CS152

1
CS152 Computer Architecture andEngineeringLect
ure 18 ECC, RAID, Bandwidth vs. Latency
2004-10-28 John Lazzaro(www.cs.berkeley.edu/lazz
aro) Dave Patterson (www.cs.berkeley.edu/patters
on) www-inst.eecs.berkeley.edu/cs152/
2
Review

• Buses are an important technique for building
  large-scale systems
• Their speed is critically dependent on factors
  such as length, number of devices, etc.
• Critically limited by capacitance
• Direct Memory Access (dma) allows fast, burst
  transfer into processors memory
• Processors memory acts like a slave
• Probably requires some form of cache-coherence so
  that DMAed memory can be invalidated from cache.
• Networks and switches popular for LAN, WAN
• Networks and switches starting to replace buses
  on desktop, even inside chips

3
Review ATA cables

• Serial ATA, Rounded parallel ATA,Ribbon parallel
  ATA cables
• 40 inches max vs. 18 inch

• Serial ATA cables are thin

4
Outline

• ECC
• RAID Old School Update
• Latency vs. Bandwidth (if time permits)

5
Error-Detecting Codes

• Computer memories can make errors occasionally
• To guard against errors, some memories use
  error-detecting codes or error-correcting codes
  (ECC)
• gt extra bits are added to each memory word
• When a word is read out of memory, the extra
  bits are checked to see if an error has occurred
  and, if using ECC, correct them
• Data extra bits called code words

6
Error-Detecting Codes

• Given 2 code words, can determine how many
  corresponding bits differ.
• To determine how many bits differ, just compute
  the bitwise Boolean EXCLUSIVE OR of the two
  codewords, and count the number of 1 bits in the
  result
• The number of bit positions in which two
  codewords differ is called the Hamming distance
• if two code words are a Hamming distance d apart,
  it will require d single-bit errors to convert
  one into the other

7
Error-Detecting Codes
For example, the code words 11110001 and 00110000
are a Hamming distance 3 apart because it takes 3
single-bit errors to convert one into the other.
11110001 Xor 00110000 --------
11000001 3 1s Hamming distance 3
8
Error-Detecting Codes

• As a simple example of an error-detecting code,
  consider a code in which a single parity bit is
  appended to the data.
• The parity bit is chosen so that the number of 1
  bits in the codeword is even (or odd).
• E.g., if even parity, parity bit for 11110001 is
  1.
• Such a parity code has Hamming distance 2, since
  any single-bit error produces a codeword with the
  wrong parity
• It takes 2 single-bit errors to go from a valid
  codeword to another valid codeword gt detect
  single bit errors.
• Whenever a word containing the wrong parity is
  read from memory, an error condition is signaled.

• The program cannot continue, but at least no
  incorrect results are computed.

9
Error-Correcting Codes

• a Hamming distance of 2k 1 is required to be
  able to correct k errors in any data word
• As a simple example of an error-correcting code,
  consider a code with only four valid code words
•
• 0000000000, 0000011111, 1111100000, and
  1111111111
•
• This code has a distance 5, which means that it
  can correct double errors.
• If the codeword 0000000111 arrives, the receiver
  knows that the original must have been 0000011111
  (if there was no more than a double error). If,
  however, a triple error changes 0000000000 into
  0000000111, the error cannot be corrected.

10
Hamming Codes

• How many parity-bits are needed?
• m parity-bits can code 2m-1-m info-bits

Info-bits Parity-bits
lt5 3
lt12 4
lt27 5
lt58 6
lt121 7

• How correct single error (SEC) and detect 2
  errors (DED)?
• How many SEC/DED bits for 64 bits data?

11
Administrivia - HW 3, Lab 4
12
ECC Hamming Code.

• Hamming Coding is a coding method for detecting
  and correcting errors.
• ECC Hamming distance between 2 coded words must
  be 3
• Number bits from right, starting with 1
• All bits whose bit number is a power of 2 are
  parity bits
• We use EVEN PARITY in this example
• This example shows a 4 data bits

• Bit 1 will check (parity) in all the bit
  positions that use a 1 in their number
• Bit 2 will check all the bit positions that use a
  2 in their number
• Bit 4 will check all the bit positions that use a
  4 in their number
• Etc.

7 6 5 4 3 2 1
D D D P D P P 7-BIT CODEWORD
D - D - D - P (EVEN PARITY)
D D - - D P - (EVEN PARITY)
D D D P - - - (EVEN PARITY)
13
Example Hamming Code.

