Unit II: Shallow Foundations

1
Unit II Shallow Foundations
2
Settlement
3
Distribution of soil pressure
Soil pressure distribution in cohesionless soil
Soil pressure distribution in cohesive soil
RIGID FOUNDATION
4
Distribution of soil pressure
Soil pressure distribution in cohesionless soil
Soil pressure distribution in cohesive soil
FLEXIBLE FOUNDATION
5
Components of Settlement

• Se - Elastic or Immediate Settlement
• Sc - Consolidation Settlement
• Ss - Secondary Settlement

S Se Sc Ss
6
Computation of Elastic Settlement

• Elastic settlement based on the Theory of
  Elasticity
• Janbu et al., (1956) method of determining
  settlement under an undrained condition
• Schmertmann's method of calculating settlement in
  granular soils by using CPT values.

7
Computation of Modulus of Elasticity

• Laboratory Methods
• Triaxial tests on representative undisturbed
  samples
• Other tests to find undrained cohesion of soil
• A varies from 500 to 1500 for inorganic stiff
  clays
• A varies from 100 to 500 for organic or soft
  clays
• Field Methods
• Plate Load Test
• Standard penetration test (SPT)
• Static cone penetration test (CPT)

8
Equations for computing Es using of SPT and CPT
values (in kPa)
9
Based on Theory of Elasticity
10
Elastic Settlement

• Net elastic settlement of flexible footing

µ varies from 0.1 to 0.5 For saturated clay, µ
0.5
If is a function of the L/B ratio of the
foundation, and the thickness H of the
compressible layer.
11
Terzaghis method of calculating If from curves
derived by Steinbrenner (1934)
For µ 0.5, If F1, µ 0, If F1 F2. For
Intermediate Values of µ,

F1 and F2 versus H/B
Method of estimating settlement
12

• Elastic Settlement of Rigid Footing
• The immediate settlement at the center is
  approximately 0.8times that obtained for a
  flexible foundation at the center.

Sef CrdfSe
Sef Final elastic settlement Cr Rigidity
Factor ( Highly rigid footing, Cr 0.8) Df
Depth factor Se Settlement for a surface
flexible footing
13
Influence factor Bowles

• Bowles (1996) - Influence factor
• (for various shapes of rigid and flexible
  footings)

14
JANBU, et al METHOD
15
JANBU, BJERRUM AND KJAERNSLI'S METHOD
OFDETERMINING ELASTIC SETTLEMENT UNDER
UNDRAINEDCONDITIONS
16
SCHMERTMANN'S METHOD OF CALCULATING SETTLEMENT IN
GRANULAR SOILS BY USING CPT VALUES
17
Modified triangular vertical strain influence
factor distribution diagram
18
SCHMERTMANN'S METHOD
19
SCHMERTMANN'S METHOD

• C1 C2
• Modulus of Elasticity Es

t Time in years for which settlement is
required
20
SCHMERTMANN'S METHOD

• Lunne and Christoffersen (1985)
• For normally consolidated sand
• For over consolidated sand (OCRgt2)

21
Consolidation Settlement
22
Equations for Computing Settlement

• Normally consolidated clay
• Over consolidated clay
• for
• for
