Cell Lab

1
Cell Lab
2

• Title Cell Lab
• Purpose
• 1. To review cell structures and their
  functions.
• 2. To compare eukaryotic prokaryotic cells.
• 3. To observe the specialization of cell
  structure function that occurs in multicellular
  organisms.

3

• Pre-Lab
• Drawings
• Draw an animal cell and label the following
  organelles.
• Nucleus, Smooth ER, Rough ER, Golgi, Mitocondria,
  Cell Membrane, Ribosomes, Vesicle, Cytoskeleton,
  Lysosome
• Draw a plant cell and label the following
  organelles.
• Nucleus, cell wall, cell membrane, central
  vacuole, chloroplast, golgi, ER, mitochondria
• Draw a prokaryotic cell and label the following
  organelles.
• Cilia, flagella, DNA, capsid

4

• Questions
• 1. What is the difference between prokaryotic
  eukaryotic cells?
• 2. What cellular organelles are only found in
  plant cells?
• 3. Where in the cell is DNA stored in eukaryotic
  cells?
• 4. What organelle provides the cell with energy?
• 5. What organelle in plants is responsible for
  converting solar energy to chemical energy
  (photosynthesis)?

5

• Lab
• Part I. Cells of the Kingdom Animalia
• Part II. Cells of the Kingdom Plantae
• Part III. Cells of the Kingdom Monera

6
Analysis
Cell Type Pro. Or Euk. Size rank Cell Shape (Draw) Producer or Consumer Plant, Animal, Bacteria Uni or Multi
Cheek
Elodea
Bacteria
7

• 1. Compare the shape of the cheek cells to the
  elodea cells.
• 2. Describe the movement of the chloroplasts in
  the Elodea.
• 3. What cell parts are found in the Elodea that
  are not present in the cheek cells?
• 4. Compare the bacteria cells to the cheek and
  Elodea cells in terms of size and organelles
  present.
• 5. What special job are Elodea cells built for?
  What organelle is present that undergoes this
  process?
