AUTOMOTIVE PRODUCTS

1

• AUTOMOTIVE PRODUCTS

2
Automotive Lubricants
Gear Transmission Oils
Engine Oils
A.E.G.O
Greases
Specialties
Brake Fluid
Shock Absorber Oil
Radiator Coolant
3
A Bit About Lubricants..!!!
4
How is a Lubricant made?

• BASE OIL ADDITIVES
• FINISHED LUBRICANT

5
ADDITIVES

• ANTI OXIDANTS
• ANTI WEAR AGENTS
• DETERGENTS
• DISPERSANTS
• DEFOAMERS
• POUR POINT DEPRESSANTS
• VI IMPROVERS
• DEMULSIFIERS
• EXTREME PRESSURE AGENTS
• RUST INHIBITOR
• EMULSIFIER
• METAL DEACTIVATOR
• GELLING AGENT
• BACTERICIDES

6
PHYSICAL SPECIFICATIONS

• VISCOSITY
• SAE NUMBER (10W,20W,30,40 etc)
• ISO VG NUMBER (100,150,220,320,460,680,1000
  etc)
• HARDNESS
• NLGI NUMBER (1, 2,3 etc)

STANDARD SPECIFICATIONS

• API AMERICAN PETROLEUM INSTITUTE
• MIL-L U. S MILITARY SPECS
• BIS INDIAN STANDARDS
• ACEA ASSN DES CONSTRUCTEURS EUROPEENS DE
• JASO JAPANESE AUTOMOBILE STANDARDS ORG
• AGMA AMERICAN GEAR MANUFACTURERS ASSN

