Addressing Complexity in Emerging
Cyber-Ecosystems Experiments with Autonomic
Computational Science

• Manish Parashar
• Center for Autonomic Computing
• The Applied Software Systems Laboratory
• Rutgers, The State University of New Jersey
• In collaboration with S. Jha O. Rana

2
Outline of My Presentation

• Computational Ecosystems
• Unprecedented opportunities, challenges
• Autonomic computing A pragmatic approach for
  addressing complexity!
• Experiments with autonomics for science and
  engineering
• Concluding Remarks

3
The Cyberinfrastructure Vision

• Cyberinfrastructure integrates hardware for
  computing, data and networks, digitally-enabled
  sensors, observatories and experimental
  facilities, and an interoperable suite of
  software and middleware services and tools
• - NSFs Cyberinfrastructure Vision for 21st
  Century Discovery
• A global phenomenon several LARGE deployments
• UK National Grid Service (NGS) /European Grid
  Infrastructure (EGI), TeraGrid, Open Science Grid
  (OSG), EGEE, Cybera, DEISA, etc., etc.
• New capabilities for computational science and
  engineering
• seamless access
• resources, services, data, information,
  expertise,
• seamless aggregation
• seamless (opportunistic) interactions/couplings

4
Cyberinfrastructure gt Cyber-Ecosystems

• 21st century Science and Engineering
• New Paradigms Practices
• Fundamentally data-driven/data intensive
• Fundamentally collaborative

5
Unprecedented opportunities for
Science/Engineering

• Knowledge-based, information/data-driven,
  context/content-aware computationally intensive,
  pervasive applications
• Crisis management, monitor and predict natural
  phenomenon, monitor and manage engineered
  systems, optimize business processes
• Addressing applications in an end-to-end manner!
• Opportunistically combine computations,
  experiments, observations, data, to manage,
  control, predict, adapt, optimize,
• New paradigms and practices in science and
  engineering?
• How can it benefit current applications?
• How can it enable new thinking in science?

6
The Instrumented Oil Field (with UT-CSM, UT-IG,
OSU, UMD, ANL)
Detect and track changes in data during
production. Invert data for reservoir
properties. Detect and track reservoir
changes. Assimilate data reservoir properties
into the evolving reservoir model. Use
simulation and optimization to guide future
production.
Data Driven
Model Driven
7
Many Application Areas .

• Hazard prevention, mitigation and response
• Earthquakes, hurricanes, tornados, wild fires,
  floods, landslides, tsunamis, terrorist attacks
• Critical infrastructure systems
• Condition monitoring and prediction of future
  capability
• Transportation of humans and goods
• Safe, speedy, and cost effective transportation
  networks and vehicles (air, ground, space)
• Energy and environment
• Safe and efficient power grids, safe and
  efficient operation of regional collections of
  buildings
• Health
• Reliable and cost effective health care systems
  with improved outcomes
• Enterprise-wide decision making
• Coordination of dynamic distributed decisions for
  supply chains under uncertainty
• Next generation communication systems
• Reliable wireless networks for homes and
  businesses
• Report of the Workshop on Dynamic Data Driven
  Applications Systems, F. Darema et al., March
  2006, www.dddas.org

Source M. Rotea, NSF
8
The Challenge Managing Complexity, Uncertainty

• System
• Very large scales
• Disruptive trends
• many/multi-cores, accelerators, clouds
• Heterogeneity
• capability, connectivity, reliability,
  guarantees, QoS
• Dynamics
• Ad hoc structures, failure
• Distributed system!
• Lack of guarantees, common/complete knowledge,
• Emerging concerns
• Power, resilience,

• Data and Information
• Scale, heterogeneity
• Availability, resolution, quality
• Semantics, meta data, data models, provenance
• Trust in data, .
• Application
• Compositions
• Dynamic behaviors
• Dynamic and complex couplings
• Software/systems engineering issues
• Emergent rather than by design

