burning power plant
  • 3 x 6.7 MW Tornado generators
  • Ordered in 1999
  • Operating

23
Caspian Pipeline Consortium
  • Tengiz to Novorosisk oil pipeline
  • 10 x 5 MW Typhoon Generators
  • 7 x 5 MW Typhoon crude oil pumps
  • Ordered in 1999
  • Operating

24
Sakhalin Energy
  • Molikpak platform
  • Offshore platform for early oil production
  • 6 x Gas turbines for power generation, gas
    re-injection and water injection.
  • Ordered in1997 - 2001
  • Operating

25
TOTAL FINA ELF
  • Kharyaga Oil Field in North Western Siberia
  • 4 x 6.7 MW Tornado generators
  • Russian suppliers used
  • Packaged in Russia
  • Ordered in 2001
  • Operating

26
Turkmenneft
  • Barsa-Gelmes, Western Turkmenistan
  • 1 x 5 MW Typhoon generator
  • Ordered in 2001
  • Operating

27
Togliatti AZOT
  • Togliatti AZOT Ammonia Export Terminal on Black
    Sea coast
  • 1 x 7 MW Tornado ammonia compressor driver
  • Ordered in 2002
  • Delivery phase

28
Severnaya Neft
  • Severnaya Neft for Khasyreyskoye Oil Field in
    Komi Rebublic
  • 2 x 4.70MW Typhoon generator packages
  • Ordered in 2003
  • Under manufacture

29
