Title: MARINE PROCESSES


1
MARINE PROCESSES
  • Chapters 13 15
  • Test 1 Material
  • End

2
OCEANOGRAPHY
  • STUDY OF ALL ASPECTS OF THE WORLD OCEAN
  • OCEAN MAKES UP 71 OF TOTAL EARTH SURFACE
  • AVERAGE DEPTH OF OCEAN IS ABOUT 12,500 FEET

3
Oceans
4
SALINITY
  • PROPORTION OF DISSOLVED SALTS TO PURE WATER
  • EXPRESSED IN PARTS PER THOUSAND
  • THE AVERAGE OCEAN SALINITY IS 35 PARTS PER
    THOUSAND

5
SEA SALTS
  • SODIUM CHLORIDE
  • MAGNESIUM CHLORIDE
  • SODIUM SULFATE
  • CALCIUM CHLORIDE
  • POTASSIUM CHLORIDE
  • SODIUM BICARBONATE
  • HYDROGEN BORATE, STRONTIUM CHLORIDE, SODIUM
    FLUORIDE

6
SOURCES FOR SEA SALTS
  • CHEMICAL WEATHERING OF ROCKS
  • EARTHS INTERIOR BY OUTGASSING
  • DESALINATION - REMOVING SALTS TO GET FRESH WATER

7
3 LAYERS OF OCEAN BASED ON TEMPERATURE-SALINITY
  • SURFACE MIXED ZONE - WARMEST TEMPS
  • TRANSITION ZONE
  • DEEP ZONE - WHERE TEMPS ARE NOT MUCH ABOVE
    FREEZING

8
(No Transcript)
9
MAPPING THE OCEAN FLOOR
  • ECHO SOUNDER - SONAR
  • VELOCITY OF SOUND WAVES IN WATER IS ABOUT 1500
    METERS PER SECOND. DIVIDE TOTAL TIME BY 2 TO
    CALCULATE DEPTH
  • 10 seconds X 1500 meters 15,000/2 7,500
    meters deep

10
(No Transcript)
11
3 MAJOR UNITS OF OCEAN TOPOGRAPHY
  • CONTINENTAL MARGINS
  • DEEP-OCEAN BASINS
  • MID-OCEAN RIDGES

12
(No Transcript)
13
CONTINENTAL MARGIN TYPES
  • PASSIVE - NOT ASSOCIATED WITH PLATE BOUNDARIES -
    CONTINENTAL SHELF, CONTINENTAL SLOPE, CONTINENTAL
    RISE, DEEP SEA FAN
  • ACTIVE - SUBDUCTION ZONES, VERY LITTLE
    CONTINENTAL SHELF

14
PASSIVE MARGIN
15
ACTIVE MARGIN
16
OCEAN BASIN FLOOR
  • DEEP-OCEAN TRENCHES
  • ABYSSAL PLAINS
  • SEAMOUNTS

17
MID-OCEAN RIDGES
  • MID-ATLANTIC RIDGE SYSTEM
  • RIFT VALLEYS

18
ESTUARIES
  • PARTIALLY ENCLOSED COASTAL WATER BODY THAT IS
    CONNECTED TO THE OCEAN
  • GREAT BIODIVERSITY

19
THE LITTORAL ZONE
  • COASTAL ENVIRONMENT FROM HIGHEST WATER LINE
    ONSHORE TO THE SEA WHERE STORM WAVES CAN NO
    LONGER MOVE SEDIMENT DUE TO OCEAN DEPTH (200 FEET)

20
The littoral zone
21
MEAN SEA LEVEL
  • AVERAGE TIDAL LEVELS RECORDED HOURLY AT A GIVEN
    SITE OVER MANY YEARS
  • EUSTATIC CHANGES (CHANGE IN AMOUNT OF TOTAL
    WATER)
  • TECTONIC CHANGES (CHANGE DUE TO RISE OR FALL OF
    LAND)

