Title: Multiprocessor Systems


1
Multiprocessor Systems
  • A presentation by
  • Chris Hargreaves

2
Flynns Classification
  • SISD Single instruction single data
  • SIMD Single instruction multiple data
  • MISD Multiple instruction single data
  • MIMD Multiple instruction multiple data

3
Bisection Bandwidth
  • Split the system into a half (or next to half)
    and find the bottleneck.

4
System Topologies
  • The pattern of connections between the processors

5
Shared Bus
  • Processors communicate over a shared bus
  • Most cases the processors communicate directly
    with their locally memory
  • More processors cause delays as traffic increases

6
Ring
  • Direct connections between processors
  • Allows simultaneous links to be active
  • Data may have to travel through multiple
    processors before reaching its final destination

7
Shared Bus Ring
8
Tree Topology
  • Each processor has three connections
  • Lowers the diameter
  • Only one unique path between any pair of
    processors

9
Mesh Topology
  • Each processor connects to the its left and
    right, top and bottom
  • Without wraparound connections has a diameter of
    2 n(1/2). With it has n(1/2)

10
Tree Mesh
11
Hypercube Topology
  • Each processor connects to all other processors
    whose binary value differs by only one bit
  • Ex Processor 0 connects to 1, 2, 4 and 8
  • Low Diameter (lg n). Good.

12
Completely Connected
  • Each processor has (n-1) connections
  • Diameter is a constant 1

13
Hypercube Completely Connected
14
MIMD Architecture
  • Refers to connections with respect to system
    memory

15
SMP (Symmetric Multiprocessor)
  • UMA Uniform Memory Access
  • NUMA - Nonuniform Memory Access
  • CC-NUMA Cache Coherent NUMA
  • COMA Cache Only Memory Access
  • NOW COW - Multicomputer

16
UMA
  • Equal access to all locations in shared memory
  • Each processor may also have its own cache memory
  • Interact with memory over a communication
    mechanism such as a shared bus

17
UMA
18
NUMA
  • Can access the memory closest
  • Non Uniform access times to memory

19
NUMA
20
CC-NUMA
  • Same as NUMA except each processor includes cache
    memory
  • Problem occurs when two caches hold the same
    piece of data
  • Must have coherence to make sure caches contain
    the same information

21
COMA
  • Solution to CC-NUMA
  • Local Memory treated as cache
  • If data is loaded multiple times, one is marked
    as the Master Copy which is kept current
  • Few of these machines have every been built

22
Multicomputing
  • NOW Network of workstations
  • COW Cluster of workstations
  • SETI_at_Home
  • United Devices (www.ud.com)

23
MMP
  • Massively Parallel Processor
  • Process massive ammounts of data in parallel
  • Typically at the level of the ALU
  • Communicate using shared memory
  • Example IBM Blue Gene Computer