7
SAE J 300 DEC 95
Low temperature Viscosities Low temperature Viscosities Low temperature Viscosities Low temperature Viscosities High Temp. Viscosities High Temp. Viscosities High Temp. Viscosities
SAE Visco. Grade Cranking (cP), max. , at Temp. ( oC ) Cranking (cP), max. , at Temp. ( oC ) Pumping (cP), max., with no yield stress at Temp. ( oC ) Pumping (cP), max., with no yield stress at Temp. ( oC ) Kinematic (cSt), _at_ 100 oC min max Kinematic (cSt), _at_ 100 oC min max (cP),_at_ 150oC High Shear 106 s-1, min
0W 3250 (-30) 60,000 (-40) 3.8
5W 3500 (-25) 60,000 (-35) 3.8
10W 3500 (-20) 60,000 (-30) 4.1
15W 3500 (-15) 60,000 (-25) 5.6
20W 4500 (-10) 60,000 (-20) 5.6
25W 6000 (-5 ) 60,000 (-15) 9.3
Contd
8
SAE J 300 DEC 95
Low temperature Viscosities Low temperature Viscosities Low temperature Viscosities Low temperature Viscosities High Temp. Viscosities High Temp. Viscosities High Temp. Viscosities
SAE Visco.Grade Cranking (cP), max. , at Temp. ( oC ) Cranking (cP), max. , at Temp. ( oC ) Pumping (cP), max., with no yield stress at Temp.( oC ) Pumping (cP), max., with no yield stress at Temp.( oC ) Kinematic (cSt), _at_ 100 oC min max Kinematic (cSt), _at_ 100 oC min max (cP),_at_ 150oC High Shear 106 s-1, min
20 5.6 lt9.3 2.6
30 9.3 lt12.5 2.9
40 12.5 lt16.3 2.9 (0W-40,5W-40, 10W-40 grades)
40 12.5 lt16.3 3.7 (15W-40, 20W-40, 25W-40, 40 grades)
50 16.3 lt21.9 3.7
60 21.9 lt26.1 3.7
9
"S" SERVICE STATION CLASSIFICATIONS
SA Oil without additive
SB Formerly for Utility Gasoline and Diesel Service under very mild conditions
SC Oil with some anti-oxidation anti-scuff capabilities
SD Minimum duty Gasoline engine Service
SE Oil providing control of high and low temperature sludge deposit, wear, rust and corrosion in gasoline engines
10
"S" SERVICE STATION CLASSIFICATIONS
SF 1964 to 1967 Gasoline Engine Warranty Maintenance Service
SG Oil providing more protection to engines than API SC grade.
SH 1968 to 1971 Gasoline Engine Warranty Maintenance service
SJ Oil providing better control than API SD grade against high temperature sludge deposition, oil oxidation, rust and corrosion gasoline engines.
11
"C" COMMERCIAL FLEET CLASSIFICATIONS
CA Light Duty Diesel Engine Service. Protection from bearing corrosion ring belt deposits in naturally aspirated diesel engines
CB Moderate Duty Diesel Engine Service. Protection from bearing corrosion from high temperature deposits in normally aspirated diesel engines with high sulfur fuels.
CC Moderate to Severe Duty Diesel certain heavy duty Gasoline engines. Protection from high temperature deposits bearing corrosion in these diesel engines also from rust, corrosion low temperature deposits in Gasoline engines.
CD Naturally aspirated, turbocharged or super charged Diesel Engine Service. Highly effective control of wear deposits when using fuels of a wide quality range, including sulfur fuels. Oil providing protection from bearing corrosion from high temperature deposits in these diesel engines.
CD-II Severe Duty Two stroke Cycle Diesel Engine Service. Oil meets all performance requirements of API CD
12
"C" COMMERCIAL FLEET CLASSIFICATIONS
CE Diesel Engine service for certain turbo-charged or supercharged heavy duty diesel engine operated under both slow speed, high load high speed, high load conditions. Oil enables controlled oil consumption oil thickening, formation of deposits on pistons reduced wear in relation to API CD oil.
CF-4 Exceeds requirements of API CE.Improved control on oil consumption and piston deposits. 1990 and later Diesel Engine Warranty Maintenance Services.
CF Service typical of Indirect-injected diesel engines and other diesel engines using broad range of fuel types including high sulfur fuels (over 0.5 by wt.) In existence since 1994.
CF-2 For severe duty two-stroke diesel engine service. Requires highly effective control on wear and deposits. In existence since 1994. Can be used wherever a CD-II type of oil is recommended.
13
"C" COMMERCIAL FLEET CLASSIFICATIONS
CG-4 For use in high-speed four-stroke diesel engines used in both on heavy-duty on-highway (0.05 wt. sulfur fuel) and off-highway (less than 0.05 wt sulfur fuel) Designed to meet 1994 exhaust emission standards.
CH-4 Suitable for high-speed, four-stroke diesel engines designed to meet 1998 exhaust emission standards and are specifically compounded for use with diesel fuels ranging in sulfur content up to 0.5 weight. Superior in performance to those meeting API CF-4 and API CG-4 and can effectively lubricate engines calling for those API Service Categories. 1998 Severe-Duty Diesel Engine Service
14
IS 13656 1993
15
Viscosity Classification for Automotive Gear Oils
(SAE J 306 MARCH '85)
16
NLGI CLASSIFICATION OF GREASESNational
Lubricating Grease Institute

NLGI Number Worked Penetration
000 445 457
00 400 430
0 355 385
1 310 340
2 265 295
3 220 250
4 175 205
5 130 160
6 85 - 115
_at_ 25OC, after working 60 strokes.
17
Engine Oils
Diesel Engine Oils
Petrol Engine Oils
Petrol Engine Oils for 2 Stroke Engines
Petrol Engine Oils for 4 Stroke Engines
Petrol Engine Oils for Cars
Petrol Engine Oils for 4 Stroke Bikes
18
FUNCTIONS OF ENGINE OILS

• PERMIT EASIER STARTING
• LUBRICATE AND PREVENT WEAR
• REDUCE FRICTION
• PROTECT AGAINST RUST AND CORROSION
• KEEP ENGINE INTERIORS CLEAN
• COOL ENGINE PARTS
• SEAL COMBUSTION PRODUCTS
• BE NON-FOAMING
• AID FUEL ECONOMY

19
WHY USE MULTI-GRADES ?

• TO AVOID SEASONAL OIL CHANGES
• TO HELP IN REDUCING EXHAUST EMISSIONS
• TO REDUCE OIL CONSUMPTION
• TO HELP IN COLD STARTING
• TO REDUCE DRAIN OF BATTERY AT START
• POSSIBLE SAVINGS IN FUEL CONSUMPTION UPTO 25
• REDUCED ENGINE WEAR AT START.

