Title: G1000 Observer Training


1
G1000 Observer Training
  • Day 1
  • Cockpit Familiarization and MFD

2
Revision History
Date Who ID Notes
12 Dec 2009 1st Lt Todd Gamber CAPID 443746 v1 Initial Revision
07 Mar 2010 1st Lt Todd Gamber CAPID 443746 v2 - Added a Simulator section - Fixed an error in Amending a Flight Plan instructions Fixed an error in Storing a Flight Plan instructions Fixed logic error in formulas for calculating proper grid width on Parallel Track Search slide Fixed screen shot for picking Latitude/Longitude representation in AUX page group (incorrect representation was highlighted was misleading) Added a picture of the Technisonic FM radio Fixed misc text formatting/overlapping issues Added a note that the Route Search can be performed using some other methods.
09 Apr 2010 Next revision expected 07 Jul 2010 1st Lt Todd Gamber CAPID 443746 v3 Moved revision history to second page instead of first page Noted that the Flight Plan page group is accessed differently than other page groups (on Page Groups vs. Individual Pages slide) Exclaimed that G1000 does not display CAP grids
3
Table of Contents
  • G1000 Panel
  • Multi-Function Display
  • G1000 Simulator
  • System requirements
  • Start-up
  • Modes
  • Simulating movement
  • Basic concepts
  • FMS Knob
  • Pages/Groups
  • Soft Keys
  • Flight Navigation
  • Waypoints
  • Flight Plans
  • Creating Custom Waypoints
  • Mission Coordination
  • SAR setup
  • SAR patterns

4
CAP G1000 Panel
5
Primary Flight Display (PFD)
6
Multifunction Display (MFD)
For pilot use only
7
Audio Panel
  • Two audio panels in CAP aircraft
  • One for the pilot
  • One for observer
  • Ideally, managed by the Observer
  • Two audio panels installed in each CAP G1000
    aircraft
  • Allows Observer to control Scanners volume and
    push-to-talk switch

8
Direction Finder (Becker)
  • Supports new 406MHz as well as 121.5MHz
  • Easy to interpret

9
CAP FM Radio
  • Same interface and functionality as in many CAP
    round dial aircraft

10
Multifunction Display (MFD)How to use it
11
G1000 Simulator
  • Included in Training DVD
  • System Requirements
  • PC (not Mac)
  • Installation
  • Copy ZIP file to computer, then unzip
  • Installer takes up to 5 minutes to look like its
    working
  • NOTE Version 8 represents N594CP and has SAR
    mode. Version 9 has synthetic vision, but no
    SAR.

12
G1000 Simulator Start-up
  • First, select an airframe
  • Some airframes are buggy and wont switch to MFD
    mode C-172R works well.
  • In version 8.20, the C-182T has SAR.
  • The POWER button starts the display.
  • Joystick can be configured under Options

13
G1000 Simulator Modes
  • Displays
  • PFD
  • MFD
  • Dual-screen Trainer (both PFD and MFD)

14
G1000 Simulator Movement
  • Press MENU twice
  • Press ENT to move to next field
  • Use small FMS knob to edit settings
  • Use a familiar waypoint (like KBJC)
  • Optional joystick can affect pitch, bank, yaw,
    and throttle

15
FMS Knob and Enter Key
  • FMS Knob
  • Twist Outer knob
  • Do something big
  • Twist Inner knob
  • Do something small
  • Push Knob
  • Changes functionality of knob twisting (cursor
    on/off)
  • Enter Key
  • Okay

16
Page Groups vs. Individual Pages
  • Page Groups
  • Maps
  • Waypoints
  • Auxiliary
  • Nearest
  • Flight Plan (accessed differently than other page
    groups)
  • Example Pages
  • Map Page Group
  • Navigation Map
  • Traffic Map
  • Weather Map
  • Aux Page Group
  • XM Radio
  • Setup

17
Soft Keys
  • Soft keys are labeled differently on various
    screens

18
Navigation
19
Waypoint
  • A vertical line extending from the Earths
    surface upward.
  • Airport
  • Intersection
  • NDB
  • VOR
  • User-defined

20
Flight Plan
  • A sequence of waypoints, connected with lines.
  • Lines legs
  • Active leg is magenta
  • Planned leg is white
  • See Flight Plan with the FPL button
  • Shown on MFD and PFD

21
Creating a Flight Plan
  1. FPL button
  2. Push FMS knob (cursor)
  3. Outer FMS knob to highlight a blank space
  4. Inner FMS knob to change
  5. ENT button to add waypoint

22
Amending a Flight Plan
  • Push FMS knob (cursor)
  • Outer FMS knob to highlight a waypoint
  • To insert a waypoint
  • Inner FMS knob to enter name of waypoint
  • ENT button to confirm
  • Inserts above highlighted point
  • To remove a waypoint
  • CLR to remove
  • ENT button to confirm

23
Storing a Flight Plan
  • Go to FPL page 1
  • Ensure cursor is deactivated
  • Push MENU
  • Outer FMS knob to highlight Store
  • ENT button to confirm

24
Activating a Stored Flight Plan
  • Go to second page of FPL page group
  • Push FMS knob
  • Outer FMS knob to highlight desired plan
  • ACTIVE soft key
  • ENT to confirm

25
Creating a Custom Waypointfrom Present Position
  • Push the joystick (activates pointer at present
    location)
  • Dont rush the marked point wont move.
  • Press ENT to save
  • Write down coordinates