• Example The message 1101 would be sent as
  1100110, since

7 6 5 4 3 2 1
1 1 0 0 1 1 0 7-BIT CODEWORD
1 - 0 - 1 - 0 (EVEN PARITY)
1 1 - - 1 1 - (EVEN PARITY)
1 1 0 0 - - - (EVEN PARITY)
EVEN PARITY If number of 1s is even then Parity
0 Else Parity 1
Let us consider the case where an error caused by
the channel transmitted message received
message 1 1 0 0 1 1 0 ------------gt 1 1 1 0 1
1 0 BIT 7 6 5 4 3 2 1 BIT 7 6 5 4 3 2
1
14
Example Hamming Code.
transmitted message received message 1 1 0 0
1 1 0 ------------gt 1 1 1 0 1 1 0 BIT 7 6 5
4 3 2 1 BIT 7 6 5 4 3 2 1 The above
error (in bit 5) can be corrected by examining
which of the three parity bits was affected by
the bad bit

7 6 5 4 3 2 1
1 1 1 0 1 1 0 7-BIT CODEWORD
1 - 1 - 1 - 0 (EVEN PARITY) NOT! 1
1 1 - - 1 1 - (EVEN PARITY) OK! 0
1 1 1 0 - - - (EVEN PARITY) NOT! 1
bad parity bits labeled 101 point directly to the
bad bit since 101 binary equals 5
15
Will Hamming Code detect and correct errors on
parity bits? Yes!
transmitted message received message 1 1 0 0
1 1 0 ------------gt 1 1 0 0 1 1 1 BIT 7 6 5
4 3 2 1 BIT 7 6 5 4 3 2 1 The above
error in parity bit (bit 1) can be corrected by
examining as below

7 6 5 4 3 2 1
1 1 0 0 1 1 1 7-BIT CODEWORD
1 - 0 - 1 - 0 (EVEN PARITY) NOT! 1
1 1 - - 1 1 - (EVEN PARITY) OK! 0
1 1 0 0 - - - (EVEN PARITY) OK! 0
the bad parity bits labeled 001 point directly to
the bad bit since 001 binary equals 1. In this
example error in parity bit 1 is detected and can
be corrected by flipping it to a 0
16
RAID Beginnings

• We had worked on 3 generations of Reduced
  Instruction Set Computer (RISC) processors 1980
  1987
• Our expectation I/O will become a performance
  bottleneck if doesnt get faster
• Randy Katz gets Macintosh with disk along side
• Use PC disks to build fast I/O to keep pace with
  RISC?

17
Redundant Array of Inexpensive Disks (1987-93)

• Hard to explain ideas, given past disk array
  efforts
• Paper to educate, differentiate?
• RAID paper spread like virus
• Products from Compaq, EMC, IBM,
• RAID I
• Sun 4/280, 128 MB of DRAM,
• 4 dual-string SCSI controllers,
• 28 5.25 340 MB disks SW
• RAID II
• Gbit/s net 144 3.5 320 MB disks
• 1st Network Attached Storage
• Ousterhout Log Structured File Sys. widely used
  (NetAp)
• Today RAID 25B industry 80 of server disks
  in RAID
• 1998 IEEE Storage Award

Students Peter Chen, Ann Chevernak, Garth
Gibson, Ed Lee, Ethan Miller, Mary Baker, John
Hartman, Kim Keeton, Mendel Rosenblum, Ken
Sherriff,
18
Latency Lags Bandwidth

• Over last 20 to 25 years, for network disk,
  DRAM, MPU, Latency Lags Bandwidth
• Bandwidth Improved 120X to 2200X
• But Latency Improved only 4X to 20X
• Look at examples, reasons for it

19
Disks Archaic(Nostalgic) v. Modern(Newfangled)

• Seagate 373453, 2003
• 15000 RPM (4X)
• 73.4 GBytes (2500X)
• Tracks/Inch 64000 (80X)
• Bits/Inch 533,000 (60X)
• Four 2.5 platters (in 3.5 form factor)
• Bandwidth 86 MBytes/sec (140X)
• Latency 5.7 ms (8X)
• Cache 8 MBytes

• CDC Wren I, 1983
• 3600 RPM
• 0.03 GBytes capacity
• Tracks/Inch 800
• Bits/Inch 9550
• Three 5.25 platters
• Bandwidth 0.6 MBytes/sec
• Latency 48.3 ms
• Cache none

20
Latency Lags Bandwidth (for last 20 years)

• Performance Milestones
• Disk 3600, 5400, 7200, 10000, 15000 RPM (8x,
  143x)

(latency simple operation w/o contention BW
best-case)
21
MemoryArchaic(Nostalgic)v. Modern(Newfangled)

• 1980 DRAM (asynchronous)
• 0.06 Mbits/chip
• 64,000 xtors, 35 mm2
• 16-bit data bus per module, 16 pins/chip
• 13 Mbytes/sec
• Latency 225 ns
• (no block transfer)

