Flattened Butterfly Topology for On-Chip Networks

• John Kim, James Balfour, and William J. Dally
• Presented by Jun Pang

2
Motivation Goal

• Most on-chip networks (2D mesh) low-radix
• Pros simple short wires
• Cons long network diameter energy inefficiency
  (many hops)
• High-radix networks
• Intermediate routers reduced a lot
• Small latency lower power
• Goal how does on-chip network use high-radix
  routers to reduce latency energy

3
On-chip network

• Plentiful bandwidth due to inexpensive wires
  while buffers are expensive
• lower cost from smaller distance
• By reducing number of channels buffers
• Concentration several terminal nodes share
  resources (routers)
• Latency
• Reduce hop count at the expense of TS?to get an
  overall reduced latency

4
On-chip Flattened Butterfly
Fig. 3a

• Topology
• Radix10(concentration factor4 3d1 3d2)
• 2 hops
• Longer wires-gt deeper buffers
• Non-minimal global adaptive routing (UGAL)
• Load balance performance path diversity
• Routing minimally or non-minimally
• Non-minimal minimal Direction-ordered routing
  (prevent deadlock)
• Only 2 VCs

5
Bypass Channels Microarchitecture

• Goal reduce distance traveled by packets to
  reduce latency and energy
• Two types of muxes
• Input muxes bypass inputs or direct inputs
• Output muxes direct outputs or bypass inputs
• Yield arbiter to guarantee global fairness
• If primary input is idle, non-primary input is
  chosen
• Control packet prevent starvation
• Combination of minimal and non-minimal routing

6
Bypass Channels (continue)

• Switch architecture
• Minimal simplified crossbar switch
• Non-minimal more complexity
• Non-minimal with bypass channels less complexity
• Flow control routing
• Buffers for non-primary inputs
• Separate buffers for destination of control
  packets
• Modify UGAL to support bypass channels

7
Evaluation

• Throughput up to 50 throughput increase
  compared to concentrated mesh
• Power about 38 power reduction compared to mesh
• Latency about 28 latency reduction compared to
  mesh

8
Scalability

• Lower channel increasing factor than hypercube
• Three ways to scale
• Concentrate factor
• Dimension of the flattened butterfly
• Hybrid approach
• Future technology helps long wires
• Increasing VCs will slightly reduce latency

9
Conclusion Concerns

• Flattened-butterfly
• interesting idea
• Maximum distance between nodes2
• Non-minimal routing to balance load
• Bypassing channel to reduce latency
• Lower latency and power, high throughput compared
  to mesh
• Concerns
• High channel count? (bigger than mesh torus)
• Low channel utilization? (due to high channel)
• Control complexity? (arbitration, control
  packets)
• Bypass channel good idea? (How about just use
  non-minimal or minimal?)
