A case study: IPTV SLA Monitoring

1
A case study IPTV SLA Monitoring
Corso di Reti di Calcolatori II

• Giorgio Ventre
• The COMICS Research Group
• _at_
• The University of Napoli Federico II,

2
Outline

• The general problem SLA, who cares?
• A business case for QoS
• Defining Service Level Agreements
• A Real-Life SLA monitoring service
• A case study IPTV SLA Monitoring

3
Recent trends in the industry

• New emerging multimedia services both in fixed
  and wireless networks
• Traditional voice carriers are moving to NGN
• Essential to control costs and drive up revenues
• Triple play services Voice Video Data
• Video represents a key element of the service
  portfolio
• Price/quality balance must attract/retain users
• TV quality must compete with satellite and cable

4
Challenges and quality issues

• Users are conditioned to expect high quality TV
  pictures
• Users unlikely tolerate poor/fair quality
  pictures in IPTV
• Early delivery of broadband services is
  unfeasible due to the limited bandwidth compared
  to cable and satellite
• Compulsory data compression can potentially
  degrade quality
• Need for robust transmission to minimize
  data-loss and delay

5
Why Quality Assurance is a major issue?

• Because otherwise we wouldnt be here
• Quality Assurance adds a new perspective to the
  flatness of the current market of triple-play
  services
• Quality measurement for service assurance
• End-to-end quality monitoring
• SLA based on quality delivered to end-user
• New business models and scenarios

6
QoS vs QoE

• Quality of Service (QoS) refers to the capability
  of a network to provide better service to
  selected network traffic over various
  technologies. QoS is a measure of performance at
  the packet level from the network perspective.
• Quality of Experience (QoE) describes the
  performance of a device, system, service, or
  application (or any combination thereof) from the
  users point of view. QoE is a measure of
  end-to-end performance at the service level from
  the user perspective.

7
From QoS to MOS

• MOS Mean Opinion Score
• Used in POTS to have a quantitative value for a
  qualitative evaluation
• How do you evaluate the quality you perceived
  during your last service usage/access?
• Very easy for simple services telephony
• Very complex for complex services multimedia
  (sound vs video vs data vs mix)
• Even more complex when quality of service depends
  on the distribution network AND terminals AND
  servers

8
QoS evaluation
9
Requirements

• Identify parameters contributing to a
  satisfactory QoE
• Define network performance requirements to
  achieve target QoE
• Design measurement methods to verify QoE

10
Performance parameters

• IPTV service is highly sensitive to packet loss
• The impact of packet loss depends on several
  factors
• Compression algorithm (MPEG2, H.264)
• GOP structure
• Type of information lost (I, P, B frame)
• Codec performance (coding, decoding)
• Complexity of the video content
• Error concealment at STB

11
Quality Measurement

• Quality Measurement
• Objective
• Pure computational
• Network performance
• Objective perceptual
• Measurements representative of human perception
• Traditional metrics such as PSNR, PLR, BER are
  inadequate
• Requirements for objective perceptual metrics

12
Why Quality-Monitoring is hard?

• Measures have to be
• Time-based
• Remoted
• Distributed
• Sharp
• Highly etherogeneous environments (codecs, CPEs,
  media-types, )
• Sampled measures?
• SLAs are not sampled.
• In order to ensure quality, measures have to be
  carried out with quality

13
Why Quality-Monitoring is hard?

• High impact also of content based factors
• MPEG performance depends on content pattern and
  scene changes
• Highly variable (movements, colours, lights)
  scenes generates more data
• Stallone vs Bergman
• or better
• Rambo vs The Seventh Seal

14
Methods state of the art

• Full-Reference
• Reduced-Reference
• No-Reference

15
Full-reference

• Measures are performed at both the input to the
  encoder and the output of the decoder
• Both the source and the processed video sequences
  are available
• Requires a reliable communication channel in
  order to collect measurement data

16
Reduced-Reference

• Extracts only a (meaningful) sub-set of features
  from both the source video and the received video
• A perceptual objective assessment of the video
  quality is made
• The transmitter needs to send extracted features
  in addition to video data

17
No-Reference

• Perceptual video quality evaluation is made based
  solely on the processed video sequence
• There is no need for the source sequence
• Measurements results are intrinsically based on a
  predictive model

18
Standards for voice quality assessment

• ITU-T P.862 (Feb. 2001)
• Full-reference perceptual model (PESQ)
• Signal-based measurement
• Narrow-band telephony and speech codecs
• P.862.1 provides output mapping for prediction on
  MOS scale
• ITU-T P.563 (May 2004)
• No-reference perceptual model
• Signal-based measurement
• Narrow-band telephony applications