• 2000 Double Data Rate Synchr. (clocked) DRAM
• 256.00 Mbits/chip (4000X)
• 256,000,000 xtors, 204 mm2
• 64-bit data bus per DIMM, 66 pins/chip (4X)
• 1600 Mbytes/sec (120X)
• Latency 52 ns (4X)
• Block transfers (page mode)

22
Latency Lags Bandwidth (last 20 years)

• Performance Milestones
• Memory Module 16bit plain DRAM, Page Mode DRAM,
  32b, 64b, SDRAM, DDR SDRAM (4x,120x)
• Disk 3600, 5400, 7200, 10000, 15000 RPM (8x,
  143x)

(latency simple operation w/o contention BW
best-case)
23
LANs Archaic(Nostalgic)v. Modern(Newfangled)

• Ethernet 802.3
• Year of Standard 1978
• 10 Mbits/s link speed
• Latency 3000 msec
• Shared media
• Coaxial cable

• Ethernet 802.3ae
• Year of Standard 2003
• 10,000 Mbits/s (1000X)link speed
• Latency 190 msec (15X)
• Switched media
• Category 5 copper wire

Coaxial Cable
Plastic Covering
Braided outer conductor
Insulator
Copper core
24
Latency Lags Bandwidth (last 20 years)

• Performance Milestones
• Ethernet 10Mb, 100Mb, 1000Mb, 10000 Mb/s
  (16x,1000x)
• Memory Module 16bit plain DRAM, Page Mode DRAM,
  32b, 64b, SDRAM, DDR SDRAM (4x,120x)
• Disk 3600, 5400, 7200, 10000, 15000 RPM (8x,
  143x)

(latency simple operation w/o contention BW
best-case)
25
CPUs Archaic(Nostalgic) v. Modern(Newfangled)

• 1982 Intel 80286
• 12.5 MHz
• 2 MIPS (peak)
• Latency 320 ns
• 134,000 xtors, 47 mm2
• 16-bit data bus, 68 pins
• Microcode interpreter, separate FPU chip
• (no caches)

• 2001 Intel Pentium 4
• 1500 MHz (120X)
• 4500 MIPS (peak) (2250X)
• Latency 15 ns (20X)
• 42,000,000 xtors, 217 mm2
• 64-bit data bus, 423 pins
• 3-way superscalar,Dynamic translate to RISC,
  Superpipelined (22 stage),Out-of-Order execution
• On-chip 8KB Data caches, 96KB Instr. Trace
  cache, 256KB L2 cache

26
Latency Lags Bandwidth (last 20 years)

• Performance Milestones
• Processor 286, 386, 486, Pentium, Pentium
  Pro, Pentium 4 (21x,2250x)
• Ethernet 10Mb, 100Mb, 1000Mb, 10000 Mb/s
  (16x,1000x)
• Memory Module 16bit plain DRAM, Page Mode DRAM,
  32b, 64b, SDRAM, DDR SDRAM (4x,120x)
• Disk 3600, 5400, 7200, 10000, 15000 RPM (8x,
  143x)

Note Processor Biggest, Memory Smallest
(latency simple operation w/o contention BW
best-case)
27
Annual Improvement per Technology
CPU DRAM LAN Disk
Annual Bandwidth Improvement (all milestones) 1.50 1.27 1.39 1.28
Annual Latency Improvement (all milestones) 1.17 1.07 1.12 1.11

• But what about recent BW, Latency change?

Annual Bandwidth Improvement (last 3 milestones) 1.55 1.30 1.78 1.29
Annual Latency Improvement (last 3 milestones) 1.22 1.06 1.13 1.09

• How summarize BW vs. Latency change?

28
Towards a Rule of Thumb

• How long for Bandwidth to Double?

Time for Bandwidth to Double (Years, all milestones) 1.7 2.9 2.1 2.8

• How much does Latency Improve in that time?

Latency Improvement in Time for Bandwidth to Double (all milestones) 1.3 1.2 1.3 1.3

• But what about recently?

