Condor Tutorial

1
Condor Tutorial

• Prabhaker Mateti
• Wright State University

2
Acknowledgements

• Many of these slides are adapted from
  tutorials byMiron Livny, and his
  associatesUniversity of Wisconsin-Madisonhttp//
  www.cs.wisc.edu/condor

3
Clusters with Part Time Nodes

• Cycle Stealing Running of jobs on a workstations
  that don't belong to the owner.
• Definition of Idleness E.g., No keyboard and no
  mouse activity
• Tools/Libraries
• Condor
• PVM
• MPI

4
Performance v. Throughput

• High Performance - Very large amounts of
  processing capacity over short time periods
• FLOPS - Floating Point Operations Per Second
• High Throughput - Large amounts of processing
  capacity sustained over very long time periods
• FLOPY - Floating Point Operations Per Year
• FLOPY 365x24x60x60FLOPS?

5
Cooperation

• Workstations are personal
• Others use slows you down
• Immediate-Eviction
• Pause-and-Migrate
• Willing to share
• Letting you cycle-steal
• Willing to trust

6
Granularity of Migration

• Process migration
• Process Collection of objects
• at least one active object
• Object migration
• Passive objects
• Active objects

7
Migration of Jobs Technical Issues

• Checkpointing Preserving the state of the
  process so it can be resumed.
• One architecture to another
• Your environment
• keyboard, mouse, display, files,

8
Condor

• A system for high throughput computing by making
  use of idle computing resources
• Lots of jobs over a long period of time, not a
  short burst of high performance
• Manages both machines and jobs
• Has been stable, and delivered thousands of CPU
  hours

9
Condor Techniques

• Migratory programs
• Checkpointing
• Remote IO
• Resource matching

10
Condor Assumptions

• Large numbers of workstations are idle most of
  the time
• Owners of such machines would not mind their use
  by others while idle
• Owners want their work to be given high priority

11
Roles

• Owner offers his machine for use by others
• User requests to run his jobs
• Administrator manages the pool of available
  machines
• Multiple roles possible

12
Classified Advertisements Example

• MyType "Machine"
• TargetType "Job"
• Name "froth.cs.wisc.edu"
• StartdIpAddr
• "lt128.105.73.44
• 33846gt"
• Arch "INTEL"
• OpSys "SOLARIS26"
• VirtualMemory 225312

• Disk 35957
• KFlops 21058
• Mips 103
• LoadAvg 0.011719
• KeyboardIdle 12
• Cpus 1
• Memory 128
• Requirements LoadAvg lt 0.300000
  KeyboardIdle gt 15 60
• Rank 0

13
Condor User Requests

• Describes the program, and its needs
• Example condor_submit File
• Universe standard
• Executable /home/wsu03/condor/my_job.condor
• Input my_job.stdin
• Output my_job.stdout
• Error my_job.stderr
• Log my_job.log
• Arguments -arg1 -arg2
• InitialDir /home/wsu03/condor/run_1
• Queue

14
ClassAds Example for Jobs

• Requirements Arch INTEL
• OpSys LINUX
• Memory gt 20
• Rank (Memory gt 32)
• ( (Memory 100)
• (IsDedicated 10000)
• Mips )

15
Condor Pool of Machines

• Pool can be a single machine, or a group of
  machines volunteered by their owners
• Determined by a central manager - the
  matchmaker and centralized information repository
• Each machine runs various daemons to provide
  different services, either to the users who
  submit jobs, the machine owners, or the pool
  itself

16
Condor System Structure
17
Condor Agents

• Condor Resource Agent
• condor_startd daemon
• allows a machine to execute Condor jobs
• enforces owner policy
• Condor User Agent
• condor_schedd daemon
• allows a machine to submit jobs to a pool

18
Condor Robustness

• Checkpointing allows guaranteed forward progress
  of your jobs, even jobs that run for weeks before
  completion
• If an execute machine crashes, you only loose
  work done since the last checkpoint
• Condor maintains a persistent job queue - if the
  submit machine crashes, Condor will recover

19
Whats Condor Good For?

• Managing a large number of jobs
• You specify the jobs in a file and submit them to
  Condor, which runs them all and can send you
  email when they complete
• Mechanisms to help you manage huge numbers of
  jobs (1000s), all the data, etc.
• Condor can handle inter-job dependencies (DAGMan)

20
Throughput

• Checkpointing allows your job to run on
  opportunistic resources, not dedicated
• Checkpointing permits migration - if a machine is
  no longer available, migrate
• With remote system calls, you dont even need an
  account on a machine where your job executes

21
Can your program work with Condor?

• What kind of I/O does it do?
• Does it use TCP/IP? (network sockets)
• Can the job be resumed?
• Multiple processes?
• fork(), pvm_addhost(), etc.