19
Standards for voice quality assessment

• ITU-T P.862.2 (Nov. 2005)
• Extension of ITU-T P.862
• Wide-band telephony and speech codecs(5 7Khz)
• ITU-T P.VQT (ongoing)
• Targeted at VoIP applications
• Uses P.862 as a reference measurement
• Models analyze packet statistics speech payload
  is assumed

20
Standards for video quality assessment

• ITU-T J.144 and ITU-R BT.1683 (2004)
• Full reference perceptual model
• Digital TV
• Rec. 601 image resolution (PAL/NTSC)
• Bit rates 768 kbps 5 Mbps
• Compression errors

21
Standards for video quality assessment

• IETF RFC 4445 (April 2006) A proposed Media
  Delivery Index (MDI)
• MDI can be used as a quality indicator for
  monitoring a network intended to deliver
  applications such as streaming media, MPEG video,
  Voice over IP, or other information sensitive to
  arrival time and packet loss.
• It provides an indication of traffic jitter, a
  measure of deviation from nominal flow rates, and
  a data loss at-a-glance measure for a particular
  video flow.

22
Our research

• Objectives
• Real-time computation of achieved quality level
• Quality as perceived by the user
• Per-single-user measurements
• Light computation (about 5 overhead)
• Approach
• Media playout and measures are both part of an
  integrated process
• Measurement subsystems exposes a consistent
  abstract interface
• Measurements results are high-level quality
  indicators

23
VQM (1/2)

• No-Reference
• Evaluates the video quality as perceived by the
  user
• QoS ? QoE
• Based on MPEG2
• Light parsing
• Doesnt parse motion vectors, DCT coefficients,
  and other macroblock-specific information
• degradation due to packet losses is estimated
  using only the high-level information contained
  in Group of Pictures, frame, and slice headers

24
VQM (2/2)

• Does not need to make assumptions concerning how
  the decoder deals with corrupted information
• i.e. what kind of error concealment strategy it
  uses.
• Based on this information it determines exactly
  which slices are lost
• GoP loss-rate
• Frame loss-rate
• Slice loss-rate
• Differentiation per frame type (I, P, B)
• It computes how the error from missing slices
  propagates spatially and temporally into other
  slices
• Appropriate for measuring video quality in a
  real-time fashion within a network

25
Parsing method (1/2)
GOP
I
B
B
P
B
B
P
B
B
P
B
B
Frame
26
Parsing method (2/2)
27
QoE vs. MOS

• Mapping between Quality of Experience evaluation
  and MOS (Mean Opinion Score ITU/T P.800) value

28
MOS vs SLAs

• Knowledge of the function MOS(t) directly enables
  SLAs monitoring

29
Experimental testbed
Controlled-Loss Router
Video Server
Video Client Quality Meter
Dropped Packets
Video Characteristics MPEG2-TS Constant Bit
Rate 3.9Mbps
30
High Quality
Throughput 5.0 Mbps
31
Medium Quality
Throughput 3.9 Mbps
32
Low Quality
Throughput 3.0 Mbps
33
From SLA to PLA Provisioning Level Agreements
Scuola di Dottorato in Ingegneria
Informatica Palermo, 17-28 settembre 2007

• Giorgio Ventre
• The COMICS Research Group
• _at_
• The University of Napoli Federico II,
• ITEM Laboratory, Italian University Consortium on
  Informatics

34
A service model for resilient networks

• We are moving from Quality of Service to a more
  complex concept of qualityresiliency

35
Quality of future distributed services

• The most important QoS characteristic for future
  distributed services is arguably going to be
  resilience
• Resilience is the property of a system to restore
  services to normal after a failure (as fast as
  the service users need)
• However, an investigation into resilience reveals
  the importance of considering risk when
  developing our future research agenda

36
The need for resilience

• We are increasingly reliant on the Internet and
  on networked systems in general (including of
  course the Web)
• This is happening in businesses and indeed in
  every walk of life including the home
• The EU is promoting and developing the
  Information Society, which is based on
  communication technologies and systems

37
Interdependence of networks (1)

• Not only are we dependent on networks
• But all sorts of other networks are, too
• Electricity, water, gas
• Corporate networks
• Banking networks
• Health networks
• Information networks are crucial to the
  successful operation of other networks

38
Interdependence of networks (2)

• Interdependencies of critical infrastructures
• Power nets and information nets
• The virtual utility
• Rune.Gustavsson_at_bth.se
• The introduction of proper supporting ICT of
  power nets forming a virtual utility is an
  important instance of networked enabled
  capabilities (NEC) systems. Furthermore, by
  pursuing this task we can gain experiences and
  develop models and technologies that besides
  addressing societal critical systems also can be
  useful in other efforts on development and
  maintenance of complex systems.
• In Italy, Report del Comitato sulla Protezione
  delle Infrastrutture Critiche, Presidenza del
  Consiglio dei Ministri, 2004

