Authentication Methods: From Digital Signatures to Hashes

1
Authentication Methods From Digital Signatures
to Hashes
2
Lecture Motivation

• We have looked at confidentiality services, and
  also examined the information theoretic framework
  for security.
• Confidentiality between Alice and Bob only
  guarantees that Eve cannot read the message, it
  does not address
• Is Alice really talking to Bob?
• Is Bob really talking to Alice?
• In this lecture, we will look at the following
  problems
• Entity Authentication Proof of the identity of
  an individual
• Message Authentication (Data origin
  authentication) Proof that the source of
  information really is what it claims to be
• Message Signing Binding information to a
  particular entity
• Data Integrity Ensuring that information has not
  been altered by unknown entities

3
Lecture Outline

• Discrete Logarithms and ElGamal
• Primitive elements and some more number theory
  (quickly)
• DLOG
• ElGamal, another Public Key Algorithm
• Digital Signatures
• The basic idea
• RSA Signatures and ElGamal Signatures
• Inefficiencies Hashing and Signing
• Hash Functions
• Definitions and terminology
• CHP Hash
• SHA-1
• Message Authentication Codes

Note Some attacks will be discussed. More
attacks and cryptanalysis will come later in the
semester
4
Primitive Roots

• Consider the following powers of 3 (mod 7)
• Note that we obtain all non-zero numbers mod 7.
• When this happens, we call 3 a primitive root (or
  generator) mod 7.
• Is a number always a primitive root? No.
• If p is prime there are f(p-1) primitive roots
  mod p.
• How to find them? Good homework problem ?
• Proposition Let g be a primitive root for the
  prime p
• If n is an integer, then gn1 (mod p) if and
  only if and only if n0 (mod p-1) .
• If j and k are integers, then gjgk (mod p) if
  and only if jk (mod p-1).
• Proof We sketch (1) on the board.

5
Discrete Logarithms

• Let p be a prime, and a and b nonzero integers
  (mod p) with
• The problem of finding x is called the discrete
  logarithm problem, and is written
• Often a will be a primitive root mod p.
• The discrete log behaves like the normal log in
  many ways
• Generally, finding the discrete log is a hard
  problem.
• f(x) ax (mod p) is an example of a one-way
  function.

6
ElGamal Public Key Cryptosystem

• One way functions are often used to construct
  public key cryptosystems. We saw one in RSA, we
  now show an example using the DLOG problem.
• Alice wants to send m to Bob. Bob chooses a large
  prime p and a primitive root a. We assume 0 lt m lt
  p. Bob also chooses a secret integer a and
  computes baa (mod p).
• Bobs Public key is (p, a, b)
• Alice does
• Chooses a secret random integer k and computes
  rak (mod p)
• Computes tbkm (mod p).
• Sends (r,t) to Bob.
• Bob decrypts by

7
ElGamal Public Key Cryptosystem, pg. 2

• Important issues
• a must be kept secret, else Eve can decrypt
• Eve sees (r,t) t is the product of two random
  numbers and is hence random. Knowing r does not
  really help as Eve would need to be able to solve
  DLOG in order to get k.
• Very important A different random k must be used
  for each message!
• If we have m1 and m2, and use the same k, then
  the ciphertexts will be (r,t1) and (r,t2)
• If Eve ever finds m1 then she has m2 also!!!

8
Overview of Digital Signatures

• Suppose you have an electronic document (e.g. a
  Word file). How do you sign the document to prove
  to someone that it belongs to you?
• You cant use a scanned signature at the end
  this is easy to forge and use elsewhere.
• Conventional signing cant work in the digital
  world.
• We require a digital signature to satisfy
• Digital signatures cant be separated from the
  message and attached to another message.
• Signature needs to be verified by others.

9
An Application for Digital Signatures

• Suppose we have two countries, A and B, that have
  agreed not to test any nuclear bombs (which
  produce seismic waves when detonated). How can A
  monitor B by using seismic sensors?
• The sensors need to be in country B, but A needs
  to access them. There is a conflict here.
• Country B wants to make sure that the message
  sent by the seismic sensor does not contain
  other data (espionage).
• Country A, however, wants to make sure that the
  data has not been altered by country B.
  (Assumption the sensor itself is tamper proof).
• How can we solve this problem?

10
Treaty Verification Example

• RSA provides a solution
• Country A makes an RSA public/private key. (n,e)
  are given to B but (p,q,d) are kept private in
  the tamper-proof sensor.
• Sensor collects data x and uses d to encrypt
  yxd (mod n), and sends x and y to country B.
• Country B takes x and y and calculates zye (mod
  n).
• If zx, then B can be sure that the encrypted
  message corresponds to x. B then forwards (x,y)
  to A.
• Country A checks that ye (mod n)x. If so, then A
  is sure that x has not been modified, and A can
  trust x as being authentic.
• In this example, it is hard for B to forge (x,y)
  and hence if (x,y) verifies A can be sure that
  data came unaltered from the sensor.