22
Typical IO

• Interactive TTY
• Batch TTY (just reads from STDIN and writes to
  STDOUT or STDERR, but you can redirect to/from
  files)
• X Windows
• NFS, AFS, or another network file system
• Local file system
• TCP/IP

23
Condor Universes

• Different universes support different
  functionalities
• Vanilla
• Standard
• Scheduler
• PVM

24
Condor Universes IO support

• No support for interactive TTY

X11 NFS LocalFiles TCP
Vanilla x x - x
Standard - x x -
Scheduler x x x x
PVM x x x x
25
Condor Universes

• PVM (Parallel Virtual Machine)
• Multiple processes in Condor
• Scheduler
• The job is run on the submit machine, not on a
  remote execute machine
• Job is automatically restarted if the
  condor_schedd is shutdown
• Used to schedule jobs

26
Submitting Jobs to Condor

• Choosing a Universe for your job
• Preparing your job
• Making it batch-ready
• Re-linking if checkpointing and remote system
  calls are desired (condor_compile)
• Creating a submit description file
• condor_submit your request to the User Agent
  (condor_schedd)

27
Making your job batch-ready

• Must be able to run in the background no
  interactive input, windows, GUI, etc.
• Can still use STDIN, STDOUT, and STDERR but files
  are used for these instead of the actual devices
• If your job expects input from the keyboard, you
  have to put the input you want into a file

28
Preparing Your Job (contd)

• If you are going to use the standard universe
  with checkpointing and remote system calls, you
  must re-link your job with Condors libraries
• condor_compile gcc -o myjob myjob.c

29
Submit Description File

• Tells Condor about your job
• Which executable, universe, input, output and
  error files to use, command-line arguments,
  environment variables, any special requirements
  or preferences (more on this later)
• Can describe many jobs at once (a cluster) each
  with different input, arguments, output, etc.

30
Example condor_submit File
Universe standard Executable
/home/wsu03/condor/my_job.condor Input
my_job.stdin Output my_job.stdout Error
my_job.stderr Log my_job.log Arguments
-arg1 -arg2 InitialDir /home/wsu03/condor/ru
n_1 Queue
31
Example Submit Description File

• Submits a single job to the standard universe,
  specifies files for STDIN, STDOUT and STDERR,
  creates a UserLog, defines command line
  arguments, and specifies the directory the job
  should be run in
• As if you did

cd /home/wright/condor/run_1
/home/wsu03/condor/my_job.condor -arg1 -arg2 \
gt my_job.stdout 2gt my_job.stderr \ lt
my_job.stdin
32
Clusters and Processes

• A submit file describes one or more jobs
• The collection of jobs is called a cluster
• Each job is called a process or proc
• A Condor Job ID is the cluster number, a
  period, and the proc number (e.g., 23.5)
• Proc numbers always start at 0

33
A Cluster Submit Description File

• Universe standard
• Executable /home/wsu03/condor/my_job.condor
• Input my_job.stdin
• Output my_job.stdout
• Error my_job.stderr
• Log my_job.log
• Arguments -arg1 -arg2
• InitialDir /home/wsu03/condor/run_(Process)
• Queue 500

34
A Cluster Submit Description File

• Queue 500 submit 500 jobs at once
• The initial directory for each job is specified
  with the (Process) macro
• (Process) will be expanded to the process number
  for each job in the cluster
• run_0, run_1, run_499 directories
• All the input/output files will be in different
  directories

35
condor_submit

• condor_submit the-submit-file-name
• condor_submit parses the file and creates a
  ClassAd that describes your job(s)
• Creates the files you specified for STDOUT and
  STDERR
• Sends your jobs ClassAd(s) and executable to the
  condor_schedd, which stores the job in its queue

