THUNDERSTORMS

1
THUNDERSTORMS
2

• Types of Thunderstorms
• Airmass or Ordinary Cell Thunderstorms
• Supercell / Severe Thunderstorms

• Limited wind shear
• Often form along shallow
• boundaries of converging
• surface winds

• Precipitation does not fall
• into the updraft
• Cluster of cells at various
• developmental stages due
• to cold outflow undercutting
• updraft

3

• ORDINARY CELL THUNDERSTORMS
• CUMULUS STAGE
• Sun heats the land
• Warm, humid air rises
• Condensation point is
• reached, producing a
• cumulus cloud
• Grows quickly (minutes)
• because of the release of
• latent heat
• Updrafts suspend droplets
• Towering cumulus or

4

• MATURE STAGE
• Droplets large enough
• to overcome resistance
• of updrafts (rain/hail)
• Entrainment
• Drier air is drawn in
• Air descends in
• downdraft, due to
• evaporative cooling
• and falling rain/hail
• Anvil head when stable
• layer reached (cloud
• follows horizontal wind)
• Strongest stage, with

5
Mature, ordinary cell thunderstorm with anvil head
6
(No Transcript)
7
Downdrafts and Gust Fronts
8
Microbursts create aviation hazards
9

• 3. DISSIPATING STAGE
• Updrafts weaken as gust front moves away from the
  storm
• Downdrafts cut off the
• storms fuel supply
• Anvil head sometimes
• remains afterward
• Ordinary cell
• thunderstorms may pass through all three stages
  in only 60 minutes

10
Review of Stages Developing (cumulus), mature
and dissipating
11

• Thunderstorms
• Typical conditions
• Conditional instability
• Trigger Mechanism
• (eg. front, sea-breeze front, mountains,
• localized zones of excess surface heating,
• shallow boundaries of converging surface
• winds)

12
Conditional Instability
13
Thunderstorm Development

• 1. Heating within boundary layer
• Air trapped here due to stable layer aloft
• increasing heat/moisture within boundary layer
• (BL).
• External trigger mechanism forces air parcels
• to rise to the lifted condensation level (LCL)
• Clouds form and temperature follows MALR
• 3. Parcel may reach level of free convection
• (LFC). Parcel accelerates under own buoyancy.
• Warmer than surroundings - explosive updrafts
• 4. Saturated parcel continues to rise until
• stable layer is reached

14
CAPE Convective available potential energy (J/kg)
15
CAPE (J/kg) 0 Stable lt1000 Marginally Unstable
1000-2500 Moderately Unstable 2500-3000 Very
Unstable gt3500 Extremely Unstable
16

• The Severe Storm Environment
• High surface dew point
• Cold air aloft (increases conditional
  instability)
• Shallow, statically-stable layer capping the
• boundary layer
• 4. Strong winds aloft (aids tornado development)
• 5. Wind shear in low levels (allows for
• long-lasting storms)
• Dry air at mid-levels (increases downdraft
• velocities)

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
A squall line (MCS)
21
Radar image of squall line
22
Wind shear and vertical motions in a squall line
thunderstorm
23
Mesoscale convective complex (MCC)
24
Outflow Boundaries
25
Thunderstorm movement in an MCC
26
See http//rsd.gsfc.nasa.gov/rsd/movies/preview.h
tml
27

• Tornado Development
• Pre-storm conditions
• Horizontal shaft of rotating air at altitude of
• wind shift (generally S winds near surface
• and W winds aloft)
• 2. If capping is breached and violent
• convection occurs, the rotating column is
• tilted toward the vertical

28
(No Transcript)
29

• Supercell Thunderstorms
• Defined by mid-level rotation (mesocyclone)
• Highest vorticity near updraft core
• Supercells form under the following conditions
• High CAPE, capping layer, cold air aloft, large
• wind shear

30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34

• Tornadogenesis
• Mesocyclone 5-20 km wide develops
• Vortex stretching Lower portion of
• mesocyclone narrows in strong updrafts
• Wind speed increases here due to conservation
• of angular momentum
• Narrow funnel develops visible due to adiabatic
• cooling associated with pressure droppage

35
(No Transcript)
36
(No Transcript)
37
2 hours after the Lethbridge tornado
38
(No Transcript)
39
Tornado producing supercell
insert fig 11-29
40
Global tornado frequency
insert fig 11-32
41
insert table 11-2
42

• Waterspouts
• Similar to tornadoes
• Develop over warm waters
• Smaller and weaker than tornadoes

43
Distribution of lightning strikes
insert fig 11-23
44

• Lightning
• Source of lightning the cumulonimbus cloud
• Collisions between supercooled cloud particles
  and
• graupel (or hail) cause clouds to become charged
• Most of the base of the cumulonimbus cloud
• becomes negatively charged the rest becomes
• positively charged (positive electric dipole)
• Net transfer of positive ions from warmer object
  to
• colder object (hailstone gets negatively charged

• fall toward bottom - ice crystals get charge)
• Many theories exist open area of research

45
(No Transcript)
46
Development of lightning
47
Flashes per square kilometre per year
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Four types of cloud- ground lightning
Most common
52
(No Transcript)
53

• Intracloud Discharges
• Cloud to Ground Discharges
• - death and destruction of property
• - disruption of power and communication
• - ignition of forest fires
• - Lightning is an excellent source of soil
• nitrogen!

54
Cloud-ground lightning 90 induced by negatively
charged leaders 10 induced by positively charged
leaders Sometimes, there are ground to cloud
leaders Negative cloud-ground lightning Leaders
branch toward the ground at about 200 km/s, with
a current of 100-1000 Amperes The return stroke
produces the bright flash
55

• Potential difference between lower portion of
• negatively-charged leader and ground
• 10,000,000 V
• As the leader nears the ground, the electric
• potential breaks the threshold breakdown
• strength of air
• An upward-moving discharge is emitted from
• the Earth to meet with the leader

56
The return stroke lasts about 100
microseconds, and carries a charge of 30
kiloAmperes, producing the main flash The
temperature along the channel heats to 30,000
K, creating an expanding high pressure channel,
producing shockwaves
57
Blue jet
58
Multiple suction vortices greatly increase damage
insert fig 11-37