11
RSA Signatures

• The treaty example is an example of RSA
  signatures. We now formalize it with Alice and
  Bob.
• Alice publishes (n,eA) and keeps private (p,q,dA)
• Alice signs m by calculating ymdA (mod n). The
  pair (m,y) is the signed document.
• Bob can check that Alice signed m by
• Downloading Alices (n,eA) from a trusted third
  party. Guaranteeing that he gets the right (n,eA)
  is another problem (well talk about this in a
  later lecture).
• Calculate zyeA (mod n). If zm then Bob (or
  anyone else) can be guaranteed that Alice signed
  m.

12
RSA Signatures, pg. 2

• Suppose Eve wants to attach Alices signature to
  another message m1. She cannot simply use (m1, y)
  since
• Therefore, she needs y1 with y1eAm1 (mod n).
• m1 looks like a ciphertext and y1 like a
  plaintext. In order for Eve to make a fake y1 she
  needs to be able to decrypt m1 to get y1!!! She
  cant due to hardness of RSA.
• Existential Forgery Eve could choose y1 first
  and then calculate an m1 using (n,eA) via m1y1eA
  (mod n). Now (m1, y1) will look like a valid
  message and signature that Alice created since
  m1y1eA (mod n).
• Problem with existential forgery Eve has made an
  m1 that has a signature, but m1 might be
  gibberish!
• Usefulness of existential forgery depends on
  whether there is an underlying language
  structure.

13
Blind RSA Signatures

• Sometimes we might want Alice to sign a document
  without knowing its contents (e.g. privacy
  concerns purchaser does not want Bank to know
  what is being purchased, but wants Bank to
  authorize purchase).
• We can accomplish this with RSA signatures (Bob
  wants Alice to sign a document m)
• Alice generates an RSA public and private key
  pair.
• Bob generates a random k mod n with gcd (k,n)1.
• Bob computes tkeAm (mod n), and sends t to
  Alice.
• Alice signs t as following the normal RSA
  signature procedure by calculating stdA (mod n).
  Alice sends Bob s.
• Bob computes k-1s (mod n). This is the signed
  message mdA (mod n).
• Verification
• Does Alice learn anything about m from t?

14
ElGamal Signatures

• We may modify the ElGamal public key procedure to
  become a signature scheme.
• Alice wants to sign m. Alice chooses a large
  prime p and a primitive root a. Alice also
  chooses a secret integer a and computes baa (mod
  p).
• Alices Public key is (p, a, b). Security of the
  signature depends on the fact a is private.
• Alice does
• Chooses a secret random integer k with
  gcd(k,p-1)1, and computes rak (mod p)
• Computes sk-1(m-ar) (mod p).
• The signed message is the triple (m,r,s).

15
ElGamal Signatures, pg. 2

• Bob can verify by
• Downloading Alices public key (p, a, b).
• Computes v1brrs (mod p) and v2am (mod n)
• The signature is valid if and only if v1v2 (mod
  p)
• Verification We have
• Therefore
• This scheme is believed to be secure, as long as
  DLOG is hard to solve.
• Dont Choose a p with (p-1) the product of small
  primes and dont reuse k.

16
Wastefulness of plain signatures

• In signature schemes with appendix, where we
  attach the signature to the end of the document,
  we increase the communication overhead.
• If we have a long message mm1,m2,,mN, then
  our signed document is m1,m2,,mN,sigA(m1),,s
  igA(mN).
• This doubles the overhead!
• We dont want to do this when communication
  resources are precious (which is always!).
• Solution We need to shrink the message into a
  smaller representation and sign that.
• Enter Hash functions

17
Hash Functions

• Straight-forward application of digital
  signatures can be expensive when the message is
  large
• In general, many security protocols benefit from
  using a digested or compressed representative
  of a message
• We typically need additional cryptographic
  properties in order for the compression operation
  to be useful
• This compression function is a hash function

Domain
Range
h(m)
18
Hash Functions, pg. 2

• Formally, a cryptographic hash function h takes
  an input message of arbitrary length and produces
  a message digest of fixed length, and satisfies
• Given a message m, h(m) is quick to calculate
• One-Way (preimage resistance) Given a digest y,
  it is computationally infeasible to find an m
  with h(m)y.
• Strongly Collision Free It is computationally
  infeasible to find messages m1 and m2 with
  h(m1)h(m2).
• Can we ever have h(m1)h(m2)? Yes. Why?
• We will look at a couple examples.

19
Chaum, vanHeijst, Pfitzman Hash

• We may use the DLOG problem to construct a hash
  function
• Choose a prime p such that q(p-1)/2 is also
  prime. (Theres an algorithm for doing this, but
  thats not our goal today). Choose two primitive
  roots a and b.
• The hash function h(m) will take integers (mod
  q2) to integers (mod p). Hence, producing half
  the bits.
• Write mx0x1q with .
• Define the hash by

20
CHP Hash is strongly collision-free

• Proposition If we know with
  , then we can solve the
  discrete logarithm .
• Proof Will be given on the board after we cover
  all of the slides.