9
The Challenge Managing Complexity, Uncertainty
(I)

• Increasing application, data/information, system
  complexity
• Scale, heterogeneity, dynamism, unreliability,
• New application formulations, practices
• Data intensive and data driven, coupled, multiple
  physics/scales/resolution, adaptive,
  compositional, workflows, etc.
• Complexity/uncertainty must be simultaneously
  addressed at multiple levels
• Algorithms/Application formulations
• Asynchronous/chaotic, failure tolerant,
• Abstractions/Programming systems
• Adaptive, application/system aware, proactive,
• Infrastructure/Systems
• Decoupled, self-managing, resilient,

10
The Challenge Managing Complexity, Uncertainty
(II)

• The ability of scientists to realize the
  potential of computational ecosystems is being
  severely hampered due to the increased complexity
  and dynamism of the applications and computing
  environments.
• To be productive, scientists often have to
  comprehend and manage complex computing
  configurations, software tools and libraries as
  well as application parameters and behaviors.
• Autonomics and self- can help ?
• (with the plumbing for starters)

11
Outline of My Presentation

• Computational Ecosystems
• Unprecedented opportunities, challenges
• Autonomic computing A pragmatic approach for
  addressing complexity!
• Experiments with autonomics for science and
  engineering
• Concluding Remarks

12
The Autonomic Computing Metaphor

• Current paradigms, mechanisms, management tools
  are inadequate to handle the scale, complexity,
  dynamism and heterogeneity of emerging systems
  and applications
• Nature has evolved to cope with scale,
  complexity, heterogeneity, dynamism and
  unpredictability, lack of guarantees
• self configuring, self adapting, self optimizing,
  self healing, self protecting, highly
  decentralized, heterogeneous architectures that
  work !!!
• Goal of autonomic computing is to enable
  self-managing systems/applications that addresses
  these challenges using high level guidance
• Unlike AI duplication of human thought is not the
  ultimate goal!

Autonomic Computing An Overview, M. Parashar,
and S. Hariri, Hot Topics, Lecture Notes in
Computer Science, Springer Verlag, Vol. 3566, pp.
247-259, 2005.
13
Motivations for Autonomic Computing
Sourcehttp//www.almaden.ibm.com/almaden/talks/Mo
rris_AC_10-02.pdf
2/27/07 Dow fell 546. Since worst plunge took
place after 230 pm, trading limits were not
activated
Source httpidc 2006
8/3/07 (EPA) datacenter energy use by 2011 will
cost 7.4 B, 15 power plants, 15 Gwatts/hour peak
8/1/06 UK NHS hit with massive computer outage.
72 primary care 8 acute hospital trusts
affected.
8/12/07 20K people 60 planes held at LAX after
computer failure prevented customs from screening
arrivals
Key Challenge Current levels of scale,
complexity and dynamism make it infeasible for
humans to effectively manage and control systems
and applications
14
Autonomic Computing A Pragmatic Approach

• Separation Integration Automation !
• Separation of knowledge, policies and mechanisms
  for adaptation
• The integration of selfconfiguration, healing,
  protection,optimization,
• Self- behaviors build on automation concepts and
  mechanisms
• Increased productivity, reduced operational
  costs, timely and effective response
• System/Applications self-management is more than
  the sum of the self-management of its individual
  components

M. Parashar and S. Hariri, Autonomic Computing
Concepts, Infrastructure, and Applications, CRC
Press, Taylor Francis Group, ISBN
0-8493-9367-1, 2007.
15
Autonomic Computing Theory

• Integrates and advances several fields
• Distributed computing
• Algorithms and architectures
• Artificial intelligence
• Models to characterize,
• predict and mine
• data and behaviors
• Security and reliability
• Designs
• and models of
• robust systems
• Systems and software architecture
• Designs and models of
• components at different IT layers
• Control theory
• Feedback-based control and estimation
• Systems and signal processing theory
• System and data models and optimization methods
• Requires experimental validation

• (From S. Dobson et al.,
• ACM Tr. on Autonomous Adaptive Systems,
• Vol. 1, No. 2, Dec. 2006.)

