Chair Design

1
Chair Design

• 8th grade project

Written by Sony Gala
2
Problem

• Students will use the engineering design process
  to design and build a cardboard chair. The
  teacher will sit in the chair for at least 90
  seconds.
• Final products
• Engineering design portfolio (need not be typed)
• ¼ scale chair
• Cardboard chair

3
Requirements

• Students will work in groups of four
• Assign each member a duty
• Member Name - Design Engineer
• Member Name - Document handler
• Member Name - Researcher
• Member Name - Material handler
• Decide on a group name relate to the project
  (ex CardChairs R Us)

4

• Requirements
• 2 sheets of cardboard 7 x 3.5
• Chair must have a back
• Seat of chair must be at least 18 off the floor.
• Constraints
• Students will not use any form of adhesives to
  build the cardboard chair
• No glue, tape, staples, nails etc.

5
(No Transcript)
6
Center of Gravity

• A structure remains standing only if its center
  of gravity is directly over the perimeter of its
  base.

Center of Gravity
7
Loads and Joints

• 1. What is a load?
• What is the load on a chair?
• What is a static load?
• What is the static load on a chair?
• What is a dynamic load?
• What is the dynamic load on a chair?
• What are joints?
• How can one take care of weak links?
• Why do most chairs fail?
• 10. What does orthotropic mean?
• 11. Give an example of orthotropic material.
• 12. How would you cut cardboard?

8
Orthotropic Material

1. What does orthotropic mean?
2. Give an example of orthotropic material.
3. How would you cut cardboard?

9

• Research
• Go to the Cardboard chairs websites from Ms.
  Galas website.
• http//www.rockdale.k12.ga.us/personal/sgala2/8th
  grade/default.aspx
• Watch video
• Read about cardboard chair designs
• Google image search on cardboard chairs
• http//www.pbs.org/wgbh/buildingbig/lab/materials.
  html

10
Alternative Solutions

• Each student in a group sketches three chairs you
  may have at home or school.
• ex dining chair, sofa chair, office chair, deck
  chair, lawn chair, etc.
• Think about form, comfort, looks etc.
• Sketch ideas for cardboard chair.
• Use graph paper

11

• (copy definition)
• Orthographic Drawing sketches made in two
  dimensional views. Objects can be seen from the
  front, top, side and back.

12

• Measure your classroom chair (inches)
• Fill in the chart provided. This will give you an
  idea about chair dimensions.

Standard Classroom chair Length Height Width
Back of chair
Chair seat
Legs or base
13
Plan on measurements for cardboard chair
(inches) Fill in chart. Convert all measurements
to ¼ scale. Divide each number by 4. Write ¼
scale number in parenthesis.
Your Cardboard Chair Length Height Width
Back of chair
Chair seat
Legs or base
14
Final Design

• Use graph paper, ruler and pencil
• Orthographic drawings front view, side view and
  top view
• Show measurements

Scale 4 1
18 inches
15
¼ scale chairs

• Refer to the orthographic drawing
• Use one sheet of poster paper
• Draw and cut out patterns to build a ¼ scale
  chair.
• Remember no adhesives or attachements of any type

16
Full Size Chairs

• First draw patterns on the cardboard sheets
• Minimize use of material
• Use gloves, base cardboard mats and box cutters
• Score cardboard to make sharp folds
• Cut slots that are straight and parallel to make
  tight joints