36
Monitoring Your Jobs

• Using condor_q
• Using a User Log file
• Using condor_status
• Using condor_rm
• Getting email from Condor
• Using condor_history after completion

37
Using condor_q

• Displays the status of your jobs, how much
  compute time it has accumulated, etc.
• Many different options
• A single job, a single cluster, all jobs that
  match a certain constraint, or all jobs
• Can view remote job queues, either individual
  queues, or -global

38
Using a User Log file

• Specify in your submit file
• Log filename
• Entries logged for
• When it was submitted
• when it started executing
• if it is checkpointed or vacated
• if there are any problems, etc.

39
Using condor_status

• the -run option to see
• Machines running jobs
• The user who submitted each job
• The machine they submitted from
• Can also view the status of various submitters
  with -submitter ltnamegt

40
Using condor_rm

• Removes a job from the Condor queue
• You can only remove jobs that you own
• Root can condor_rm someone elses jobs
• You can give specific job IDs (cluster or
  cluster.proc), or you can remove all of your jobs
  with the -a option.

41
Getting Email from Condor

• By default, Condor will send you email when your
  jobs completes
• If you dont want this email, put this in your
  submit file
• notification never
• If you want email every time something happens to
  your job (checkpoint, exit, etc), use this
• notification always

42
Getting Email from Condor

• If you only want email if your job exits with an
  error, use this
• notification error
• By default, the email is sent to your account on
  the host you submitted from. If you want the
  email to go to a different address, use this
• notify_user email_at_address.here

43
Using condor_history

• Once your job completes, it will no longer show
  up in condor_q
• Now, you must use condor_history to view the
  jobs ClassAd
• The status field (ST) will have either a C
  for completed, or an X if the job was removed
  with condor_rm

44
Classified Advertisements

• A ClassAd is a set of named expressions
• Each named expression is an attribute
• Expressions are similar to those in C
• Constants, attribute references, operators

45
Classified Advertisements Example

• MyType "Machine"
• TargetType "Job"
• Name "froth.cs.wisc.edu"
• StartdIpAddr
• "lt128.105.73.44
• 33846gt"
• Arch "INTEL"
• OpSys "SOLARIS26"
• VirtualMemory 225312

• Disk 35957
• KFlops 21058
• Mips 103
• LoadAvg 0.011719
• KeyboardIdle 12
• Cpus 1
• Memory 128
• Requirements LoadAvg lt 0.300000
  KeyboardIdle gt 15 60
• Rank 0

46
ClassAd Matching

• ClassAds are always considered in pairs
• Does ClassAd A match ClassAd B (and vice versa)?
• This is called 2-way matching
• If the same attribute appears in both ClassAds,
  you can specify which attribute you mean by
  putting MY. or TARGET. in front of the
  attribute name

47
ClassAd Matching Example

• ClassAd B
• MyType "ApartmentRenter"
• TargetType "Apartment"
• UnderGrad False
• RentOffer 900
• Rank 1/(TARGET.RentOffer 100.0)
  50HeatIncluded
• Requirements OnBusLine
• SquareArea gt 2700

• ClassAd A
• MyType "Apartment
• TargetType "ApartmentRenter
• SquareArea 3500
• RentOffer 1000
• OnBusLine True
• Rank UnderGradFalse TARGET.RentOffer
• Requirements MY.RentOffer - TARGET.RentOffer lt
  150

48
ClassAds in the Condor System

• ClassAds allow Condor to be a general system
• Constraints and ranks on matches expressed by the
  entities themselves
• Only priority logic integrated into the
  Match-Maker
• All principal entities in the Condor system are
  represented by ClassAds
• Machines, Jobs, Submitters

49
ClassAds Example for Machines

• Friend Owner "tannenba
• Owner "wright"
• ResearchGroup Owner "jbasney" Owner
  "raman"
• Trusted Owner ! "rival" Owner !
  "riffraff"
• Requirements Trusted
• ( ResearchGroup (LoadAvg lt 0.3
  KeyboardIdle gt 1560) )
• Rank Friend ResearchGroup10