20
Viscosity / Temperature Relationship

• Too Thick when cold

Thick
SAE 40
SAE 10W40
Increasing Viscosity
SAE 10W
Too Thin when hot
Thin
100oc
0oc
Engine operating temperature
Winter starting temperature
21
Petrol Engine Oils
4 Stroke Engines
2 Stroke Engines

• Petrol Engine Oils for
• Cars
• HP Extra Super Motor Oil 20W-40
• HP Extra Super Motor Oil 20W-50
• HP Cruise
• HP SJX 15W-40

• Petrol Engine Oils for
• 2 Stroke Bikes/Scooters/Auto
• HP Racer 2
• HP Sundari

• Petrol Engine Oils for
• 4 Stroke Bikes
• HP Racer 4

22
Diesel Engine Oils
Premium Oils
Engine Oils for Cost Driven Market

• HP Milcy Power
• HP Milcy Toofan
• HP Milcy Super
• HP Milcy 30, 40
• Hylube X-3 10W, 30, 40
• Hylube HDX Multi Grade 20W-40

• HP Laal Ghoda Plus
• HP Laal Ghoda 20W-40

• HP Supertrak 20W-40
• HP Tractor Oil
• HP Pump Set Oil

• HP Laal Ghoda Tractor Oil
• HP Pump Set Oil

23
PETROL ENGINE OILS
24
2-STROKE ENGINE OILS
25
TYPES OF LUBRICATION SYSTEMIN TWO STROKE ENGINES

• PREMIX
• SEPERATE LUBE INJECTION/ AUTO LUBE

26
PERFORMANCE REQUIREMENTS OF TWO STROKE ENGINE OIL

• LUBRICITY / MISCIBILITY
• DETERGENCY
• LOW SMOKE
• RESISTANCE TO EXHAUST PORT BLOCKING
• LOW TEMPERATURE FLUIDITY / STABILITY
• ANTI RUST PROPERTY

27
HP RACER 2 PUNCH LINES

• SEMI-SYNTHETIC
• CLEANER BURNING COMPONENT
• ENGINE ENVIRONMENT FRIENDLY
• MEETS JASO M345 FC SPECS

28
HP RACER 2

• PERFORMANCE BENEFITS
• Environmental friendly with very low visible
  smoke emission.
• Maximises engine power life.
• Minimises deposit formation pre-ignition.
• Quick Start
• Ideal for modern engines with oil injection
  system as well as conventional engines.

APPLICATION AREAS All Air-cooled two stroke
engines- Scooters, Motorcycles, Mopeds Three
Wheelers. SPECIFICATION API TC JASO M 345 FC
Ketan1
29
HP SUNDARI

• DESCRIPTION
• Premium Quality Semi-Synthetic low smoke engine
  oil for 2/3 wheelers
• SPECIFICATIONS
• API TC
• JASO M-345FC
• APPLICATION AREAS
• All 2-stroke Petrol engines
• SPECIAL FEATURES
• Special Engine Care
• Fuel Economy
• Low Smoke

Ketan1
30
REASONS WHY MOTOR AND DIESEL OILS MUST NOT BE
USED IN 2T ENGINES

• FACTOR RESULTS
• CRANKCASE OILS CONTAIN ZDDP HIGHER DEPOSITS
  SPARK PLUG FOULING
• HIGH ASH CONTENT PRE IGNITION DUE TO COMBUSTION
  DEPOSITS
• SINGLE GRADE OILS HAVE DEPOSITS SMOKE
• HIGHER VISCOSITY BASE OILS
• PRESENCE OF STABLE SEVERE DEPOSITS DUE TO POOR
  COMBUSTION
• POLYMER IN MULTIGRADES
• CRANKCASE OILS DO NOT CONTAIN POOR FUEL
  MISCIBILITY
• SOLVENT

