Title: Pure Bending of Straight Symmetrical Beams


1
(No Transcript)
2
Pure Bending of Straight Symmetrical Beams
  • Linear bending stress distribution, and no shear
    stress (Fig. 4.3)
  • Neutral axis passes through centroid of
    cross-section
  • Section modulus, ZI/c, used for the case when
    the neutral axis is also a symmetry axis for the
    cross-section
  • Table 4.2 for properties of plane sections
  • Restrictions to straight, homogeneous beams
    loaded in elastic range and cutting planes
    sufficiently far from discontinuities

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Bending of Straight Symmetrical Beams Under
Transverse Forces
  • Any cut cross-section loaded by two types of
    stresses (if no torsion occurs)
  • Bending stress as in case of pure bending
  • Transverse shear stresses
  • Direct and transverse shear stress
  • Direct average shear stress in pin and clevis
    joint (Fig. 4.4) is smaller than maximum stress
  • Non-linear distributions are caused in reality by
    stiffnesses and fits between mating members, etc.

8
(No Transcript)
9
(No Transcript)
10
Transverse Shear Stress Equations
  • Bending of laminated beam explains existence of
    transverse shear (Fig. 4.5)
  • Beam loaded in a vertical plane of symmetry
  • Elemental slab in equilibrium under differential
    bending and shear forces (Fig. 4.6)
  • Derived equation valid for any cross-sectional
    shape
  • Expressed in terms of moment of area about
    neutral axis, leading to the area moment method
    for calculating transverse shearing stresses
  • Irregular cross-sections can be divided into
    regular parts (4-25)

11
Transverse Shear Stress Equations
Stress distribution in section at z at distance
y1 from neutral axis
Area Moment method for calculating transverse
shear stresses
Irregular Cross-Section
12
(No Transcript)
13
Conclusions on Transverse Shearing Stress
Calculations
  • Maximum Value at Neutral Axis
  • Depends on Shape of Cross Section (Table 4.3)
  • Equal to Zero at Top and Bottom Boundaries
  • Important for Short Beams
  • Wood Beams if span/depth lt 24
  • Metal Beams with Thin Webs- if span/depthlt15
  • Metal Beams with Solid Section-if span/depthlt8

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
MAE 343-Intermediate Mechanics of
MaterialsHomework No. 2 - Thursday, Sep. 02,
2004
        1) Textbook problems required on
Thursday, Sep. 9, 2004
Problems 4.10 and 4.15     2)
Textbook problems recommended for practice before
Sep. 9, 2004   Problems 4.7 4.18
(except 4.10 and 4.15)
