Title: Supernovae


1
Supernovae
Lab 9

2
Lets go Supernova!
  • Stars which are 8x massive than our Sun end
    their lives in a most spectacular way they go
    supernova!
  • First, the star swells into a red supergiant
  • Then core yields to gravity and begins shrinking
  • As it shrinks, it grows hotter and denser

3
Sequence of events
  • Then a new series of nuclear reactions begin to
    occur....temporarily halting the collapse of the
    core
  • When the core contains just iron, there is
    nothing left to fuse and fusion ceases
  • In less than a second, the star begins the final
    phase of gravitational collapse
  • The core temperature rises to over 100 billion
    degrees as the iron atoms are crushed together

4
Core Collapse!
  • The repulsive force between the nuclei overcomes
    the force of gravity
  • This combination, a process called "electron
    capture", creates a neutron and releases a
    neutrino
  • The neutrinos escape from the core, carrying away
    energy and further accelerating the collapse,
    which proceeds in milliseconds as the core
    detaches from the outer layers of the star
  • This is called core collapse!
  • So the core compresses, but then recoils

5
Ka-boom!!!
  • The energy of the recoil is transferred to the
    envelope of the star, which then explodes and
    produces a shock wave
  • As the shock wave travels to the star's outer
    layers, the material is heated, fusing to form
    new elements and radioactive isotopes
  • The shock then propels the matter out into space
  • The material that is exploded away from the star
    is now known as a supernova remnant
  • All that remains of the original star is a small,
    super-dense core composed almost entirely of
    neutrons -- a neutron star
  • If the original star was very massive (15 or
    more times the mass of our Sun), even the
    neutrons cannot survive the core collapse...and a
    black hole forms

6
Implosion to Explosion!
  • Even neutrons sometimes fail depending on the
    mass of the star's core. When the collapse is
    abruptly stopped by the neutrons, matter bounces
    off the hard iron core, thus turning the
    implosion into an explosion ka-BOOM!!!

7
Remnant of Kepler's Supernova, SN 1604
8
Temps of Fusion
  • Min temp required for the fusion of Hydrogen is 5
    million degrees
  • More protons in nuclei require higher
    temperatures - to fuse Carbon requires a
    temperature of about 1 billion degrees
  • Lighter elements release energy when they fuse
    and heavier elements release energy when they
    split
  • As iron "ash" begins to accumulate in the core of
    the star, gravity pulls more and more mass into
    the area of fusion, which, in turn, goes through
    all of the steps of fusion Hydrogen ? helium by
    the proton chain, He? carbon by the triple a
    process, C and He combine into oxygen, O fuses
    into neon, Ne into magnesium, Mg into silicon and
    Si into iron

9
The Crab Nebula is an expanding cloud of gas
created by the 1054 supernova
10
(No Transcript)
11
Animation of a supernova
  • http//heasarc.gsfc.nasa.gov/docs/snr.html

12
Types of Supernovae
  • Two distinct types of supernovae -- those which
    occur for a single massive star and those which
    occur because of mass transfer onto a white dwarf
    in a binary system
  • Difference between the two types lies only in
    what gets the process started toward the
    explosion

13
Supernovae Classification based on H
  • The presence or absence of a line from hydrogen
  • If a supernova's spectrum contains a hydrogen
    line, it is classified Type II, otherwise it is
    Type I

14
A White Dwarf Goes Thermonuclear Type I
  • A white dwarf star in a binary star system will
    draw material off its companion star if they are
    close to each other
  • Once the in-falling matter from the companion
    star cause the white dwarf to approach a mass of
    1.4 times that of the Sun (the Chandrasekhar
    limit), the pressure at the center increases so C
    and O nuclei to start to fuse uncontrollably
  • This results in a thermonuclear detonation of the
    entire star
  • Nothing is left behind, except whatever elements
    were left over from the white dwarf or forged in
    the supernova blast
  • Among the new elements is radioactive nickel,
    which liberates huge amounts of energy, including
    visible light

15
Type II
  • A much larger star, however, has enough gravity
    needed to create T and P to cause the C in the
    core to fuse once the star contracts
  • The cores of these massive stars become layered
    like onions as progressively heavier atomic
    nuclei build up at the center
  • An outermost layer of H gas, sinks down on a
    layer of H fusing into He, the He sinks down into
    a layer of He fusing into C, and the C sinks down
    to fuse into heavier elements

16
Type II contd
  • These stars go through progressive stages where
    the core will shrink, atomic nuclei which were
    previously unfusable start fusing then the core
    springs back into equilibrium with gravity
  • This causes them to be irregular variables -
    each new burst of fusion pushes elements out of
    the fusing core into the "stellar envelope
  • This dims the star, and causes gravity to pull
    mass back into the fusing core and begin the
    cycle over again

17
Type II subdivisions
  • Type II supernovae can be further classified
    based on the shape of their light curves into
    Type II-P and Type II-L
  • Type II-P reach a "plateau" in their light curve
    while II-Ls have a "linear" decrease in their
    light curve ("linear" in magnitude versus time,
    or exponential in luminosity versus time)
  • This is due to differences in the envelope of the
    stars.
  • II-Ps have a large H envelope that traps energy
    released in the form of gamma rays and releases
    it slowly, while II-Ls are believed to have much
    smaller envelopes converting less of the ? ray
    energy into visible light

18
Subdivisions
  • Subdivisions according to the presence of other
    lines and the shape of its light curve
  • Type I
  • - No hydrogen Balmer lines
  • Type Ia
  • - Si II line at 615.0 nm
  • Type Ib
  • - He I line at 587.6 nm
  • Type Ic
  • Weak or no He lines
  • Type II
  • - Has hydrogen Balmer lines
  • Type II-P
  • -Plateau
  • Type II-L
  • - Linear

19
Type Ia
  • Observations of Type Ia supernovae reveal a
    picture of the cosmic environment in the way that
    the width of tree ring growth indicates the
    Earth's climatic environment over time
  • Unlike the other types of supernovae, Type Ia
    supernovae are generally found in all types of
    galaxies, including ellipticals.

20
Hypernovae
  • There has been some speculation that some
    exceptionally large stars may instead produce a
    "hypernova" when they die
  • Here, the core of a very massive star collapses
    directly into a black hole and 2 extremely
    energetic jets of plasma are emitted from its
    rotational poles at nearly light speed.
  • These jets emit intense ? rays

21
Are We Made of Stardust?
  • Yes! (recycled, that is)
  • The common elements are made through nuclear
    fusion in the stable cores of stars
  • Supernovae are not stable, so they can make heavy
    elements beyond iron that require more energy to
    form.
  • These are the elements that make up stars,
    planets and everything on Earth -- including
    ourselves