31
ENGINE OIL FOR 4-STROKE 2-WHEELERS 4T OIL
32
WHY A 4T OIL IS DIFFERENT?
4T OIL
ENGINE HIGH OIL TEMP HIGH ENGINE SPEED
TRANSMISSION GEAR LUBRICATION
CLUTCH WET CLUTCH PERFORMANCE SHIFT FEEL
CHARACTERISTICS
ENHANCED SPEED, ANTISCUFF PERFORMANCE FOR
CYLINDER SCUFFING PREVENTION IMPROVED OXIDATION
STABILITY ANTISHUDDER AIRCOOLED
WET CLUTCH REQUIRES SPECIAL - FRICTION
CHARACTERISTICS -VISCOSITY
IMPROVED SHEAR STABILITY FOR GEAR
DURABILITY ENHANCED ANTIWEAR EXTREME PRESSURE
AGENTS FOR VALVE TRAIN PROTECTION
33
HOW A 4-STROKE BIKE IS DIFFERENT FROM OTHER
2/3-WHEELERS ?
2/3 WHEELERS OTHER THAN 4- STROKE BIKES ARE
HAVING A 2-STROKE ENGINE IN THEM THEY REQUIRE
CONVENTIONTIONAL 2T OILS FOR LUBRICATION WHERE
AS 4-STROKE 2-WHEELERS REQUIRE A SPECIAL OIL FOR
LUBRICATION
34
IT MEANS A FOUR STROKE BIKE IS MORE LIKE A CAR
WHICH IS HAVING A FOUR STROKE ENGINE..! NOT
REALLY
35
HOW LUBRICATION IS DIFFERENT IN A 4-STROKE
2-WHEELER AS COMPARED TO A CAR?
SINGLE LUBRICANT FOR Clutch Transmission En
gine other components in the crankcase
36
PROBLEMS WITH FRICTION MODIFIED OILS

• ENGINE START FAILURES
• (STARTER CLUTCH SLIPPAGE WITH FM OILS)
• NEGATIVE (NOT SMOOTH) RUNNING FEELING
  INCREASED FUEL CONSUMPTION DUE TO HIGHER ENGINE
  STALL SPEEDS
• MANUAL / MULTIPLE CLUTCH SLIDING DURING HIGH LOAD
  RUNNING
• BACK TORQUE LIMITER CLUTCH SLIDING DURING HIGH
  LOAD RUNNING OR WEAK BRAKE EFFECT
• GEAR PITTING

• LOW COEFFICIENT OF FRICTION
• MAY BE DUE TO THREE REASONS
• OILS VISCOUSITY
• FRICTION MODIFIERS
• MOLYBDENUM COMPOUNDS

37
HP RACER 4

• DESCRIPTION
• Multipurpose Engine oil for lubrication of
  Engine, Gear box wet Clutches in 4-Stroke
  2-Wheelers
• SPECIFICATIONS
• Meets API SG and JASO T 903 MA specs.
• APPLICATION AREAS
• All 4-stroke Motorcycles, Scooters,Mopeds
  Scooterettes
• SPECIAL FEATURES
• Optimized Co-efficient of Friction
• Excellent Oxidation stability
• Sludge Varnish Control
• Gear Anti-wear Extreme Pressure

HP RACER 4
38
ENGINE OIL FOR CARS
39
HP EXTRA SUPER MOTOR OIL 20W-40

• PERFORMANCE BENEFITS
• Outstanding engine cleanliness
• Excellent oxidation stability
• Improved wear protection
• Extended engine life
• Improved fuel economy
• All the year round protection
• Compatible with catalytic converter
• APPLICATION AREAS
• Engine oil for all passenger cars