26
Creating a Custom Waypointfrom Coordinates or
Distance/Bearing
  • Go to WPT page group
  • Go to USER WPT page
  • NEW soft key
  • Use inner and outer FMS knobs, and ENT

27
Mission Coordination
28
SAR Observer Setup
  • Essential Setup
  • North up
  • Lat/Lon and Data Bar Display
  • Terrain height
  • Grid lines shown
  • Optional Overlays
  • Terrain overlay
  • Traffic overlay
  • Weather overlay

29
North-up
  • Knobs NAVIGATION MAP page
  • MENU button
  • Knobs Map Setup
  • ENT button
  • Knobs Map GROUP
  • North up
  • Track up
  • Desired Track (DTK) up
  • Heading (HDG) up
  • Knob Push to deactivate cursor and exit

30
Lat/Lon and Data Bar Display
  • Knobs SYSTEM SETUP page (in the AUX group)
  • Knob Push to activate cursor
  • Knobs Position HDDD MM SS.S (in the DISPLAY
    UNITS area)
  • ENT button
  • Knob Push to deactivate cursor

31
Terrain Height (MSL)
  • Knobs NAVIGATION MAP
  • Joystick Push to activate pointer
  • Do some math
  • Joystick Push to de-activate pointer
  • Waypoint B
  • 2.0nm away from you
  • Bearing 354 (to get there)
  • 1,473 ft. MSL
  • Search altitude
  • 1,473 ft. MSL 1000 ft. AGL
  • 2,473 ft. MSL

32
Grid Lines
  • Knobs NAVIGATION MAP page
  • MENU button
  • Knobs Map Setup
  • ENT button
  • Knobs Land GROUP
  • LAT/LON TEXT Med
  • LAT/LON RNG 30NM
  • Press the FMS knob to deactivate the cursor and
    exit
  • NOTE
  • DOES NOT DISPLAY CAP GRIDS!

33
Optional Overlays
  • Tools you will need during a mission
  • Traffic overlay
  • Terrain overlay
  • Weather overlay

34
Traffic Overlay
  1. Knobs NAVIGATION MAP page
  2. MENU button
  3. Knobs Map Setup
  4. ENT button
  5. Knobs Traffic GROUP
  6. ENT button
  7. Knobs Traffic on/off
  8. Knob Push to deactivate cursor and exit

1,200ft above, climbing, heading Southeast
35
Terrain Overlay
  • Knobs NAVIGATION MAP page
  • Soft key MAP
  • Soft key TERRAIN
  • Soft key BACK
  • Red Terrain is above or 0-100ft. below
  • Yellow Terrain is 100 - 1000 ft. below

36
Weather (NEXRAD) Overlay
  • Knobs NAVIGATION MAP page
  • Soft key MAP
  • Soft key NEXRAD
  • Soft key BACK

37
SAR Patterns
  • Parallel Track/Grid
  • Sector
  • Expanding Square
  • Route

38
Parallel Track/Grid Search
  • Activate a flight plan consisting of at least the
    start point (a grid corner)
  • FPL button
  • Knob Push to activate cursor
  • Knobs Highlight entry point (grid corner)
  • MENU button
  • Knobs Search and Rescue
  • ENT button
  • (continued)

39
Parallel Track/Grid Search (contd)
  • Knobs
  • Waypoint Entry Point
  • Pattern Parallel
  • Initial DTK Mag heading on first leg (you
    correct for variation)
  • Initial Turn Left/right after entering search
    pattern
  • Leg Length 5NM - 7.5NM
  • Spacing 1.0NM
  • Number of legs 6 8
  • Knobs ACTIVATE SAR
  • ENT button
  • NOTE Will go direct-to entry point

40
Sector Search
  • Activate a flight plan consisting of at least the
    start point
  • FPL button
  • Knob Push to activate cursor
  • Knobs Highlight entry point (grid corner)
  • MENU button
  • Knobs Search and Rescue
  • ENT button
  • (continued)

41
Sector Search (contd)
  • Knobs
  • Waypoint Entry Point
  • Pattern Sector
  • Initial DTK Mag heading on first leg (you
    correct for variation)
  • Initial Turn Left/Right
  • Leg Length Your Choice
  • Knobs ACTIVATE SAR
  • ENT button
  • NOTE Will go direct-to entry point

42
Expanding Square Search
  • Activate a flight plan consisting of at least the
    start point
  • FPL button
  • Knob Push to activate cursor
  • Knobs Highlight entry point (grid corner)
  • MENU button
  • Knobs Search and Rescue
  • ENT button
  • (continued)

43
Expanding Square Search (contd)
  • Knobs
  • Waypoint Entry Point
  • Pattern Exp Sqr
  • Initial DTK Mag heading on first leg (you
    correct for variation)
  • Initial Turn Left/Right
  • Number of legs Your choice
  • Knobs ACTIVATE SAR
  • ENT button
  • NOTE Will go direct-to entry point

44
Route Search
  • Ensure your data bar fields contain XTK
    (Cross-track)
  • Activate a flight plan consisting of at least the
    start and end points of the route.
  • Fly down one side of the route at 1.0NM XTK, then
    down the other side at 1.0NM XTK
  • Can also perform a Route Search using a highly
    modified parallel track SAR pattern or even a
    Parallel Track flight plan
