Measuring Tools and Systems

1
Measuring Tools and Systems

• Chapter 5
• Page 40

2
Measuring Systems U.S.

• U.S.
• Length miles, feet, inches, fractions of an
  inch, tenths, hundredths, thousandths, ten
  thousandths, and decimals.
• Pressure pounds per square inch (p.s.i.) vacuum
  (inches of mercury)
• Weight pounds
• Liquids gallons, quarts, pints, and ounces,
  cubic inches
• Temperature Fahrenheit
• Torque Foot pounds

3
Measuring Systems Metric

• Metric
• Length kilometers, meters, centimeters,
  millimeters
• Pressure Kilograms per square centimeter
• Weight kilograms, grams,
• Liquids Liters, cubic centimeters
• Temperature Celsius
• Torque Newton Meters

4
Measuring Tools

• Ruler/Tape Measure

5
Feeler Gauges and Wire Gauges
6
Safety Check

• Never use feeler gauges on operating machinery.
• Feeler gauges are strips of hardened metal that
  have been ground or rolled to a precise
  thickness. They can be very thin and will cut
  through skin if not handled correctly.

7
Points to Note

• There are many types of feeler gauges, each with
  a specific application.
• Feeler gauges usually come in sets with a number
  of blades. The thickness of each blade is marked
  in thousandths of an inch and hundredths of a
  millimeter. A marking of 0.040 indicates the
  feeler is 40 thousandths of an inch thick. It may
  also indicate a measurement of 1.02 millimeters.
  A feeler marked 0.005 indicates the thickness is
  5 thousandths of an inch. It may also indicate
  0.12 millimeters.

8

• Some sets contain feelers made of brass. These
  are to take measurements between magnetic
  components.
• When measuring a spark plug gap, it is preferable
  to use wire feeler gauges. These feelers use
  accurately machined pieces of wire instead of
  metal strips.
• If the feeler gauge feels too loose when
  measuring a gap, select the next size larger and
  measure the gap again. Repeat this procedure
  until the feeler gauge fits snugly in the gap. If
  the feeler gauge is too tight, select a smaller
  size until the feeler gauge fits snugly in the
  gap.

9
Feeler Gauges
10
Vernier Calipers
Picture from pg 42
11
Calipers

• Outside Measurement- Measure outside diameters of
  an object. (Ex. Camshaft)
• Inside Measurement- Measure inside diameters of
  an object. (Ex. Cylinder bore)
• Depth Measurement-Measure depth of an object.
  (Ex. Bolt hole depth)

12
Micrometers
Digital Mic
U.S Metric
Inside Mic
Bore Gauge
Depth Gauge
13
Micrometers

• Very accurate
• Measures to the nearest ten thousandth
• Very Fragile
• Tricky to use
• Easy to use after you learn how

14
Micrometers
15
How to Read the Micrometer

• First find dollars 600 (dont use
  decimal point)
• Next find Quarters 50 (two quarters
  equals 50 cents)
• Next Find Pennies 13 ( Pennies are
  on the thimble)
  __________
• Now Place Decimal Point Here .663
• Find the Size of the Micrometer and Place Here
  2.663 (use smaller of the two numbers)

16
Lets Do Another

• First find dollars 700 (dont use
  decimal point)
• Next find Quarters 50 (two quarters
  equals 50 cents)
• Next Find Pennies 24 ( Pennies are
  on the thimble)
  __________
• Now Place Decimal Point Here .774
• Find the Size of the Micrometer and Place Here
  0.774 (use smaller of the two numbers)

17
Dial Indicators
18
Dial Indicators

• Measures movement
• Measures to the nearest thousandth
• Must set to zero and move object to its stop
  move the opposite way to read the movement.

Bore Gauge- Another type of Dial Micrometer
19
Dial Indicators
20
Other Measuring Tools
Thread Gauges
Height Gauges
21
Other Measuring Tools
Hole Tee Transfer Gauges
Squares
22
Other Measuring Tools
Vacuum Gauge
Compression Tester
Torque Wrenches
Antifreeze Tester
Fuel Pressure Tester
23
Your Job.

• Complete chapter Questions 1-10 (review) and 1-5
  (ASE-style). Page 51. Also the eight mic readings
  on page 52
• Write on a separate paper and write out the
  complete question and your answer. ( do not write
  the other answer options).
• Complete the chapter worksheet (I will give it
  out). You may write on it.
• File these items in your note book.
• Notebooks will be graded in the future.
