Homeland Security Overview

1
HAVOC
Presented to Mr. James Q. Roberts Office of the
Assistant Secretary of Defense For Special
Operations and Low Intensity Conflict
Homeland Security Overview for
William L. McCoy Director, Homeland Technology
wmccoy_at_resourceconsultants.com
Resource Consultants, Inc. 2650 Park Tower Dr.,
Suite 800 Vienna, VA 22180
www.resourceconsultants.com
2
Summary and Introduction
RCI Has Successfully Supported Government and
Commercial Clients for 25 Years

• RCI Is A Privately Held Company Of 3,200
  Personnel
• Headquartered in Vienna, VA, with 100 branch
  offices on three continents

We Offer A Full Range Of Services

• Enterprise Management and Outsourcing
• Engineering
• Information Technology

• Business Process Analysis
• Reengineering and
• Implementation
• Economic/Cost Analysis

Our Diverse Service Offerings Enable Us To Serve
Clients With Talented, Experienced Teams With The
Right Mix Of Skills
3
Learning Curve
Khobar Towers -- 1996
Baghdad -- 2004
I M P R O V E M E N T
1996 1997 1998 1999
2000 2001 2002 2003
2004
FLAT LINED! Different Address Same
Problem Eight Years Later!
4
HAVOC Harmonized Analysis of Vehicles on Command

• CHALLENGE
• Vehicles are terrorists delivery method of
  choice for bombs.
• Attacks facilitated by the uncontrolled use of
  vehicles
• impact on the ability of United States to
  achieve its National
• Security policy goals and objectives in the
  GWOT.
• SOLUTION
• Create an expanded, policy linked,
  technically implemented buffer
• zone around headquarters complexes and other
  key assets.
• VALUE
• Enables achieving National Security policy
  goals and objectives by
• Controlling threats, thus
• Attenuating the perception of challenges to US
  objectives and
• Reducing casualties

5
Concept Three Legged Stool
HAVOC
Employment
Policy
Technology
6
Policy Local Execution - Central Collection

• Vehicle Licensing
• Local officials responsible for licensing.
• Chain of responsibility - vehicle linked to
• Owner/driver
• Garaging location
• Local official validates and approves.
• Driver Licensing
• Local officials responsible for licensing.
• Chain of responsibility - driver
• Photographed - hyper spectral imagery
• Fingerprinted
• DNA sample collected
• Local official validates and approves.

Central
Database
7
Technology Remote Sensor Interface/Gateway
Controller

• TECHNICAL READINESS
• Remote Sensor Interface, Gateway Controller,
  servers, and database
• technology are currently available off the
  shelf
• TECHNICAL CAPABLITY AND CHARACTERISTICS
• COMMERCIAL APPLICATION
• Cargo and vehicle tracking and identification

• Remote Sensor Interface (RSI)
• Bluetooth
• WiFi (planned)
• Serial Interface (up to 115.2kbaud)
• Temperature sensor
• Electronic Seal
• Up to 1Mbps link to gateway
• Patent Pending on key components

• Gateway Controller (GC)
• Linux based
• PCMCIA (PC Card)
• USB and WiFi
• Bluetooth
• Mobile Phone (CDMA, GSM)
• Satellite (Globalstar)

8
Technology Class Based Networking
Current networking protocols for point to point
radios network with their closest neighbor
Class Switched Networks create intranet links
with other RSIs of the same class.
9
Technology Current Feature Set
10
Technology Hyper Spectral Analysis

• TECHNICAL READINESS
• Base technology currently available
• MIRVed to fit HAVOC requirement
• TECHNICAL CAPABLITY AND CHARACTERISTICS
• Video tracking algorithms to produce a data
  package for each object
• Simultaneously, produce remote biometric
  information for each object
• Extract data from visible areas of the target
  for continuous updating
• Provides the extra dimension to greatly enhance
  the tracking process.
• COMMERCIAL APPLICATION
• Transportation hubs
• Industrial sites
• Government facilities