16
Some Information Sources

• Autonomic Computing Concepts, Infrastructure
  and Applications, M. Parashar and S. Hariri
  (Ed.), CRC Press, ISBN 0-8493-9367-1 (Available
  at http//www.crcpress.com/)
• NSF Center on Autonomic Computing
• http//nsfcac.rutgers.edu
• http//www.nsfcac.org
• Autonomic Computing Portal
• http//www.autnomiccomputing.org
• IEEE International Conference on Autonomic
  Computing
• http//www.autonomic-conference.org
• IEEE Task Force on Autonomous and Autonomic
  Systems
• http//tab.computer.org/aas/

17
Autonomics for Science and Engineering ?

• Autonomic computing aims at developing systems
  and application that can manage and optimize
  themselves using only high-level guidance or
  intervention from users
• dynamically adapt to changes in accordance with
  business policies and objectives and take care of
  routine elements of management
• Separation of management and optimization
  policies from enabling mechanisms
• allows a repertoire of a mechanisms to be
  automatically orchestrated at runtime to respond
  to heterogeneity, dynamics, etc.
• E.g., develop strategies that are capable of
  identifying and characterizing patterns at design
  and at runtime and, using relevant (dynamically
  defined) policies, managing and optimizing the
  patterns.
• Application, Middleware, Infrastructure

• Manage application/information/system complexity
• not just hide it!
• Enabling new thinking, formulations
• how do I think about/formalize my problem
  differently?

18
A Conceptual Framework for ACS (GMAC 07, with
S. Jha and O. Rana)

• Hierarchical
• Within and across level

19
Crosslayer Autonomics
20
Existing Autonomic Practices in Computational
Science (GMAC 09, SOAR 09, with S. Jha and O.
Rana)
Autonomic tuning of the application
Autonomic tuning by the application
21
Spatial, Temporal and Computational Heterogeneity
and Dynamics in SAMR
Temperature
Simulation of combustion based on SAMR (H2-Air
mixture ignition via 3 hot-spots)
OH Profile
Courtesy Sandia National Lab
22
Autonomics in SAMR

• Tuning by the application
• Application level when and where to refine
• Runtime/Middleware level When, where, how to
  partition and load balance
• Runtime level When, where, how to partition and
  load balance
• Resource level Allocate/de-allocate resources
• Tuning of the application, runtime
• When/where to refine
• Latency aware ghost synchronization
• Heterogeneity/Load-aware partitioning and
  load-balancing
• Checkpoint frequency
• Asynchronous formulations

23
Outline of My Presentation

• Computational Ecosystems
• Unprecedented opportunities, challenges
• Autonomic computing A pragmatic approach for
  addressing complexity!
• Experiments with autonomics for science and
  engineering
• Concluding Remarks

24
Autonomics for Science and Engineering
Application-level Examples

• Autonomic to address complexity in science and
  engineering
• Autonomic as a paradigm for science and
  engineering
• Some examples
• Autonomic runtime management multiphysics,
  adaptive mesh refinement
• Autonomic data streaming and in-network data
  processing coupled simulations
• Autonomic deployment/scheduling HPC Grid/Cloud
  integration
• Autonomic workflows simulation based
  optimization
• (Many system level examples not presented here )

25
Adaptive Methods in Science and Engineering
26
Autonomic (Physics/Model/System Driven) Runtime
Management
Hybrid Runtime Management of Space-Time
Heterogeneity for Dynamic SAMR Applications, X.
Li and M. Parashar, IEEE TPDS 18(8), pp. 1202
1214, August 2007.
27
Cross-layer Adaptations for SAMR
When resources are under-utilized
When resources are scarce
ALP Trade in space (resource) for time
(performance) ALOC Trade in time (performance)
for space (resource)
28
Experimental Results - ALP
Performance gain up to 40 on 512 processors
Experiment Setup IBM SP4 cluster (DataStar at
San Diego Supercomputing Center, total 1632
processors) SP4 (p655) node 8 processors(1.5
GHz), memory 16 GB, 6.0 GFlops
29
Effects of Finite Memory - ALOC
Intel Pentium 4 CPU 1.70GHz, Linux 2.4
kernel Cache size 256 KB, Physical memory 512
M, Swap space 1 G.
30
Experimental Results - ALOC
Boewulf Cluster (Frea at Rutgers, 64
processors) Intel Pentium 4 CPU 1.70GHz, Linux
2.4 kernel Cache size 256 KB, Physical memory
512 M, Swap space 1 G.
31
Coupled Fusion Simulations A Data Intensive
Workflow
32
Autonomic Data Streaming and In-Transit
Processing for Data-Intensive Workflows