SPECIFICATION API SF/CC, MIL-L-46152B
E-PL2/E-DL1 of IS 13656-1993
40
HP Cruise

• PERFORMANCE BENEFITS
• Outstanding engine cleanliness
• Excellent lubricity and wear protection, hence a
  low noise
• Extended engine life
• Improved fuel economy with 15W-40 Visco-matrix
• All the year round protection
• Compatible with catalytic converter
• SPECIFICATIONS
• API SG/CD, MIL-L-46152D, E-PL3/E-DL 2 OF
  IS136561993
• APPLICATIONS
• ENGINE OIL FOR ALL NEW GENERATION AS WELL AS ALL
  EXISTING CARS

HP Cruise
HP Cruise
41
DIESEL ENGINE OILS
42
HYLUBE HDX MULTIGRADE 20W-40

• PERFORMANCE BENEFITS
• Excellent engine protection under high
  temperature operation
• Good engine start up under cold conditions
• Better all-round performance

APPLICATION AREAS All four stroke diesel engines
for round the year operation SPECIFICATION API
CC/SC, MIL-L-2104B E-DL1/E-PL1 of IS 13656-1993
43
HYLUBE MILCY PUNCH LINES

• IDEAL DIESEL ENGINE OIL TAILORED ACCORDING TO
  INDIAN CONDITIONS
• LESS OIL THICKENING
• EXCELLENT TBN RETENTION
• LONGER DRAIN

MACK T-7
44
ADDITIONAL ADVANTAGES OF MULTIGRADES

• TO AVOID SEASONAL OIL CHANGES
• TO HELP IN REDUCING EXHAUST EMISSIONS
• TO REDUCE OIL CONSUMPTION
• TO HELP IN COLD STARTING
• TO REDUCE DRAIN OF BATTERY AT START
• POSSIBLE SAVINGS IN FUEL CONSUMPTION UPTO 25
• REDUCED ENGINE WEAR AT START.

HYLUBE MILCY HP MILCY SUPER
45
HYLUBE MILCY 30, 40 HP MILCY SUPER

• PERFORMANCE BENEFITS
• Extended TBN Quality reserves
• Prevents oil thickening and enhances oil life
• Possess absolute control of corrosive wear.
• Excellent thermal oxidation stability
• Superior diesel engine Protection for prolonged
  engine life
• Enhanced drain period
• Outstanding engine cleanliness

APPLICATION AREAS Heavy duty diesel engine oil
for both naturally aspirated supercharged
engines SPECIFICATION API CD MIL-L-2104CMack
T-7, EDL-3 of IS 13656-1993
46
HP MILCY TOOFAN
PERFORMANCE BENEFITSSuperior engine deposit
controlMinimize ring sticking liner
wear.Extended TBN quality reserves.Reduce oil
consumption better fuel economyProlonged
engine life.Suitable for wide temperatures
range.Minimum insoluble build upExcellent soot
sludge control
APPLICATION AREAS For turbo charged and
super-charged heavy duty diesel engines fitted in
both on and off highway services. Recommended for
DG sets and Earthmoving equipment as
well. SPECIFICATION API CF-4, E-DL3 of IS
13656-1993
47
HP MILCY POWER

• PERFORMANCE BENEFITS
• Superior engine deposit control
• Minimize ring sticking liner wear.
• Extended TBN quality reserves.
• Reduce oil consumption better fuel economy
• Prolonged engine life.
• Suitable for wide temperatures range.
• Minimum insoluble build up
• Excellent soot sludge control

APPLICATION AREAS For turbo charged and
super-charged heavy duty diesel engines fitted in
both on and off highway services. Recommended for
DG sets and Earthmoving equipment as
well. SPECIFICATION API CF-4, MIL-L 2104E,MB
228.1,CCMC D4 E-DL3 of IS 13656-1993
48
HP LAAL GHODA PUNCH LINES

• ATTACK SPURIOUS MARKET
• MARKET UPGRADATION BY ENSURING A MINIMUM QUALITY
  LEVEL
• TO MAKE A COSTWISE ATTRACTIVE HP BRAND
  AVAILABLE IN THE MARKET
• IMPROVE HP SHARE IN COST DRIVEN PERFORMANCE
  PURCHASE
• INCREASE OUR VALUE ADDED SALES