39
Internet meltdown?

• Article in The Independent (UK) 8 September 2004
• The internet is becoming a utility Karl
  Auerbach
• As a utility, the net will have to live up to
  different, more stringent standards than its
  previous uses as an academic and research
  playground, and then a mainstream experiment.
  People are building billion-dollar businesses,
  governments are turning themselves digital, and
  in the meantime there isn't so much as a
  service-level agreement to guarantee that the
  most basic level of connectivity will be there
  tomorrow.
• If the technologists no longer believe they can
  fix it by themselves, the Internet really has hit
  a meltdown.

40
Vulnerabilities

• The Internet was originally designed to withstand
  basic link and switch failures
• But it was never envisaged as a utility (i.e.
  offering near-perfect availability), supporting
  commercial initiatives and acting as a vital
  infrastructure
• Whatever vulnerabilities are present in the
  infrastructure may be inherited by the
  applications it aims to support

41
Attacks

• Complex, well engineered systems should be built
  by keeping in mind faults
• Today, we need to keep into account other
  disruption sources
• Network attacks of all sorts are increasing in
  variety and number
• Spam / junk
• Viruses, Worms etc.
• DDoS attacks
• Physical
• These cause huge costs in time and energy, but no
  coherent approach to a solution

42
Multiple levels

• This is of course a multi-level problem
• Physical layer
• Networking / IP
• Middleware layer / O.S.
• Web / applications
• A solution to achieving resilience needs to apply
  at all levels this is a grand challenge for
  future networked systems infrastructure

43
Complexity

• This is a distributed computing problem
• According to Leonard Kleinrock, we have no
  suitable theory to handle this, because of its
  inherent complexity
• This is compounded by nomadicity
• complicated difficult to study but fit for
  purpose, static whereas complex growing,
  evolving

44
Complexity not simplicity

• In spite of all hype on global network
  architectures, today we face a complex,
  heterogeneous reality
• Fixed access networks POTS, xDSL, CATV, MetroLAN
• Mobile, wireless access networks GPRS, UMTS,
  WiFi, Wimax
• Interoperability with terrestrial digital
  broadcasting
• Additional complexity issues
• New, diverse terminals (Symbian Cell. Phones,
  PDAs, smart set-top-boxes)
• Dynamic creation of novel services and
  applications

45
Complexity as an opportunity

• The availability of a multiplicity of networks,
  devices and services should be seen as an
  opportunity
• No single infrastructure of critical importance
• Ease of access to all players government,
  companies, common people
• Availability of a multitude of sources of
  information
• Availability of a multitude of computing
  resources
• Availability of a multitude of communication
  media/networks
• provided that such a rich scenario can be
  managed as a system

46
Some recent events

• We learned some lessons recently
• 9/11 2001 Attacks
• US East Coast Blackout
• Italy Blackout
• Series of attacks
• Worms (NIMDA, Witty, Slammer )
• DDOS
• Routing attacks
• We probably need to re-discover traditional
  values typical of traditional engineering practice

47
Lessons from 9/11 2001

• The Internet under Crisis Conditions A
  Committee of the National Research Council of the
  National Academies (www.nap.edu)
• Findings of the Committee
• Attacks had very limited effects on the Internet
  as a global, best effort communication system
• Internet technology appears to be robust per se
  but considerable efforts are needed to protect
  Internet-based systems
• Many critical interdependencies discovered only
  after the attacks

48
Known and less known effects

• Dependency of Internet on other telecommunication
  systems (fixed, wireless, cellular)
• Obvious co-location of sites, tubes, cables
  running out of diesel
• Not so obvious e.g. communications between NYC
  ISPs and TelCos hampered by problems to toll-free
  numbers
• Facility disaster planning as a rare
  expertise/culture in the Internet world
• Very limited capacity of backup power generation
  even in major ISP sites/POPs
• Other issues, e.g.
• DNS for .za domain was hosted on a server in NYC
• WiFi LANs of two major Manhattan hospitals
  operating in outsourcing via Internet

49
Lessons from 9/28 2003

• Anticipated by the US East Coast blackout much
  larger scale than WTC but apparently more limited
  damage
• Different effects and impacts
• POTS infrastructure capable of enduring very long
  power outages practically no effects
• Cellular Networks locally in deep crisis
• National TV and Radio broadcasters OK, local
  players generally in crisis
• Global and VoIP operators knocked-out
• What about the Internet?
• All IT based services affected AAA, CDN, Servers