• Large-scale distributed environments and data
  intensive workflows
• Applications entities separated in space and time
• Seamless interactions and couplings across
  entities
• Distributed application entities need to interact
  at runtime
• Data processing, interactive data monitoring,
  online data analysis, visualization,
  data/service/vm migration, data archiving,
  collaboration, etc.
• Large data volumes and rates, heterogeneous data
  types
• Must be streamed efficiently and effectively
  between distributed application components
• Application-specific manipulations need to be
  applied in-transit

An Self-Managing Wide-Area Data
Streaming Service, V. Bhat, M. Parashar, H.
Liu, M. Khandekar, N. Kandasamy, S. Klasky, and
S. Abdelwahed, Cluster Computing The Journal of
Networks, Software Tools, and Applications,
Volume 10, Issue 7, pp. 365 383, December 2007.
33
Autonomic Data Streaming and In-Transit
Processing for Data-Intensive Workflows

• Workflow with coupled simulation codes, i.e., the
  edge turbulence particle-in-cell (PIC) code (GTC)
  and the microscopic MHD code (M3D) -- run
  simultaneously on separate HPC resources
• Data streamed and processed enroute -- e.g. data
  from the PIC codes filtered through noise
  detection processes before it can be coupled
  with the MHD code
• Efficiently data streaming between live
  simulations -- to arrive just-in-time -- if it
  arrives too early, times and resources will have
  to be wasted to buffer the data, and if it
  arrives too late, the application would waste
  resources waiting for the data to come in
• Opportunistic use of in-transit resources

An Self-Managing Wide-Area Data
Streaming Service, V. Bhat, M. Parashar, H.
Liu, M. Khandekar, N. Kandasamy, S. Klasky, and
S. Abdelwahed, Cluster Computing The Journal of
Networks, Software Tools, and Applications,
Volume 10, Issue 7, pp. 365 383, December 2007.
34
Autonomic Data Streaming In-Transit Processing

• Application level
• Proactive QoS management strategies using
  model-based LLC controller
• Capture constraints for in-transit processing
  using slack metric
• In-transit level
• Opportunistic data processing using dynamic
  in-transit resource overlay
• Adaptive run-time management at in-transit nodes
  based on slack metric generated at application
  level
• Adaptive buffer management and forwarding

35
Autonomics for Coupled Fusion Simulation Workflows
36
Autonomic Streaming Implementation/Deployment

• Simulation Workflow
• SS Simulation Service (GTC)
• ADSS Autonomic Data Streaming Service
• CBMS LLC Controller based buffer management
  service
• DTS Data Transfer service
• DAS Data Analysis Service
• SLAMS Slack Manager Service
• PS Processing Service
• BMS Buffer Management Service
• ArchS Archiving data at sink

• Simulations executes on leadership class machines
  at ORNL and NERSC
• In-transit nodes located at PPPL and Rutgers

37
Adaptive Data Transfer

• No congestion in intervals 1-9
• Data transferred over WAN
• Congested at intervals 9-19
• Controller recognizes this congestion and advises
  the Element Manager, which in turn adapts DTS to
  transfer data to local storage (LAN).
• Adaptation continues until the network is not
  congested
• Data sent to the local storage by the DTS falls
  to zero at the 19th controller interval.

