Wireless Communications

1
Wireless Communications Alternative Power

• IGVC- Danielle E. Johnson BSEE
• Mary Grace Soleil B. Janas BSCE

2
Omnex R161 Wireless Receiver
3
Omnex R161 Wireless Receiver

• The R161 receiver has 19FET output
• One E-Stop output for safe emergency shutdown of
  power to the output and external circuits
• Designed to be switched to ground instead of
  battery

4
Omnex T50 Transmitter
5
Omnex Origa T50 transmitter

• Designed for digital ON/OFF applications
• Trusted Frequency Hopping Spread Spectrum
  technology
• Fits in pocket

6
Omnex Origa T100 Transmitter
7
Omnex Origa T100 Transmitter

• Trusted Frequency Hopping Spread Spectrum
  technology
• Maintenance Item- Battery
• High impact plastic exterior for rugged
  environments

8
Omnex Origa T110 Transmitter
9
Omnex T110 Transmitter

• Frequency Hopping Spread Spectrum
• Weatherproof Transmitter
• Ten Function controls
• Unique ID code for transmitter to ensure no two
  system conflict
• Power up and Power down modes
• Three shift functions
• Momentary
• Non-latched
• Latched

10
Power Sources

• On board Generator
• Detachable Power Supply

11
Detachable Power Supply 1

• Super Flower Plug-N 14cm Power Switching
• 450 Watt / 550 Watt Power Supply
• Adjustable 3 speed 14cm Fan w/Blue LED, ATX
  1.3/BTX Compatibility
• 64.00

12
Power Supply 2Ultra X-Finity PSU
Price 99.99
13
Power supply 2Ultra X-Finity PSU

• Supports AMD and Intel Motherboards
• Low Acoustic Noise
• 120mm Fan
• Meets ATX Version 2.2, v1.3, and
• ATX 12V Version 2.03 Specifications
• Short Circuit Protection
• In-Rush Current Protection
• Thermal Overload Cutoff Protection
• MTBF gt 100,000 Hours at Full Load,
• 110VAC and 25C Ambient Condition
• FCC and UL Recognized

14
Power Supply 3Enermax Noisetaker AX 2.0
Price 152.99
15
Power Supply 3Enermax Noisetaker AX 2.0

• Independent 12V rails supply to MB/CPU and drives

• Active PFC reduced harmonic distortion
• Smart Fan Delay
• ATX12V ver 2.0
• Dual 12V rails
• Supports PCI Express Video card that require a 6
  pins connectors

16
Power Supply 4Xion 600 watt PowerReal ATX
Price 89.99
17
Power Supply 4Xion PowerReal ATX

• 20/24-Pins Mainboard Connector
• SRS (Smart Relay System)
• 140 mm Cooling Blue LED Fan (One of a kind and
  patented)
• SATA Ready
• Manual/Automatic Fan Speed Switch
• Acoustic Silent Control
• PCI Express VGA Connector (6 pins)
• Coated Surface

18
Power Supply 5Ultra V-Series ATX
Price 39.99
19
Power Supply 5 Ultra V-Series ATX

• Supports AMD and Intel Motherboards
• Low Acoustic Noise
• Meets ATX Version 2.03 and ATX 12V Version 1.2
  Specifications
• Short Circuit Protection
• In-Rush Current Protection
• Thermal Overload Cutoff Protection MTBF gt 100,000
  Hours at Full Load, 110VAC and 25C Ambient
  Condition

20
Power Supply 6Coolmax ATX
Price 34.99
21
Power Supply 6Coolmax ATX

• Long life 120mm silent cooling fan
• High performance components are designed for
  extra long life and provide maximum system
  performance
• Heavy duty transformers designed to support high
  performance system several drives
• Built in EMI filter, low ripple noise
• Over voltage,Over power and Short circuit
  protection
• Efficiencygt65 at full load

22
On Board Generator
23
Generator 1Robin 900 Watt Portable Generator
Price 699.99
24
Robin R1100 Generator

• Extreme Easy Starting Features automatic
  decompression direct injection systems
• New Silent Technology Very quiet 59 decibels _at_
  7 meters
• Lightweight
• Fuel Efficient Reliable air-cooled Robin Suburu
  engine runs up to 4 hours
• Weight- 55lbs
• Dimensions- 19.3"L x 11.6"W x 17.5"H

25
Generator 2Mitsubishi 950 Watt Generator w/
Inverter Technology
Price 599.99
26
Mitsubishi 950 Watt Generator w/ Inverter
Technology

• Inverter Technology Safely power computers and
  sensitive electronics
• Extremely Lightweight (45 lbs) Easy to take
  tailgating, camping, hunting, etc.
• Very Quiet (60 decibels _at_ 7 meters) Power your
  stuff without disturbing your neighbors
• Fuel Tank- 1 Gallon
• Run Time- (50 load) 5 hours

27
Generator 3Coleman Powermate Pulse 1850
Price 499.99
28
Generator 3Coleman Powermate Pulse 1850

• 3.5 HP Briggs Stratton Engine
• 1500 Running/ 1850 Starting Watts
• 7 hours Run Time _at_ 50 load
• Rubber Feet to Minimize Vibration
• No converter
• Weight- 70lbs
• Fuel Tank 1.3 Gallon
• Four 120VAC/ 15Amp outlets

29
Generator 4Coleman Powermate Sport 1850
Price 450.00
30
Generator 4 Coleman Powermate Sport 1850

• 3.5 HP Briggs Stratton Engine
• 1500 Running/ 1850 Starting Watts
• 7 hours Run Time _at_ 50 load
• Rubber Feet to Minimize Vibration
• No converter
• Weight- 70lbs
• Fuel Tank 1.3 Gallon
• Two 120VAC/ 15Amp outlets, One 12VDC 15Amp Outlet