49
HP LAAL GHODA 20W-40

• PERFORMANCE BENEFITS
• Good Engine Cleanliness
• All round performance

APPLICATION AREAS All four stroke diesel engines
for round the year operation (product in Economy
range) SPECIFICATION API CC/SC, MIL-L-2104B
E-DL1/E-PL1 of IS 13656-1993
50
HP LAAL GHODA PLUS

• PERFORMANCE BENEFITS
• Very good thermal oxidation stability
• Effective control of piston deposits,
• Good protection against wear and
  copper-containing bearing corrosion

APPLICATION AREAS All four stroke diesel engines
for round the year operation (product in Economy
range) SPECIFICATION API CF
51
GEAR OILS
52
AUTOMOTIVE GEAR OILS

• FUNCTION
• TO PROVIDE LUBRICATION TO
• THE GEAR TEETH
• TO REDUCE EFFECTS OF
• FRICTION
• TO ACT AS A SILENCER
• TO CARRY AWAY FRICTIONAL
• HEAT

53
HP GEAR OIL EP 80, 90, 140

• SPECIAL FEATURES
• Multipurpose Gear oil containing extreme pressure
  additives for moderate service conditions
• SPECIFICATIONS
• API GL-4, MIL-L-2105
• EP Type GL-4 Level of IS11181992
• APPLICATION AREAS
• Hypoid gears manual transmissions of
  automobiles requiring this type of extreme
  pressure oils
• PERFORMANCE BENEFITS
• Excellent thermal chemical stability
• Protection against rust corrosion ensuring
  longer trouble free protection

54
HP GEAR OIL XP 80W, 90, 140

• SPECIAL FEATURES
• Multipurpose Gear oil containing extreme pressure
  additives for moderate as well as severe
  condition service
• SPECIFICATIONS
• API GL-5, MIL-L-2105B
• EP Type GL-5 Level of IS11181992
• APPLICATION AREAS
• Hypoid Differential Drive axles
• Manual transmissions of Automobiles
• PERFORMANCE BENEFITS
• Excellent thermal chemical stability
• Protection against rust corrosion ensuring
  longer trouble free protection
• Good performance even under extreme pressure
  varying load conditions

55
HP GEAR OIL XP 80W-90

• SPECIAL FEATURES
• Multipurpose Gear oil containing extreme pressure
  additives for moderate as well as severe
  condition service
• SPECIFICATIONS
• API GL-5, MIL-L-2105C/D
• EP Type GL-5 Level of IS11181992
• APPLICATION AREAS
• Hypoid Differential Drive axles
• Manual transmissions of Automobiles
• PERFORMANCE BENEFITS
• Excellent thermal chemical stability
• Protection against rust corrosion ensuring
  longer trouble free protection
• Good performance even under extreme pressure
  varying load conditions

56
HP LAAL GHODA GEAR OIL EP 90

• SPECIAL FEATURES
• Multipurpose Gear oil containing extreme pressure
  additives for moderate service conditions
• SPECIFICATIONS
• API GL-4, MIL-L-2105
• EP Type GL-4 Level of IS11181992
• APPLICATION AREAS
• Hypoid gears manual transmissions of
  automobiles requiring this type of extreme
  pressure oils
• PERFORMANCE BENEFITS
• Very good thermal chemical stability
• Protection against rust corrosion ensuring
  longer trouble free protection
• Good performance even under extreme pressure
  varying load conditions

57
AUTOMOTIVE COOLANT

• EFFECTIVE HEAT EXCHANGE FLUID
• CAPABLE OF PROVIDING FREEZING AND BOILING
  PROTECTION
• PROTECTION OF METALS AGAINST CORROSION
• COMPATIBILITY WITH PLASTIC AND ELASTOMERS
• CHEMICALLY STABLE AT HIGH AND LOW TEMPERATURES
• COMPATIBLE WITH HARD WATER
• LOW FOAMING
• ECOLOGICALLY AND TOXICOLOGICALLY ACCEPTABLE