38
Adaptation of the Workflow

• Create multiple instances of the Autonomic Data
  Streaming Service (ADSS)
• Effective Network Transfer Rate dips below the
  threshold (our case around 100Mbs)

Transfer
Simulation
ADSS-0
Buffer
Data Transfer
ADSS-1
Buffer
Data Transfer
Network throughput is difference between the
max and current network transfer rate
ADSS-2
Buffer
Data Transfer
39
Buffer Occupancy _at_ In-Transit Nodes w w/o
Coupling

• Buffer occupancy at in-transit nodes before
  congestion is around 50
• During congestion application level controller
  throttles data items
• Buffer occupancy at in-transit nodes reduces
  from 80 without coupling to 60.8 with coupling
• Higher buffer occupancies at in-transit nodes
  lead to failures loss of data

40
Reservoir Characterization EnKF-based History
Matching (with S. Jha)

• Black Oil Reservoir Simulator
• simulates the movement of oil and gas in
  subsurface formations
• Ensemble Kalman Filter
• computes the Kalman gain matrix and updates the
  model parameters of the ensembles
• Hetergeneous, dynamic workflows
• Based on Cactus, PETSc

41
Experiment Background and Set-Up (2/2)

• Key metrics
• Total Time to Completion (TTC)
• Total Cost of Completion (TCC)
• Basic assumptions
• TG gives the best performance but is relatively
  more restricted resource.
• EC2 is a relatively more freely available but is
  not as capable.
• Note that the motivation of our experiments is to
  understand each of the usage scenarios and their
  feasibility, behaviors and benefits, and not to
  optimize the performance of any one scenario.

42
Establishing Baseline Performance
Baseline TTC for EC2 and TG for a 1-stage, 128
ensemble member EnKF run. The first 4 bars
represent the TTC as the number of EC2 VMs
increase the next 4 bars represent the TTC as
the number of CPUs (nodes) used increases.
43
Autonomic Integration of HPC Grids Clouds
(with S. Jha)

• Acceleration Clouds used as accelerators to
  improve the application time-to-completion
• alleviate the impact of queue wait times or
  exploit an additionally level of parallelism by
  offloading appropriate tasks to Cloud resources
• Conservation Clouds used to conserve HPC Grid
  allocations, given appropriate runtime and budget
  constraints
• Resilience Clouds used to handle unexpected
  situations
• handle unanticipated HPC Grid downtime,
  inadequate allocations or unanticipated queue
  delays

44
Objective I Using Clouds as Acceleratorsfor HPC
Grids (1/2)

• Explore how Clouds (EC2) can be used as
  accelerators for HPC Grid (TG) work-loads
• 16 TG CPUs (1 node on Ranger)
• average queuing time for TG was set to 5 and 10
  minutes.
• the number of EC2 nodes from 20 to 100 in steps
  of 20.
• VM start up time was about 160 seconds

45
Objective I Using Clouds as Acceleratorsfor HPC
Grids (2/2)
The TTC and TCC for Objective I with 16 TG CPUs
and queuing times set to 5 and 10 minutes. As
expected, more the number of VMs that are made
available, the greater the acceleration, i.e.,
lower the TTC. The reduction in TTC is roughly
linear, but is not perfectly so, because of a
complex interplay between the tasks in the work
load and resource availability
46
Objective II Using Clouds for ConservingCPU-Time
on the TeraGrid

• Explore how to conserve fixed allocation of CPU
  hours by offloading tasks that perhaps dont need
  the specialized capabilities of the HPC Grid

Distribution of tasks across EC2 and TG, TTC and
TCC, as the CPU-minute allocation on the TG is
increased.
47
Objective III Response to Changing Operating
Conditions (Resilience) (1/4)

• Explore the situation where resources that were
  initially planned for, become unavailable at
  runtime, either in part or in entirety
• How can Cloud services be used to address this
  situations and allow the system/application to
  respond to a dynamic change in availability of
  resources.
• Initially 16 TG CPUs for 800 minutes allocated.
  After about 50 minutes of execution (i.e., 3
  Tasks were completed on the TG), available CPU
  time is change to only 20 CPU minutes remain