22
SEA MOTIONS
  • WAVES
  • CURRENTS
  • TIDES

23
WAVES
  • ROUGHEN THE WATER SURFACE

24
CURRENTS
  • COLD AND WARM WATER STREAMS THAT FLOW FASTER THAN
    THE SURFACE WATER

25
(No Transcript)
26
TIDES
  • DAILY RISE AND FALL OF THE SEA SURFACE

27
HOW ARE TIDES PRODUCED?
  • GRAVITATIONAL ATTRACTION OF THE SUN AND MOON
  • CENTRIFUGAL FORCE OF THE EARTH/MOON SYSTEM AS IT
    REVOLVES AROUND THE SUN

28
(No Transcript)
29
TYPES OF TIDES
  • EBB TIDE
  • FLOOD TIDE
  • TIDAL RANGE
  • SPRING TIDE - GREATEST TIDAL RANGE
  • NEAP TIDE - LEAST TIDAL RANGE
  • TIDAL BORE ON BAY OF FUNDY 70 FEET TIDAL RANGE

30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
WAVE ANATOMY
  • CREST
  • TROUGH
  • HEIGHT
  • LENGTH
  • PERIOD

34
(No Transcript)
35
FORCED WAVES
  • CREATED BY WIND
  • SIZE OF THE WAVE HEIGHT IS RELATED TO THE SPEED
    OF THE WIND

36
SEISMIC WAVES
  • TSUNAMI
  • CAUSED BY EARTHQUAKES, LANDSLIDES, VOLCANOES
  • OPEN SEA HAVE HEIGHT OF 3 FEET BUT LENGTH OF 60
    MILES
  • SPEEDS UP TO 500 MPH

37
TSUNAMI
38
WAVE REFRACTION
  • MOST WAVES APPROACH SHORELINE AT AN ANGLE. AS
    THEY NEAR SHALLOW WATER THEY BEND AND BECOME
    PARALLEL TO THE SHORE

39
HEADLAND
  • HEAD OF LAND EXTENDING OUTWARD FROM SHORE
  • FIRST LANDFORM FEATURE TO ERRODE

40
(No Transcript)
41
LONGSHORE CURRENT
  • PRODUCED BY WAVE REFRACTION
  • RUNS PARALLEL TO SHORELINE

42
(No Transcript)
43
WAVE BREAK
  • INCOMING WAVES DECREASE IN LENGTH AND INCREASE IN
    HEIGHT
  • AS HEIGHT INCREASES THE SPEED DECREASES
  • WAVES REACH A BREAKING POINT AND COLLAPSE DUE TO
    LACK OF SUPPORT FROM WATER BELOW

44
(No Transcript)
45
TYPES OF BREAKERS
  • COLLAPSING (MASS OF FOAM)
  • SPILLING (GRADUAL DOWNWARD SLIDE)
  • PLUNGING (CREST SHOOTS FORWARD) - SURFERS WAVE
    DUDE!

46
COASTAL EROSION
  • SEA CLIFFS FORMED BY UNDERCUTTING OF SEA
  • WAVE-CUT PLATFORM IS A HORIZONTAL BENCH EXTENDING
    FROM CLIFF OUT TO SEA
  • SEA CAVE
  • SEA ARCH SEA STACK

47
Coastal erosion
48
SEA CLIFF
49
SEA CAVE
50
(No Transcript)
51
SEA STACK
52
DEPOSITIONAL FEATURES
  • MOST MATERIAL ALONG BEACHES COMES FROM RIVERS AND
    STREAMS FLOWING INTO SEA. THE LONGSHORE CURRENT
    TAKES THIS MATERIAL AND DEPOSITS IT ALONG THE
    SHORELINE

53
DEPOSITIONAL LANDFORMS
  • SPIT
  • BAYMOUTH BAR
  • TOMBOLO
  • BARRIER ISLAND

54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
BARRIER ISLANDS
  • SPITS SEVERED FROM MAINLAND
  • SAND PILED UP DURING STORM
  • SAND DUNE REMAINS WHEN SEA LEVEL WAS LOWER