11
Technology Hyper Spectral Analysis
APPROACH

• Disruptive rapidly emerging technology
• Interrogating remotely colour of a threat /
  target
• Offers the potential for remote covert
  identification of humans subject to
  infrastructure could use as an input sensor to
  establish and maintain a large keep out zone
• Offers the potential to provide an additional
  tracking discriminant to increase system
  robustness
• Current status proof of concept hardware and
  software are available for assessing
  identification concepts

12
Technology Hyper Spectral Analysis

• Solution combines robust sequential Monte Carlo

• (particle) filtering techniques with an
  innovative
• approach to efficient data association
• Solution offers the potential to
• Track hundreds of targets
• Address obscuration
• Integrate capabilities with multiple cameras

13
Technology Hyper Spectral Analysis
IDENTIFICATION SOLUTIONS

• Stand-off biometric for security access control
• Assessment to date indicates skin colour is
  unique to the individual
• - like a fingerprint
• Provides a capability for verification/identificat
  ion which is
• Non contact
• Independent of viewpoint angle
• Covert
• Fast
• Potentially robust to countermeasures
• An alternative to face recognition, without the
  drawbacks

14
Technology Hyper Spectral Analysis
TRACKING SOLUTIONS

• QinetiQ video tracking algorithms to produce a
  data package for each object
• Label
• Position
• Velocity vector
• Colour information is produced for each object
  and added to the data package
• Much greater resolution than conventional RGB
• Ability to extract from all visible areas of the
  target and update continuously.

• Provides the extra dimension to greatly
  enhance the tracking process.

15
Technology Hyper Spectral Analysis
Summary

• Outlined a disruptive technology for
• Remote identification system as a input sensor to
  the HAVOC system
• Provide the basis for additional input data for
  tracking systems
• Significantly increases system robustness
• System available now for concept assessment

16
Employment Concept

• POLICY
• Establishes requirement for security Smart Tag
  for
• Vehicles entering proscribed areas or
• Vehicle classes having elevated threat potential,
  for example
• High Capacity Vehicles
• Tank Trucks
• Coalition Vehicles by Class
• Driver/Vehicle registration establishes identity
  metrics
• Ownership
• Garaging location
• Digital pictures of owner, drivers and vehicles
• Paint, sound, and skin information

17
Employment Concept

• OPERATIONALLY
• On vehicle approach, GC identifies RSI and at
  least one additional identification metric,
  passes to decision support system
• Motion detectors advise of vehicles without RSI
  video tracks and establishes technical signature
• Decision support system hands off vehicle
  tracking from camera to camera
• Operations Center directs acquisition of
  vehicles of interest
• Decision support system provides likely future
  vehicle position
• Vehicles of interest shunted into safe areas
  away from buildings, check points, and personnel
  for further interrogation

18
Employment Concept
SPOOF PROOF?

• Of course not nothing is BUT HAVOC
• Separates identified traffic from vehicles of
  interest at an
• actionable distance
• Increases the complexity of problems terrorists
  must
• resolve to deliver a vehicle bomb on target,
  thus
• Increases terrorists exposure and risk of
  discovery
• Reduces the risk to critical facilities, check
  points, and
• personnel
• Facilitates free movement of identified traffic

19
An Employment Scenario

• PROVIDES
• Early Identification
• Useable Decision Space
• Flexible Response Options

SATELLITE, CELL, OR OTHER RELAY
RSI
GC, Camera, Motion Detector, et al
DECISION SUPPORT SYSTEM
ANALYSIS RESULT
SECURITY TEAM
RESOLVE
Lethal - Nonlethal
OPERATIONS CENTER
PASS
DECISION
Track No track
20
Hypothetical HAVOC GC Placement
Gateway Controller
21
Related Applications

• Convoy Security Creates a technical security
  bubble
• Vehicle Monitoring by Class
• High Capacity Vehicles
• Tank Trucks
• Other Vehicles by Class
• Identifying and tracking vehicles/people of
  interest

Applications are bounded only by your policy
INGENUITY and IMAGINATION
22
Potential Market

