NAESB Smart Grid Task Force PAP 04 Update

1
NAESB Smart Grid Task ForcePAP 04 Update

• Robert B. Burke NAESB Task Force Co-Chair
• Toby Considine

2
PAP 04 DescriptionDevelop Common Mechanism for
Communications Schedule and Interval for Energy
Transactions

• For human interactions and human scheduling,
  ICalendar format is used.
• There is no equivalent standard for use in web
  services.
• Goal of this action plan is to develop a standard
  for how schedule and event information is
  communicated between and within services.
• The standard should support all of the
  functionality currently supported by ICalendar
  for application to the completion of a web
  service contract.
• Bring a common scheduling operation to diverse
  contracts in different domains.

3
PAP 04 Objectives

• Engage key participants from domains from Survey
  work to date and determine short-list precursors.

• Determine plan to expedite development of
  specifications to standards.
• Develop a plan for cross-referencing schedules
  and other documents/contracts in a message.

4
PAP 04 Document Ready For Comment

• On September 30, 2009, the National Institute of
  Standards and Technology officially assigned
  NAESB the responsibility to develop Requirements
  and Use Cases pertinent to Priority Action Plan
  items 3, 4 and 9.
• Recommendation contains a set of requirements
  relating to the use of date and time based data
  elements that are used in transactions for Demand
  Response Programs.
• This standard representation for date/time based
  data elements, would possibly be an XML
  representation of Icalendar date/times.

5
Sample Instances
Representative Instances Description
Adjustment Window The period of time prior to a Demand Response Event used for calculating a Baseline Adjustment.
Advance Notification One or more communications to Demand Resources of an impending Demand Response Event in advance of the actual event.
Baseline Window The window of time preceding and optionally following, a Demand Response Event over which the electricity consumption data is collected for the purpose of establishing a Baseline.
Demand Response Event The time periods, deadlines and transitions during which Demand Resources perform. The Program Administrator should specify the duration and applicability of a Demand Response Event. All deadlines, time periods and transitions may not be applicable to all Demand Response products or services.
Deployment The time at which a Demand Resource begins reducing Demand on the system in response to an instruction.
Deployment Period The time in a Demand Response Event beginning with the Deployment and ending with the Release/Recall
6
PAP 04 Document Ready For Comment

• Document reviewed by NAESB SGTF on Nov. 5
• Task Force voted to release for comment
• Comments due November 30, 2009