58
HP THANDA RAJA

• SPECIAL FEATURES
• Ready to use Radiator Coolant with Anti Freeze
  Anti Corrosive Properties
• SPECIFICATIONS
• Meets JIS K 2234 of 1994
• APPLICATION AREAS
• All Diesel Vehicles,Passenger cars,Jeeps,Vans
  Tempos
• COMPOSITION
• 30 Concentration
• PERFORMANCE BENEFITS
• Effective Cooling
• Good Chemical Stability
• Excellent Protection against Rust Corrosion

59
HP KOOLGARD

• SPECIAL FEATURES
• Radiator Coolant
• SPECIFICATIONS
• Meets JIS K 2234 of 1994
• APPLICATION AREAS
• All Diesel Vehicles,Passenger cars,Jeeps,Vans
  Tempos
• COMPOSITION
• 100 Concentration
• PERFORMANCE BENEFITS
• Easy miscibility with water
• Effective Cooling
• Good Chemical Stability
• High Boiling Point Low Freezing point

60
BRAKE OIL
61
Brake System
62
HP SUPER DUTY BRAKE FLUID DOT-3

• SPECIAL FEATURES
• Superior Quality Synthetic Fluid meant for the
  hydraulic brakes of Automobiles.
• SPECIFICATIONS
• Meets U S Dept. of Transportations stringent
  specification FMVSS 116 DOT 3. It also meets
  IS86541986 SAE J 1703F specifications
• APPLICATIONS
• All Automobiles having hydraulic brakes
• PERFORMANCE BENEFITS
• Exceptional Thermal Stability
• Excellent Chemical Stability
• Good water tolerance
• Good Fluidity at Low temperatures

63
HP SUPER DUTY BRAKE FLUID DOT-4

• SPECIAL FEATURES
• Superior Quality Synthetic Fluid meant for the
  hydraulic brakes of Automobiles.
• SPECIFICATIONS
• Meets U S Dept. of Transportations stringent
  specification FMVSS 116 DOT 4. It also meets
  IS86541986 SAE J 1703F specifications
• APPLICATIONS
• All Automobiles having hydraulic brakes
• PERFORMANCE BENEFITS
• Exceptional Thermal Stability
• Excellent Chemical Stability
• Excellent water tolerance
• Good Fluidity at Low temperatures

64
GREASES
65
HP CHASSIS GREASE
DESCRIPTION Premium quality calcium soap
grease APPLICATION AREAS Designed for general
chassis lubrication. Also recommended for the
lubrication of track rollers and Idlers of
certain crawler type tractors.

• PERFORMANCE BENEFITS
• Excellent water resistance.
• Lasting qualities in spring shackles and steering
  connections.
• Acts as protective layer on exposed parts.
• Easily pumpable.
• Clings to bearing surfaces

66
HP MULTIPURPOSE GREASE 2 3
DESCRIPTION Premium quality multipurpose grease
suitable for all classes of service. APPLICATION
AREAS Recommended for all classes of service in
automotive lubrication. Wheel bearings, Chassis
fittings Grease cups, Grease lubricated type
universal joints also Water pumps bearings.

• PERFORMANCE BENEFITS
• High drop point.
• Good thermal resistance to oxidation.
• Protection against rusting corrosion

67
HP WHEEL BEARING GREASE
DESCRIPTION Sodium based premium quality
grease APPLICATION AREAS Lubrication of universal
joints, wheel bearings, High temperature clutch
release, Generator and Fan bearings.

• PERFORMANCE BENEFITS
• Trouble free long service
• Good structural stability under high temperature
  of centrifugal force.
• Easily pumpable.
• Does not channel when cold.

68
HP LAAL GHODA AP GREASE
DESCRIPTION Premium quality multipurpose grease
suitable for all classes of service. APPLICATION
AREAS Recommended for all classes of service in
automotive lubrication. Wheel bearings, Chassis
fittings Grease cups, Grease lubricated type
universal joints also Water pumps bearings.

• PERFORMANCE BENEFITS
• High drop point
• Good thermal resistance to oxidation.
• Protection against rusting corrosion.

69
(No Transcript)
