Processor Data Organization

1
Chapter 12

• Processor Data Organization

2
Objectives (1 of 2)

• Describe a processor file.
• Explain what two files make up a processor file.
• Explain the function of a program file.
• Explain the function of a data file.
• List the contents of a program file.
• Explain the contents of a bit file.

3
Objectives (2 of 2)

• Explain how a bit file is made up.
• Explain the contents and makeup of an integer
  file.
• Explain what an element and a sub-element are.
• List which instructions have multiple word
  elements.
• Describe what status bits are and where they are
  used.

4
Project File Terms (1 of 2)

• Project
• The collection of the ladder program and all
  associated information
• Processor file
• Contains all information that is downloaded into
  the processor
• The processor file contains program files and
  data files.

5
Project File Terms (2 of 2)

• Program files
• Program files are ladder files.
• The SLC 500 can contain up to 256 ladder files.
• Data files
• Data files contain data associated with the
  ladder file(s).
• The SLC 500 can contain up to 256 data files.
• Database files
• Database files contain ladder documentation file
  data.

6
RSLogix 500 Project Tree (1 of 2)

• The RSLogix 500 software stores all project files
  in the project tree.
• File is a group of related elements.
• Project tree is similar to a table of contents.

7
RSLogix 500 Project Tree (2 of 2)
8
Processor Memory Is Like a Two-Drawer File
Cabinet
9
Program Files in Their Separate File Drawer
10
Data Files Stored in Their Separate Drawer
11
SLC 500 Default Data Files

• When a new project is created, the software
  creates data files 0 through 8.
• Each file has a file identifier and a file
  number.
• A file is a group of related elements.
• The file identifier and file number make up part
  of the data stored in the files address.

12
SLC 500 Default Data Files (1 of 2)
13
SLC 500 Default Data Files (2 of 2)

• Each file contains specific information needed by
  the processor in order to complete its job of
  executing the user ladder program.
• Default data files are organized as follows

14
File 0, Output Status File (1 of 2)

• Made up of single bits grouped into a 16-bit word
• Each bit represents the ON or OFF state of one
  output point.
• There is one output word reserved for each output
  module in your SLC 500 system.

15
File 0, Output Status File (2 of 2)

• File identified as file O.
• Bit identifiers across top of file represent
  discrete output screw terminal designation.
• Address format O2.0.
• O identifies output file type.
• 2 identifies output module in chassis slot 2.
• .0 identifies word zero.

16
SLC 500 Output Status File
17
File 1, Input Status File (1 of 2)

• Made up of single bits grouped into a 16-bit
  word.
• Each bit represents the ON or OFF state of one
  input point.
• There is one input word reserved for each input
  module in your SLC 500 system.

18
File 1, Input Status File (2 of 2)

• File identified as file 1.
• Bit identifiers across top of file represent
  discrete output screw terminal designation.
• Address format I3.0.
• I identifies output file type.
• 3 identifies input module in chassis slot 3.
• .0 identifies word zero.

19
SLC 500 Input Status File (1 of 2)
20
SLC 500 Input Status File (2 of 2)

• Only words in the output and input status files
  are created for I/O modules that actually exist
  in the SLC 500 system.
• Output and input status file word creation is
  part of the I/O configuration process.

21
B3, Binary, or Bit File

• The binary or bit file stores single-bit data.
• Binary file also referred to as an internal coil,
  internal relay storage.
• Internal bits are used to store internal data.
• Identified as file B3.

22
Each Bit File Element Consists of One 16-bit Word
23
T4, Timer File

• The timer file stores only timer elements.
• An element is a word or group of words that work
  together as a unit.
• A timer is made of three pieces or words.
• Preset value
• Accumulated value
• Status bits
• The preset value and accumulated value are 16-bit
  signed integers.
• Status bits are single bits that make up one
  16-bit word.
• These three words work together as a unit.

