Microbiology- Microscopy and Staining

1
Microbiology-Microscopy and Staining

• Microbiology
• Chapter 3, pp. 50-73.

2
What is the smallest object ever seen?
3
SPM of a Bacillus Bacterium
4
SPM of Coccus Bacterium
5
Carbon Atoms on Graphite
6
Neon Atoms on Nickel
7
What is light?

• Light is visible energy!

8
Wavelength

• Length of a light ray
• Greek letter lambda

9
Wavelength
10
Wavelength
11
The sun

• Produces a continuous spectrum of of
  electromagnetic radiation with waves of various
  lengths

12
See it move
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Can other animals see other parts of the EM
spectrum?

• An Application
• Video- Discovery Vipers (Pit Vipers)

19
Properties of Light

• Wavelength and Resolution
• Light and Objects

20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
How does wavelength compare to energy?

• An Application Video- The Blue Planet The Deep

24
Light and Wavelength

• Length of a light ray- wavelength.
• Usually represented by the Greek letter ?.
• Sun produces a continuous spectrum of EM
  radiation.
• Visible light is from about ? 420 nm (blue) to
  680 nm (red).
• Fig 3.2, p 51.

25
(No Transcript)
26
A. Resolution

• Resolution - the ability to see two objects as
  separate and discrete.
• A wavelength of light must be able to pass
  between the objects for them to be seen as
  separate.
• Shorter the wavelength, the greater the
  resolution.

27
Resolution

• Visible Light (? 550 nm) has a resolution of
  about 220 nm.
• UV (? 100-400 nm) has a resolution of about 110
  nm.
• Electron Microscopes use electrons rather than
  light, e- ? 0.005 nm, resolution of EM is about
  0.2 nm

28
B. Reflection

• Fig. 3.7, p. 56.
• Reflection- particular wavelengths strike an
  object and bounce back
• Reflected wavelengths give objects color.

29
(No Transcript)
30
C. Transmission

• Transmission- passage of light through an object.
• Opaque objects cannot transmit any light.

31
D. Absorption

• Absorption- when light rays do not pass through
  nor do they bounce back, but are used when light
  rays are neither transmitted nor reflected, they
  are absorbed.

32
(No Transcript)
33
What happens to the energy of absorbed light?

• Energy from light rays can be used.
• Green leaf absorbs all wavelengths (except green)
  for use in photosynthesis.
• Energy from absorbed light is transformed into
  heat.
• Ex. Black car on a hot day.

34
What happens to the energy of absorbed light?

• Absorbed light rays are changed into longer
  wavelengths and reemitted- luminescence
• Bacteria and other organisms can bioluminesce

35
Two Types of 1. Luminescence

• a. If luminescence occurs after an object has
  been exposed to light - phosphorescence.

36
Deep Sea Angler Fish
37
Phosphorescent Bacteria in Lanternfish
38
Show me Phosphorescence!

• Vibrio fischeri- a phosphorescent bacterium

39
Two types of 1. Luminescence

• b. If luminescence occurs only while light rays
  are striking an object - fluorescence.

40
Fluorescent Methanosarcina Bacterium
41
Use of Fluorescent Antibodies to Stain Cells
(Bovine Pulmonary Arterial Endothelial Cell)
42
Show me Fluorescence!

• Pseudomonas fluorescens- a fluorescent bacterium

43
(No Transcript)
44
An Application of Refraction

• Video Built for the Kill- River

45
E. Refraction

• Refraction- bending of light as it passes from
  one medium to another of a different density.
• Index of Refraction- a measure of the speed at
  which light passes through a material.

46
A Magic Trick!

• Using the physics of light to make money!
