Title: Instrumentation Amplifier Noise Analysis


1
Instrumentation Amplifier Noise Analysis
2
Short Review of 3 Amp INA
3
Three Stage IA
4
Real World Input to Mathematical Model
5
Analyze the Input and Output Separately
6
Split Input Stage in Half
7
Use Superposition on Output Amp
8
Gain For Three Amp IA
9
Noise Model of 3 Amp INA
10
Complex Noise Model
11
The Complex Model is Simplified
12
The Input amplifier dominates at High Gain
G Total Input-Referred Noise (nV/rtHz) Total Output Noise (nV/rtHz)
1 206.2 206.2
2 111.8 223.6
5 64 320
10 53.9 539
100 50 5000
1000 50 50,000
13
Two Ways to represent INA Spectral Density
G Input-Referred Noise (nV/rtHz)
1 206.2
10 53.9
100 50
1000 50
G Input-Referred Noise (nV/rtHz)
1 110
10 12
100 8
1000 8
Calculated using graphs and formula
Taken directly from the graph
14
Hand Analysis of 3 Amp INA
15
Find the total RMS Noise Voltage at the Output
16
Look at Noise Sources Bridge, INA333,
Reference Buffer
17
Noise Equivalent Model for Reference Pin Buffer
18
Reference buffer
19
The reference voltage directly adds to the output
noise
20
The bridge generates thermal noise, in x
R_bridge
21
Noise From Bridge / Current Sources
22
Combine all the noise sources
23
Rule of 3x
24
(No Transcript)
25
(No Transcript)
26
Calculate RMS Output Noise for INA333 From
Voltage Noise
27
Simulation of 3 Amp INA
28
Simulate the Circuit
29
Using Tina Spice
30
Noise Spectral Density at the Output
31
Total RMS Noise at the Output
32
Why doesnt calculation match simulation exactly?
Bandwidth from Data Sheet and simulated bandwidth
is different.
The roll-off was approximated as first order in
the calculations. Simulation shows that it is
not first order.
33
Reduce Noise Using Averaging Circuit
34
Averaging Circuit
35
Noise in Averaging Circuit
36
Averaging Circuit with INA333
37
Experiment with 20 Parallel INA333
20 INA333 amps in parallel (jumper selectable)
Socketed Gain Set Resistors
OPA333 Averaging Circuit
38
Standard Noise Measurement Precautions
Linear Power Source
Steel Paint Can for Shielding
39
Total Output Noise vs Number of Amplifiers Being
Averaged
40
Measured vs simulated spectral density
41
References
  • 1 Hann, Gina. "Selecting the right op amp -
    Electronic Products." Electronic Products
    Magazine Component and Technology News. 21 Nov.
    2008. Web. 09 Dec. 2009. lthttp//www2.electronicpr
    oducts.com/Selecting_the_right_op_amp-article-facn
    texas_nov2008-html.aspxgt.
  • Henry W. Ott, Noise Reduction Techniques in
    Electronics Systems, John Wiley and Sons

Acknowledgments
  • R. Burt, Technique for Computing Noise based on
    Data Sheet Curves, General Noise Information
  • T. Green, General Information
  • B. Trump, General Information
  • Matt Hann, General INA information and review

Noise Article Series (www.en-genius.net)
http//www.en-genius.net/site/zones/audiovideoZONE
/technical_notes/avt_022508
42
Thank You for Your Interest in INA Noise
Calculation and Measurement