24
One Timer Element Is Made of Three 16-bit Words
25
Timer Addressing

• Sample timer element addressT42
• T4 timer file 4
• 2 timer element 2 (0-255 timer elements per
  file)

26
Sub-Element

• A sub-element is part of an element addressable
  as a unit.
• The preset value and accumulated value are
  sub-elements of a timer.
• T40.PRE
• T40.ACC

27
Timer Status Bits

• Timers have three status bits.
• Done bit (DN) is true when the accumulated value
  and preset are equal.
• Timer timing bit (TT) is true when the timer is
  timing.
• Enable bit (EN) is true when the timer
  instruction is enabled or true.

28
Timer Bit Addressing

• Status bit addresses for timer file 4, timer
  element 2 (T42) are listed below
• T42/DN is the address for the done bit.
• T42/EN is the address for the enable bit.
• T42/TT is the address for the timer timing bit.

29
Timer File T4
30
C5, Counter File

• The counter file stores only counter elements.
• An element is a word or group of words that work
  together as a unit.
• A counter is made of three pieces or words
• Preset value
• Accumulated value
• Status bits
• The preset value and accumulated value are 16-bit
  signed integers.
• Status bits are single bits that make up one
  16-bit word.
• These three words work together as a unit.

31
One Counter Element Is Made of Three 16-bit Words
32
Counter Addressing

• Sample counter element address C52
• C5 timer file 5
• 2 counter element 2 (0-255 timer elements per
  file)

33
Sub-Element

• A sub-element is part of an element addressable
  as a unit.
• The preset value and accumulated value are
  sub-elements of a counter.
• C50.PRE
• C50.ACC

34
Counter Status Bits (1 of 2)

• Counter has five status bits.
• Done bit (DN) is true when the accumulated value
  and preset are equal.
• Count up enable bit (CU) is true when the up
  counter is true or enabled.
• Count down enable bit (CD) is true when the count
  down counter is enabled or true.

35
Counter Status Bits (2 of 2)

• The overflow bit (OV) is true when the up counter
  has overflowed above 32767.
• The underflow bit (UN) is true when the down
  counter has underflowed below -32768.
• The update accumulator bit (UA) is a high-speed
  counter status bit for fixed SLC 500 PLCs.

36
Counter Status Bit Addressing (1 of 2)

• Status bit addresses for counter file 5, counter
  element 0 (C50) are listed below
• C50/DN is the address for the done bit.
• C50/CU is the address for the count up enable
  bit.

37
Counter Status Bit Addressing (2 of 2)

• C50/CD is the address for the count down enable
  bit.
• C50/OV is the address for the count up overflow
  bit.
• C50/UN is the address for the count down
  underflow bit.

38
Counter File C5
39
R6, the Control File

• The control file is used to store status
  information for
• Bit shift
• First-in and first-out stacks (FIFO)
• Last-in and first-out stacks (LIFO)
• Sequencer instructions
• Certain ASCII instructions

40
One Control Element Is Made of Three 16-bit Words
41
N7, Integer File

• The integer file stores a 16-bit signed integer
  representing a whole number.
• Integer file data range 32,768 to 37,767.
• Integer file has no status bits.
• Each integer file can have 0 to 255 integer
  elements.

42
Integer File Element Consists of 16-bit Elements
43
F8, Floating Point File

• Storage of fractional numerical data or values
  greater than 32767
• Data range of 1.1754944e-38 to 3.40282347e38
• Floating point file is processor operating system
  dependent
• Must have 5/03 modular processor with OS 301 or
  above, 5/04 or 5/05 processor

44
Floating Point File Data Representation
45
User-Defined Data Files (1 of 2)

• Default files are data files 0 through 8.
• Total of 256 data files if processor will support
  them.
• Each data file can have up to 256 elements if
  processor supports them and has enough memory.
• Files greater than file number 8 are user-defined
  files.

46
User-Defined Data Files (2 of 2)

• User-defined files are data files the user can
  create and define as needed for specific
  applications.
• They cannot create additional output, input, or
  status files.

47
SLC 500 User-Defined Files
48
Review of SLC 500 Data Files
