Biomass

1
Biomass Biofuels
2
(No Transcript)
3
Technology

• Biomass technology today serves many markets
  that were developed with fossil fuels and
  modestly reduces their use
• Uses - Industrial process heat and steam,
  Electrical power generation, Transportation fuels
  (ethanol and biodiesel) and other products.
• Primary focus of the Biomass Program
  development of advanced technologies.

4
Current Focus

• Platform technologies
• Sugar Platform Technology
• Thermochemical Platform Technology

5
Bio-refinery

• A facility that integrates biomass conversion
  processes and equipment to produce fuels, power,
  and chemicals from biomass.
• Analogous to today's petroleum refineries
• It is based on the Sugar Platform and the
  Thermochemical Platform

6
(No Transcript)
7
Bio-diesel

• Made by transforming animal fat or vegetable oil
  with alcohol .
• Fuel is made from rapeseed (canola) oil or
  soybean oil or recycled restaurant grease.
• Directly substituted for diesel either as neat
  fuel or as an oxygenate additive

8
Modified Waste Vegetable Fat

• Designed for general use in most compression
  ignition engines .
•  The production of MWVF can be achieved in a
  continuous flow additive process.
• It can be modified in various ways to make a
  'greener' form of fuel

9
E-Diesel

• Uses additives in order to allow blending of
  ethanol with diesel.
• Ethanol blends of 7.7 to 15 and up to 5
• Additives that prevent the ethanol and diesel
  from separating at very low temperatures or if
  water contamination occurs.

10
Jatropha

• Biodiesel from Jatropha
• Seeds of the Jatropha nut is
• crushed and oil is extracted
• The oil is processed and
• refined to form bio-diesel.

11
Gaseous fuel Technology
12
Gasification Technology

• Gobar gas Production
• Biogas
• Synthesis gas

13
Gasification

• A process that uses heat, pressure, and steam to
  convert materials directly into a gas composed
  primarily of carbon monoxide and hydrogen.
• Gasification technologies rely four key
  engineering factors
• 1. Gasification reactor atmosphere (level of
  oxygen or air content).
• 2. Reactor design.
• 3. Internal and external heating.
• 4. Operating temperature.

14
Gasification

• Typical raw materials - coal, petroleum-based
  materials, and organic materials.
• The feedstock is prepared and fed, in either dry
  or slurried form, into a sealed reactor chamber
  called a gasifier.
• The feedstock is subjected to high heat,
  pressure, and either an oxygen-rich or
  oxygen-starved environment within the gasifier.

15
Raw Materials for Gasification
16
Gasification

• Products of gasification
• Hydrocarbon gases (also called syngas).
• Hydrocarbon liquids (oils).
• Char (carbon black and ash).
• Syngas is primarily carbon monoxide and hydrogen
  (more than 85 percent by volume) and smaller
  quantities of carbon dioxide and methane

17
Gasifier Plant
18
Gasifier Plant
19
(No Transcript)
20
Types of Gasifiers

• Updraft Gasifier

21
Types of Gasifiers

• Downdraft Gasifier

22
Types of Gasifiers

• Twin-fire Gasifier

23
Types of Gasifiers

• Crossdraft gas producers

24
Gobar gas

• Gobar gas production is an anaerobic process
• Fermentation is carried out in an air tight,
  closed cylindrical concrete tank called a
  digester

25
(No Transcript)
26
(No Transcript)
27
Solid Fuel

28
Wood

• Domestic heating with wood is still by far the
  largest market for bio-energy
• Dramatic improvements of technology in domestic
  heating equipment
• Improved tiled stoves, advanced logwood boilers,
  woodchip boilers, pellet boilers and pellet
  stoves.
• Pourable wood-based fuel is also available

29
Woodchip boilers
30
Environmental Concerns

• Air Pollution
• Soil Deterioration

31
Air Concerns

• Biomass processing technologies and biofuels use
  have the potential to increase emissions of ozone
  precursors
• Increase in Nox emissions
• Excessive inhalation of ethanol is harmful
• Combustion of ethanol would result in increased
  atmospheric concentrations of carcinogens
• Emission of relatively large sized particulate
  matter

32
Soil Concerns

• Burning biomass deprives local eco-systems of
  nutrients
• Production of dedicated energy crops renders
  land fallow
• Reduced land availability for cattle grazing
• Increased use of pesticides and fertilizers to
  produce energy crops contaminate ground and
  surface water
• Affects fish and wildlife

33
Environmental Benefits

• Reduction of waste
• Extremely low emission of greenhouse gases
  compared to fossil fuels
• Ethanol is Carbon neutral and forms a part of
  the carbon cycle
• Growing variety of crops increases bio-diversity

34
Socio-Economic Benefits

• Helps developing economies by promoting agrarian
  communities
• Increase in jobs
• Increase in trade balance (Indian perspective)
  due to lesser dependence on foreign resources

35
BIO FUELS

• THE WORLD SCENARIO

36
BRAZIL

• World leader in production and export of ethanol.
• Ethanol produced per day equivalent to 200,000
  barrels of gasoline.
• 24 blend ethanol mandatory.
• Competitiveness
• Bio diesel initiatives underway

37
U.S.A.

• Ethanol a big boost to economy
• E85 sells cheaper than gasoline
• Currently production aimed at 4.5 Billion
  gallons/yr
• MTBE phased out in many states
• Soya bean main source of biodiesel

38
E.U.

• Rapeseed main source of bio diesel
• 3-15 blended petrol
• France Bio diesel exempted from domestic tax
• Germany Sales of bio diesel 99 million US
  gallons
• Rise of SVO as domestic fuel

39
The Significant Others

• China 3rd largest producer of ethanol producing
  220,000 tons of ethanol, exporting 90,000 tons in
  2000.
• In southeast Asia, the Jatropha tree is used as a
  significant fuel source
• Malaysia and Indonesia are starting pilot-scale
  production from palm oil.

40
India

• Sources of ethanol
• Sugarcane
• Molasses
• Agricultural waste
• Low average cost of Rs.18/litre projected
• Annual production capacity of 1.5 Billion litres

41
India (Contd.)

• Sources of biodiesel
• Honge
• Jatropha
• High capital, broad scale production plan
  initiated
• Cost per liter projected at Rs. 27

42
Bio Mass

• Biomass already supplies 14 of the worlds
  primary energy consumption. On average, biomass
  produces 38 of the primary energy in developing
  countries.
• USA 4 of total energy from bio mass, around
  9000 MW
• INDIA is short of 15,000 MW of energy and it
  costs about 25,000 crores annually for the
  government to import oil.

43

• Bio Mass from cattle manure, agricultural waste,
  forest residue and municipal waste.
• Anaerobic digestion of livestock wastes to give
  bio gas
• Digester consumes roughly one third the power
  its capable of producing.
• Fertilizers as by product.
• Average electricity generation of 5.5kWh per cow
  per day!!

44