50
Lessons in ATC systems

• Press Releases (http//www.natca.org/mediacenter/p
  ress-release-detail.aspx?id394)
• MASSIVE POWER, COMMUNICATIONS FAILURE AT MAJOR
  AIR TRAFFIC CONTROL CENTER PUTS CONTROLLERS IN
  DARK, FLIGHTS IN JEOPARDY
• 07/19/2006 Bob Marks
                 PALMDALE, Calif. A massive
  power and communications failure late Tuesday at
  the Los Angeles Air Route Traffic Control Center
  left scrambling air traffic controllers to deal
  with a nightmare scenario how to keep dozens of
  flights away from each other above a large swath
  of the Southwestern United States despite the
  inability to see them, talk to them or relay
  crucial instructions for 15 excruciatingly long
  minutes.Every ounce of skill, heart and
  determination that controllers bring into the
  control room every day was put to the test during
  one of the worst outages to ever hit the
  facility. It was so bad, controllers say, that
  the only thing they had of use to aid the
  situation that actually worked was their cell
  phones devices which the Federal Aviation
  Administration, inexplicably, has barred from
  control rooms, further impeding the safety of the
  system.
• More details in http//themainbang.typepad.com/blo
  g/2006/07/complete_failur.html

51
Issues for research (1)

• Forget OSI-type layering/abstractions
• Services depend not only on peer and adjacent
  layers
• Resiliency is a system-wide issue, with vertical
  and horizontal dependencies
• Start speaking about networked systems and not
  only of networks
• IT based services must be considered as part of
  the whole picture
• Contributions from several disciplines
• Multi-level approach
• Cross-layer approach

52
Issues for research (2)

• Monitoring of services and infrastructures
• We cant trust what we cant control
• Robustness of services
• To unexpected situations faults,
  misconfigurations, excessive demand, soft attacks
  (DDOS)
• To expected but complex situations
  tools/methodologies for proper dimensioning of
  services (Service Engineering)
• Resiliency of infrastructures
• Focus on survivability of communication systems
  to hard attacks (terrorist hits, natural
  disasters)
• Reconfigurability of communication systems
• Make different networks/systems a single
  infrastructure

53
Issues for research (3)

• Towards a GRID of communication infostructures
• Connect them all physically
• Make them resilient separately
• Allow for services to migrate
• Prepare for interconnecting them if needed
• From the computational GRID to the communication
  GRID
• But try to make it with an autonomic
  communication flavour

54
Issues for research

• Resiliency of infrastructures
• Focus on survivability of communication systems
  to hard attacks (terrorist hits, natural
  disasters)
• Reconfigurability of communication systems
• Make different networks a single infrastructure
• Resiliency of services
• To unexpected situations faults, excessive
  demand, soft attacks (D-DOS)
• To expected but complex situations
  tools/methodologies for proper dimensioning of
  services (Service Engineering)

55
From QoS to Resiliency to

• We should not forget the past
• QoS is as important as resiliency, and is
  backValue of supporting Class-of-Services in IP
  Backbones, M. Yuksel et al., IWQOS 2007
• Also because QoS is a good mechanism to improve
  resiliency of a distributed system
• So, we should probably talk about
• QoSiliency

56
User-Centered Architectures
Service Directories
57
Info about content (metadata)
SLAs are the triggers
Service Directories
Access Controllers
Service Controller
SLS
Resource Controllers
User
Policy rules
QoS-capable Networks
58
A change of perspective

• One of the major problems with SLA based
  architectures was their limited capability to
  scale with the number of users and services
• We therefore introduce the concept of
  Provisioning Level Agreement (PLA) A PLA is a
  contract between a service provider and the owner
  of the Infrastructure defining the level of
  service to be guaranteed to final users during
  the provisioning of a service on top of that
  Infrastructure.

59
A change of perspective (cont.)

• In a PLA it is the service provider who defines
• the type of service
• the treatment the service needs to get from the
  network (QoS, resiliency needs, security and
  privacy reqs.)
• the classes of possible SLAs that can be
  subscribed by the users
• A PLA is signed at service deployment time, and
  can be dynamically modified and updated any time
  the service characteristics and requirements
  change
• Once a PLA is signed, Provisioning Level
  Specifications are produced to allow the
  infrastructure to be properly configured to
  accommodate the new service and future service
  subscriptions by final users

60
Info about content (metadata)
Service Centered Architectures
Service Directories
Service Provider
PLS
Resource Controllers
Policy rules
QoS-figurable Networks
PLAs are the triggers