• EXPECTED USE / MARKET SIZE
• Security
• Monitoring
• Tracking
• Access control
• Size Estimate 1,000 US sites public and
  private sector
• GEOGRAPHICS OF MARKET
• Applicable to protecting high value assets
  worldwide
• EXPECTED ENHANCED CAPABILITY
• Adds technical buffer zone
• Alerts to vehicles of interest at
  actionable distances
• COMPETITION
• None currently New spin on emerging technology

23
Business Model

• SUCCESS POTENTIAL
• RCI has significant experience implementing
  large, complex programs
• The HAVOC system will significantly reduce the
  success of vehicle-
• based attacks against critical assets
• WHY
• RCI understands the requirements for the HAVOC
  program
• Provides expanded technical stand-off space
  prior to encountering
• physical stand-off
• Technical stand-off space facilitates
  identification and tiered
• engagement
• Requires a local official sign-off on
  registration thus
• takes advantage of local knowledge,
• empowers local officials, and
• provides an audit trail of responsibility

24
Business Model
MANAGEMENT STRENGTHS RCI is a Large, Stable
Defense and Federal Sector Services Company

• 274 Million in 2003 Revenues
• 294 Million projected in 2004 Revenue
• Strong Organic Growth 27.1 CAGR Since 1998
• Predominance of Prime Contracts 93 of Revenues
• Diverse Base of DoD and Federal Agency Customers
• 133 Department of Defense Customers
• 22 Federal Agency Customers

RCI Clients include
DOT
Army
FBI
DO
Navy
NA
HS
OS
SBA
DOE
GSA
NASA
UPS
Coast Guard
25
Business Model

• STRATEGIC ALLIANCES FOR THIS PROJECT
• SeekerNet - provides an integrated
  platform that enables on- demand condition
  monitoring and location tracking of physical
  assets for security, supply chain management,
  asset management and other applications.
• QinetiQ - combines a breadth and depth of
  technical expertise, uniquely derived from
  decades of experience in harnessing science and
  technology to meet defense needs.

26
Business Model
FUNDING

• CURRENT FUNDING
• Basic product RSI/GC development is basically
  complete
• Funding requirement exists for
  identification/tracking product
• FUNDING REQUIREMENTS
• Funding may be sought to
• Complete identification/tracking sensor
• Develop a full scale working prototype, with
  software
• Conduct Proof of Application testing and
• demonstration

27
Business Model Results

• OTHER PRODUCTS
• Directed Energy Dahlgren
• Anti-IED Dahlgren
• DOJ and FBI Business Process Reengineering
• Army Research Laboratory Evaluation and
  Marketing
• US Navy Major Logistics Engagements
• Department of Transportation Operations Center
  Staffing
• US Border Patrol Land Based Intelligence
  System
• Energy Information Administration Analysis and
  Information
• Management
• Numerous Others
• RCIs SUCCESS
• Repeat business speaks for our performance
• Only one recompete contract lost in the last 15
  years

28
RCI Team Summary
OTHER PRODUCTS OF INTEREST

• Advanced Processing
• Spectrum Solutions
• Marine and Acoustics
• Remote Sensor Interface
• Gateway Controllers
• Asset Commander Operating System

• Information Technology
• C4ISR Systems Engineering
• Enterprise Outsourcing
• Human Strategies
• Defense Logistics
• Program Management
• Avionics and Vetronics
• Optronincs

29
Timeline
Milestones
Abbreviated HAVOC available
We can field an abbreviated HAVOC model, sans the
hyper spectral module, in about eight weeks.
30
Summary

• RESULTS
• Probability of successful vehicular attack
  can be reduced to half with an increase in
  registered and RSI-
• equipped vehicles
• Reduce attendant casualties and damage
• Improve climate to pursue US policy objectives

• ACTION ITEMS
• Government funding sponsor!
• Hyperspectral module testing
• Platform integration
• Soft/Firmware development

• NEXT STEPS
• Develop a working prototype
• Conduct Proof of Application
• testing
• Test in a field environment

31
Resource Consultants, Inc.
Questions?
/
William L. McCoy Director, Homeland Technology
wmccoy_at_resourceconsultants.com
Resource Consultants, Inc. 2650 Park Tower Dr.,
Suite 800 Vienna, VA 22180
www.resourceconsultants.com