Time for Bandwidth to Double (Years, last 3 milestones) 1.6 2.7 1.2 2.7
Latency Improvement in Time for Bandwidth to Double (last 3 milestones) 1.4 1.2 1.2 1.3

• Despite faster LAN, all 1.2X to 1.4X

29
Rule of Thumb for Latency Lagging BW

• In the time that bandwidth doubles, latency
  improves by no more than a factor of 1.2 to 1.4
• Stated alternatively Bandwidth improves by more
  than the square of the improvement in Latency
• (and capacity improves faster than bandwidth)

30
6 Reasons Latency Lags Bandwidth

• 1. Moores Law helps BW more than latency
• Faster transistors, more transistors, more pins
  help Bandwidth
• MPU Transistors 0.130 vs. 42 M xtors (300X)
• DRAM Transistors 0.064 vs. 256 M xtors (4000X)
• MPU Pins 68 vs. 423 pins (6X)
• DRAM Pins 16 vs. 66 pins (4X)
• Smaller, faster transistors but communicate over
  (relatively) longer lines limits latency
• Feature size 1.5 to 3 vs. 0.18 micron (8X,17X)
• MPU Die Size 35 vs. 204 mm2 (ratio sqrt ? 2X)
• DRAM Die Size 47 vs. 217 mm2 (ratio sqrt ?
  2X)

31
6 Reasons Latency Lags Bandwidth (contd)

• 2. Distance limits latency
• Size of DRAM block ? long bit and word lines ?
  most of DRAM access time
• Speed of light and computers on network
• 1. 2. explains linear latency vs. square BW?
• 3. Bandwidth easier to sell (biggerbetter)
• E.g., 10 Gbits/s Ethernet (10 Gig) vs. 10
  msec latency Ethernet
• 4400 MB/s DIMM (PC4400) vs. 50 ns latency
• Even if just marketing, customers now trained
• Since bandwidth sells, more resources thrown at
  bandwidth, which further tips the balance

32
6 Reasons Latency Lags Bandwidth (contd)

• 4. Latency helps BW, but not vice versa
• Spinning disk faster improves both bandwidth and
  rotational latency
• 3600 RPM ? 15000 RPM 4.2X
• Average rotational latency 8.3 ms ? 2.0 ms
• Things being equal, also helps BW by 4.2X
• Lower DRAM latency ? More access/second (higher
  bandwidth)
• Higher linear density helps disk BW (and
  capacity), but not disk Latency
• 9,550 BPI ? 533,000 BPI ? 60X in BW

33
6 Reasons Latency Lags Bandwidth (contd)

• 5. Bandwidth hurts latency
• Queues help Bandwidth, hurt Latency (Queuing
  Theory)
• Adding chips to widen a memory module increases
  Bandwidth but higher fan-out on address lines may
  increase Latency
• 6. Operating System overhead hurts Latency more
  than Bandwidth
• Long messages amortize overhead overhead bigger
  part of short messages

34
3 Ways to Cope with Latency Lags Bandwidth
If a problem has no solution, it may not be a
problem, but a fact--not to be solved, but to be
coped with over time Shimon Peres (Peress
Law)

• Caching (Leveraging Capacity)
• Processor caches, file cache, disk cache
• Replication (Leveraging Capacity)
• Read from nearest head in RAID, from nearest
  site in content distribution
• Prediction (Leveraging Bandwidth)
• Branches Prefetching disk, caches

35
HW BW Example Micro Massively Parallel
Processor (mMMP)

• Intel 4004 (1971) 4-bit processor,2312
  transistors, 0.4 MHz, 10 micron PMOS, 11 mm2
  chip

• RISC II (1983) 32-bit, 5 stage pipeline, 40,760
  transistors, 3 MHz, 3 micron NMOS, 60 mm2 chip
• 4004 shrinks to 1 mm2 at 3 micron

• 250 mm2 chip, 0.090 micron CMOS 2312 RISC IIs
  Icache Dcache
• RISC II shrinks to 0.05 mm2 at 0.09 mi.
• Caches via DRAM or 1 transistor SRAM
  (www.t-ram.com)
• Proximity Communication via capacitive coupling
  at gt 1 TB/s (Ivan Sutherland_at_Sun)

• Processor new transistor?
• Cost of Ownership, Dependability, Security v.
  Cost/Perf. gt mMPP

36
Too Optimistic so Far (its even worse)?

• Optimistic Cache, Replication, Prefetch get more
  popular to cope with imbalance
• Pessimistic These 3 already fully deployed, so
  must find next set of tricks to cope hard!
• Its even worse bandwidth gains multiplied by
  replicated components ? parallelism
• simultaneous communication in switched LAN
• multiple disks in a disk array
• multiple memory modules in a large memory
• multiple processors in a cluster or SMP

37
Conclusion Latency Lags Bandwidth

• For disk, LAN, memory, and MPU, in the time that
  bandwidth doubles, latency improves by no more
  than 1.2X to 1.4X
• BW improves by square of latency improvement
• Innovations may yield one-time latency reduction,
  but unrelenting BW improvement
• If everything improves at the same rate, then
  nothing really changes
• When rates vary, require real innovation
• HW and SW developers should innovate assuming
  Latency Lags Bandwidth