59
MANS ATTEMPT TO CONTROL EROSION
  • JETTY
  • GROIN
  • BREAKWATER
  • SEAWALL
  • BEACH NOURISHMENT - VIRGINIA BEACH 30,000 TRUCK
    LOADS OF SAND

60
JETTIES
61
JETTY
62
GROIN
63
HARBOR - BREAKWATER
64
SEAWALL
65
BEACH FILL - NOURISHMENT
66
CORAL REEF COASTS
  • CORAL ARE SIMPLE MARINE ANIMALS WITH A SMALL
    SAC-LIKE BODY
  • SECRETE CALCIUM CARBONATE
  • NEED LIGHT SO YOU NEVER FIND THEM BELOW A DEPTH
    OF 150-180 FEET BELOW SEA LEVEL

67
CORAL
  • NEED WATER TEMPERATURES ABOVE 65 DEGREES F
  • NEED CLEAR WATER
  • LIVE SYMBIOTICALLY WITH SIMPLE ALGAE

68
LONELY PLANET PHOTO
69
TYPES OF CORAL REEFS
  • FRINGING REEF
  • BARRIER REEF
  • ATOLL

70
(No Transcript)
71
ATOLLS
72
TEST REVIEW
  • HOW WILL YOU DO ON THE EXAM?

73
NEWTONS FIRST LAW OF MOTION DEALT WITH
  • GRAVITY
  • KINETIC ENERGY
  • INERTIA
  • NONE OF THESE
  • CORRECT RESPONSE ?
  • INERTIA

74
SEA SALT SOURCES INCLUDE ALL BUT?
  • CHEMICAL WEATHERING OF ROCKS
  • EARTHS INTERIOR OUTGASSING
  • TRANSPIRATION OF OCEAN PLANTS
  • ALL OF THESE
  • CORRECT RESPONSE
  • TRANSPIRATION OF OCEAN PLANTS

75
RIDGE OF SAND THAT CONNECTS ISLAND/ LAND
  • SPIT
  • BAYMOUTH BAR
  • TOMBOLO
  • BARRIER ISLAND
  • CORRECT RESPONSE?
  • TOMBOLO

76
EUSTATIC CHANGE IN SEA LEVEL IS DUE TO?
  • RISING LAND
  • FALLING LAND
  • CHANGE IN TOTAL AMOUNT WATER
  • NONE OF THESE
  • CORRECT RESPONSE
  • CHANGE IN TOTAL AMOUNT OF WATER

77
MODERN SCIENTIFIC STUDY OF THE UNIVERSE IS ?
  • COSMOGRAPHY
  • ASTROLOGY
  • ASTRONOMY
  • METEOROLOGY
  • CORRECT RESPONSE?
  • ASTRONOMY

78
FIRST PERSON TO MEASURE SIZE OF THE EARTH WAS?
  • ARISTARCHUS
  • ERASTOTHENES
  • HIPPARCHUS
  • PTOLEMY
  • CORRECT RESPONSE?
  • ERASTOTHENES

79
WHICH IS NOT TRUE OF JOVIAN PLANETS?
  • THEY ARE THE GIANT PLANETS
  • HAVE THICK ATMOSPHERES
  • LARGE AMOUNTS OF DENSE ROCKY METALLIC MINERALS
  • MORE MOONS THAN TERRESTRIALS
  • CORRECT RESPONSE?
  • DENSE ROCKY METALLIC MINERALS

80
NOT A MAJOR UNIT OF OCEAN TOPOGRAPHY?
  • CONTINENTAL MARGINS
  • TRANSITION ZONE
  • DEEP-OCEAN BASINS
  • MID-OCEAN RIDGES
  • CORRECT RESPONSE?
  • TRANSITION ZONE

81
WAVES BECOME PARALLEL TO THE SHORE DUE TO?
  • WAVE CREST
  • WAVE TROUGH
  • WAVE PERIOD
  • WAVE REFRACTION
  • CORRECT RESPONSE?
  • WAVE REFRACTION