50
ClassAd Machine Example

• Machine will never start a job submitted by
  rival or riffraff
• If someone from ResearchGroup (jbasney or
  raman) submits a job, it will always run
• If anyone else submits a job, it will only run
  here if the keyboard has been idle for more than
  15 minutes and the load average is less than 0.3

51
Machine Rank Example Described

• If the machine is running a job submitted by
  owner foo, it will give this a Rank of 0, since
  foo is neither a friend nor in the same research
  group
• If wright or tannenba submits a job, it will
  be ranked at 1 (since Friend will evaluate to 1
  and ResearchGroup is 0)
• If raman or jbasney submit a job, it will
  have a rank of 10
• While a machine is running a job, it will be
  preempted for a higher ranked job

52
ClassAds Example for Jobs

• Requirements Arch INTEL
• OpSys LINUX
• Memory gt 20
• Rank (Memory gt 32)
• ( (Memory 100)
• (IsDedicated 10000)
• Mips )

53
Job Example Described

• The job must run on an Intel CPU, running Linux,
  with at least 20 megs of RAM
• All machines with 32 megs of RAM or less are
  Ranked at 0
• Machines with more than 32 megs of RAM are ranked
  according to how much RAM they have, if the
  machine is dedicated (which counts a lot to this
  job!), and how fast the machine is, as measured
  in MIPS

54
ClassAd Attributes in your Pool

• Condor defines a number of attributes by default,
  which are listed in the User Manual (About
  Requirements and Rank)
• To see if machines in your pool have other
  attributes defined, use
• condor_status -long lthostnamegt
• A custom-defined attribute might not be defined
  on all machines in your pool, so youll probably
  want to use meta-operators

55
ClassAd Meta-Operators

• Meta operators allow you to compare against
  UNDEFINED as if it were a real value
• ? is meta-equal-to
• ! is meta-not-equal-to
• Color ! Red (non-meta) would evaluate to
  UNDEFINED if Color is not defined
• Color ! Red would evaluate to True if Color
  is not defined, since UNDEFINED is not Red

56
Priorities In Condor

• User Priorities
• Priorities between users in the pool to ensure
  fairness
• The lower the value, the better the priority
• Job Priorities
• Priorities that users give to their own jobs to
  determine the order in which they will run
• The higher the value, the better the priority
• Only matters within a given users jobs

57
User Priorities in Condor

• Each active user in the pool has a user priority
• Viewed or changed with condor_userprio
• The lower the number, the better
• A given users share of available machines is
  inversely related to the ratio between user
  priorities.
• Example Freds priority is 10, Joes is 20.
  Fred will be allocated twice as many machines as
  Joe.

58
User Priorities in Condor, cont.

• Condor continuously adjusts user priorities over
  time
• machines allocated gt priority, priority worsens
• machines allocated lt priority, priority improves
• Priority Preemption
• Higher priority users will grab machines away
  from lower priority users (thanks to
  Checkpointing)
• Starvation is prevented
• Priority thrashing is prevented

59
Job Priorities in Condor

• Can be set at submit-time in your description
  file with
• prio ltnumbergt
• Can be viewed with condor_q
• Can be changed at any time with condor_prio
• The higher the number, the more likely the job
  will run (only among the jobs of an individual
  user)

60
Managing a Large Cluster of Jobs

• Condor can manage huge numbers of jobs
• Special features of the submit description file
  make this easier
• Condor can also manage inter-job dependencies
  with condor_dagman
• For example job A should run first, then, run
  jobs B and C, when those finish, submit D, etc
• Well discuss DAGMan later

61
Submitting a Large Cluster

• Each process runs in its own directory
• InitialDir dir.(process)
• Can either have multiple Queue entries, or put a
  number after Queue to tell Condor how many to
  submit
• Queue 1000
• A cluster is more efficient Your jobs will run
  faster, and theyll use less space
• Can only have one executable per cluster
  Different executables must be different clusters!