21
SHA-1

• In order to get fast hash functions, we need to
  operate at the bit-level. SHA-1 is one such
  algorithm.
• Many of the popular hash functions (e.g. MD5,
  SHA-1) use an iterative design
• Start with a message m of arbitrary length and
  break it into n-bit blocks, mm1,m2,,ml. The
  last block is padded to fill out a full block
  size.
• Message blocks are processed via a sequence of
  rounds using a compression function h which
  combines current block and the result of the
  previous round
• X0 is an initial value, and Xl is the message
  digest.

22
SHA-1, pg. 2

• In SHA-1, we pad according to the rule
• Start with a message m of arbitrary length and
  break it into n-bit blocks.
• The last block is padded with a 1 followed by
  enough 0 bits to make the new message 64 bits
  short of a multiple of 512 bits in length.
• Into the 64 unfilled bits of the last block, we
  append the 64-bit representation of the length T
  of the message.
• Overall, we have
  blocks of 512 bits.
• The appended message becomes mm1,m2,,mL.

23
SHA-1, pg. 3 (Basic Operations)

• We will need the following bit operations

24
SHA-1, pg. 4 (Basic Algorithm)
25
SHA-1, pg. 5 (Inside the Alg.)
Initial 160-bit register X0H0,H1,H2,H3,H4
26
SHA-1, pg. 6 (Subregister Operations)

• The operations done by ft(b,C,D) depend on the
  round number t
• The word Wt depends on the round number t
• The constant Kt depends on the round number t

27
Message Authentication Codes

• A message authentication code (MAC) is a function
  that is used to prevent alteration of messages
• MACs use a shared key K between Alice and Bob
• Alice will send not only the message m, but also
  MACK(m).
• Bob checks whether the attached MAC matches what
  he calculates
• Eve cannot alter the message because she does not
  have K.
• The MAC takes two inputs the key K and an
  arbitrary size m.
• Ideally, a MAC should be a random mapping from
  all possible inputs to n-bits of output.
• The uncertainty (and security) of the MAC is
  directly associated with the size of the key K
• Remember to Eve, the message is known, so its
  the key that contains the security

28
CBC-MAC

• CBC-MAC is a method for turning a block cipher
  into a MAC
• Idea encrypt m using CBC mode and throw away all
  but last block of ciphertext.
• For messages P1, P2, , Pk, the MAC is calculated
  by
• Do not use the same key for encryption
  (confidentiality) and authentication!

29
CBC-MAC, pg. 2

• Be careful when using CBC-MAC. Heres a possible
  protocol failure
• Observe Fix K. If MAC(a)MAC(b), then MAC(ac)
  MAC(bc), where c is a single block length in
  size.
• Now, suppose attacker collects many MAC values
  and finds a collision. This gives a and b for
  which MAC(a)MAC(b).
• If attacker can get the sender to authenticate
  (ac) (How is another matter) then the
  attacker can replace the message being sent to
  the receiver with (bc).
• Comment Its not an easy attack to do, but it is
  a possible weakness!

30
CBC-MAC, pg. 3

• Practical Implementation Details
• Generally, if your message is m, do not just
  calculate MAC(m), rather you should make an
  intermediate message s(lm), where l is the
  length of m in a fixed-length format.
• Pad s to be a multiple of block size
• Apply CBC-MAC to the padded string s
• Output the last ciphertext block. Do not output
  any intermediate block values!
• CBC-MAC can reuse same code as confidentiality
  (encryption) functions
• CBC-MAC is generally tough to use correctly,
  though.

31
HMAC

• We may also use hash functions to build MACs.
• We cannot simply use MACK(m)h(Km) or h(mK)
• Having the key at the front allows for length
  extension attacks
• Having the key at the end allows for key-recovery
  attacks
• Designers of HMAC considered these issues
• HMAC computes
• Where a and b are constants that are specified.
• HMAC has been around for a while and has been
  cryptanalyzed. Its the preferred MAC to use.

32
Using MACs

• We must be careful using MACs.
• If Alice sends Bob mMACK(m) and Eve records
  this, she may send it again at a later time (the
  replay attack!)
• Generally, you want to authenticate not just the
  message, but the context. That is, you want to
  authenticate m and additional data d (such as
  message number, source, destination, protocol
  identifier, sizes for different fields, etc.)
• Why all these possibilities? If you tie the
  message to the specific context, then it is
  harder for an adversary to manipulate context
  fields to forge.
• Make certain, though, that you have clear rules
  on how to split concatenations (dm) back into d
  and m.

33
Problems with Hashes

• We must be careful when using hash functions,
  they are subject to some attacks
• Length Extension Attack Consider a block-based
  hash like SHA-1, with input blocks m(m1, m2, ,
  mk), and hash h(m).
• A new message m (m1, m2, , mk, mk1), will
  have hash h(m)h(h(m),mk1), where h is the
  compression sub-function.
• In systems, such as authentication applications,
  where we calculate h(Xm), Eve can append extra
  text to m and also update the hash.
• Partial Message Collision Attack Suppose we are
  able to find m and m such that h(m)h(m). If a
  system uses h(mX) as an authentication
  parameter, then due to the iterative nature
  h(mX)h(mX).
• An adversary can replace m with m during
  authentication.
• In general hashing practice, we really use f(m)
  h(h(m)m) or f(m)h(h(m)) as the hash.