48
Objective III Response to Changing Operating
Conditions (Resilience) (2/4)
Allocation of tasks to TG CPUs and EC2 nodes for
usage mode III. As the 16 allocated TG CPUs
become unavailable after only 70 minutes rather
than the planned 800 minutes, the bulk of the
tasks are completed by EC2 nodes.
49
Objective III Response to Changing Operating
Conditions (Resilience) (3/4)
Number of TG cores and EC2 nodes as a function of
time for usage mode III. Note that the TG CPU
allocation goes to zero after about 70 minutes
causing the autonomic scheduler to increase the
EC2 nodes by 8.
50
Objective III Response to Changing Operating
Conditions (Resilience) (4/4)
Overheads of resilience on TTC and TCC.
51
Autonomic Formulations/Programming
52
LLC-based Self Management in Accord

• Element/Service Managers are augmented with LLC
  Controllers
• monitors state/execution context of elements
• enforces adaptation actions determined by the
  controller
• augment human defined rules

53
The Instrumented Oil Field

• Production of oil and gas can take advantage of
  installed sensors that will monitor the
  reservoirs state as fluids are extracted
• Knowledge of the reservoirs state during
  production can result in better engineering
  decisions
• economical evaluation physical characteristics
  (bypassed oil, high pressure zones) productions
  techniques for safe operating conditions in
  complex and difficult areas

Application of Grid-Enabled Technologies for
Solving Optimization Problems in Data-Driven
Reservoir Studies, M. Parashar, H. Klie, U.
Catalyurek, T. Kurc, V. Matossian, J. Saltz and M
Wheeler, FGCS. The International Journal of Grid
Computing Theory, Methods and Applications
(FGCS), Elsevier Science Publishers, Vol. 21,
Issue 1, pp 19-26, 2005.
54
Effective Oil Reservoir Management Well
Placement/Configuration

• Why is it important
• Better utilization/cost-effectiveness of existing
  reservoirs
• Minimizing adverse effects to the environment

Bad Management
Better Management
Less Bypassed Oil
Much Bypassed Oil
55
Autonomic Reservoir Management Closing the
Loop using Optimization
Dynamic Decision System
Dynamic Data-Driven Assimilation

• Optimize
• Economic revenue
• Environmental hazard
• Based on the present subsurface knowledge and
  numerical model

Subsurface characterization
Management decision
Data assimilation
Acquire remote sensing data
Update knowledge of model
Plan optimal data acquisition
Experimental design
START
Autonomic Grid Middleware
Grid Data Management
Processing Middleware
56
An Autonomic Well Placement/Configuration Workflow
Oil prices, Weather, etc.
57
Autonomic Oil Well Placement/Configuration
Contours of NEval(y,z,500)(10)
Pressure contours 3 wells, 2D profile
permeability
Requires NYxNZ (450) evaluations. Minimum appears
here.
VFSA solution walk found after 20 (81)
evaluations
58
Autonomic Oil Well Placement/Configuration (VFSA)
An Reservoir Framework for the Stochastic
Optimization of Well Placement, V. Matossian, M.
Parashar, W. Bangerth, H. Klie, M.F. Wheeler,
Cluster Computing The Journal of Networks,
Software Tools, and Applications, Kluwer Academic
Publishers, Vol. 8, No. 4, pp 255 269, 2005
Autonomic Oil Reservoir Optimization on the
Grid, V. Matossian, V. Bhat, M. Parashar, M.
Peszynska, M. Sen, P. Stoffa and M. F. Wheeler,
Concurrency and Computation Practice and
Experience, John Wiley and Sons, Volume 17, Issue
1, pp 1 26, 2005.
59
Summary

• CI and emerging computational ecosystems
• Unprecedented opportunity
• new thinking, practices in science and
  engineering
• Unprecedented research challenges
• scale, complexity, heterogeneity, dynamism,
  reliability, uncertainty,
• Autonomic Computing can address complexity and
  uncertainty
• Separation Integration Automation
• Experiments with Autonomics for science and
  engineering
• Autonomic data streaming and in-transit data
  manipulation, Autonomic Workflows, Autonomic
  Runtime Management,
• However, there are implications
• Added uncertainty
• Correctness, predictability, repeatability
• Validation

60
Thank You!
Email parashar_at_rutgers.edu