62
Inter-Job Dependencies with DAGMan

• DAGMan handles a set of jobs that must be run in
  a certain order
• Also provides pre and post operations, so you
  can have a program or script run before each job
  is submitted and after it completes
• Robust handles errors and submit-machine crashes

63
Using DAGMan

• You define a DAG description file, which is
  similar in function to the submit file you give
  to condor_submit
• DAGMan restrictions
• Each job in the DAG must be in its own cluster
  (for now)
• All jobs in the DAG must have a User Log and must
  share the same file

64
DAGMan Description File

• is a comment
• First section names the jobs in your DAG and
  associates a submit description file with each
  job
• Second (optional) section defines PRE and POST
  scripts to run
• Final section defines the job dependencies

65
Example DAGMan File
Job A A.submit Job B B.submit Job C C.submit Job
D D.submit Script PRE D d_input_checker Script
POST A a_output_processor A.out PARENT A CHILD
B C PARENT B C CHILD D
66
Setting up a DAG for Condor

• Create all the submit description files for the
  individual jobs
• Prepare any executables you plan to use
• Can have a mix of Vanilla and Standard jobs
• Setup any PRE/POST commands or scripts you wish
  to use

67
Submitting a DAG to Condor

• condor_submit_dag DAG-description-file
• This will check your input file for errors and
  submit a copy of condor_dagman as a scheduler
  universe job with all the necessary command-line
  arguments

68
Removing a DAG

• On shutdown, DAGMan will remove any jobs that are
  currently in the queue that are associated with
  its DAG
• Once all jobs are gone, DAGMan itself will exit,
  and the scheduler universe job will be removed
  from the queue

69
Typical Problems

• Special requirements expressions for vanilla jobs
• You didnt submit it from a directory that is
  shared
• Condor isnt running as root
• You dont have your file permissions setup
  correctly

70
Special Requirements Expressions for Vanilla Jobs

• When you submit a vanilla job, Condor
  automatically appends two extra Requirements
• UID_DOMAIN ltsubmit_uid_domaingt
• FILESYSTEM_DOMAIN ltsubmit_fsgt
• Since there are no remote system calls with
  Vanilla jobs, they depend on a shared file system
  and a common UID space to run as you and access
  your files

71
Special Requirements Expressions for Vanilla Jobs

• By default, each machine in your pool is in its
  own UID_DOMAIN and FILESYSTEM_DOMAIN, so your
  pool administrator has to configure your pool
  specially if there really is a common UID space
  and a network file system
• If you dont have an account on the remote
  system, Vanilla jobs wont work

72
Shared Files for Vanilla Jobs

• May be not all directories are sharedInitialdir
  /tmp will probably cause trouble for Vanilla
  jobs!
• You must be sure to set Initialdir to a shared
  directory (or cd into it to run condor_submit)
  for Vanilla jobs

73
Why Dont My Jobs Run?

• Try condor_q -analyze
• Try specifying a User Log for your job
• Look at condor_userprio maybe you have a low
  priority and higher priority users are being
  served
• Problems with file permissions or network file
  systems
• Look at the SchedLog

74
Using condor_q -analyze

• Analyzes your jobs ClassAd, get all the ClassAds
  of the machines in the pool, and tell you whats
  going on
• Will report errors in your Requirements
  expression (impossible to match, etc.)
• Will tell you about user priorities in the pool
  (other people have better priority)

75
Looking at condor_userprio

• You can look at condor_userprio yourself
• If your priority value is a really high number
  (because youve been running a lot of Condor
  jobs), other users will have priority to run jobs
  in your pool

76
File Permissions in Condor

• If Condor isnt running as root, the
  condor_shadow process runs as the user the
  condor_schedd is running as (usually condor)
• You must grant this user write access to your
  output files, and read access to your input files
  (both STDOUT, STDIN from your submit file, as
  well as files your job explicitly opens)

77
File Permissions in Condor

• Often, there will be a condor group and you can
  make your files owned and write-able by this
  group
• For vanilla jobs, even if the UID_DOMAIN setting
  is correct, and they match for your submit and
  execute machines, if Condor isnt running as
  root, your job will be started as user Condor,
  not as you!

78
Problems with NFS in Condor

• For NFS, sometimes the administrators will setup
  read-only mounts, or have UIDs remapped for
  certain partitions (the classic example is root
  nobody, but modern NFS can do arbitrary
  remappings)

79
Problems with NFS in Condor

• If your pool uses NFS automounting, the directory
  that Condor thinks is your InitialDir might not
  exist on a remote machine
• With automounting, you always need to specify
  InitialDir explicitly
• InitialDir /home/me/...

80
Problems with AFS in Condor

• If your pool uses AFS, the condor_shadow, even if
  its running with your UID, will not have your
  AFS token.
• You must grant an unauthenticated AFS user the
  appropriate access to your files
• Some sites provide a better alternative that
  world-writable files
• Host ACLs
• Network-specific ACLs

81
Looking at the SchedLog

• Looking at the log file of the condor_schedd, the
  SchedLog file can possibly give you a clue if
  there are problems.
• Find it with
• condor_config_val schedd_log
• You might need your pool administrator to turn on
  a higher debugging level to see more verbose
  output

82
Other User Features

• Submit-Only installation
• Heterogeneous Submit
• PVM jobs

83
Submit-Only Installation

• Can install just a condor_master and
  condor_schedd on your machine
• Can submit jobs into a remote pool
• Special option to condor_install

84
Heterogeneous Submit

• The job you submit doesnt have to be the same
  platform as the machine you submit from
• Maybe you have access to a pool that is full of
  Alphas, but you have a Sparc on your desk, and
  moving all your data is a pain
• You can take an Alpha binary, copy it to your
  Sparc, and submit it with a requirements
  expression that says you need to run on ALPHA/OSF1

85
PVM Jobs in Condor

• Condor can run parallel applications
• PVM applications now
• Future work includes support for MPI
• Master-Worker Paradigm
• What does Condor-PVM do?
• How to compile and submit Condor-PVM jobs

86
Master-Worker Paradigm

• Condor-PVM is designed to run PVM applications
  based on the master-worker paradigm.
• Master
• has a pool of work, sends pieces of work to the
  workers, manages the work and the workers
• Worker
• gets a piece of work, does the computation, sends
  the result back

87
What does Condor-PVM do?

• Condor acts as the PVM resource manager.
• All pvm_addhost requests get re-mapped to Condor.

• Condor dynamically constructs PVM virtual
  machines out of non-dedicated desktop machines.
• When a machine leaves the pool, the user gets
  notified via the normal PVM notification
  mechanisms.

88
Submission of Condor-PVM jobs

• Binary Compatible
• Compile and link with PVM library just as normal
  PVM applications. No need to link with Condor.
• In the submit description file, set
• universe PVM
• machine_count ltmingt..ltmaxgt

89
Resource Agent Configuration Expressions
90
Resource Agent Configuration

• Default Setup
• WANT_VACATE True
• WANT_SUSPEND True
• START Keyboard_Idle CPU_Idle
• SUSPEND Keyboard_Busy CPU_Busy
• CONTINUE Keyboard and CPU idle again
• VACATE If Suspended gt 10 minutes
• KILL If spent gt 10 minutes in VACATE state

91
condor_master

• Watches/restarts other daemons
• Sends Email if suspicious problems arise
• Runs condor_preen
• Provides administrator remote control

92
Condor Administrator Commands

• condor_off hostname
• condor_on
• condor_restart
• condor_reconfig
• condor_vacate
• Can be used by the Owner also

93
Host-based Access Control

• HOST_ALLOW and HOST_DENY to grant machines
  (subnets, domains) different access levels
• READ access
• WRITE access
• ADMINISTRATOR access
• OWNER access

94
Host-based Access Control Ex.

• HOSTDENY_READ .com
• HOSTALLOW_WRITE .cs.wright.edu
• HOSTDENY_WRITE ppp.wright.edu, 172.44.
• HOSTALLOW_ADMINISTRATOR
  osis111.cs.wright.edu
• HOSTALLOW_OWNER (FULL_HOSTNAME),
  (HOSTALLOW_ADMINISTRATOR)

95
Configuration File Hierarchy

• condor_config
• Pool-wide default
• Condor pool administrators requirements
• condor_config.local
• Overrides for a specific machine
• Reflects Owners requirements
• condor_config.root
• System Administrator requirements

96
Obtaining Condor

• Condor accounts available! E-mailmiron_at_cs.wisc.e
  du
• Condor executables can be downloaded from
  http//www.cs.wisc.edu/condor
• Complete Users and Administrators manual
  http//www.cs.wisc.edu/condor/manual
